CPU load is the percent usage of one CPU core when run at 48kHz. The MetaModule has two CPU cores total, so essentially there is 200% available.
There is an additional overhead of 7-9% in each patch, plus more for each cable and mapping.
Running at 24kHz at 32kHz will reduce the CPU load proportionally.
| Plugin | Module | CPU load (Min–Max) | CPU load (Min–Max) | CPU load (Min–Max) | CPU load (Min–Max) | CPU load (Min–Max) | CPU load (Min–Max Poly) | CPU load (Min–Max Poly) | CPU load (Min–Max Poly) | CPU load (Min–Max Poly) | CPU load (Min–Max Poly) | Tags | Description |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 21kHz |  D∞ |
2 – 3% | 2% | 2% | 2% | 2% | 2 – 3% | 2 – 3% | 2% | 2% | 2% | Tuner, Utility, Polyphonic | Polyphonic module for modifying V/OCT signals by transposition and inversion |
| 21kHz |  PalmLoop |
6 – 10% | 6 – 10% | 6 – 9% | 6 – 9% | 6 – 9% | 6 – 10% | 6 – 10% | 6 – 9% | 6 – 9% | 6 – 9% | Oscillator | CPU friendly voltage controlled oscillator with polyBLEP/BLAMP anti-aliasing |
| 21kHz |  TachyonEntangler |
9 – 14% | 9 – 13% | 9 – 14% | 8 – 14% | 8 – 13% | 9 – 14% | 9 – 13% | 9 – 14% | 8 – 14% | 8 – 13% | Oscillator | Anti-aliased chaotic sync voltage controlled oscillator |
| 4ms |  Attenuverter 2 |
2% | 2% | 2% | 2% | 1 – 2% | 2 – 4% | 2% | 2% | 2% | 1 – 2% | Attenuator, Dual, Utility | Two-channel attenuverter |
| 4ms |  BPF |
3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 2 – 3% | 3 – 10% | 3 – 10% | 3 – 10% | 3 – 10% | 2 – 10% | Filter | Band-pass filter |
| 4ms |  Basic WAV Player |
2 – 4% | 2 – 4% | 2 – 3% | 2% | 2% | 2 – 4% (mono) | 2 – 4% (mono) | 2 – 3% (mono) | 2% (mono) | 2% (mono) | Sampler | Simple streaming .wav player optimized for microSD cards and USB drives |
| 4ms |  CLK Divider |
2% | 2% | 2% | 2% | 2% | 2% (mono) | 2% (mono) | 2% (mono) | 2% (mono) | 2% (mono) | Clock modulator | Outputs a clock signal as a division of an incoming clock signal's tempo. |
| 4ms |  CLK Multiplier |
2 – 4% | 2 – 4% | 2 – 3% | 2% | 2% | 2 – 4% (mono) | 2 – 4% (mono) | 2 – 3% (mono) | 2% (mono) | 2% (mono) | Clock modulator | Outputs a clock signal at a multiple of an incoming clock signal's tempo. |
| 4ms |  ComplexEG |
3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 9% | 3 – 9% | 3 – 9% | 3 – 9% | 3 – 9% | Envelope Generator | ComplexEG |
| 4ms |  Dual EnvVCA |
10 – 11% | 10 – 11% | 10 – 11% | 10 – 11% | 10 – 11% | 10 – 28% | 10 – 29% | 10 – 29% | 10 – 29% | 10 – 29% | Envelope Generator, Voltage-controlled amplifier, LFO, Hardware clone, Dual, Slew limiter | Dual AD Envelope + VCA |
| 4ms |  Dual Looping Delay |
17 – 19% | 17 – 19% | 17 – 19% | 17 – 19% | 17 – 18% | 17 – 19% (mono) | 17 – 19% (mono) | 17 – 19% (mono) | 17 – 19% (mono) | 17 – 18% (mono) | Dual, Digital, Delay, Effect, Hardware clone | |
| 4ms |  Detune |
4% | 4% | 4% | 4% | 4% | 4 – 10% | 4 – 10% | 4 – 10% | 4 – 10% | 4 – 10% | Effect | Detune |
| 4ms |  Djembe |
6 – 9% | 6 – 9% | 6 – 9% | 5 – 9% | 6 – 9% | 6 – 30% | 6 – 30% | 6 – 30% | 5 – 30% | 6 – 30% | Drum | Physically modeled Djembe based on FAUST models by Romain Michon, Pierre-Amaury Grumiaux, and Yann Orlarey |
| 4ms |  Drum |
8 – 10% | 7 – 10% | 6 – 10% | 6 – 10% | 6 – 9% | 8 – 33% | 7 – 33% | 6 – 32% | 6 – 32% | 6 – 32% | Drum | Drum |
| 4ms |  EnvVCA |
5 – 7% | 5 – 7% | 5 – 7% | 5 – 7% | 5% | 5 – 13% | 5 – 13% | 5 – 14% | 5 – 14% | 5 – 13% | Envelope Generator, Voltage-controlled amplifier, LFO, Hardware clone, Slew limiter | A compact envelope generator with a built-in exponential VCA. |
| 4ms |  Ensemble Oscillator |
27 – 28% | 27 – 28% | 26 – 27% | 26% | 25 – 26% | 27 – 53% | 27 – 53% | 26 – 52% | 26 – 52% | 25 – 52% | Oscillator, Digital, Hardware clone | The Ensemble Oscillator (EnOsc) is a unified polyphonic voice of sixteen complex oscillators combining additive, FM, phase-distortion and wavefolding synthesis techniques in new unorthodox ways. |
| 4ms |  FM VCO |
4 – 7% | 3 – 7% | 3 – 7% | 3 – 7% | 3 – 7% | 4 – 7% | 3 – 7% | 3 – 7% | 3 – 7% | 3 – 7% | Oscillator | FM Oscillator |
| 4ms |  Follow |
2% | 2% | 2% | 2% | 2% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | Envelope follower | Envelope follower with gate output |
| 4ms |  Freeverb |
9 – 13% | 9 – 12% | 8 – 13% | 8 – 13% | 8 – 12% | 9 – 40% | 9 – 40% | 8 – 40% | 8 – 40% | 8 – 40% | Effect, Reverb | |
| 4ms |  Gate |
2 – 3% | 2% | 2% | 2% | 2% | 2 – 4% | 2 – 4% | 2 – 4% | 2 – 4% | 2 – 4% | Utility | Gate/trigger delay with pulse width control |
| 4ms |  HPF |
3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 10% | 3 – 9% | 3 – 9% | 3 – 9% | 3 – 9% | Filter | HPF |
| 4ms |  Karplus |
10 – 11% | 9 – 10% | 9 – 10% | 9 – 10% | 9 – 10% | 10 – 17% | 9 – 17% | 9 – 17% | 9 – 16% | 9 – 16% | Oscillator | Karplus-Strong string sound oscillator |
| 4ms |  Listen 4 |
8 – 9% | 8 – 9% | 8 – 9% | 8% | 7 – 8% | 8 – 11% | 8 – 12% | 8 – 12% | 8 – 12% | 7 – 12% | Mixer | Four channel stereo mixer |
| 4ms |  LPG |
3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 9% | 3 – 9% | 3 – 9% | 3 – 9% | 3 – 9% | Filter, VCA, Low-pass gate | Low-pass Gate |
| 4ms |  MinMax |
2% | 2% | 1 – 2% | 1 – 2% | 1 – 2% | 2% | 2% | 1 – 2% | 1 – 2% | 1 – 2% | Utility | Takes in two signals and outputs the minimum and maximum voltages. |
| 4ms |  Mini PEG |
6 – 8% | 6 – 8% | 6 – 7% | 6 – 7% | 6 – 7% | 6 – 24% | 6 – 24% | 6 – 24% | 6 – 24% | 6 – 24% | Clock generator, Clock modulator, Envelope Generator, Hardware clone | |
| 4ms |  MultiLFO |
2 – 3% | 2% | 2% | 2% | 2% | 2 – 3% (mono) | 2% (mono) | 2% (mono) | 2% (mono) | 2% (mono) | LFO | MultiLFO |
| 4ms |  Noise |
3 – 4% | 3 – 4% | 2 – 4% | 2 – 3% | 3% | 3 – 4% (mono) | 3 – 4% (mono) | 2 – 4% (mono) | 2 – 3% (mono) | 3% (mono) | Noise | Noise |
| 4ms |  Octave |
2 – 3% | 2 – 3% | 2 – 3% | 2% | 2% | 2 – 3% | 2 – 3% | 2 – 3% | 2% | 2% | Utility | Octave |
| 4ms |  PEG |
13 – 15% | 12 – 15% | 12 – 15% | 12 – 14% | 12 – 14% | 13 – 48% | 12 – 48% | 12 – 47% | 12 – 47% | 12 – 47% | Clock generator, Clock modulator, Envelope Generator, Dual, Hardware clone | Clock-synced envelopes and LFOs |
| 4ms |  Percussion Interface |
3 – 4% | 3 – 4% | 3% | 3% | 3% | 3 – 6% | 3 – 6% | 3 – 6% | 3 – 6% | 3 – 6% | Envelope follower, Hardware clone | Audio to gates, triggers and envelopes |
| 4ms |  Pan |
2 – 3% | 2 – 3% | 2% | 2% | 2% | 2 – 3% | 2 – 3% | 2% | 2% | 2% | Panning | Mono-to-stereo panner. |
| 4ms |  PitchShift |
4 – 5% | 4% | 4% | 4% | 4% | 4 – 15% | 4 – 13% | 4 – 12% | 4 – 12% | 4 – 12% | Effect | PitchShift |
| 4ms |  Prob8 |
2 – 4% | 2 – 4% | 2 – 3% | 2 – 3% | 2% | 2 – 4% (mono) | 2 – 4% (mono) | 2 – 3% (mono) | 2 – 3% (mono) | 2% (mono) | Clock modulator, Sequencer | Prob8 |
| 4ms |  QCD |
6 – 11% | 6 – 11% | 6 – 11% | 6 – 11% | 6 – 11% | 6 – 11% (mono) | 6 – 11% (mono) | 6 – 11% (mono) | 6 – 11% (mono) | 6 – 11% (mono) | Clock generator, Clock modulator, Quad, Hardware clone | |
| 4ms |  QPLFO |
6 – 7% | 6 – 7% | 6 – 7% | 6 – 7% | 6 – 7% | 6 – 7% (mono) | 6 – 7% (mono) | 6 – 7% (mono) | 6 – 7% (mono) | 6 – 7% (mono) | LFO, Hardware clone, Quad | |
| 4ms |  Rotating Clock Divider |
3% | 3% | 3% | 3% | 3% | 3% (mono) | 3% (mono) | 3% (mono) | 3% (mono) | 3% (mono) | Clock modulator, Hardware clone | |
| 4ms |  Shuffling Clock Multiplier |
4 – 7% | 4 – 7% | 4 – 7% | 4 – 7% | 4 – 6% | 4 – 7% (mono) | 4 – 7% (mono) | 4 – 7% (mono) | 4 – 7% (mono) | 4 – 6% (mono) | Clock modulator, Hardware clone | |
| 4ms |  Sample/Hold |
2% | 2% | 2% | 2% | 2% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | Random, Sample and hold | SH |
| 4ms |  Shaped Dual EnvVCA |
12 – 14% | 12 – 14% | 12 – 14% | 12 – 13% | 11 – 14% | 12 – 34% | 12 – 33% | 12 – 33% | 12 – 33% | 11 – 33% | Envelope Generator, Voltage-controlled amplifier, LFO, Hardware clone, Dual, Slew limiter | Variable waveshape dual AD envelope + VCA |
| 4ms |  SISM |
4% | 4% | 4% | 4% | 4% | 4 – 8% | 4 – 8% | 4 – 8% | 4 – 8% | 4 – 8% | Utility, Mixer, Hardware clone | |
| 4ms |  Seq8 |
2% | 2% | 1 – 2% | 1 – 2% | 1% | 2% (mono) | 2% (mono) | 1 – 2% (mono) | 1 – 2% (mono) | 1% (mono) | Sequencer | An 8-step unipolar voltage sequencer. |
| 4ms |  Slew |
2% | 2% | 2% | 2% | 2% | 2 – 4% | 2 – 4% | 2 – 4% | 2% | 2% | Slew limiter | Slew |
| 4ms |  Source |
2% | 1 – 2% | 1% | 1% | 1 – 2% | 2% (mono) | 1 – 2% (mono) | 1% (mono) | 1% (mono) | 1 – 2% (mono) | Utility | Generates two outputs voltages based on knob positions. |
| 4ms |  Stereo Mixer |
3 – 4% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | 3 – 6% | 2 – 6% | 2 – 6% | 2 – 6% | 2 – 6% | Mixer, Panning | A mixer with four stereo channels and variable panning per-channel. |
| 4ms |  Switch 1 to 4 |
3% | 3% | 2 – 3% | 2 – 3% | 2% | 3 – 4% | 3 – 4% | 2 – 4% | 2 – 3% | 2 – 3% | Switch, Quad | Switch 1:4 |
| 4ms |  Switch 4 to 1 |
3 – 4% | 3 – 4% | 2 – 4% | 3 – 4% | 2 – 3% | 3 – 4% | 3 – 4% | 2 – 4% | 3 – 4% | 2 – 4% | Switch, Quad | Switch 4:1 |
| 4ms |  Tapographic Delay |
29 – 34% | 15 – 16% | 15 – 16% | 15 – 16% | 15 – 16% | 29 – 34% (mono) | 15 – 16% (mono) | 15 – 16% (mono) | 15 – 16% (mono) | 15 – 16% (mono) | Effect, Delay, Digital, Hardware clone | |
| 4ms |  VCAMatrix |
6 – 9% | 6 – 9% | 6 – 10% | 6 – 9% | 6 – 9% | 6 – 18% | 6 – 18% | 6 – 19% | 6 – 18% | 6 – 18% | Voltage-controlled amplifier, Hardware clone, Mixer | |
| 4ms |  Verb |
9 – 12% | 9 – 12% | 8 – 12% | 8 – 12% | 8 – 12% | 9 – 44% | 9 – 45% | 8 – 45% | 8 – 45% | 8 – 45% | Reverb | Experimental reverb using comb filters and all-pass filters |
| Airwindows |  ADClip7 |
17 – 22% | 17 – 18% | 15 – 17% | 15 – 17% | 15 – 17% | 17 – 22% | 17 – 18% | 15 – 17% | 15 – 17% | 15 – 17% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  ADClip8 |
8 – 11% | 8 – 11% | 8 – 11% | 8 – 11% | 8 – 11% | 8 – 12% | 8 – 11% | 8 – 11% | 8 – 11% | 8 – 11% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  ADT |
12 – 14% | 12 – 13% | 12 – 13% | 12% | 12% | 12 – 14% | 12 – 13% | 12 – 13% | 12% | 12% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  AQuickVoiceClip |
10 – 12% | 10% | 10 – 12% | 9% | 9% | 10 – 12% | 10% | 10 – 12% | 9 – 10% | 9 – 10% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Acceleration |
8 – 9% | 8 – 9% | 8% | 8% | 8 – 9% | 8 – 9% | 8 – 9% | 8% | 8% | 8 – 9% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Acceleration2 |
9% | 8 – 9% | 8% | 8% | 8 – 9% | 9% | 8 – 9% | 8 – 9% | 8 – 9% | 8 – 9% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Air |
10 – 11% | 10% | 10% | 10% | 10% | 10 – 11% | 10 – 11% | 10% | 10% | 10% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Air2 |
13 – 15% | 13% | 13% | 13% | 13% | 13 – 15% | 13% | 13% | 13% | 13% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Air3 |
7 – 8% | 7 – 9% | 7% | 7% | 7% | 7 – 8% | 7 – 9% | 7% | 7% | 7% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Apicolypse |
13 – 14% | 13 – 14% | 12 – 14% | 11 – 14% | 11 – 14% | 13 – 14% | 13 – 14% | 12 – 14% | 11 – 14% | 11 – 14% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  AtmosphereBuss |
11 – 13% | 11 – 12% | 11 – 12% | 11% | 11% | 11 – 13% | 11 – 12% | 11 – 12% | 11% | 11% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  AtmosphereChannel |
10 – 11% | 10 – 11% | 10% | 10% | 10% | 10 – 11% | 10 – 11% | 10% | 10% | 10% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Aura |
10 – 11% | 9 – 10% | 9 – 10% | 9% | 9% | 10 – 11% | 9 – 10% | 9 – 10% | 9 – 10% | 9 – 10% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  AutoPan |
9 – 10% | 9 – 10% | 9% | 9% | 9% | 9 – 10% | 9 – 10% | 9% | 9% | 9% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  AverMatrix |
9 – 18% | 8 – 13% | 8 – 11% | 8 – 11% | 8 – 10% | 9 – 19% | 8 – 14% | 8 – 11% | 8 – 11% | 8 – 11% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Average |
8% | 8% | 7 – 8% | 7 – 8% | 7 – 8% | 8% | 8 – 9% | 7 – 8% | 7 – 8% | 7 – 8% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Balanced |
7% | 6 – 7% | 6 – 7% | 6% | 6% | 7% | 6 – 7% | 6 – 7% | 6 – 7% | 6 – 7% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  BassAmp |
18 – 27% | 18 – 22% | 18 – 22% | 18 – 22% | 18 – 22% | 18 – 27% | 18 – 23% | 18 – 23% | 18 – 23% | 18 – 22% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  BassDrive |
14 – 19% | 14 – 16% | 14 – 16% | 14 – 15% | 13 – 15% | 14 – 19% | 14 – 16% | 14 – 16% | 14 – 16% | 13 – 15% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  BassKit |
12 – 14% | 11 – 12% | 11 – 12% | 11% | 11% | 12 – 14% | 11 – 12% | 11 – 12% | 11 – 12% | 11 – 12% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Baxandall |
10 – 12% | 10 – 11% | 10 – 11% | 10% | 9 – 10% | 10 – 12% | 10 – 11% | 10 – 11% | 10% | 9 – 10% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Baxandall2 |
7 – 8% | 7% | 7% | 7% | 7% | 7 – 8% | 7% | 7% | 7 – 8% | 7% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Beam |
10% | 9 – 10% | 9 – 10% | 9 – 10% | 9% | 10% | 9 – 10% | 9 – 10% | 9 – 10% | 9 – 10% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  BigAmp |
39 – 51% | 39 – 44% | 39 – 44% | 39 – 44% | 39 – 44% | 39 – 51% | 39 – 44% | 39 – 44% | 39 – 44% | 39 – 44% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Biquad |
10 – 11% | 10% | 10% | 10% | 10% | 10 – 11% | 10% | 10% | 10% | 10% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Biquad2 |
14 – 15% | 14 – 15% | 14% | 14% | 14% | 14 – 15% | 14 – 15% | 14 – 15% | 14 – 15% | 14% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  BiquadDouble |
10 – 11% | 10 – 11% | 10 – 11% | 10% | 10% | 10 – 11% | 10 – 11% | 10 – 11% | 10% | 10% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows | BiquadHiLo | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them | ||||||||||
| Airwindows |  BiquadNonLin |
8 – 9% | 8% | 8% | 7 – 8% | 7 – 8% | 8 – 9% | 8% | 8% | 7 – 8% | 7 – 8% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  BiquadOneHalf |
10 – 11% | 10% | 10% | 10% | 9 – 10% | 10 – 11% | 10% | 10% | 10% | 9 – 10% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  BiquadPlus |
8 – 9% | 7 – 8% | 7 – 8% | 7 – 8% | 7% | 8 – 9% | 7 – 8% | 7 – 8% | 7 – 8% | 7 – 8% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  BiquadStack |
9 – 10% | 9 – 11% | 9% | 9% | 9% | 9 – 10% | 9 – 11% | 9% | 9% | 9% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  BiquadTriple |
11% | 11% | 11% | 10 – 11% | 10 – 11% | 11% | 11% | 11% | 10 – 11% | 10 – 11% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  BitGlitter |
10 – 11% | 10% | 10% | 9 – 10% | 9 – 10% | 10 – 11% | 10% | 10% | 9 – 10% | 9 – 10% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  BitShiftGain |
3% | 3% | 3% | 2 – 3% | 2 – 3% | 3% | 3% | 3% | 2 – 3% | 2 – 3% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  BitShiftPan |
3% | 3 – 5% | 3% | 3% | 3% | 3% | 3 – 5% | 3% | 3% | 3% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Bite |
9% | 8 – 9% | 8 – 9% | 8% | 8% | 9% | 8 – 9% | 8 – 9% | 8 – 9% | 8 – 9% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  BlockParty |
11 – 14% | 11 – 13% | 11% | 11% | 11% | 11 – 14% | 11 – 13% | 11% | 11% | 11% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  BrassRider |
11 – 13% | 11% | 11% | 11% | 11% | 11 – 13% | 11% | 11% | 11% | 11% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  BrightAmbience |
20 – 106% | 17 – 68% | 17 – 66% | 17 – 63% | 17 – 55% | 20 – 106% | 17 – 68% | 17 – 66% | 17 – 63% | 17 – 55% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  BrightAmbience2 |
15 – 191% | 14 – 137% | 14 – 80% | 13 – 53% | 11 – 52% | 15 – 191% | 14 – 137% | 14 – 80% | 13 – 53% | 11 – 53% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  BrightAmbience3 |
15 – 231% | 15 – 183% | 14 – 112% | 13 – 74% | 12 – 74% | 15 – 231% | 15 – 183% | 14 – 112% | 13 – 75% | 12 – 74% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  BuildATPDF |
5% | 5% | 5% | 5% | 5% | 5% | 5% | 5% | 5% | 5% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  BussColors4 |
27 – 30% | 27 – 29% | 27 – 28% | 27 – 28% | 27 – 28% | 27 – 30% | 27 – 29% | 27 – 28% | 27 – 28% | 27 – 28% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  ButterComp |
9% | 9% | 8 – 9% | 8 – 9% | 8 – 9% | 9% | 9% | 8 – 9% | 8 – 9% | 8 – 9% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  ButterComp2 |
11 – 12% | 11% | 11% | 11% | 10 – 11% | 11 – 12% | 11% | 11% | 11% | 10 – 11% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  C5RawBuss |
10% | 10 – 11% | 9 – 10% | 9 – 10% | 9 – 10% | 10% | 10 – 11% | 9 – 10% | 9 – 10% | 9 – 10% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  C5RawChannel |
10% | 10% | 9 – 10% | 9 – 10% | 9% | 10% | 10% | 9 – 10% | 9 – 10% | 9 – 10% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows | CStrip | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them | ||||||||||
| Airwindows |  CStrip2 |
16 – 19% | 16 – 19% | 15 – 19% | 15 – 18% | 15 – 18% | 16 – 21% | 16 – 20% | 15 – 20% | 15 – 19% | 15 – 18% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Cabs |
28 – 32% | 27 – 28% | 27% | 27% | 27% | 28 – 32% | 27 – 28% | 27% | 27% | 27% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Calibre |
13 – 15% | 12 – 14% | 12 – 14% | 11 – 14% | 11 – 14% | 13 – 15% | 12 – 14% | 12 – 14% | 11 – 14% | 11 – 14% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Capacitor |
8 – 9% | 8 – 9% | 8% | 8% | 8% | 8 – 9% | 8 – 9% | 8% | 8 – 9% | 8% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Capacitor2 |
9 – 10% | 8 – 10% | 8 – 9% | 8 – 9% | 8% | 9 – 10% | 8 – 10% | 8 – 9% | 8 – 9% | 8 – 9% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Chamber |
12 – 15% | 12 – 14% | 12% | 11 – 12% | 11 – 12% | 12 – 15% | 12 – 14% | 12% | 11 – 12% | 11 – 12% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Chamber2 |
13 – 15% | 12 – 14% | 12 – 13% | 12 – 13% | 11 – 13% | 13 – 15% | 12 – 14% | 12 – 13% | 12 – 13% | 11 – 13% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Channel4 |
4 – 5% | 4 – 6% | 4% | 4% | 4% | 4 – 5% | 4 – 6% | 4% | 4% | 4% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Channel5 |
4% | 4 – 5% | 4% | 4% | 4% | 4% | 4 – 5% | 4% | 4% | 4% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Channel6 |
8 – 9% | 8% | 8% | 8% | 8% | 8 – 9% | 8 – 9% | 8% | 8% | 8% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Channel7 |
9 – 10% | 9 – 10% | 9 – 10% | 9% | 9% | 9 – 10% | 9 – 10% | 9 – 10% | 9% | 9% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Channel8 |
10 – 11% | 10% | 10% | 10% | 10% | 10 – 11% | 10% | 10% | 10% | 10% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Channel9 |
11 – 12% | 10 – 12% | 10 – 11% | 10 – 11% | 10 – 11% | 11 – 12% | 10 – 12% | 10 – 11% | 10 – 11% | 10 – 11% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Chorus |
10 – 12% | 10% | 10% | 10% | 9 – 10% | 10 – 12% | 10% | 10% | 10% | 9 – 10% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  ChorusEnsemble |
16 – 17% | 15 – 17% | 15 – 16% | 15 – 16% | 15 – 16% | 16 – 17% | 15 – 17% | 15 – 16% | 15 – 16% | 15 – 16% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  ChromeOxide |
10 – 11% | 9 – 10% | 9% | 9% | 9% | 10 – 11% | 9 – 10% | 9 – 10% | 9 – 10% | 9 – 10% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Cider |
13 – 15% | 12 – 14% | 12 – 14% | 11 – 14% | 11 – 14% | 13 – 15% | 12 – 14% | 12 – 14% | 11 – 14% | 11 – 14% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  ClearCoat |
48 – 55% | 31 – 48% | 23 – 47% | 20 – 39% | 18 – 37% | 48 – 55% | 31 – 48% | 23 – 47% | 20 – 39% | 18 – 37% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  ClipOnly2 |
3 – 6% | 3% | 3% | 3% | 3% | 3 – 6% | 3% | 3% | 3% | 3% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  ClipSoftly |
8 – 11% | 8% | 8% | 8% | 8% | 8 – 11% | 8% | 8% | 8% | 8% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  CloudCoat |
22 – 61% | 22 – 55% | 22 – 53% | 21 – 53% | 21 – 50% | 22 – 61% | 22 – 55% | 22 – 54% | 21 – 54% | 21 – 50% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Coils |
9 – 10% | 8 – 9% | 8 – 9% | 8 – 9% | 8 – 9% | 9 – 10% | 8 – 10% | 8 – 9% | 8 – 9% | 8 – 9% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Coils2 |
10 – 11% | 10 – 11% | 10 – 11% | 10% | 10% | 10 – 11% | 10 – 11% | 10 – 11% | 10 – 11% | 10 – 11% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Cojones |
9 – 10% | 9% | 9% | 9% | 9% | 9 – 10% | 9% | 9% | 9% | 9% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Compresaturator |
10 – 12% | 10 – 11% | 10% | 10% | 10% | 10 – 12% | 10 – 11% | 10 – 11% | 10% | 10% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Console0Buss |
7 – 8% | 7 – 8% | 7% | 7% | 7% | 7 – 8% | 7 – 8% | 7 – 8% | 7 – 8% | 7% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Console0Channel |
7 – 8% | 7 – 9% | 7% | 7% | 7% | 7 – 8% | 7 – 9% | 7% | 7% | 7% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Console4Buss |
7 – 8% | 7 – 8% | 7% | 7% | 7% | 7 – 8% | 7 – 8% | 7% | 7% | 7% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Console4Channel |
7 – 9% | 7% | 7% | 7% | 7% | 7 – 9% | 7% | 7% | 7% | 7% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Console5Buss |
10 – 12% | 10% | 10% | 9 – 10% | 9 – 10% | 10 – 12% | 10% | 10% | 9 – 10% | 9 – 10% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Console5Channel |
9 – 12% | 9 – 10% | 9 – 10% | 9 – 10% | 9% | 9 – 12% | 9 – 10% | 9 – 10% | 9 – 10% | 9% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Console5DarkCh |
9 – 10% | 9 – 10% | 9% | 9% | 9% | 9 – 10% | 9 – 10% | 9% | 9% | 9% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Console6Buss |
8% | 7 – 8% | 7 – 8% | 7 – 8% | 7 – 8% | 8% | 7 – 8% | 7 – 8% | 7 – 8% | 7 – 8% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Console6Channel |
7 – 9% | 7 – 9% | 7 – 9% | 7% | 7% | 7 – 9% | 7 – 9% | 7 – 9% | 7% | 7% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Console7Buss |
11 – 15% | 11% | 11% | 11% | 11% | 11 – 15% | 11% | 11% | 11% | 11% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Console7Cascade |
20 – 21% | 20 – 21% | 19 – 21% | 19 – 21% | 19 – 21% | 20 – 21% | 20 – 21% | 19 – 21% | 19 – 21% | 19 – 21% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Console7Channel |
11 – 12% | 10 – 11% | 10 – 11% | 10 – 11% | 10 – 11% | 11 – 12% | 10 – 11% | 10 – 11% | 10 – 11% | 10 – 11% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Console7Crunch |
20 – 21% | 19 – 21% | 19 – 21% | 19 – 21% | 19 – 21% | 20 – 21% | 19 – 21% | 19 – 21% | 19 – 21% | 19 – 21% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Console8BussHype |
11 – 13% | 11% | 10 – 12% | 10 – 11% | 10 – 11% | 11 – 13% | 11% | 10 – 12% | 10 – 11% | 10 – 11% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Console8BussIn |
9 – 10% | 9 – 10% | 9% | 9% | 9% | 9 – 10% | 9 – 10% | 9 – 10% | 9% | 9% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Console8BussOut |
9 – 10% | 8 – 9% | 8 – 9% | 8 – 9% | 8 – 9% | 9 – 10% | 8 – 9% | 8 – 9% | 8 – 9% | 8 – 9% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Console8ChannelHype |
9 – 10% | 8 – 9% | 8 – 9% | 8% | 8% | 9 – 10% | 8 – 9% | 8 – 9% | 8 – 9% | 8 – 9% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Console8ChannelIn |
7 – 10% | 7% | 7% | 7% | 7% | 7 – 10% | 7% | 7% | 7% | 7% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Console8ChannelOut |
9 – 10% | 9% | 9% | 9% | 8 – 9% | 9 – 10% | 9% | 9% | 9% | 8 – 9% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Console8LiteBuss |
11 – 14% | 11 – 12% | 11% | 11% | 11% | 11 – 14% | 11 – 12% | 11% | 11% | 11% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Console8LiteChannel |
10% | 10% | 10% | 9 – 10% | 9 – 10% | 10% | 10% | 10% | 9 – 10% | 9 – 10% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Console8SubHype |
11 – 12% | 11% | 10 – 11% | 10 – 12% | 10% | 11 – 12% | 11% | 10 – 11% | 10 – 12% | 10 – 11% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Console8SubIn |
9 – 10% | 9% | 9 – 10% | 9 – 10% | 9% | 9 – 10% | 9 – 10% | 9 – 10% | 9 – 10% | 9% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Console8SubOut |
9 – 10% | 9% | 9% | 9% | 9% | 9 – 10% | 9% | 9% | 9% | 9% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Console9Buss |
12 – 15% | 12% | 12% | 12% | 12% | 12 – 15% | 12% | 12% | 12% | 12% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Console9Channel |
12 – 13% | 12% | 12% | 11 – 12% | 10 – 12% | 12 – 13% | 12% | 12% | 11 – 12% | 10 – 12% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  ConsoleLABuss |
11 – 13% | 11% | 10 – 11% | 11% | 10 – 11% | 11 – 13% | 11% | 10 – 11% | 11% | 10 – 11% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  ConsoleLAChannel |
19 – 20% | 19% | 18 – 19% | 18 – 19% | 18 – 19% | 19 – 20% | 19% | 18 – 19% | 18 – 19% | 18 – 19% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  ConsoleMCBuss |
14 – 15% | 14% | 13 – 14% | 13 – 14% | 13 – 14% | 14 – 15% | 14% | 13 – 14% | 13 – 14% | 13 – 14% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  ConsoleMCChannel |
18 – 23% | 17 – 21% | 17 – 20% | 17 – 19% | 17 – 19% | 18 – 23% | 17 – 22% | 17 – 20% | 17 – 19% | 17 – 19% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  ConsoleMDBuss |
11 – 14% | 11% | 10 – 11% | 10 – 11% | 10 – 11% | 11 – 14% | 11% | 10 – 11% | 10 – 11% | 10 – 11% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  ConsoleMDChannel |
16 – 21% | 15 – 20% | 15 – 18% | 15 – 17% | 15 – 17% | 16 – 21% | 15 – 20% | 15 – 19% | 15 – 18% | 15 – 18% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows | ConsoleXBuss | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them | ||||||||||
| Airwindows | ConsoleXChannel | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them | ||||||||||
| Airwindows |  ContentHideD |
3 – 4% | 3% | 3% | 3% | 3% | 3 – 4% | 3% | 3% | 3% | 3% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  CreamCoat |
42 – 48% | 25 – 41% | 16 – 41% | 11 – 41% | 11 – 41% | 42 – 48% | 25 – 42% | 16 – 42% | 11 – 41% | 11 – 41% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Creature |
12 – 47% | 10 – 27% | 10 – 23% | 10 – 23% | 10 – 21% | 12 – 48% | 10 – 28% | 10 – 23% | 10 – 23% | 10 – 22% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  CrickBass |
40 – 47% | 40 – 41% | 39 – 41% | 39 – 40% | 38 – 39% | 40 – 47% | 40 – 42% | 39 – 41% | 39 – 40% | 38 – 40% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  CrunchCoat |
12 – 46% | 12 – 43% | 12 – 42% | 12 – 41% | 9 – 41% | 12 – 46% | 12 – 44% | 12 – 42% | 12 – 42% | 9 – 41% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  CrunchyGrooveWear |
10 – 17% | 9 – 17% | 9 – 17% | 9 – 17% | 9 – 17% | 10 – 17% | 9 – 17% | 9 – 17% | 9 – 17% | 9 – 17% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Crystal |
11 – 12% | 11 – 12% | 10 – 12% | 10 – 12% | 10 – 12% | 11 – 12% | 11 – 12% | 10 – 12% | 10 – 12% | 10 – 12% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  DCVoltage |
3% | 3% | 2 – 3% | 2 – 3% | 2 – 3% | 3% | 3% | 2 – 3% | 2 – 3% | 2 – 3% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Dark |
10% | 10 – 11% | 9% | 9% | 9% | 10% | 10 – 11% | 9 – 10% | 9 – 10% | 9 – 10% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  DarkNoise |
9 – 19% | 9 – 14% | 8 – 14% | 8 – 14% | 8 – 13% | 9 – 20% | 9 – 14% | 8 – 14% | 8 – 14% | 8 – 14% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  DeBess |
9 – 37% | 10 – 34% | 9 – 28% | 9 – 21% | 9 – 21% | 9 – 37% | 10 – 34% | 9 – 28% | 9 – 21% | 9 – 21% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  DeEss |
10 – 11% | 10 – 11% | 10 – 11% | 10% | 10% | 10 – 12% | 10 – 11% | 10 – 11% | 10 – 11% | 10 – 11% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  DeHiss |
10% | 9 – 10% | 9 – 10% | 9 – 10% | 9 – 10% | 10% | 9 – 10% | 9 – 10% | 9 – 10% | 9 – 10% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  DeRez |
7% | 7% | 7% | 7% | 7% | 7% | 7% | 7% | 7% | 7% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  DeRez2 |
8 – 14% | 8 – 14% | 8 – 14% | 8 – 14% | 8 – 14% | 8 – 14% | 8 – 14% | 8 – 14% | 8 – 14% | 8 – 14% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  DeRez3 |
10 – 12% | 10% | 10% | 10% | 10% | 10 – 12% | 10% | 10% | 10% | 10% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Deckwrecka |
18 – 22% | 18 – 19% | 18% | 18% | 18% | 18 – 22% | 18 – 19% | 18% | 18% | 18% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Density |
9 – 27% | 8 – 17% | 8 – 17% | 8 – 17% | 8 – 15% | 9 – 27% | 8 – 18% | 8 – 17% | 8 – 17% | 8 – 16% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Density2 |
11 – 48% | 11 – 30% | 11 – 30% | 11 – 29% | 11 – 26% | 11 – 49% | 11 – 30% | 11 – 30% | 11 – 29% | 11 – 26% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Desk |
9% | 9 – 10% | 9% | 8 – 9% | 8 – 9% | 9% | 9 – 10% | 9% | 8 – 9% | 8 – 9% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Desk4 |
12 – 15% | 12 – 14% | 12 – 13% | 12 – 13% | 12 – 13% | 12 – 15% | 12 – 14% | 12 – 13% | 12 – 13% | 12 – 13% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  DigitalBlack |
9 – 11% | 9% | 8 – 9% | 8 – 9% | 8 – 9% | 9 – 11% | 9% | 8 – 9% | 8 – 9% | 8 – 9% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Dirt |
11 – 13% | 11% | 11% | 11% | 11% | 11 – 13% | 11% | 11% | 11% | 11% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Discontinuity |
11 – 12% | 11 – 12% | 11% | 11% | 11% | 11 – 12% | 11 – 12% | 11% | 11% | 11% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Distance |
9 – 10% | 9 – 10% | 9 – 10% | 9% | 9% | 9 – 10% | 9 – 10% | 9 – 10% | 9 – 10% | 9 – 10% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Distance2 |
11 – 13% | 11 – 12% | 11 – 12% | 11 – 12% | 11% | 11 – 13% | 11 – 12% | 11 – 12% | 11 – 12% | 11 – 12% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Distance3 |
16 – 17% | 16% | 15 – 16% | 15 – 16% | 15 – 16% | 16 – 17% | 16% | 15 – 16% | 15 – 16% | 15 – 16% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Distortion |
8 – 12% | 8 – 10% | 8 – 9% | 7 – 9% | 7 – 9% | 8 – 12% | 8 – 11% | 8 – 10% | 7 – 9% | 7 – 9% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  DitherFloat |
7% | 6 – 7% | 6 – 7% | 6% | 6% | 7% | 6 – 7% | 6 – 7% | 6% | 6% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  DitherMeDiskers |
3 – 4% | 3 – 4% | 3% | 3% | 3% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  DitherMeTimbers |
3 – 5% | 3 – 4% | 3% | 3 – 4% | 3 – 4% | 3 – 5% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Ditherbox |
4 – 14% | 4 – 10% | 4 – 7% | 4 – 7% | 4 – 6% | 4 – 14% | 4 – 10% | 4 – 7% | 4 – 7% | 4 – 6% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  DoublePaul |
4 – 6% | 4% | 4% | 4% | 4% | 4 – 6% | 4% | 4 – 5% | 4% | 4% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Doublelay |
22 – 26% | 22 – 24% | 22 – 23% | 22 – 23% | 22% | 22 – 26% | 22 – 24% | 22 – 23% | 22 – 23% | 22% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Drive |
7 – 9% | 7 – 8% | 7 – 8% | 7 – 8% | 7 – 8% | 7 – 9% | 7 – 8% | 7 – 8% | 7 – 8% | 7 – 8% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  DrumSlam |
11 – 13% | 11 – 12% | 11 – 12% | 11 – 12% | 11 – 12% | 11 – 13% | 11 – 13% | 11 – 12% | 11 – 12% | 11 – 12% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  DubCenter |
13 – 15% | 12 – 15% | 12 – 14% | 12 – 13% | 12 – 13% | 13 – 15% | 12 – 15% | 12 – 14% | 12 – 14% | 12 – 14% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  DubSub |
18 – 19% | 17 – 19% | 17 – 18% | 17 – 18% | 17 – 18% | 18 – 20% | 17 – 19% | 17 – 19% | 17 – 18% | 17 – 18% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Dubly |
13 – 14% | 13 – 14% | 13 – 15% | 13% | 13% | 13 – 14% | 13 – 14% | 13 – 15% | 13% | 13% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  DustBunny |
4 – 5% | 4% | 4% | 4% | 3 – 4% | 4 – 5% | 4% | 4% | 4% | 3 – 4% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Dynamics |
11 – 12% | 10 – 11% | 10 – 11% | 10 – 11% | 10 – 11% | 11 – 12% | 10 – 11% | 10 – 11% | 10 – 11% | 10 – 11% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Dyno |
10 – 11% | 10 – 11% | 10% | 10% | 10% | 10 – 11% | 10 – 11% | 10% | 10% | 10% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  EQ |
15 – 16% | 14 – 15% | 14 – 15% | 14 – 15% | 14% | 15 – 16% | 14 – 15% | 14 – 15% | 14 – 15% | 14 – 15% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  EdIsDim |
7 – 8% | 7% | 6 – 7% | 6 – 7% | 6% | 7 – 8% | 7% | 6 – 7% | 6 – 7% | 6 – 7% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Edge |
10 – 12% | 10% | 10% | 10% | 10% | 10 – 12% | 10% | 10% | 10% | 10% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Elation |
13 – 15% | 13 – 14% | 13 – 14% | 12 – 13% | 11 – 13% | 13 – 15% | 13 – 14% | 13 – 14% | 12 – 13% | 11 – 13% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  ElectroHat |
7 – 8% | 7 – 8% | 7% | 7% | 7% | 7 – 8% | 7 – 8% | 7% | 7% | 7% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Energy |
15 – 18% | 14% | 14% | 14% | 14% | 15 – 18% | 14 – 15% | 14 – 15% | 14% | 14% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Energy2 |
13 – 15% | 13% | 13% | 12 – 13% | 12 – 13% | 13 – 15% | 13% | 13% | 12 – 13% | 12 – 13% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Ensemble |
13 – 100% | 12 – 56% | 13 – 56% | 12 – 56% | 12 – 54% | 13 – 101% | 12 – 57% | 13 – 57% | 12 – 57% | 12 – 54% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  EveryConsole |
7 – 8% | 7 – 9% | 7% | 7% | 6 – 7% | 7 – 8% | 7 – 9% | 7% | 7% | 6 – 7% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  EverySlew |
8 – 15% | 8 – 13% | 8 – 11% | 8 – 9% | 7 – 9% | 8 – 15% | 8 – 13% | 8 – 11% | 8 – 10% | 7 – 10% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  EveryTrim |
7% | 7% | 7% | 7% | 7% | 7% | 7% | 7% | 7% | 7% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Exciter |
9 – 10% | 9% | 9% | 9% | 9% | 9 – 10% | 9 – 10% | 9% | 9% | 9% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Facet |
7% | 6 – 7% | 6 – 7% | 6 – 7% | 6 – 7% | 7% | 6 – 7% | 6 – 7% | 6 – 7% | 6 – 7% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  FathomFive |
4 – 5% | 4% | 4% | 4% | 4% | 4 – 5% | 4% | 4% | 4% | 4% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  FinalClip |
4% | 3 – 4% | 3 – 4% | 3% | 3 – 4% | 4% | 3 – 4% | 3 – 4% | 3% | 3 – 4% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  FireAmp |
39 – 48% | 39 – 40% | 39% | 39% | 39% | 39 – 48% | 39 – 40% | 39 – 40% | 39 – 40% | 39 – 40% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Flipity |
3% | 3% | 2 – 3% | 2 – 3% | 2% | 3% | 3% | 2 – 3% | 2 – 3% | 2 – 3% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Floor |
14 – 19% | 14 – 19% | 14 – 19% | 13 – 19% | 13 – 18% | 14 – 19% | 14 – 19% | 14 – 19% | 13 – 19% | 13 – 19% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Flutter |
9 – 10% | 9% | 9% | 8 – 9% | 8 – 9% | 9 – 10% | 9% | 9% | 8 – 9% | 8 – 9% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Flutter2 |
11% | 10 – 11% | 10% | 10% | 10% | 11% | 10 – 11% | 10 – 11% | 10% | 10% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Focus |
11 – 14% | 10 – 14% | 10 – 13% | 10 – 12% | 10 – 12% | 11 – 15% | 10 – 14% | 10 – 13% | 10 – 12% | 10 – 12% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Fracture |
7 – 8% | 7 – 8% | 7 – 8% | 7% | 7% | 7 – 8% | 7 – 8% | 7 – 8% | 7 – 8% | 7 – 8% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Fracture2 |
8 – 10% | 8 – 9% | 8 – 9% | 8 – 9% | 8% | 8 – 10% | 8 – 9% | 8 – 9% | 8 – 9% | 8 – 9% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  FromTape |
15 – 16% | 14 – 15% | 14 – 15% | 14 – 15% | 14 – 15% | 15 – 16% | 14 – 15% | 14 – 15% | 14 – 15% | 14 – 15% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Galactic |
15 – 18% | 15 – 16% | 15 – 16% | 14 – 16% | 14 – 15% | 15 – 18% | 15 – 16% | 15 – 16% | 14 – 16% | 14 – 15% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Galactic2 |
22 – 25% | 21 – 23% | 21 – 22% | 20 – 21% | 20 – 21% | 22 – 25% | 21 – 23% | 21 – 22% | 20 – 22% | 20 – 21% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  GalacticVibe |
10 – 11% | 9 – 10% | 9 – 10% | 9 – 10% | 9 – 10% | 10 – 11% | 9 – 10% | 9 – 10% | 9 – 10% | 9 – 10% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Gatelope |
8 – 9% | 8% | 7 – 8% | 7 – 8% | 7 – 8% | 8 – 9% | 8% | 7 – 8% | 7 – 8% | 7 – 8% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  GlitchShifter |
11 – 13% | 11 – 12% | 11% | 11% | 11% | 11 – 13% | 11 – 12% | 11 – 12% | 11% | 11% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  GoldenSlew |
9% | 9 – 10% | 9% | 9% | 9% | 9 – 10% | 9 – 10% | 9% | 9% | 9% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Golem |
7 – 8% | 7% | 7% | 7% | 7% | 7 – 8% | 7% | 7% | 7% | 7% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  GrindAmp |
42 – 56% | 42 – 48% | 42 – 47% | 42 – 47% | 42 – 47% | 42 – 56% | 42 – 48% | 42 – 48% | 42 – 48% | 42 – 48% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Gringer |
10 – 11% | 10% | 10% | 9 – 10% | 9 – 10% | 10 – 11% | 10% | 10% | 9 – 10% | 9 – 10% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  GrooveWear |
10 – 17% | 9 – 17% | 9 – 17% | 9 – 17% | 9 – 17% | 10 – 17% | 9 – 17% | 9 – 17% | 9 – 17% | 9 – 17% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  GuitarConditioner |
8 – 9% | 8% | 7 – 8% | 7 – 8% | 7 – 8% | 8 – 9% | 8% | 7 – 8% | 7 – 8% | 7 – 8% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  HardVacuum |
10 – 13% | 10 – 12% | 10 – 11% | 10 – 11% | 10% | 10 – 13% | 10 – 12% | 10 – 11% | 10 – 11% | 10 – 11% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  HermeTrim |
7% | 7% | 7 – 8% | 7% | 7% | 7 – 8% | 7% | 7 – 8% | 7% | 7% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Hermepass |
9 – 10% | 9 – 10% | 9% | 9% | 9% | 9 – 10% | 9 – 10% | 9% | 9% | 9% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  HighGlossDither |
3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 5% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 5% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  HighImpact |
11 – 15% | 10 – 14% | 10 – 12% | 10 – 12% | 10 – 12% | 11 – 15% | 10 – 14% | 10 – 12% | 10 – 12% | 10 – 12% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Highpass |
5% | 4 – 5% | 4% | 4% | 4% | 5% | 4 – 5% | 4% | 4% | 4% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Highpass2 |
8 – 9% | 7 – 8% | 7 – 8% | 7 – 8% | 7 – 8% | 8 – 9% | 7 – 8% | 7 – 8% | 7 – 8% | 7 – 8% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Holt |
9 – 10% | 8 – 9% | 8 – 9% | 8 – 9% | 8 – 9% | 9 – 10% | 8 – 9% | 8 – 9% | 8 – 9% | 8 – 9% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Holt2 |
8 – 10% | 8 – 9% | 8 – 9% | 8 – 9% | 7 – 9% | 8 – 10% | 8 – 9% | 8 – 9% | 8 – 9% | 7 – 9% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Hombre |
8 – 10% | 8 – 9% | 8% | 8% | 8% | 8 – 10% | 8 – 9% | 8% | 8% | 8% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Huge |
11 – 13% | 11 – 12% | 11% | 11% | 11% | 11 – 13% | 11 – 12% | 11 – 12% | 11% | 11 – 12% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Hull |
8 – 40% | 8 – 33% | 8 – 22% | 8 – 17% | 7 – 17% | 8 – 40% | 8 – 34% | 8 – 23% | 8 – 17% | 7 – 17% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Hull2 |
10% | 9% | 9 – 10% | 9% | 9% | 10% | 9% | 9 – 10% | 9% | 9% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Hype |
8 – 9% | 8% | 8% | 8% | 7 – 8% | 8 – 9% | 8% | 8% | 8% | 7 – 8% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  HypersonX |
7 – 9% | 7% | 7% | 7% | 7% | 7 – 9% | 7% | 7% | 7% | 7% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Hypersonic |
9 – 10% | 9 – 10% | 9% | 9% | 9% | 9 – 10% | 9 – 10% | 9% | 9% | 9% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Infinity |
17 – 20% | 16 – 18% | 16 – 17% | 15 – 17% | 15 – 17% | 17 – 20% | 16 – 18% | 16 – 17% | 15 – 17% | 15 – 17% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Infinity2 |
18 – 24% | 18 – 20% | 18 – 19% | 18 – 19% | 17 – 18% | 18 – 24% | 18 – 20% | 18 – 19% | 18 – 19% | 17 – 18% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Inflamer |
9 – 14% | 9 – 13% | 8 – 13% | 8 – 13% | 8 – 12% | 9 – 14% | 9 – 14% | 8 – 13% | 8 – 13% | 8 – 12% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Infrasonic |
9 – 11% | 9 – 10% | 9 – 10% | 9% | 9% | 9 – 11% | 9 – 10% | 9 – 10% | 9 – 10% | 9 – 10% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Interstage |
7 – 8% | 7% | 7% | 7% | 7% | 7 – 8% | 7% | 7% | 7% | 7% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  IronOxide5 |
16 – 19% | 16 – 17% | 16% | 16% | 15 – 16% | 16 – 19% | 16 – 17% | 16 – 17% | 16% | 15 – 16% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  IronOxideClassic |
13 – 16% | 12 – 13% | 12 – 13% | 12 – 13% | 12 – 13% | 13 – 16% | 12 – 14% | 12 – 13% | 12 – 13% | 12 – 13% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  IronOxideClassic2 |
13 – 17% | 13 – 14% | 13% | 13% | 12 – 13% | 13 – 17% | 13 – 14% | 13% | 13% | 12 – 13% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Isolator |
11 – 12% | 11 – 12% | 11 – 12% | 11% | 11% | 11 – 12% | 11 – 12% | 11 – 12% | 11 – 12% | 11% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Isolator2 |
12 – 14% | 12% | 12% | 12% | 12% | 12 – 14% | 12% | 12 – 13% | 12% | 12% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Kalman |
9 – 10% | 8 – 9% | 8 – 9% | 8% | 8% | 9 – 10% | 8 – 9% | 8 – 9% | 8 – 9% | 8 – 9% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  LRFlipTimer |
3% | 3% | 3% | 3% | 3% | 3% | 3% | 3% | 3% | 3% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  LeadAmp |
46 – 56% | 46 – 53% | 45 – 52% | 45 – 52% | 45 – 52% | 46 – 56% | 46 – 53% | 45 – 53% | 45 – 53% | 45 – 53% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  LeftoMono |
3 – 4% | 2 – 3% | 2% | 2% | 2 – 3% | 3 – 4% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  LilAmp |
33 – 39% | 33 – 36% | 33 – 35% | 33 – 35% | 33 – 35% | 33 – 39% | 33 – 36% | 33 – 36% | 33 – 35% | 33 – 35% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Logical4 |
14 – 20% | 14 – 20% | 14 – 17% | 14 – 16% | 14 – 15% | 14 – 20% | 14 – 20% | 14 – 17% | 14 – 16% | 14 – 16% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Loud |
9 – 11% | 9 – 11% | 9 – 10% | 9 – 10% | 9% | 9 – 11% | 9 – 11% | 9 – 10% | 9 – 10% | 9% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Lowpass |
4 – 5% | 4 – 5% | 4% | 4% | 4% | 4 – 5% | 4 – 5% | 4% | 4% | 4% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Lowpass2 |
8 – 10% | 7 – 8% | 7 – 8% | 7 – 8% | 7 – 8% | 8 – 10% | 7 – 8% | 7 – 8% | 7 – 8% | 7 – 8% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Luxor |
13 – 14% | 12 – 14% | 12 – 14% | 11 – 14% | 11 – 14% | 13 – 14% | 12 – 14% | 12 – 14% | 11 – 14% | 11 – 14% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  MSFlipTimer |
3 – 5% | 3% | 3% | 3% | 3% | 3 – 5% | 3% | 3% | 3% | 3% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  MV |
13 – 20% | 12 – 16% | 12 – 15% | 11 – 14% | 11 – 14% | 13 – 20% | 12 – 16% | 12 – 15% | 11 – 14% | 11 – 14% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  MV2 |
12 – 21% | 12 – 16% | 12 – 15% | 11 – 14% | 11 – 14% | 12 – 22% | 12 – 17% | 12 – 15% | 11 – 15% | 11 – 14% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  MackEQ |
26 – 31% | 26 – 27% | 26% | 26% | 25 – 26% | 26 – 31% | 26 – 27% | 26 – 27% | 26% | 25 – 26% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Mackity |
12% | 12% | 11 – 12% | 11% | 11% | 12% | 12% | 11 – 12% | 11 – 12% | 11 – 12% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  MatrixVerb |
147 – 154% | 145 – 148% | 146 – 147% | 145 – 146% | 144 – 146% | 147 – 154% | 145 – 148% | 145 – 147% | 145 – 146% | 144 – 146% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Melt |
11 – 14% | 11 – 12% | 11% | 11% | 11% | 11 – 14% | 11 – 12% | 11% | 11 – 12% | 11% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  MidAmp |
38 – 47% | 37 – 40% | 37 – 40% | 37 – 39% | 37 – 39% | 38 – 47% | 37 – 40% | 37 – 40% | 37 – 40% | 37 – 40% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  MidSide |
6 – 7% | 6 – 7% | 6% | 6% | 6% | 6 – 7% | 6 – 7% | 6% | 6% | 6 – 7% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  MoNoam |
7 – 8% | 6 – 7% | 6% | 6% | 6% | 7 – 8% | 6 – 7% | 6 – 7% | 6% | 6 – 7% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Mojo |
10 – 13% | 10% | 10% | 10% | 10% | 10 – 13% | 10% | 10% | 10% | 10% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Monitoring |
17 – 19% | 12 – 16% | 10 – 16% | 10 – 16% | 9 – 16% | 17 – 19% | 12 – 16% | 10 – 16% | 10 – 16% | 9 – 16% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Monitoring2 |
18 – 20% | 14 – 18% | 13 – 18% | 11 – 18% | 11 – 18% | 18 – 20% | 14 – 18% | 13 – 18% | 11 – 18% | 11 – 18% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Monitoring3 |
23 – 25% | 18 – 23% | 18 – 22% | 16 – 22% | 16 – 22% | 23 – 25% | 18 – 23% | 18 – 22% | 16 – 22% | 16 – 22% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  MultiBandDistortion |
10 – 16% | 9 – 16% | 9 – 16% | 9 – 15% | 9 – 16% | 10 – 16% | 9 – 16% | 9 – 16% | 9 – 15% | 9 – 16% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  NCSeventeen |
15 – 17% | 15 – 17% | 15% | 15% | 15% | 15 – 17% | 15 – 17% | 15% | 15% | 15% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  NaturalizeDither |
7 – 9% | 7% | 7% | 7% | 7% | 7 – 9% | 7% | 7% | 7% | 7% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Neverland |
13 – 14% | 12 – 14% | 12 – 14% | 11 – 14% | 11 – 14% | 13 – 14% | 12 – 14% | 12 – 14% | 11 – 14% | 11 – 14% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Nikola |
7 – 8% | 7 – 8% | 7% | 7 – 8% | 7% | 7 – 8% | 7 – 8% | 7 – 8% | 7 – 8% | 7% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  NodeDither |
4% | 3 – 4% | 3 – 4% | 3% | 3% | 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Noise |
12 – 15% | 12 – 13% | 12 – 13% | 12 – 13% | 12 – 13% | 12 – 15% | 12 – 13% | 12 – 13% | 12 – 13% | 12 – 13% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  NonlinearSpace |
33 – 45% | 32 – 38% | 31 – 35% | 31 – 34% | 30 – 33% | 33 – 45% | 32 – 38% | 31 – 35% | 31 – 34% | 30 – 33% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  NotJustAnotherCD |
6 – 8% | 6% | 6 – 7% | 6% | 6% | 6 – 8% | 6 – 7% | 6 – 7% | 6% | 6% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  NotJustAnotherDither |
7 – 8% | 7% | 7% | 7% | 6 – 7% | 7 – 8% | 7% | 7% | 7% | 6 – 7% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  OneCornerClip |
7 – 9% | 7% | 7% | 7% | 7% | 7 – 9% | 7 – 8% | 7 – 8% | 7% | 7% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  OrbitKick |
7 – 9% | 7 – 9% | 7 – 9% | 7 – 9% | 7 – 8% | 7 – 10% | 7 – 10% | 7 – 10% | 7 – 9% | 7 – 9% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Overheads |
8 – 9% | 8% | 8% | 8% | 7 – 8% | 8 – 9% | 8 – 9% | 8% | 8% | 7 – 8% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  PDBuss |
9 – 10% | 8 – 9% | 8 – 9% | 8 – 9% | 8 – 9% | 9 – 10% | 8 – 9% | 8 – 9% | 8 – 9% | 8 – 9% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  PDChannel |
8 – 9% | 8% | 8% | 8% | 7 – 8% | 8 – 9% | 8% | 8% | 8% | 7 – 8% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows | Pafnuty | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them | ||||||||||
| Airwindows |  Pafnuty2 |
10 – 11% | 10 – 11% | 10% | 10% | 10% | 10 – 11% | 10 – 11% | 10 – 11% | 10 – 11% | 10 – 11% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Parametric |
13 – 16% | 13 – 14% | 13% | 13% | 13% | 13 – 16% | 13 – 14% | 13 – 14% | 13 – 14% | 13% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  PaulDither |
4% | 4 – 5% | 4% | 4% | 4% | 4% | 4 – 5% | 4% | 4% | 4% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  PaulWide |
5% | 4 – 5% | 5% | 4 – 5% | 4% | 5% | 4 – 5% | 5% | 4 – 5% | 4 – 5% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  PeaksOnly |
17 – 18% | 17% | 17% | 17% | 17% | 17 – 18% | 17 – 18% | 17 – 18% | 17% | 17% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Pear |
7 – 10% | 8 – 9% | 7 – 9% | 7 – 9% | 7 – 9% | 7 – 10% | 8 – 9% | 7 – 9% | 7 – 9% | 7 – 9% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Pear2 |
8 – 16% | 8 – 16% | 7 – 16% | 7 – 16% | 7 – 15% | 8 – 16% | 8 – 16% | 7 – 16% | 7 – 16% | 7 – 15% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  PhaseNudge |
9% | 9% | 9% | 8 – 9% | 8 – 9% | 9% | 9% | 9% | 8 – 9% | 8 – 9% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  PitchDelay |
18 – 21% | 18 – 19% | 17 – 18% | 17 – 18% | 17 – 18% | 18 – 21% | 18 – 19% | 17 – 18% | 17 – 18% | 17 – 18% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  PitchNasty |
9 – 10% | 8% | 8% | 8% | 8% | 9 – 10% | 8 – 9% | 8 – 9% | 8% | 8 – 9% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  PlatinumSlew |
12 – 14% | 12 – 14% | 12 – 14% | 12 – 14% | 12 – 13% | 12 – 14% | 12 – 14% | 12 – 14% | 12 – 14% | 12 – 13% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  PocketVerbs |
101 – 118% | 93 – 116% | 86 – 111% | 80 – 107% | 79 – 92% | 101 – 118% | 93 – 116% | 86 – 111% | 80 – 107% | 79 – 92% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Pockey |
14 – 15% | 14% | 14% | 13 – 14% | 13 – 14% | 14 – 15% | 14% | 14% | 13 – 14% | 13 – 14% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Pockey2 |
11% | 10 – 11% | 10 – 11% | 10% | 10% | 11% | 10 – 11% | 10 – 11% | 10 – 11% | 10 – 11% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Podcast |
16 – 18% | 15 – 17% | 16% | 15 – 16% | 15 – 16% | 16 – 18% | 15 – 17% | 16% | 15 – 16% | 15 – 16% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  PodcastDeluxe |
18 – 20% | 18% | 18% | 18% | 18% | 18 – 20% | 18% | 18% | 18% | 18% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Point |
9% | 9% | 8 – 9% | 8% | 8% | 9% | 9% | 8 – 9% | 8 – 9% | 8 – 9% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Pop |
12 – 14% | 12% | 11% | 11 – 12% | 11% | 12 – 14% | 12% | 11 – 12% | 11 – 12% | 11 – 12% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Pop2 |
9% | 8 – 9% | 8 – 9% | 8% | 8% | 9% | 8 – 9% | 8 – 9% | 8 – 9% | 8 – 9% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows | Pop3 | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them | ||||||||||
| Airwindows |  PowerSag |
9 – 10% | 9% | 9% | 9% | 9% | 9 – 10% | 9% | 9% | 9% | 9% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  PowerSag2 |
8 – 9% | 8% | 8% | 8% | 8% | 8 – 9% | 8% | 8% | 8% | 8% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Precious |
13 – 14% | 12 – 14% | 12 – 14% | 11 – 14% | 11 – 14% | 13 – 14% | 12 – 14% | 12 – 14% | 11 – 14% | 11 – 14% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Preponderant |
10 – 12% | 10 – 11% | 10% | 10% | 10% | 10 – 12% | 10 – 11% | 10 – 11% | 10 – 11% | 10% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Pressure4 |
9 – 10% | 8 – 9% | 8 – 9% | 8% | 8% | 9 – 10% | 8 – 9% | 8 – 9% | 8% | 8% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Pressure5 |
9 – 11% | 9% | 9% | 9% | 9% | 9 – 11% | 9 – 10% | 9% | 9% | 9% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  PurestAir |
9 – 10% | 9% | 8 – 9% | 8 – 9% | 8 – 9% | 9 – 10% | 9% | 8 – 9% | 8 – 9% | 8 – 9% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  PurestConsole2Buss |
8 – 11% | 8% | 8% | 8% | 8% | 8 – 11% | 8% | 8 – 9% | 8 – 9% | 8% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  PurestConsole2Channel |
8 – 10% | 7 – 8% | 7 – 8% | 7% | 7% | 8 – 10% | 7 – 8% | 7 – 8% | 7 – 8% | 7 – 8% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  PurestConsole3Buss |
18 – 20% | 18% | 18% | 18% | 18% | 18 – 20% | 18% | 18% | 18% | 18% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  PurestConsole3Channel |
18 – 19% | 18% | 18% | 18% | 18% | 18 – 19% | 18% | 18% | 18% | 18% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  PurestConsoleBuss |
8 – 11% | 8 – 9% | 8 – 10% | 8% | 8% | 8 – 11% | 8 – 9% | 8 – 10% | 8 – 9% | 8% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  PurestConsoleChannel |
7 – 9% | 7% | 7% | 7% | 7% | 7 – 9% | 7% | 7% | 7% | 7% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  PurestDrive |
8 – 9% | 7 – 8% | 7 – 8% | 7 – 8% | 7% | 8 – 9% | 7 – 8% | 7 – 8% | 7 – 8% | 7 – 8% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  PurestEcho |
8 – 10% | 8 – 9% | 8 – 9% | 8 – 9% | 8 – 9% | 8 – 10% | 8 – 9% | 8 – 9% | 8 – 9% | 8 – 9% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  PurestFade |
7 – 8% | 7% | 7% | 7% | 7% | 7 – 8% | 7% | 7% | 7% | 7% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  PurestGain |
7 – 9% | 7% | 7% | 7% | 7% | 7 – 9% | 7% | 7% | 7% | 7% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  PurestSquish |
10 – 11% | 10 – 11% | 10 – 11% | 10% | 10% | 10 – 11% | 10 – 11% | 10 – 11% | 10% | 10% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  PurestWarm |
11 – 12% | 11% | 9 – 11% | 9 – 11% | 8 – 11% | 11 – 12% | 11% | 9 – 11% | 9 – 11% | 8 – 11% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  PurestWarm2 |
8 – 9% | 8 – 9% | 8% | 8% | 8% | 8 – 9% | 8 – 9% | 8% | 8% | 8% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Pyewacket |
9 – 10% | 9% | 9% | 8 – 9% | 8 – 9% | 9 – 10% | 9% | 9% | 8 – 9% | 8 – 9% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  RawGlitters |
4% | 4 – 5% | 4% | 4% | 4% | 4% | 4 – 5% | 4% | 4% | 4% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  RawTimbers |
4 – 6% | 4% | 4% | 4% | 4% | 4 – 6% | 4% | 4% | 4% | 4% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Recurve |
11 – 12% | 10 – 11% | 10 – 11% | 10 – 11% | 10% | 11 – 12% | 10 – 11% | 10 – 11% | 10 – 11% | 10 – 11% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Remap |
8 – 9% | 8 – 9% | 8% | 8% | 8% | 8 – 9% | 8 – 9% | 8% | 8% | 8% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  ResEQ |
17 – 21% | 16 – 17% | 16 – 17% | 16 – 17% | 16 – 17% | 17 – 21% | 16 – 17% | 16 – 17% | 16 – 17% | 16 – 17% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  ResEQ2 |
8 – 20% | 7 – 20% | 7 – 20% | 7 – 20% | 7 – 19% | 8 – 21% | 7 – 21% | 7 – 20% | 7 – 20% | 7 – 19% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Reverb |
145 – 153% | 145 – 148% | 144 – 147% | 145 – 146% | 145 – 146% | 145 – 153% | 145 – 148% | 144 – 147% | 145 – 146% | 145 – 146% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Righteous4 |
15 – 18% | 15% | 15% | 15% | 15% | 15 – 18% | 15 – 16% | 15 – 16% | 15% | 15% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  RightoMono |
3% | 2 – 3% | 2 – 4% | 2% | 2% | 3% | 2 – 3% | 2 – 4% | 2 – 3% | 2 – 3% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  SampleDelay |
7 – 8% | 7% | 7% | 7% | 7% | 7 – 8% | 7% | 7% | 7% | 7% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Shape |
9 – 10% | 8 – 10% | 8 – 9% | 8 – 9% | 8 – 9% | 9 – 10% | 8 – 10% | 8 – 10% | 8 – 9% | 8 – 9% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  ShortBuss |
8 – 9% | 8 – 9% | 8 – 10% | 8% | 8% | 8 – 9% | 8 – 9% | 8 – 10% | 8% | 8% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  SideDull |
7% | 7 – 9% | 6 – 7% | 6 – 7% | 6 – 7% | 7% | 7 – 9% | 6 – 7% | 6 – 7% | 6 – 7% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Sidepass |
7% | 7% | 7% | 7% | 6 – 7% | 7% | 7% | 7% | 7% | 6 – 7% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Silhouette |
10 – 12% | 10% | 10% | 9 – 10% | 9 – 10% | 10 – 12% | 10% | 10% | 9 – 10% | 9 – 10% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Sinew |
7 – 8% | 7% | 7% | 7% | 7% | 7 – 8% | 7% | 7% | 7% | 7% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  SingleEndedTriode |
8 – 10% | 8 – 11% | 8 – 9% | 7 – 9% | 7 – 9% | 8 – 10% | 8 – 11% | 8 – 9% | 7 – 9% | 7 – 9% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Slew |
3% | 3% | 3% | 3% | 3% | 3% | 3% | 3% | 3% | 3% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Slew2 |
5% | 4 – 5% | 4% | 4% | 4% | 5% | 4 – 5% | 4 – 5% | 4 – 5% | 4% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Slew3 |
7 – 8% | 7% | 7% | 7% | 7% | 7 – 8% | 7% | 7% | 7% | 7% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  SlewOnly |
3% | 3% | 3% | 3% | 3% | 3% | 3% | 3% | 3% | 3% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  SlewSonic |
8 – 9% | 8 – 9% | 8 – 9% | 8 – 9% | 7 – 9% | 8 – 9% | 8 – 9% | 8 – 9% | 8 – 9% | 7 – 9% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Smooth |
11 – 15% | 11 – 14% | 11 – 14% | 11 – 14% | 11 – 14% | 11 – 15% | 11 – 15% | 11 – 14% | 11 – 14% | 11 – 14% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  SoftGate |
7 – 8% | 7% | 7% | 7% | 6 – 7% | 7 – 9% | 7 – 8% | 7 – 8% | 7% | 6 – 7% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  SpatializeDither |
6% | 5% | 5 – 6% | 5% | 5% | 6% | 5 – 6% | 5 – 6% | 5 – 6% | 5 – 6% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Spiral |
7% | 7 – 8% | 7% | 7% | 7% | 7% | 7 – 8% | 7% | 7% | 7% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Spiral2 |
8 – 9% | 8 – 9% | 8 – 9% | 8% | 8% | 8 – 9% | 8 – 9% | 8 – 9% | 8 – 9% | 8 – 9% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Srsly |
11 – 13% | 11 – 12% | 11% | 11% | 11% | 11 – 13% | 11 – 12% | 11 – 12% | 11% | 11% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Srsly2 |
11 – 12% | 11 – 12% | 11% | 11% | 11% | 11 – 13% | 11 – 12% | 11 – 12% | 11 – 12% | 11 – 12% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Srsly3 |
9 – 11% | 9 – 10% | 9 – 10% | 9 – 10% | 9% | 9 – 11% | 9 – 10% | 9 – 10% | 9 – 10% | 9 – 10% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  StarChild |
15 – 62% | 14 – 35% | 14 – 31% | 14 – 30% | 14 – 27% | 15 – 62% | 14 – 35% | 14 – 31% | 14 – 30% | 14 – 27% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  StarChild2 |
13 – 57% | 13 – 33% | 13 – 29% | 13 – 28% | 13 – 25% | 13 – 57% | 13 – 33% | 13 – 29% | 13 – 28% | 13 – 25% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  StereoChorus |
12 – 13% | 11 – 12% | 11 – 12% | 11 – 12% | 11 – 12% | 12 – 13% | 11 – 12% | 11 – 12% | 11 – 12% | 11 – 12% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  StereoDoubler |
21 – 24% | 21 – 22% | 21% | 21% | 21% | 21 – 24% | 21 – 22% | 21% | 21% | 21% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  StereoEnsemble |
10 – 11% | 9 – 11% | 9 – 10% | 9% | 9% | 10 – 11% | 9 – 11% | 9 – 10% | 9 – 10% | 9 – 10% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  StereoFX |
10 – 11% | 9 – 10% | 9 – 10% | 9 – 10% | 9 – 10% | 10 – 11% | 9 – 10% | 9 – 10% | 9 – 10% | 9 – 10% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows | StoneFireComp | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them | ||||||||||
| Airwindows |  Stonefire |
10 – 12% | 10 – 11% | 10 – 11% | 10 – 11% | 10 – 11% | 10 – 12% | 10 – 11% | 10 – 11% | 10 – 11% | 10 – 11% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  StudioTan |
4 – 7% | 4 – 7% | 3 – 7% | 3 – 7% | 3 – 7% | 4 – 7% | 4 – 7% | 3 – 7% | 3 – 7% | 3 – 7% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  SubTight |
8 – 18% | 7 – 18% | 7 – 16% | 7 – 15% | 7 – 15% | 8 – 19% | 7 – 18% | 7 – 16% | 7 – 15% | 7 – 15% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  SubsOnly |
14 – 15% | 14% | 13 – 14% | 13 – 14% | 13 – 14% | 14 – 15% | 14% | 13 – 14% | 13 – 14% | 13 – 14% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Surge |
8 – 10% | 8 – 9% | 8% | 8% | 8% | 8 – 10% | 8 – 9% | 8% | 8% | 8% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  SurgeTide |
7 – 8% | 7 – 8% | 7 – 8% | 7 – 9% | 7% | 7 – 8% | 7 – 9% | 7 – 8% | 7 – 9% | 7 – 8% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Sweeten |
7% | 7% | 7% | 7% | 6 – 7% | 7% | 7% | 7% | 7% | 6 – 7% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Swell |
7 – 8% | 7% | 7% | 7% | 7% | 7 – 8% | 7% | 7% | 7% | 7% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  TPDFDither |
4 – 6% | 4 – 5% | 4% | 4% | 4% | 4 – 6% | 4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  TPDFWide |
5% | 5% | 5 – 6% | 5% | 5% | 5% | 5% | 5 – 6% | 5% | 5% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Tape |
17 – 19% | 17% | 17% | 17% | 17% | 17 – 19% | 17% | 17% | 17% | 17% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  TapeDelay |
9 – 10% | 8% | 8% | 8% | 8% | 9 – 10% | 8% | 8% | 8% | 8% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  TapeDelay2 |
11 – 13% | 11 – 12% | 11% | 11% | 11% | 11 – 13% | 11 – 12% | 11 – 12% | 11% | 11% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  TapeDither |
4 – 5% | 4% | 4% | 4% | 4% | 4 – 5% | 4% | 4% | 4% | 4% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  TapeDust |
11 – 12% | 11 – 12% | 11% | 11% | 11% | 11 – 12% | 11 – 12% | 11 – 12% | 11% | 11% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  TapeFat |
7 – 8% | 7 – 8% | 7 – 8% | 7 – 8% | 7 – 8% | 7 – 8% | 7 – 8% | 7 – 8% | 7 – 8% | 7 – 8% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Texturize |
11 – 12% | 10 – 11% | 10 – 11% | 10% | 10% | 11 – 12% | 10 – 11% | 10 – 11% | 10 – 11% | 10 – 11% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  TexturizeMS |
11% | 10 – 12% | 10 – 11% | 10 – 11% | 10 – 11% | 11 – 12% | 10 – 12% | 10 – 11% | 10 – 11% | 10 – 11% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Thunder |
9 – 11% | 9% | 9% | 9% | 8 – 9% | 9 – 11% | 9% | 9% | 9% | 8 – 9% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  ToTape5 |
20 – 24% | 20 – 21% | 20% | 20% | 20% | 20 – 24% | 20 – 21% | 20% | 20% | 20% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  ToTape6 |
22 – 25% | 22% | 22% | 21 – 22% | 21 – 22% | 22 – 25% | 22% | 22% | 21 – 22% | 21 – 22% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  ToVinyl4 |
17 – 21% | 17 – 18% | 17% | 17% | 17% | 17 – 21% | 17 – 18% | 17% | 17% | 17% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  ToneSlant |
18 – 49% | 18 – 46% | 18 – 36% | 17 – 25% | 14 – 25% | 18 – 49% | 18 – 46% | 18 – 36% | 17 – 25% | 14 – 25% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  TransDesk |
11 – 13% | 11 – 12% | 11% | 11% | 11% | 11 – 13% | 11 – 12% | 11% | 11% | 11% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  TremoSquare |
7% | 7% | 7 – 8% | 7% | 7% | 7% | 7% | 7 – 8% | 7% | 7% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Tremolo |
14 – 15% | 14 – 15% | 14% | 14% | 14% | 14 – 15% | 14 – 15% | 14% | 14% | 14% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Trianglizer |
10 – 11% | 10 – 11% | 10 – 11% | 10% | 10% | 10 – 11% | 10 – 11% | 10 – 11% | 10 – 11% | 10 – 11% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  TripleSpread |
11 – 27% | 11 – 44% | 11 – 19% | 11% | 11% | 11 – 27% | 11 – 44% | 11 – 19% | 11 – 17% | 11 – 15% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Tube |
7 – 8% | 7 – 8% | 7 – 8% | 7% | 7% | 7 – 8% | 7 – 8% | 7 – 8% | 7 – 8% | 7 – 8% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Tube2 |
10 – 12% | 10 – 11% | 10% | 10% | 10% | 10 – 12% | 10 – 11% | 10% | 10% | 10% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  TubeDesk |
12 – 13% | 12% | 12% | 12% | 12% | 12 – 13% | 12% | 12% | 12% | 12% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  UltrasonX |
7 – 9% | 7% | 7% | 7% | 7% | 7 – 9% | 7% | 7% | 7% | 7% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Ultrasonic |
9 – 11% | 9 – 10% | 9 – 10% | 9% | 9% | 9 – 11% | 9 – 10% | 9 – 10% | 9 – 10% | 9 – 10% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  UltrasonicLite |
7% | 7% | 7% | 7% | 7% | 7% | 7% | 7% | 7% | 7% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  UltrasonicMed |
7 – 9% | 7 – 8% | 7 – 8% | 7% | 7% | 7 – 9% | 7 – 8% | 7 – 8% | 7% | 7% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  UnBox |
11 – 12% | 10 – 11% | 10 – 11% | 10% | 10% | 11 – 12% | 10 – 11% | 10 – 11% | 10 – 11% | 10% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  VariMu |
9 – 10% | 9 – 10% | 9% | 9% | 9% | 9 – 10% | 9 – 10% | 9 – 10% | 9% | 9% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Verbity |
12 – 15% | 12 – 13% | 11 – 13% | 11 – 13% | 11 – 13% | 12 – 15% | 12 – 13% | 11 – 13% | 11 – 13% | 11 – 13% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Verbity2 |
19 – 27% | 18 – 22% | 18 – 22% | 18 – 21% | 17 – 20% | 19 – 27% | 18 – 22% | 18 – 22% | 18 – 21% | 17 – 20% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Vibrato |
12 – 13% | 11 – 12% | 11 – 12% | 11% | 11% | 12 – 13% | 11 – 12% | 11 – 12% | 11 – 12% | 11 – 12% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  VinylDither |
14 – 17% | 14% | 13 – 14% | 13 – 14% | 13 – 14% | 14 – 17% | 14% | 13 – 14% | 13 – 14% | 13 – 14% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  VoiceOfTheStarship |
9 – 10% | 8 – 9% | 8 – 9% | 8% | 8% | 9 – 10% | 8 – 9% | 8 – 9% | 8 – 9% | 8 – 9% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  VoiceTrick |
7 – 9% | 7% | 7% | 7% | 7% | 7 – 9% | 7% | 7% | 7% | 7% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Weight |
9 – 10% | 9 – 10% | 9% | 9% | 9% | 9 – 10% | 9 – 10% | 9% | 9% | 9% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Wider |
9 – 10% | 8 – 9% | 8 – 9% | 8 – 9% | 8 – 9% | 9 – 10% | 8 – 9% | 8 – 9% | 8 – 9% | 8 – 9% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  Wolfbot |
12 – 13% | 12% | 12% | 12% | 12% | 12 – 13% | 12% | 12% | 12% | 12% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  XBandpass |
11 – 18% | 10 – 17% | 10 – 17% | 10 – 17% | 10 – 17% | 11 – 19% | 10 – 18% | 10 – 17% | 10 – 17% | 10 – 17% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  XHighpass |
8 – 10% | 8 – 10% | 8 – 10% | 8 – 9% | 8 – 9% | 8 – 10% | 8 – 10% | 8 – 10% | 8 – 9% | 8 – 9% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  XLowpass |
12 – 19% | 12 – 19% | 12 – 19% | 11 – 19% | 11 – 18% | 12 – 19% | 12 – 19% | 12 – 19% | 11 – 19% | 11 – 18% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  XNotch |
12 – 19% | 12 – 18% | 12 – 18% | 12 – 18% | 12 – 17% | 12 – 20% | 12 – 18% | 12 – 18% | 12 – 18% | 12 – 17% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  XRegion |
12 – 21% | 12 – 20% | 12 – 20% | 12 – 20% | 12 – 20% | 12 – 21% | 12 – 21% | 12 – 21% | 12 – 20% | 12 – 20% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  YBandpass |
15 – 17% | 15% | 15% | 15% | 15% | 15 – 17% | 15 – 16% | 15% | 15% | 15% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  YHighpass |
15 – 17% | 15 – 16% | 15 – 16% | 15% | 15% | 15 – 17% | 15 – 16% | 15 – 16% | 15 – 16% | 15 – 16% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  YLowpass |
15 – 17% | 15% | 15% | 15% | 15% | 15 – 17% | 15 – 16% | 15 – 16% | 15 – 16% | 15 – 16% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  YNotBandpass |
15 – 18% | 14 – 15% | 14 – 15% | 14 – 15% | 14 – 15% | 15 – 18% | 14 – 15% | 14 – 15% | 14 – 15% | 14 – 15% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  YNotHighpass |
15 – 16% | 15 – 17% | 14 – 15% | 14 – 16% | 14% | 15 – 16% | 15 – 17% | 14 – 15% | 14 – 16% | 14 – 15% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  YNotLowpass |
14 – 18% | 14 – 15% | 14 – 15% | 14% | 14% | 14 – 18% | 14 – 15% | 14 – 15% | 14 – 15% | 14 – 15% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  YNotNotch |
15 – 16% | 14 – 15% | 14 – 15% | 14 – 15% | 14% | 15 – 16% | 14 – 15% | 14 – 15% | 14 – 15% | 14 – 15% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  YNotch |
15 – 17% | 15 – 16% | 15 – 16% | 15% | 15% | 15 – 17% | 15 – 16% | 15 – 16% | 15 – 16% | 15% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  ZBandpass |
10 – 13% | 10 – 12% | 10 – 12% | 10 – 12% | 10 – 12% | 10 – 13% | 10 – 12% | 10 – 12% | 10 – 12% | 10 – 12% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  ZBandpass2 |
11 – 14% | 11 – 14% | 11 – 14% | 10 – 14% | 11 – 13% | 11 – 14% | 11 – 14% | 11 – 14% | 10 – 14% | 11 – 13% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  ZHighpass |
10 – 11% | 9 – 11% | 9 – 11% | 9 – 11% | 9 – 11% | 10 – 12% | 9 – 11% | 9 – 11% | 9 – 11% | 9 – 11% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  ZHighpass2 |
10 – 12% | 10 – 12% | 10 – 12% | 10 – 12% | 10 – 12% | 10 – 12% | 10 – 12% | 10 – 12% | 10 – 12% | 10 – 12% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  ZLowpass |
10 – 13% | 10 – 13% | 10 – 13% | 10 – 12% | 10 – 12% | 10 – 13% | 10 – 13% | 10 – 13% | 10 – 12% | 10 – 12% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  ZLowpass2 |
12 – 14% | 11 – 14% | 11 – 14% | 11 – 14% | 11 – 14% | 12 – 14% | 11 – 14% | 11 – 14% | 11 – 14% | 11 – 14% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  ZNotch |
11 – 13% | 10 – 13% | 10 – 13% | 10 – 13% | 10 – 12% | 11 – 13% | 10 – 13% | 10 – 13% | 10 – 13% | 10 – 12% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  ZNotch2 |
11 – 14% | 11 – 14% | 11 – 13% | 11 – 14% | 10 – 13% | 11 – 14% | 11 – 14% | 11 – 13% | 11 – 14% | 10 – 13% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  ZOutputStage |
8 – 10% | 8 – 9% | 8% | 8% | 8% | 8 – 10% | 8 – 9% | 8% | 8% | 8% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  ZRegion |
15 – 22% | 15 – 22% | 15 – 22% | 14 – 21% | 14 – 21% | 15 – 23% | 15 – 22% | 15 – 22% | 14 – 21% | 14 – 21% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  ZRegion2 |
16 – 22% | 16 – 22% | 16 – 22% | 16 – 21% | 16 – 21% | 16 – 23% | 16 – 22% | 16 – 22% | 16 – 21% | 16 – 21% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  curve |
10 – 12% | 10 – 11% | 10% | 10% | 10% | 10 – 12% | 10 – 11% | 10 – 11% | 10% | 10 – 11% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  kCathedral |
36 – 42% | 36 – 37% | 35 – 36% | 35 – 36% | 35% | 36 – 42% | 36 – 37% | 35 – 36% | 35 – 36% | 35 – 36% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  kCathedral2 |
39 – 47% | 38 – 41% | 37 – 39% | 37 – 38% | 37% | 39 – 47% | 38 – 41% | 37 – 39% | 37 – 38% | 37% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  kCathedral3 |
15 – 25% | 15 – 23% | 15 – 23% | 14 – 23% | 14 – 20% | 15 – 27% | 15 – 23% | 15 – 23% | 14 – 23% | 14 – 20% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  kChamberAR |
34 – 44% | 34 – 43% | 33 – 43% | 33 – 43% | 33 – 43% | 34 – 44% | 34 – 43% | 33 – 43% | 33 – 43% | 33 – 43% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows | kGuitarHall | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them | ||||||||||
| Airwindows | kPlate140 | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them | ||||||||||
| Airwindows | kPlate240 | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them | ||||||||||
| Airwindows |  kPlateA |
32 – 41% | 32 – 36% | 31 – 34% | 30 – 32% | 29 – 31% | 32 – 41% | 32 – 36% | 31 – 34% | 30 – 32% | 29 – 31% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  kPlateB |
34 – 42% | 33 – 36% | 32 – 34% | 31 – 33% | 30 – 32% | 34 – 42% | 33 – 36% | 32 – 34% | 31 – 33% | 30 – 32% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  kPlateC |
32 – 41% | 31 – 35% | 30 – 33% | 29 – 32% | 29 – 30% | 32 – 41% | 31 – 35% | 30 – 33% | 29 – 32% | 29 – 31% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  kPlateD |
34 – 43% | 34 – 38% | 33 – 35% | 31 – 34% | 31 – 33% | 34 – 43% | 34 – 38% | 33 – 35% | 31 – 34% | 31 – 33% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  uLawDecode |
10 – 11% | 10% | 10% | 9 – 10% | 9 – 10% | 10 – 11% | 10% | 10% | 9 – 10% | 9 – 10% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| Airwindows |  uLawEncode |
10 – 11% | 10% | 10% | 9 – 10% | 9 – 10% | 10 – 11% | 10% | 10% | 9 – 10% | 9 – 10% | Effect, Multiple | Airwindows is a collection of effects; this module contains all of them |
| AlliewayAudio_Freebies |  Chilly Cheese |
12 – 20% | 12 – 19% | 12 – 19% | 12 – 19% | 12 – 19% | 12 – 20% | 12 – 19% | 12 – 19% | 12 – 19% | 12 – 19% | Attenuator, Compressor, Envelope follower, Hardware clone, Logic, Ring modulator, Slew limiter, Utility, Voltage-controlled amplifier, Waveshaper | 1:1 digital recreation of Mannequins 'Cold Mac' esoteric macro-utility (made with permission, but not by Mannequins) |
| Amalgamated Harmonics |  Arpeggiator MkII (deprecated) |
4 – 5% | 4% | 4% | 4% | 4% | 4 – 5% | 4 – 5% | 4% | 4% | 4% | Arpeggiator | A multi-input arpeggiator |
| Amalgamated Harmonics |  Bombe |
4 – 9% | 4 – 7% | 4 – 6% | 4 – 6% | 4 – 6% | 4 – 9% | 4 – 7% | 4 – 6% | 4 – 6% | 4 – 6% | Sequencer, Polyphonic | A semi-random shift-register chord generator and looper |
| Amalgamated Harmonics |  D'acchord |
30 – 32% | 31% | 31% | 30 – 31% | 30 – 31% | 30 – 32% | 31% | 31% | 30 – 31% | 30 – 31% | VCO, Polyphonic | Six voice VCO |
| Amalgamated Harmonics |  Fifths and Fourths |
4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | 4 – 8% | 4 – 6% | 4 – 5% | 4 – 5% | 4 – 5% | Utility | An implementation of the Circle of Fifths |
| Amalgamated Harmonics |  Galaxy |
3 – 6% | 3 – 5% | 3 – 5% | 3 – 5% | 3 – 5% | 3 – 6% | 3 – 5% | 3 – 5% | 3 – 5% | 3 – 5% | Sequencer, Polyphonic | Semi-random chord generation |
| Amalgamated Harmonics |  Generative |
10 – 12% | 10 – 11% | 10 – 11% | 10 – 11% | 10 – 11% | 10 – 12% | 10 – 11% | 10 – 11% | 10 – 11% | 10 – 11% | Noise, Sample and hold, LFO, Random, Clock generator | A toolkit of functions intended to support generative music creation |
| Amalgamated Harmonics |  Imp |
8 – 9% | 7 – 9% | 7 – 9% | 7 – 8% | 7 – 8% | 8 – 9% | 7 – 9% | 7 – 9% | 7 – 8% | 7 – 8% | Clock modulator, Polyphonic | A single channel trigger-to-gate and clock divider module |
| Amalgamated Harmonics |  Imperfect MkII |
13 – 19% | 12 – 19% | 12 – 19% | 12 – 19% | 12 – 18% | 13 – 19% | 12 – 19% | 12 – 19% | 12 – 19% | 12 – 18% | Clock modulator | A multi-channel trigger-to-gate and clock divider module |
| Amalgamated Harmonics |  Progress (deprecated) |
8 – 19% | 8 – 19% | 8 – 19% | 8 – 19% | 8 – 18% | 8 – 19% | 8 – 19% | 8 – 19% | 8 – 19% | 8 – 18% | Sequencer | A chord sequencer |
| Amalgamated Harmonics |  Progress MkII |
11 – 19% | 11 – 18% | 11 – 18% | 11 – 18% | 11 – 18% | 11 – 19% | 11 – 18% | 11 – 18% | 11 – 18% | 11 – 18% | Sequencer, Polyphonic | A chord sequencer |
| Amalgamated Harmonics |  Ruckus |
18% | 18% | 18% | 18% | 18% | 18% | 18% | 18% | 18% | 18% | Sequencer | A trigger sequencer based on summed clock-dividers |
| Amalgamated Harmonics |  SLN |
6 – 7% | 6% | 6% | 6% | 6% | 6 – 7% | 6% | 6% | 6% | 6% | Sample and hold, Noise | Slew-Limited Noise |
| Amalgamated Harmonics |  Scale Quantizer (legacy) |
6 – 12% | 6 – 12% | 6 – 12% | 6 – 11% | 6 – 11% | 6 – 12% | 6 – 12% | 6 – 12% | 6 – 11% | 6 – 11% | Quantizer | Scale-aware quantizer |
| Amalgamated Harmonics |  Scale Quantizer MkII |
4 – 20% | 4 – 20% | 4 – 20% | 4 – 19% | 4 – 19% | 4 – 41% | 4 – 41% | 4 – 41% | 4 – 41% | 4 – 41% | Quantizer, Polyphonic | Scale-aware quantizer |
| Autinn |  Amp |
2 – 4% | 2 – 4% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 5% | 2 – 5% | 2 – 5% | 2 – 5% | 2 – 5% | Voltage-controlled amplifier, Polyphonic, Attenuator | Amplifier |
| Autinn |  Bass |
2 – 20% | 2 – 20% | 2 – 20% | 2 – 20% | 2 – 20% | 2 – 20% | 2 – 20% | 2 – 20% | 2 – 20% | 2 – 20% | Filter, Physical modeling | Bass and Acid synth |
| Autinn |  Mera |
2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 4% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | Voltage-controlled amplifier, Attenuator | Pre-post VCA |
| Autinn |  Conv |
2 – 3% | 2% | 2% | 2% | 2% | 2 – 4% | 2 – 4% | 2 – 3% | 2 – 3% | 2 – 3% | Utility, Polyphonic | Converts to and from uni/bi CV voltages |
| Autinn |  Rebel |
2 – 3% | 2 – 3% | 2% | 2% | 2% | 2 – 3% | 2 – 3% | 2% | 2% | 2% | Utility, Polyphonic | Plays a random selected chord from a root note (does not have to be in tune). Polyphonic outputs. |
| Autinn |  Coil |
2 – 16% | 2 – 16% | 2 – 15% | 2 – 15% | 2 – 15% | 2 – 16% | 2 – 16% | 2 – 15% | 2 – 15% | 2 – 15% | Reverb, Physical modeling, Dual | Spring reverb |
| Autinn |  Deadband |
2 – 6% | 2 – 6% | 2 – 6% | 2 – 6% | 2 – 6% | 2 – 17% | 2 – 17% | 2 – 17% | 2 – 17% | 2 – 17% | Voltage-controlled amplifier, Attenuator, Polyphonic | Constrain low voltages to zero |
| Autinn |  Digi |
2 – 6% | 2 – 5% | 2 – 5% | 2 – 6% | 2 – 6% | 2 – 15% | 2 – 15% | 2 – 15% | 2 – 15% | 2 – 15% | Utility, Digital, Effect, Quantizer, Waveshaper, Polyphonic | Quantizes a signal into discrete steps |
| Autinn |  DC |
3 – 4% | 3 – 4% | 3% | 3% | 3% | 3 – 5% | 3 – 5% | 3 – 5% | 3 – 5% | 3 – 5% | Utility, Polyphonic | Outputs DC component of signal |
| Autinn |  Nap |
2 – 9% | 2 – 9% | 2 – 9% | 2 – 9% | 2 – 9% | 2 – 24% | 2 – 25% | 2 – 25% | 2 – 25% | 2 – 25% | Effect, Distortion, Polyphonic | Taking a nap (Distortion) |
| Autinn |  Flopper |
2 – 12% | 2 – 11% | 2 – 11% | 2 – 11% | 2 – 11% | 2 – 12% | 2 – 11% | 2 – 11% | 2 – 11% | 2 – 11% | Waveshaper | Mix signals in uncommon way |
| Autinn |  Rad |
2 – 9% | 2 – 9% | 2 – 9% | 2 – 9% | 2 – 8% | 2 – 26% | 2 – 26% | 2 – 26% | 2 – 26% | 2 – 26% | Physical modeling, Polyphonic | Geiger counter |
| Autinn |  Jette |
2 – 9% | 2 – 9% | 2 – 8% | 2 – 7% | 2 – 7% | 2 – 18% | 2 – 18% | 2 – 19% | 2 – 19% | 2 – 18% | Oscillator, Polyphonic | Oscillator with harmonics control |
| Autinn |  Stomp |
2 – 6% | 2 – 6% | 2 – 6% | 2 – 5% | 2 – 5% | 2 – 15% | 2 – 15% | 2 – 15% | 2 – 15% | 2 – 15% | Drum, Polyphonic | Kick drum |
| Autinn |  Punch |
3 – 8% | 2 – 7% | 2 – 7% | 2 – 7% | 2 – 7% | 3 – 21% | 2 – 21% | 2 – 21% | 2 – 20% | 2 – 21% | Drum, Polyphonic | Snare drum |
| Autinn |  Fluencerator |
2 – 5% | 2 – 5% | 2 – 5% | 2 – 5% | 2 – 5% | 2 – 16% | 2 – 16% | 2 – 15% | 2 – 15% | 2 – 15% | Sequencer, Random, Polyphonic | Random melody sequencer with special constraints that make it sound more pleasant for the ear |
| Autinn |  6 Channel Mixer |
5 – 11% | 4 – 10% | 4 – 10% | 4 – 10% | 4 – 10% | 5 – 14% | 4 – 13% | 4 – 12% | 4 – 12% | 4 – 12% | Mixer, Equalizer, Polyphonic, Dual | 6 channel mixer with no CV |
| Autinn |  Non |
3 – 41% | 2 – 39% | 2 – 39% | 2 – 38% | 2 – 38% | 3 – 41% | 2 – 39% | 2 – 39% | 2 – 38% | 2 – 38% | Limiter, Dynamics, Dual | Limiter |
| Autinn |  Fil |
2 – 15% | 2 – 16% | 2 – 16% | 2 – 15% | 2 – 15% | 2 – 47% | 2 – 48% | 2 – 48% | 2 – 48% | 2 – 48% | Effect, Distortion, Polyphonic | Filing away at audio (Overdrive) |
| Autinn |  Oxcart |
2 – 6% | 2 – 5% | 2 – 5% | 2 – 5% | 2 – 5% | 2 – 12% | 2 – 11% | 2 – 11% | 2 – 11% | 2 – 11% | Oscillator, Polyphonic | Aggressive oscillator. Best for low/mid frequencies. |
| Autinn |  Flora |
2 – 30% | 2 – 30% | 2 – 30% | 2 – 31% | 2 – 30% | 2 – 30% | 2 – 30% | 2 – 30% | 2 – 31% | 2 – 30% | Filter, Physical modeling, Dual | A 24dB low-pass filter emulating a 4-pole transistor ladder |
| Autinn |  Saw |
2 – 8% | 2 – 8% | 2 – 8% | 2 – 8% | 2 – 8% | 2 – 23% | 2 – 23% | 2 – 23% | 2 – 23% | 2 – 23% | Oscillator, Polyphonic | Oscillator with a sawish sound |
| Autinn |  Axe |
2 – 14% | 2 – 14% | 2 – 14% | 2 – 14% | 2 – 14% | 2 – 46% | 2 – 47% | 2 – 46% | 2 – 46% | 2 – 46% | Oscillator, Polyphonic | Oscillator with an old analog sound |
| Autinn |  Scope |
2 – 7% | 2 – 8% | 2 – 7% | 2 – 7% | 2 – 7% | 2 – 7% | 2 – 8% | 2 – 7% | 2 – 7% | 2 – 7% | Visual, Utility | Oscilloscope with auto-time |
| Autinn |  Sjip |
2 – 16% | 2 – 16% | 2 – 16% | 2 – 15% | 2 – 15% | 2 – 16% | 2 – 16% | 2 – 16% | 2 – 15% | 2 – 15% | Oscillator | Oscillator with rounded waveform |
| Autinn |  Square |
2 – 8% | 2 – 8% | 2 – 8% | 2 – 8% | 2 – 8% | 2 – 22% | 2 – 22% | 2 – 22% | 2 – 22% | 2 – 22% | Oscillator, Polyphonic | Oscillator with a squarish sound |
| Autinn |  Imp |
2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 5% | 2 – 5% | 2 – 5% | 2 – 5% | 2 – 5% | Equalizer, Polyphonic | Simple Triple Band Equalizer |
| Autinn |  Vxy |
2 – 9% | 2 – 8% | 2 – 8% | 2 – 8% | 2 – 8% | 2 – 9% | 2 – 8% | 2 – 8% | 2 – 8% | 2 – 8% | Controller, Utility, Random, Polyphonic | Random x-y generator |
| Autinn |  Vibrato |
2 – 9% | 2 – 7% | 2 – 7% | 2 – 7% | 2 – 6% | 2 – 17% | 2 – 17% | 2 – 17% | 2 – 17% | 2 – 17% | Effect, Delay, Flanger, Polyphonic | Vibrato effect with optional Flanger |
| Autinn |  Zod |
2 – 53% | 2 – 54% | 2 – 54% | 2 – 53% | 2 – 53% | 2 – 53% | 2 – 54% | 2 – 54% | 2 – 53% | 2 – 53% | Compressor, Limiter, Dynamics, Expander, Dual | Dynamic range manipulator with noisegate |
| Bastl |  Kompas |
4 – 8% | 4 – 7% | 4 – 7% | 4 – 7% | 4 – 7% | 4 – 8% | 4 – 7% | 4 – 7% | 4 – 7% | 4 – 7% | Clock modulator, Hardware clone, Random, Sequencer | Kompas is a three-coordinate probabilistic pattern navigator. |
| Befaco |  ABC |
6 – 8% | 5 – 8% | 5 – 8% | 5 – 8% | 5 – 8% | 6 – 9% | 5 – 9% | 5 – 9% | 5 – 9% | 5 – 9% | Ring Modulator, Attenuator, Dual, Hardware clone, Polyphonic | Dual four-quadrant multiplier with VC offset |
| Befaco |  ADSR |
3 – 4% | 3 – 4% | 3 – 4% | 2 – 4% | 2 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 2 – 4% | 2 – 4% | Envelope generator, Hardware clone | ADSR envelope generator with gate output on each stage, plus variable shape |
| Befaco |  Atte |
4% | 4% | 4% | 4% | 4% | 4% | 4% | 4% | 4% | 4% | Attenuator, Hardware clone, Polyphonic | Quad Attenuator/Inverter, Splitter, and Offset Generator |
| Befaco |  AxBC |
5 – 6% | 5 – 6% | 5% | 5% | 5% | 5 – 6% | 5 – 6% | 5% | 5% | 5% | Ring Modulator, Attenuator, Dual, Hardware clone, Polyphonic | Voltage-Controlled Voltage Processor |
| Befaco |  Bandit |
11% | 11% | 11% | 10 – 11% | 10 – 11% | 11% | 11% | 11% | 10 – 11% | 10 – 11% | Equalizer, Filter, Hardware clone, Mixer, Polyphonic, Utility | Bandit is a spectral processing playground. |
| Befaco |  Burst |
3 – 5% | 3 – 5% | 3 – 5% | 3 – 5% | 3 – 5% | 3 – 5% | 3 – 5% | 3 – 5% | 3 – 5% | 3 – 5% | Clock generator, Clock modulator, Hardware clone | Trigger processor and generator, designed to add an organic chain of events |
| Befaco |  ChoppingKinky |
3 – 23% | 3 – 24% | 3 – 24% | 3 – 24% | 3 – 23% | 3 – 24% | 3 – 24% | 3 – 24% | 3 – 24% | 3 – 24% | Dual, Hardware clone, Voltage-controlled amplifier, Waveshaper | Voltage controllable, dual channel wavefolder |
| Befaco |  DualAtenuverter |
3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | Attenuator, Dual, Hardware clone, Polyphonic | Attenuates, inverts, and applies offset to a signal |
| Befaco |  EvenVCO |
17 – 98% | 16 – 100% | 16 – 100% | 16 – 101% | 17 – 100% | 17 – 98% | 16 – 100% | 16 – 100% | 16 – 101% | 17 – 100% | VCO, Hardware clone, Polyphonic | Even VCO is an oscillator including even-harmonic waveform |
| Befaco |  HexmixVCA |
6 – 9% | 6 – 9% | 6 – 8% | 6 – 8% | 6 – 8% | 6 – 9% | 6 – 9% | 6 – 8% | 6 – 8% | 6 – 8% | Mixer, Hardware clone, Polyphonic, VCA | Six channel VCA with response curve range from logarithmic to linear and to exponential |
| Befaco |  Kickall |
11 – 15% | 11 – 14% | 11 – 14% | 11 – 14% | 11 – 14% | 11 – 15% | 11 – 14% | 11 – 14% | 11 – 14% | 11 – 14% | Drum, Hardware clone, Synth voice | Bassdrum module, with pitch and volume envelopes |
| Befaco |  Mixer |
3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | Mixer, Hardware clone, Polyphonic | Four-channel mixer for audio or CV |
| Befaco |  Mixer2 |
3% | 3% | 3% | 2 – 3% | 2 – 3% | 3 – 4% | 3 – 4% | 3% | 2 – 3% | 2 – 3% | Hardware clone, Mixer, Polyphonic | Utilitarian audio and CV mixer |
| Befaco |  Morphader |
13 – 14% | 14% | 13 – 14% | 13 – 14% | 13 – 14% | 13 – 14% | 14% | 13 – 14% | 13 – 14% | 13 – 14% | Controller, Hardware clone, Mixer, Polyphonic, Quad | Multichannel CV/Audio crossfader |
| Befaco |  MotionMTR |
3 – 4% | 3 – 4% | 3 – 4% | 3% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3% | 3 – 4% | Attenuator, Hardware clone, Mixer, Visual | CV and audio utility / realtime visualizer |
| Befaco |  MuDi |
3 – 5% | 2 – 5% | 2 – 5% | 2 – 5% | 2 – 5% | 3 – 6% | 2 – 6% | 2 – 6% | 2 – 6% | 2 – 6% | Clock generator, Clock modulator, Hardware clone, Polyphonic | Clock Multiple, Conditioner, and Divider in a compact 2HP format |
| Befaco |  Muxlicer |
4 – 6% | 4 – 6% | 4 – 6% | 4 – 5% | 4 – 5% | 4 – 6% | 4 – 6% | 4 – 6% | 4 – 5% | 4 – 5% | Clock generator, Hardware clone, Polyphonic, Sequencer, Switch | Muxlicer is a VC adressable sequential switch and sequencer |
| Befaco |  NoisePlethora |
11 – 41% | 10 – 35% | 10 – 32% | 10 – 31% | 10 – 30% | 11 – 42% | 10 – 35% | 10 – 32% | 10 – 31% | 10 – 30% | Dual, Filter, Hardware clone, Noise | Noise Plethora is a multitimbral noise monster |
| Befaco |  Octaves |
3 – 94% | 2 – 95% | 2 – 95% | 2 – 95% | 2 – 95% | 3 – 94% | 2 – 95% | 2 – 95% | 2 – 95% | 2 – 95% | Hardware clone, Oscillator, Polyphonic | A harsh and funky take of an additive Oscillator. |
| Befaco |  Percall |
6 – 12% | 6 – 12% | 6 – 12% | 5 – 12% | 5 – 11% | 6 – 12% | 6 – 12% | 6 – 12% | 5 – 12% | 5 – 11% | Envelope generator, Mixer, Polyphonic, Hardware clone, Quad | Percussive Envelope Generator |
| Befaco |  PonyVCO |
21 – 23% | 22 – 23% | 22% | 22% | 22% | 21 – 23% | 22 – 23% | 22% | 22% | 22% | Hardware clone, Low-frequency oscillator, Oscillator, Polyphonic, Waveshaper | Pony VCO is a compact Thru-Zero (TZFM) oscillator with wavefolder and VCA |
| Befaco |  Rampage |
16 – 18% | 17 – 19% | 16 – 19% | 17 – 19% | 16 – 19% | 16 – 18% | 17 – 19% | 16 – 19% | 17 – 19% | 16 – 19% | Function Generator, Logic, Slew Limiter, Envelope Follower, Dual, Hardware clone, Polyphonic | Dual ramp generator |
| Befaco |  STMix |
6 – 7% | 6 – 7% | 6 – 7% | 6 – 7% | 6 – 7% | 6 – 7% | 6 – 7% | 6 – 7% | 6 – 7% | 6 – 7% | Hardware clone, Mixer, Polyphonic | A compact 4 channel stereo mixer with an auxiliary input |
| Befaco |  SamplingModulator |
5 – 6% | 5% | 5% | 4 – 5% | 5% | 5 – 6% | 5 – 6% | 5 – 6% | 4 – 5% | 5% | Clock generator, Hardware clone, Oscillator, Sample and hold | Multi-function module that lies somewhere between a VCO, a Sample & Hold, and an 8 step trigger sequencer |
| Befaco |  Slew |
7 – 9% | 7 – 9% | 7 – 9% | 7 – 9% | 7 – 8% | 7 – 9% | 7 – 9% | 7 – 9% | 7 – 9% | 7 – 8% | Slew Limiter, Envelope Follower, Hardware clone, Polyphonic | Voltage-controlled lag processor and slope detector |
| Befaco |  SlewLimiter |
3 – 5% | 3 – 5% | 3 – 5% | 3 – 5% | 3 – 5% | 3 – 8% | 3 – 5% | 3 – 5% | 3 – 5% | 3 – 6% | Slew Limiter, Envelope Follower, Hardware clone, Polyphonic | Voltage controlled slew limiter, AKA lag processor |
| Befaco |  SpringReverb |
697 – 698% | 352 – 355% | 181 – 182% | 95 – 96% | 53% | 697 – 698% | 352 – 355% | 181 – 182% | 95 – 96% | 53% | Reverb, Hardware clone | Spring reverb tank driver |
| Befaco |  StereoStrip |
3 – 15% | 4 – 14% | 4 – 14% | 3 – 14% | 4 – 13% | 3 – 15% | 4 – 14% | 4 – 14% | 3 – 14% | 4 – 13% | Equalizer, Hardware clone, Mixer, Limiter, Panning, Polyphonic | Stereo VCA, panning, and EQ |
| Befaco |  Voltio |
2 – 4% | 2 – 4% | 2 – 4% | 2 – 3% | 2 – 3% | 2 – 4% | 2 – 4% | 2 – 4% | 2 – 3% | 2 – 3% | Hardware clone, Polyphonic, Utility | An accurate voltage source and precision adder. |
| Bidoo |  ACnE |
39 – 49% | 39 – 49% | 39 – 50% | 39 – 50% | 40 – 50% | 39 – 49% | 39 – 50% | 39 – 50% | 39 – 50% | 40 – 50% | Mixer | Mixer with snaphots |
| Bidoo |  bAFIs |
20 – 24% | 20 – 24% | 20 – 24% | 20 – 24% | 20 – 24% | 20 – 24% | 20 – 24% | 20 – 24% | 20 – 24% | 20 – 24% | Effect, VCF, Distortion | Multiband distortion |
| Bidoo |  BISTROT |
3 – 5% | 3 – 5% | 3 – 5% | 3 – 5% | 3 – 5% | 3 – 5% | 3 – 5% | 3 – 5% | 3 – 5% | 3 – 5% | Effect, Distortion | Bit toy |
| Bidoo |  BanCau |
8 – 9% | 8 – 9% | 8 – 9% | 8 – 9% | 8 – 9% | 8 – 9% | 8 – 9% | 8 – 9% | 8 – 9% | 8 – 9% | Envelope generator, Oscillator, VCO, LFO, Waveshaper | Envelope tool |
| Bidoo |  ChUTE |
2 – 3% | 2% | 2% | 2% | 2% | 2 – 3% | 2% | 2% | 2% | 2% | Sequencer | Space/Strange trigger based on the free fall and bouncing an object. You can change the drop altitude between 1cm and 3m |
| Bidoo |  DIKTAT |
5 – 7% | 5 – 7% | 5 – 7% | 5 – 7% | 5 – 7% | 5 – 16% | 5 – 16% | 5 – 16% | 5 – 15% | 5 – 15% | Quantizer | Authoritarian quantizer |
| Bidoo |  DilEMO |
2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | Logic | Logic |
| Bidoo |  fREIN |
3 – 5% | 3 – 5% | 3 – 5% | 3 – 4% | 3 – 4% | 3 – 5% | 3 – 5% | 3 – 5% | 3 – 4% | 3 – 4% | Effect | Break |
| Bidoo |  ForK |
23 – 24% | 24% | 23 – 24% | 23 – 24% | 23 – 24% | 23 – 24% | 24% | 23 – 24% | 23 – 24% | 23 – 24% | Oscillator | Formant oscillator |
| Bidoo |  HCTIP |
354 – 367% | 178 – 184% | 90 – 95% | 47 – 49% | 25 – 26% | 354 – 367% | 178 – 185% | 90 – 95% | 47 – 49% | 25 – 26% | Effect | Pitch shifter |
| Bidoo |  HUITre |
3% | 3% | 3% | 3% | 3% | 3% | 3% | 3% | 3% | 3% | Controller | Pattern launcher |
| Bidoo |  LoURdE |
4% | 4% | 4% | 4% | 4% | 4% | 4% | 4% | 4% | 4% | Logic, Effect | Neural comparator & gate |
| Bidoo |  MS |
2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | Effect, Utility | Mid/Side Decoder/Encoder |
| Bidoo |  REI |
349 – 405% | 185 – 215% | 104 – 120% | 64 – 73% | 43 – 49% | 349 – 405% | 185 – 216% | 104 – 120% | 64 – 73% | 43 – 49% | Reverb, Effect | Reverb |
| Bidoo |  Σ multiprise :) |
2 – 3% | 2% | 2% | 2% | 2% | 2 – 3% | 2% | 2% | 2% | 2% | Multiple | Patch |
| Bidoo |  SPORE |
24 – 49% | 17 – 30% | 13 – 20% | 11 – 15% | 10 – 13% | 24 – 50% | 17 – 30% | 13 – 20% | 11 – 15% | 10 – 13% | Effect | Pitch shifter |
| Bidoo |  TiARE |
16 – 17% | 14 – 17% | 13 – 17% | 13 – 17% | 13 – 17% | 16 – 20% | 14 – 20% | 13 – 19% | 13 – 19% | 13 – 19% | Oscillator, LFO | Phase distortion oscillator |
| Bidoo |  baR |
19 – 23% | 19 – 23% | 19 – 23% | 19 – 23% | 18 – 23% | 19 – 23% | 19 – 23% | 19 – 23% | 19 – 23% | 18 – 23% | Dynamics, Effect, Compressor | Compressor |
| Bidoo |  bordL |
13 – 18% | 13 – 17% | 13 – 17% | 13 – 16% | 13 – 16% | 13 – 18% | 13 – 17% | 13 – 17% | 13 – 16% | 13 – 16% | Sequencer | Sequencer |
| Bidoo |  cANARd |
3 – 11% | 3 – 8% | 4 – 7% | 3 – 7% | 3 – 7% | 3 – 11% | 3 – 8% | 4 – 7% | 3 – 7% | 3 – 7% | Sampler | Sampler with slice tools & transients detection |
| Bidoo |  dFUZE |
24 – 26% | 24 – 26% | 24 – 26% | 24 – 25% | 24 – 25% | 24 – 26% | 24 – 26% | 24 – 26% | 24 – 25% | 24 – 25% | Reverb, Effect | Reverb |
| Bidoo |  dUKe |
5% | 5% | 5% | 5% | 5% | 5 – 6% | 5% | 5% | 5% | 5% | Controller | Controller |
| Bidoo |  eDsaroS |
9% | 9% | 8 – 9% | 9% | 9% | 9% | 9% | 8 – 9% | 9% | 9% | Sampler | Sample player base on Laurent De Soras resampler |
| Bidoo |  lATe |
2 – 3% | 2% | 2% | 2% | 2% | 2 – 3% | 2% | 2% | 2% | 2% | Logic, Sequencer, Clock modulator | Clock Modulator, Takes a clock input and applies a delay on even ticks to create swing. Reset sets the next tick for the incoming clock to odd. |
| Bidoo |  lIMbO |
9% | 9% | 9% | 8 – 9% | 9% | 9% | 9% | 9% | 8 – 9% | 9% | VCF, Effect | 4th order stereo LP ladder filter. Gain boosts the signal to compensate for global signal energy lose at high resonance. When non linear is selected gain is applied to each stage |
| Bidoo |  lambda |
2 – 4% | 2 – 4% | 2% | 2% | 2% | 2 – 4% | 2 – 4% | 2% | 2% | 2% | Logic, Sample and hold, S&H, Sample & hold | Logic |
| Bidoo |  mINIBar |
13 – 14% | 14% | 14% | 13 – 14% | 12 – 14% | 13 – 14% | 14% | 14% | 13 – 14% | 12 – 14% | Dynamics, Effect, Compressor | Compressor |
| Bidoo |  pErCO |
6% | 6% | 6% | 6% | 6% | 6% | 6% | 6% | 6% | 6% | VCF, Effect | 3 bands filter |
| Bidoo |  rabBIT |
8 – 9% | 8 – 9% | 8 – 9% | 8 – 9% | 8 – 9% | 8 – 9% | 8 – 9% | 8 – 9% | 8 – 9% | 8 – 9% | Effect, Distortion | Bit toy |
| Bidoo |  tOCAnTe |
9 – 10% | 10% | 9 – 10% | 10% | 9 – 10% | 9 – 11% | 10% | 9 – 10% | 10% | 9 – 10% | Clock | Clock |
| Bidoo |  ziNC |
43 – 47% | 44 – 48% | 44 – 48% | 44 – 48% | 44 – 48% | 43 – 47% | 44 – 48% | 44 – 48% | 44 – 48% | 44 – 48% | Effect, Vocoder | Vocoder |
| BlackNoiseModular |  Cosmos |
21 – 25% | 21 – 25% | 21 – 24% | 21 – 25% | 21 – 25% | 19 – 25% | 19 – 25% | 19 – 24% | 19 – 25% | 20 – 25% | Hardware clone, Logic, Multiple, Polyphonic | Cosmos is a new kind of module that will help you to creating complex modulation, sounds, patterns with ease and will lead you to new sounds territories. |
| BlackNoiseModular |  GomaII |
8 – 9% | 8 – 9% | 8 – 9% | 8 – 9% | 7 – 9% | 5 – 9% | 5 – 9% | 5 – 9% | 5 – 9% | 5 – 9% | Attenuator, Hardware clone, Mixer, Polyphonic | GOMA II is a new take on the classic attenuverter/mixer concept. It stands for Generator, Offset, Mixer, Attenuverter. |
| BlackNoiseModular |  SlewLFO |
6 – 8% | 6 – 8% | 6 – 8% | 6 – 7% | 6 – 7% | 6 – 18% | 6 – 18% | 6 – 18% | 6 – 18% | 6 – 18% | Hardware clone, Low-frequency oscillator, Slew limiter, Polyphonic | Slew, LFO, and much more |
| Bogaudio |  AD |
3 – 5% | 3 – 5% | 3 – 5% | 3 – 5% | 2 – 5% | 3 – 12% | 3 – 12% | 3 – 12% | 3 – 12% | 2 – 12% | Envelope generator, Polyphonic | Attack/decay envelope generator |
| Bogaudio |  ADSR |
3 – 5% | 3 – 5% | 3 – 5% | 3 – 5% | 2 – 5% | 3 – 11% | 3 – 11% | 3 – 11% | 3 – 10% | 2 – 10% | Envelope generator, Polyphonic | ADSR envelope generator |
| Bogaudio |  AMRM |
2 – 5% | 2 – 5% | 2 – 5% | 2 – 5% | 2 – 5% | 2 – 12% | 2 – 12% | 2 – 12% | 2 – 12% | 2 – 12% | Ring modulator, Effect, Polyphonic | Variable ring/amplitude modulator and rectifier |
| Bogaudio |  ASR |
3 – 5% | 3 – 6% | 2 – 5% | 3 – 5% | 2 – 5% | 3 – 13% | 3 – 13% | 2 – 13% | 3 – 13% | 2 – 13% | Envelope generator, Polyphonic | Attack/sustain/release envelope generator |
| Bogaudio |  Additator |
3 – 31% | 2 – 28% | 2 – 26% | 2 – 26% | 2 – 25% | 3 – 150% | 2 – 129% | 2 – 126% | 2 – 122% | 2 – 121% | Oscillator, Polyphonic | Additive oscillator |
| Bogaudio |  AddrSeq |
8 – 9% | 7 – 8% | 8% | 8% | 8% | 8 – 20% | 7 – 20% | 8 – 20% | 8 – 20% | 8 – 20% | Sequencer, Polyphonic | Voltage-addressable 8-step sequencer |
| Bogaudio |  Arp |
3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 6% | 3 – 6% | 3 – 6% | 3 – 6% | 3 – 6% | Arpeggiator, Polyphonic | Polyphonic-input arpeggiator |
| Bogaudio |  Assign |
3 – 4% | 3% | 3% | 3% | 3% | 3 – 6% | 3 – 5% | 3 – 5% | 3 – 5% | 3 – 5% | Polyphonic | Polyphonic voice (re)assigner |
| Bogaudio |  Bool |
3 – 4% | 3% | 3% | 3% | 3% | 3 – 5% | 3 – 5% | 3 – 5% | 3 – 5% | 3 – 5% | Logic, Polyphonic | Boolean logic |
| Bogaudio |  CVD |
3 – 28% | 3 – 15% | 3 – 9% | 3 – 6% | 3 – 4% | 3 – 3407% | 3 – 1704% | 3 – 855% | 3 – 431% | 3 – 220% | Delay, Polyphonic | Simple delay designed for triggers and other CVs |
| Bogaudio |  Chirp |
2 – 7% | 2 – 6% | 2 – 6% | 2 – 6% | 2 – 6% | 2 – 16% | 2 – 15% | 2 – 16% | 2 – 15% | 2 – 15% | Oscillator, Polyphonic | Swept-sine oscillator |
| Bogaudio |  Clpr |
2 – 6% | 2 – 6% | 2 – 6% | 2 – 5% | 2 – 5% | 2 – 15% | 2 – 15% | 2 – 15% | 2 – 15% | 2 – 15% | Dynamics, Limiter, Distortion, Polyphonic | Hard clipper and distortion |
| Bogaudio |  Cmp |
2 – 6% | 2 – 6% | 2 – 5% | 2 – 5% | 2 – 5% | 2 – 16% | 2 – 15% | 2 – 15% | 2 – 15% | 2 – 15% | Logic, Polyphonic | Window comparator |
| Bogaudio |  CmpDist |
3 – 4% | 2 – 4% | 2 – 3% | 2 – 3% | 2 – 3% | 3 – 7% | 2 – 7% | 2 – 6% | 2 – 6% | 2 – 6% | Distortion, Effect, Polyphonic | Comparator-based distortion |
| Bogaudio |  DADSRH |
4 – 8% | 4 – 8% | 4 – 8% | 4 – 8% | 4 – 7% | 4 – 22% | 4 – 22% | 4 – 23% | 4 – 23% | 4 – 23% | Envelope generator, Polyphonic | Advanced envelope generator |
| Bogaudio |  DADSRHPlus |
5 – 9% | 5 – 10% | 5 – 9% | 5 – 9% | 5 – 9% | 5 – 30% | 5 – 30% | 5 – 30% | 5 – 30% | 5 – 30% | Envelope generator, Polyphonic | Advanced envelope generator with additional CV |
| Bogaudio |  DGate |
3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 9% | 3 – 8% | 3 – 8% | 3 – 8% | 3 – 8% | Polyphonic | Trigger-to-gate converter with delay |
| Bogaudio |  Detune |
2 – 7% | 2 – 7% | 2 – 7% | 2 – 7% | 2 – 7% | 2 – 22% | 2 – 23% | 2 – 21% | 2 – 18% | 2 – 16% | Tuner, Polyphonic | Pitch CV processor for detuning oscillator pairs |
| Bogaudio |  EQ |
2 – 5% | 2 – 5% | 2 – 5% | 2 – 5% | 2 – 5% | 2 – 14% | 2 – 13% | 2 – 13% | 2 – 12% | 2 – 13% | Equalizer, Polyphonic | 3-band equalizer |
| Bogaudio |  EQS |
2 – 8% | 2 – 7% | 2 – 7% | 2 – 7% | 2 – 7% | 2 – 24% | 2 – 22% | 2 – 21% | 2 – 22% | 2 – 22% | Equalizer, Polyphonic | Stereo 3-band equalizer |
| Bogaudio |  Edge |
3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 7% | 3 – 7% | 3 – 7% | 3 – 7% | 3 – 7% | Logic, Polyphonic | Edge detector, gate-to-trigger, comparator |
| Bogaudio |  EightFO |
2 – 38% | 2 – 38% | 2 – 38% | 2 – 38% | 2 – 36% | 2 – 150% | 2 – 90% | 2 – 89% | 2 – 80% | 2 – 77% | LFO, Random, Polyphonic | LFO with outputs at 8 different phases |
| Bogaudio |  EightOne |
8 – 9% | 8 – 9% | 7 – 9% | 7 – 8% | 7 – 8% | 8 – 20% | 8 – 20% | 7 – 20% | 7 – 20% | 7 – 20% | Switch, Polyphonic | 8-channel demultiplexer & sequential switch |
| Bogaudio |  FFB |
3 – 28% | 2 – 25% | 2 – 25% | 2 – 24% | 2 – 24% | 3 – 98% | 2 – 90% | 2 – 91% | 2 – 89% | 2 – 87% | Filter, Polyphonic | Fixed filter bank |
| Bogaudio |  FMOp |
3 – 23% | 2 – 21% | 2 – 19% | 2 – 19% | 2 – 19% | 3 – 55% | 2 – 52% | 2 – 47% | 2 – 46% | 2 – 46% | Oscillator, Synth voice, Polyphonic | FM operator / oscillator / synth voice |
| Bogaudio |  FlipFlop |
4% | 4% | 4% | 4% | 4% | 4 – 7% | 4 – 7% | 4 – 7% | 4 – 7% | 4 – 7% | Logic, Dual, Polyphonic | Dual flipflop |
| Bogaudio |  Follow |
2 – 4% | 2 – 4% | 2 – 4% | 2 – 3% | 2 – 3% | 2 – 7% | 2 – 7% | 2 – 7% | 2 – 7% | 2 – 7% | Envelope follower, Polyphonic | Envelope follower |
| Bogaudio |  FourFO |
3 – 13% | 2 – 13% | 2 – 12% | 2 – 11% | 2 – 11% | 3 – 125% | 2 – 68% | 2 – 61% | 2 – 53% | 2 – 42% | LFO, Random, Polyphonic | Quadrature LFO |
| Bogaudio |  FourMan |
3 – 4% | 3% | 3% | 3 – 4% | 3 – 4% | 3 – 4% | 3% | 3% | 3 – 4% | 3 – 4% | Controller, Quad | Quad button-controlled gates / triggers |
| Bogaudio |  Inv |
3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 7% | 3 – 7% | 3 – 7% | 3 – 7% | 3 – 7% | Logic, Dual, Polyphonic | Dual signal inverter |
| Bogaudio |  LFO |
2 – 34% | 2 – 35% | 2 – 35% | 2 – 35% | 2 – 35% | 2 – 148% | 2 – 127% | 2 – 127% | 2 – 127% | 2 – 127% | LFO, Random, Polyphonic | Low frequency oscillator |
| Bogaudio |  LLFO |
3 – 6% | 2 – 5% | 2 – 5% | 2 – 5% | 2 – 5% | 3 – 12% | 2 – 11% | 2 – 11% | 2 – 11% | 2 – 11% | LFO, Random, Polyphonic | Low frequency oscillator |
| Bogaudio |  LLPG |
2 – 15% | 2 – 15% | 2 – 15% | 2 – 14% | 2 – 13% | 2 – 51% | 2 – 51% | 2 – 49% | 2 – 40% | 2 – 40% | Low-pass gate, Polyphonic | Low-pass gate |
| Bogaudio |  LPG |
2 – 15% | 2 – 15% | 2 – 14% | 2 – 14% | 2 – 14% | 2 – 48% | 2 – 48% | 2 – 48% | 2 – 47% | 2 – 47% | Low-pass gate, Polyphonic | Low-pass gate |
| Bogaudio |  LVCF |
3 – 5% | 2 – 5% | 2 – 5% | 2 – 4% | 2 – 4% | 3 – 12% | 2 – 9% | 2 – 9% | 2 – 9% | 2 – 9% | Filter, Polyphonic | Multimode filter |
| Bogaudio |  LVCO |
2 – 15% | 2 – 13% | 2 – 13% | 2 – 13% | 2 – 13% | 2 – 33% | 2 – 31% | 2 – 31% | 2 – 31% | 2 – 31% | Oscillator, Polyphonic | Oscillator |
| Bogaudio |  Lgsw |
3 – 4% | 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 10% | 4 – 10% | 3 – 10% | 3 – 10% | 3 – 10% | Switch, Logic, Polyphonic | 2-way signal router with logic |
| Bogaudio |  Lmtr |
2 – 6% | 2 – 6% | 2 – 6% | 2 – 6% | 2 – 6% | 2 – 28% | 2 – 17% | 2 – 17% | 2 – 17% | 2 – 17% | Limiter, Dynamics, Polyphonic | Limiter |
| Bogaudio |  Manual |
3% | 3% | 3% | 3% | 3% | 3% | 3% | 3% | 3% | 3% | Controller | Button controlled gates / triggers |
| Bogaudio |  Matrix18 |
3 – 10% | 3 – 10% | 4 – 10% | 3 – 10% | 3 – 10% | 3 – 32% | 3 – 33% | 4 – 33% | 3 – 33% | 3 – 33% | Switch, Polyphonic | 8-way signal router with attenuverters |
| Bogaudio |  Matrix44 |
4 – 9% | 4 – 9% | 4 – 9% | 4 – 9% | 4 – 9% | 4 – 28% | 4 – 28% | 4 – 28% | 4 – 28% | 4 – 28% | Mixer, Polyphonic | 4x4 matrix mixer |
| Bogaudio |  Matrix81 |
3 – 6% | 3 – 6% | 3 – 6% | 3 – 6% | 3 – 6% | 3 – 17% | 3 – 17% | 3 – 17% | 3 – 17% | 3 – 17% | Mixer, Polyphonic | 8-channel mixer |
| Bogaudio |  Matrix88 |
5 – 20% | 4 – 19% | 4 – 19% | 4 – 19% | 4 – 19% | 5 – 67% | 4 – 68% | 4 – 68% | 4 – 68% | 4 – 68% | Mixer, Polyphonic | 8x8 matrix mixer |
| Bogaudio |  MegaGate |
4 – 44% | 4 – 44% | 3 – 45% | 3 – 44% | 3 – 44% | 4 – 167% | 4 – 169% | 3 – 169% | 3 – 166% | 3 – 166% | Low-pass gate, Dual, Polyphonic | Low- and high-pass gate |
| Bogaudio |  Mix1 |
2 – 7% | 2 – 8% | 2 – 6% | 2 – 6% | 2 – 6% | 2 – 30% | 2 – 19% | 2 – 17% | 2 – 17% | 2 – 16% | VCA, Polyphonic | Fader/amplifier with CV-controllable mute |
| Bogaudio |  Mix2 |
3 – 9% | 2 – 9% | 2 – 9% | 2 – 9% | 2 – 9% | 3 – 59% | 2 – 33% | 2 – 32% | 2 – 30% | 2 – 29% | VCA, Polyphonic | Stereo fader/amplifier with CV-controllable mute |
| Bogaudio |  Mix4 |
4 – 23% | 3 – 23% | 3 – 23% | 3 – 23% | 3 – 22% | 4 – 23% | 3 – 23% | 3 – 23% | 3 – 23% | 3 – 23% | Mixer, Panning | 4-channel mixer and panner |
| Bogaudio |  Mix8 |
4 – 37% | 4 – 38% | 4 – 38% | 3 – 38% | 3 – 38% | 4 – 38% | 4 – 39% | 4 – 40% | 3 – 39% | 3 – 39% | Mixer, Panning | 8-channel mixer and panner |
| Bogaudio |  Mono |
6 – 7% | 6 – 7% | 6 – 7% | 6 – 7% | 6 – 7% | 6 – 9% | 6 – 9% | 6 – 8% | 6 – 8% | 6 – 7% | Polyphonic | Polyphonic-to-monophonic converter with onboard compressor |
| Bogaudio |  Mult |
3% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | 3 – 4% | 2 – 4% | 2 – 4% | 2 – 4% | 2 – 4% | Multiple, Polyphonic | 1:6 or dual 1:3 multiple/splitter |
| Bogaudio |  Mumix |
4 – 9% | 4 – 9% | 4 – 9% | 4 – 8% | 4 – 7% | 4 – 14% | 4 – 14% | 4 – 14% | 4 – 12% | 4 – 11% | Mixer, Polyphonic | 8-input unity mixer with mutes |
| Bogaudio |  Mute8 |
13 – 17% | 14 – 17% | 13 – 17% | 13 – 17% | 11 – 15% | 13 – 40% | 14 – 40% | 13 – 40% | 13 – 40% | 11 – 34% | Polyphonic | 8 independent mutes with CV control |
| Bogaudio |  Noise |
4 – 25% | 3 – 22% | 3 – 21% | 3 – 21% | 3 – 21% | 4 – 26% | 3 – 22% | 3 – 22% | 3 – 21% | 3 – 21% | Noise, Random, Polyphonic | Noise source |
| Bogaudio |  Nsgt |
2 – 7% | 2 – 6% | 2 – 6% | 2 – 6% | 2 – 5% | 2 – 31% | 2 – 18% | 2 – 17% | 2 – 16% | 2 – 16% | Dynamics, Polyphonic | Noise gate |
| Bogaudio |  Offset |
3 – 5% | 3 – 5% | 3 – 5% | 3 – 5% | 3 – 5% | 3 – 12% | 3 – 12% | 3 – 12% | 3 – 12% | 3 – 12% | Attenuator, Polyphonic | CV offset and scaler |
| Bogaudio |  OneEight |
8 – 9% | 8 – 9% | 8 – 9% | 8 – 9% | 8 – 9% | 8 – 23% | 8 – 23% | 8 – 23% | 8 – 23% | 8 – 23% | Switch, Polyphonic | 8-channel multiplexer & sequential switch |
| Bogaudio |  PEQ |
3 – 14% | 2 – 12% | 2 – 11% | 2 – 10% | 2 – 10% | 3 – 99% | 2 – 56% | 2 – 43% | 2 – 38% | 2 – 35% | Filter, Polyphonic | 3-channel parametric equalizer |
| Bogaudio |  PEQ14 |
5 – 49% | 5 – 44% | 5 – 41% | 5 – 40% | 5 – 40% | 5 – 445% | 5 – 242% | 5 – 196% | 5 – 177% | 5 – 168% | Filter, Vocoder, Polyphonic | 14-channel parametric equalizer / filter bank |
| Bogaudio |  PEQ6 |
4 – 23% | 4 – 21% | 4 – 19% | 4 – 18% | 3 – 18% | 4 – 193% | 4 – 105% | 4 – 83% | 4 – 73% | 3 – 68% | Filter, Polyphonic | 6-channel parametric equalizer / filter bank |
| Bogaudio |  Pan |
2 – 7% | 2 – 7% | 2 – 7% | 2 – 7% | 2 – 7% | 2 – 18% | 2 – 18% | 2 – 18% | 2 – 18% | 2 – 18% | Panning, Dual, Polyphonic | Dual stereo panner |
| Bogaudio |  Pgmr |
8 – 9% | 8 – 9% | 8 – 9% | 8 – 9% | 8 – 9% | 8 – 25% | 8 – 26% | 8 – 25% | 8 – 26% | 8 – 25% | Sequencer, Polyphonic | 4-step programmer and sequencer |
| Bogaudio |  PolyCon16 |
4 – 6% | 3 – 6% | 3 – 6% | 3 – 6% | 3 – 6% | 4 – 6% | 3 – 6% | 3 – 6% | 3 – 6% | 3 – 6% | Polyphonic | Polyphonic per-channel constant voltages |
| Bogaudio |  PolyCon8 |
3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | Polyphonic | Polyphonic per-channel constant voltages |
| Bogaudio |  PolyMult |
3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | Polyphonic | Monophonic-to-polyphonic multiple |
| Bogaudio |  PolyOff16 |
5 – 12% | 6 – 12% | 5 – 12% | 5 – 12% | 5 – 12% | 5 – 12% | 6 – 13% | 5 – 13% | 5 – 13% | 5 – 13% | Polyphonic | Polyphonic per-channel offset and scale |
| Bogaudio |  PolyOff8 |
5 – 9% | 5 – 9% | 5 – 9% | 5 – 9% | 5 – 9% | 5 – 12% | 5 – 13% | 5 – 12% | 5 – 12% | 5 – 13% | Polyphonic | Polyphonic per-channel offset and scale |
| Bogaudio |  Pressor |
4 – 6% | 4 – 6% | 4 – 6% | 4 – 6% | 4 – 5% | 4 – 17% | 4 – 16% | 4 – 15% | 4 – 15% | 4 – 15% | Compressor, Dynamics, Polyphonic | Stereo compressor and noise gate |
| Bogaudio |  Pulse |
2 – 26% | 2 – 26% | 2 – 26% | 2 – 26% | 2 – 26% | 2 – 36% | 2 – 36% | 2 – 36% | 2 – 36% | 2 – 35% | Oscillator, Polyphonic | Square/pulse oscillator |
| Bogaudio |  RGate |
2 – 4% | 2 – 4% | 2 – 4% | 2 – 3% | 2 – 3% | 2 – 8% | 2 – 7% | 2 – 7% | 2 – 7% | 2 – 7% | Clock modulator, Polyphonic | Clock-relative gate generator & clock divider/multiplier |
| Bogaudio |  Reftone |
3 – 4% | 3 – 4% | 2 – 4% | 2 – 4% | 2 – 3% | 3 – 4% | 3 – 4% | 2 – 4% | 2 – 4% | 2 – 3% | Tuner | Precision pitch CV generator |
| Bogaudio |  SampleHold |
4% | 4% | 4% | 4% | 4% | 4 – 7% | 4 – 7% | 4 – 7% | 4 – 7% | 4 – 7% | Sample and hold, Dual, Polyphonic | Dual sample (or track) and hold |
| Bogaudio |  Shaper |
6 – 7% | 6 – 7% | 6 – 7% | 6 – 7% | 6 – 7% | 6 – 21% | 6 – 21% | 6 – 21% | 6 – 21% | 6 – 21% | Envelope generator, VCA, Polyphonic | Retro-inspired envelope generator and amplifier |
| Bogaudio |  ShaperPlus |
6 – 10% | 6 – 10% | 6 – 10% | 6 – 10% | 6 – 10% | 6 – 32% | 6 – 33% | 6 – 33% | 6 – 33% | 6 – 33% | Envelope generator, VCA, Polyphonic | Retro-inspired envelope generator and amplifier with additional CV |
| Bogaudio |  Sine |
2 – 10% | 2 – 10% | 2 – 10% | 2 – 10% | 2 – 10% | 2 – 32% | 2 – 32% | 2 – 32% | 2 – 32% | 2 – 32% | Oscillator, Polyphonic | Sine oscillator with phase offset |
| Bogaudio |  Slew |
2 – 8% | 2 – 7% | 2 – 7% | 2 – 7% | 2 – 7% | 2 – 18% | 2 – 18% | 2 – 18% | 2 – 18% | 2 – 16% | Slew limiter, Polyphonic | Slew limiter / lag generator / glide |
| Bogaudio |  Stack |
2 – 8% | 2 – 7% | 2 – 7% | 2 – 7% | 2 – 7% | 2 – 21% | 2 – 20% | 2 – 21% | 2 – 21% | 2 – 21% | Tuner, Polyphonic | Pitch CV transposer |
| Bogaudio |  Sums |
6% | 5 – 6% | 6% | 5 – 6% | 5 – 6% | 6 – 16% | 5 – 15% | 6 – 16% | 5 – 15% | 5 – 15% | Logic, Polyphonic | Arithmetic logic |
| Bogaudio |  Switch |
3 – 4% | 3% | 3% | 3% | 3% | 3 – 5% | 3 – 6% | 3 – 5% | 3 – 5% | 3 – 5% | Switch, Polyphonic | 2-way signal router |
| Bogaudio |  Switch1616 |
7 – 52% | 6 – 52% | 5 – 52% | 5 – 52% | 5 – 52% | 7 – 194% | 6 – 196% | 5 – 197% | 5 – 198% | 5 – 198% | Mixer, Polyphonic | 16x16 matrix mixer |
| Bogaudio |  Switch18 |
4 – 10% | 4 – 10% | 3 – 10% | 3 – 10% | 3 – 10% | 4 – 32% | 4 – 33% | 3 – 33% | 3 – 33% | 3 – 33% | Switch, Polyphonic | 8-way signal router |
| Bogaudio |  Switch44 |
4 – 9% | 3 – 9% | 3 – 9% | 3 – 9% | 3 – 9% | 4 – 27% | 3 – 27% | 3 – 27% | 3 – 27% | 3 – 27% | Mixer, Polyphonic | 4x4 matrix mixer |
| Bogaudio |  Switch81 |
3 – 7% | 3 – 6% | 3 – 6% | 3 – 6% | 3 – 6% | 3 – 17% | 3 – 17% | 3 – 17% | 3 – 17% | 3 – 17% | Mixer, Polyphonic | 8-channel mixer |
| Bogaudio |  Switch88 |
4 – 20% | 4 – 19% | 4 – 19% | 4 – 19% | 4 – 19% | 4 – 67% | 4 – 67% | 4 – 68% | 4 – 68% | 4 – 68% | Mixer, Polyphonic | 8x8 matrix mixer |
| Bogaudio |  UMix |
2 – 4% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 9% | 2 – 9% | 2 – 9% | 2 – 9% | 2 – 8% | Mixer, Polyphonic | 8-input unity mixer |
| Bogaudio |  Unison |
3 – 4% | 3% | 3% | 3% | 3% | 3 – 4% | 3 – 4% | 3 – 4% | 3% | 3% | Polyphonic | Polyphonic unison voicing processor with detune |
| Bogaudio |  VCA |
3 – 6% | 3 – 7% | 3 – 6% | 3 – 6% | 3 – 6% | 3 – 14% | 3 – 14% | 3 – 14% | 3 – 14% | 3 – 14% | VCA, Dual, Polyphonic | Dual voltage controlled attenuator |
| Bogaudio |  VCAmp |
3 – 5% | 2 – 5% | 2 – 5% | 3 – 5% | 2 – 5% | 3 – 12% | 2 – 12% | 2 – 12% | 3 – 12% | 2 – 12% | VCA, Polyphonic | Voltage controlled amplifier with 12dB gain |
| Bogaudio |  VCF |
2 – 8% | 2 – 7% | 2 – 7% | 2 – 7% | 2 – 7% | 2 – 33% | 2 – 19% | 2 – 19% | 2 – 18% | 2 – 18% | Filter, Polyphonic | Multimode filter |
| Bogaudio |  VCM |
2 – 9% | 2 – 9% | 2 – 9% | 2 – 9% | 2 – 9% | 2 – 29% | 2 – 29% | 2 – 29% | 2 – 30% | 2 – 29% | Mixer, Polyphonic | 4-channel CV controllable mixer |
| Bogaudio |  VCO |
2 – 53% | 2 – 53% | 2 – 53% | 2 – 53% | 2 – 53% | 2 – 114% | 2 – 115% | 2 – 108% | 2 – 94% | 2 – 84% | Oscillator, Polyphonic | Oscillator |
| Bogaudio |  VU |
4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | Visual | Stereo signal meter |
| Bogaudio |  Velo |
2 – 9% | 2 – 9% | 2 – 9% | 2 – 9% | 2 – 9% | 2 – 26% | 2 – 25% | 2 – 26% | 2 – 26% | 2 – 26% | VCA, Polyphonic | Triple-CV VCA, for tremolo, MIDI velocity, etc |
| Bogaudio |  Vish |
2 – 7% | 2 – 7% | 2 – 7% | 2 – 7% | 2 – 7% | 2 – 19% | 2 – 20% | 2 – 19% | 2 – 17% | 2 – 16% | Envelope generator, Slew Limiter, Polyphonic | Vactrol-ish envelope generator |
| Bogaudio |  Walk |
4% | 4% | 4% | 4% | 4% | 4 – 9% | 4 – 9% | 4 – 9% | 4 – 9% | 4 – 9% | Random, Sample and hold, Polyphonic | Random-walk CV source |
| Bogaudio |  Walk2 |
6 – 9% | 5 – 7% | 5 – 7% | 5% | 5 – 6% | 6 – 9% | 5 – 7% | 5 – 7% | 5 – 6% | 5 – 6% | Random, Sample and hold, Controller | 2D random-walk and X/Y controller |
| Bogaudio |  XCO |
2 – 38% | 2 – 39% | 2 – 39% | 2 – 39% | 2 – 36% | 2 – 173% | 2 – 175% | 2 – 175% | 2 – 135% | 2 – 124% | Oscillator, Polyphonic | Oscillator |
| Bogaudio |  XFade |
2 – 9% | 2 – 9% | 2 – 9% | 2 – 8% | 2 – 7% | 2 – 18% | 2 – 18% | 2 – 18% | 2 – 18% | 2 – 18% | Mixer, Polyphonic | Crossfader |
| Cella |  2State |
3% | 3% | 3% | 3% | 3% | 3% | 3% | 3% | 3% | 3% | Utility, Switch, Sequencer | Combination of dual constant CV generator and a voltage-controlled switch |
| Cella |  Bezier |
8 – 9% | 8 – 9% | 8 – 9% | 8 – 9% | 8 – 9% | 8 – 9% | 8 – 9% | 8 – 9% | 8 – 9% | 8 – 9% | Utility, LFO, Random, Slew limiter | Smooth random voltage generator that uses Bezier curves |
| Cella |  Cognitive Shift |
6 – 7% | 6% | 6% | 6% | 6% | 6 – 7% | 6 – 7% | 6% | 6% | 6% | Sequencer, Sample and hold, Clock modulator, Logic | Advanced 8-bit digital shift register with clock, gates or trigger outputs, 4 DAC-based CV generators and various self-patching capabilities |
| Cella |  Euler |
5% | 5% | 5% | 5% | 5% | 5% | 5% | 5% | 5% | 5% | Utility, Envelope follower | Calculates rate of change of the incoming signal |
| Cella |  Integral |
6 – 7% | 5 – 7% | 5 – 7% | 5 – 7% | 5 – 7% | 5 – 7% | 5 – 7% | 5 – 7% | 5 – 7% | 5 – 7% | Utility, Sample and hold | Signal integrator, essential for feedback, chaotic and cybernetic patches |
| Cella |  Resonators |
37 – 39% | 36 – 39% | 36 – 39% | 36 – 39% | 37 – 39% | 37 – 39% | 36 – 39% | 36 – 39% | 36 – 39% | 37 – 39% | Effect, Filter, Physical modeling | Four pitched resonators based on Karplus-Strong algorithm |
| Cella |  Rich |
6 – 9% | 6 – 7% | 6 – 9% | 5 – 6% | 4 – 6% | 6 – 9% | 6 – 7% | 6 – 9% | 5 – 6% | 4 – 6% | Envelope generator | Expressive AD envelope generator with controllable and breathing accent dynamics |
| Cella |  Twin Peaks |
63 – 65% | 64 – 66% | 65 – 66% | 65 – 67% | 65% | 63 – 244% | 64 – 248% | 65 – 250% | 65 – 250% | 65 – 251% | Filter, Polyphonic | Dual resonant filter inspired by the design of Rob Hordijk's TwinPeak filter. Made to be pinged. |
| ChowDSP |  ChowDer |
8 – 9% | 8% | 8% | 8% | 7 – 8% | 8 – 9% | 8% | 8% | 8% | 7 – 8% | Effect, Distortion, Physical modeling | Truculent analog distortion effect |
| ChowDSP |  ChowModal |
7 – 11% | 7 – 11% | 7 – 11% | 6 – 11% | 6 – 11% | 7 – 11% | 7 – 11% | 7 – 11% | 6 – 11% | 6 – 11% | Effect, Oscillator, Filter | Single resonant mode |
| ChowDSP |  ChowPhaserFeedback |
7 – 9% | 7 – 8% | 7 – 8% | 7 – 8% | 7 – 8% | 7 – 9% | 7 – 8% | 7 – 8% | 7 – 8% | 7 – 8% | Effect, Phaser | A feedback phaser |
| ChowDSP |  ChowPhaserMod |
8% | 8% | 8% | 8% | 8% | 8% | 8% | 8% | 8% | 8% | Effect, Phaser | A modulation phaser |
| ChowDSP |  ChowPulse |
4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | envelope generator, physical modeling | Pulse shaper based on the TR-808 Kick Drum circuit |
| ChowDSP |  ChowTape |
57 – 96% | 57 – 97% | 58 – 98% | 58 – 99% | 58 – 99% | 57 – 96% | 57 – 97% | 58 – 98% | 58 – 99% | 58 – 99% | Effect, Distortion, Physical modeling | Analog tape emulation |
| ChowDSP |  ChowTape Chew |
5 – 7% | 5 – 6% | 5 – 6% | 5 – 6% | 5 – 6% | 5 – 7% | 5 – 6% | 5 – 6% | 5 – 6% | 5 – 6% | Effect, Distortion | Emulation of magnetic tape that has been chewed up by a tape machine |
| ChowDSP |  ChowTape Compression |
4 – 6% | 4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | 4 – 6% | 4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | Effect, Compressor, Distortion | Analog tape compression emulation |
| ChowDSP |  ChowTape Degrade |
5% | 5% | 5% | 5% | 5% | 5% | 5% | 5% | 5% | 5% | Effect, Distortion | Emulation of magnetic tape that has been degraded by time and use |
| ChowDSP |  ChowTape Loss |
79 – 80% | 42% | 23% | 14% | 9% | 79 – 80% | 42% | 23% | 14% | 9% | Effect, Filter | Emulation of playhead loss effects for a reel-to-reel analog tape machine |
| ChowDSP |  Warp |
15 – 31% | 15 – 31% | 15 – 31% | 15 – 31% | 15 – 31% | 15 – 31% | 15 – 31% | 15 – 31% | 15 – 31% | 15 – 31% | Effect, Distortion | A warping distortion, developed in collaboration with IggyLabs |
| ChowDSP |  Werner Filter |
8 – 15% | 8 – 15% | 8 – 15% | 8 – 15% | 8 – 14% | 8 – 15% | 8 – 15% | 8 – 15% | 8 – 15% | 8 – 14% | Effect, Filter, Physical modeling | SVF based on a generalized Moog-Octave CAT architecture |
| Cloned Instruments |  Quad Attenuverter |
5 – 6% | 5 – 6% | 5 – 6% | 5% | 5% | 5 – 6% | 5 – 6% | 5 – 6% | 5% | 5% | Mixer, Attenuator, Hardware clone | Based on Mutable Instruments Blinds |
| Cloned Instruments |  Algorithm VCO |
7% | 6 – 7% | 6% | 6% | 6% | 7% | 6 – 7% | 6% | 6% | 6% | Oscillator, Hardware clone | Based on Mutable Instruments Braids |
| Cloned Instruments |  Random Router |
3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 6% | 3 – 6% | 3 – 5% | 3 – 5% | 3 – 5% | Random, Dual, Hardware clone, Polyphonic | Based on Mutable Instruments Branches |
| Cloned Instruments |  Granulation |
17 – 41% | 16 – 41% | 13 – 32% | 13 – 30% | 13 – 30% | 17 – 42% | 16 – 41% | 13 – 32% | 13 – 31% | 13 – 30% | Granular, Reverb, Hardware clone | Based on Mutable Instruments Clouds |
| Cloned Instruments |  Modeler |
36 – 39% | 27 – 30% | 26 – 29% | 23 – 27% | 23 – 26% | 36 – 39% | 27 – 30% | 25 – 29% | 23 – 27% | 23 – 26% | Physical modeling, Hardware clone | Based on Mutable Instruments Elements |
| Cloned Instruments |  Keyframes |
5 – 6% | 5 – 7% | 5% | 5% | 5% | 5 – 6% | 5 – 7% | 5% | 5% | 5% | Oscillator, Mixer, Attenuator, LFO, Hardware clone | Based on Mutable Instruments Frames |
| Cloned Instruments |  Rect-Logic-S&H |
5% | 5% | 5% | 5% | 5% | 5% | 5% | 5% | 5% | 5% | Utility, Sample and hold, Noise, Hardware clone | Based on Mutable Instruments Kinks |
| Cloned Instruments |  Split-Combine |
3% | 3% | 3% | 3% | 3% | 3 – 5% | 3 – 5% | 3 – 5% | 3 – 5% | 3 – 5% | Multiple, Mixer, Hardware clone, Polyphonic | Based on Mutable Instruments Links |
| Cloned Instruments |  Random-maker |
10 – 15% | 10 – 13% | 9 – 12% | 9 – 12% | 9 – 11% | 10 – 15% | 10 – 13% | 9 – 12% | 9 – 12% | 9 – 11% | Random, Hardware clone | Based on Mutable Instruments Marbles |
| Cloned Instruments |  Algorithm VCO II |
9 – 11% | 9 – 10% | 9 – 10% | 9% | 8 – 9% | 9 – 31% | 9 – 27% | 9 – 26% | 9 – 26% | 8 – 25% | Oscillator, Hardware clone, Polyphonic | Based on Mutable Instruments Plaits |
| Cloned Instruments |  Resonator |
31 – 42% | 25 – 29% | 23 – 25% | 21 – 22% | 20 – 21% | 31 – 42% | 25 – 29% | 23 – 25% | 21 – 22% | 20 – 21% | Physical modeling, Hardware clone | Based on Mutable Instruments Rings |
| Cloned Instruments |  VC Filter |
28% | 29% | 29% | 29% | 29% | 28 – 105% | 29 – 106% | 29 – 107% | 29 – 107% | 29 – 108% | Filter, Voltage-controlled amplifier, Hardware clone, Polyphonic | Based on Mutable Instruments Ripples |
| Cloned Instruments |  Triple Mix |
3 – 4% | 3 – 4% | 3% | 3% | 3% | 3 – 4% | 3 – 4% | 3% | 3% | 3% | Mixer, Hardware clone | Based on Mutable Instruments Shades |
| Cloned Instruments |  Multi-filter |
27 – 55% | 28 – 55% | 28 – 54% | 28 – 54% | 27 – 54% | 27 – 199% | 28 – 201% | 28 – 203% | 28 – 204% | 27 – 204% | Equalizer, Filter, Polyphonic | Based on Mutable Instruments Shelves |
| Cloned Instruments |  Slope Sequencer |
8 – 10% | 7 – 10% | 7 – 10% | 7 – 10% | 7 – 10% | 8 – 10% | 7 – 10% | 7 – 10% | 7 – 10% | 7 – 10% | Function generator, Envelope generator, Hardware clone | Based on Mutable Instruments Stages |
| Cloned Instruments |  Compressing Filter |
39 – 41% | 38 – 39% | 38 – 39% | 38% | 38% | 39 – 148% | 38 – 145% | 38 – 145% | 38 – 144% | 38 – 144% | Dynamics, Low-pass gate, Polyphonic | Based on Mutable Instruments Streams |
| Cloned Instruments |  Envelopes |
6 – 7% | 5 – 7% | 5 – 6% | 4 – 5% | 4 – 5% | 6 – 7% | 5 – 7% | 5 – 6% | 4 – 5% | 4 – 5% | LFO, Oscillator, Waveshaper, Function generator, Hardware clone | Based on Mutable Instruments Tides |
| Cloned Instruments |  Envelopes II |
6 – 7% | 6 – 7% | 5 – 7% | 6% | 6% | 6 – 7% | 6 – 7% | 5 – 7% | 6% | 6% | LFO, Oscillator, Waveshaper, Function generator, Hardware clone | Based on Mutable Instruments Tides |
| Cloned Instruments |  Quad VCA |
4 – 7% | 4 – 7% | 4 – 7% | 4 – 7% | 3 – 7% | 4 – 8% | 4 – 7% | 4 – 7% | 4 – 7% | 3 – 7% | Mixer, Hardware clone | Based on Mutable Instruments Veils |
| Cloned Instruments |  Mod Osc |
19 – 25% | 18 – 21% | 13 – 17% | 12 – 15% | 11 – 13% | 19 – 25% | 18 – 21% | 13 – 17% | 12 – 15% | 11 – 13% | Ring modulator, Waveshaper, Hardware clone | Based on Mutable Instruments Warps |
| CountModula |  Analogue Shift Register |
3 – 4% | 2 – 4% | 2 – 3% | 2 – 3% | 2% | 3 – 4% | 2 – 4% | 2 – 3% | 2 – 3% | 2% | Sample and Hold | A dual 4, or single 8, step shift register |
| CountModula |  Super Arpeggiator |
4 – 5% | 3 – 5% | 3 – 5% | 3 – 5% | 3 – 5% | 4 – 5% | 3 – 5% | 3 – 5% | 3 – 5% | 3 – 5% | Arpeggiator | Arpeggiator with user definable patterns |
| CountModula |  Attenuator |
2 – 4% | 2 – 3% | 2% | 2% | 2% | 2 – 4% | 2 – 3% | 2% | 2% | 2% | Attenuator, Dual, Polyphonic | Dual attenuator with attenuverting option |
| CountModula |  Attenuverter |
3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | Utility, Attenuator, Polyphonic, Controller | Attenuverter/Attenuator |
| CountModula |  Bar Graph |
3% | 3% | 3% | 3% | 3% | 3% | 3% | 3% | 3% | 3% | Utility, Visual | Linear Bar Graph Meter |
| CountModula |  Basic 8 Step Sequencer |
3 – 6% | 3 – 6% | 3 – 5% | 3 – 5% | 3 – 5% | 3 – 6% | 3 – 6% | 3 – 5% | 3 – 5% | 3 – 5% | Sequencer | Basic single channel 8 step sequencer |
| CountModula |  Binary Comparator |
6 – 7% | 6 – 7% | 6% | 6% | 6% | 6 – 7% | 6 – 7% | 6% | 6% | 6% | Logic | Compares two binary words |
| CountModula |  Binary Sequencer |
5 – 6% | 5 – 6% | 5 – 6% | 5% | 5% | 5 – 6% | 5 – 6% | 5 – 6% | 5% | 5% | Clock generator, Sequencer | Binary counter based sequencer |
| CountModula |  Boolean AND Gate |
2 – 4% | 2 – 4% | 2 – 4% | 2 – 3% | 2 – 3% | 2 – 7% | 2 – 7% | 2 – 7% | 2 – 7% | 2 – 7% | Logic, Polyphonic | 4 input boolean AND/NAND gate |
| CountModula |  Boolean OR Gate |
2 – 4% | 2 – 4% | 2 – 4% | 2 – 4% | 2 – 3% | 2 – 8% | 2 – 7% | 2 – 9% | 2 – 7% | 2 – 7% | Logic, Polyphonic | 4 input boolean OR/NOR gate |
| CountModula |  Boolean VC Inverter |
2 – 4% | 2 – 4% | 2 – 4% | 2 – 4% | 2 – 4% | 2 – 7% | 2 – 6% | 2 – 5% | 2 – 5% | 2 – 5% | Logic, Dual, Polyphonic | Dual voltage controlled logical inverter |
| CountModula |  Boolean XOR Gate |
2 – 4% | 2 – 4% | 2 – 4% | 2 – 4% | 2 – 4% | 2 – 8% | 2 – 8% | 2 – 8% | 2 – 9% | 2 – 8% | Logic, Polyphonic | 4 input boolean XOR/XNOR gate |
| CountModula |  Breakout |
12% | 7% | 4 – 5% | 3 – 4% | 3% | 12% | 7% | 4 – 5% | 3 – 4% | 3% | Utility, Polyphonic | Breaks polyphonic signals out to individual normalled output/input pairs |
| CountModula |  Burst Generator |
6% | 6% | 6% | 6 – 7% | 6% | 6% | 6% | 6% | 6 – 7% | 6% | Clock modulator, Sequencer | Generates bursts of 1-16 pulses whenever a trigger is received at the trigger input |
| CountModula |  Burst Generator 64 |
4 – 6% | 4 – 6% | 4 – 6% | 4 – 6% | 4 – 6% | 4 – 6% | 4 – 6% | 4 – 6% | 4 – 6% | 4 – 6% | Clock modulator, Sequencer | Generates bursts of 1-64 pulses whenever a trigger is received at the trigger input |
| CountModula |  Bus Route |
3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | Switch, Logic | Switched gate combiner/router |
| CountModula |  Bus Route |
3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | Switch, Logic | Switched gate combiner |
| CountModula |  CV Spreader |
7% | 7 – 8% | 7% | 7% | 7% | 7% | 7 – 8% | 7% | 7% | 7% | Utility | Accepts "Base" and "Spread" CV inputs and creates a set of new CV values that are spread either side of the base value by an amount determined by the spread value. |
| CountModula |  Carousel Rotating Router |
3% | 3% | 2 – 3% | 2 – 3% | 2 – 3% | 3% | 3% | 2 – 3% | 2 – 3% | 2 – 3% | Switch | Sequentially rotate up to 8 inputs through up to 8 outputs |
| CountModula |  Chances - bernoulli gate |
3% | 2 – 3% | 2% | 2% | 2% | 3% | 2 – 3% | 2% | 2% | 2% | Random, Logic, Clock Modulator | Single bernoulli gate offering randomized routing of gate signals |
| CountModula |  Clock Divider |
4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | 3 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | 3 – 5% | Clock modulator | Clock divider with up/down mode and optional trigger outputs |
| CountModula |  Clocked Random Gates |
7 – 9% | 7 – 8% | 7 – 8% | 7% | 7% | 7 – 10% | 7 – 10% | 7 – 9% | 7 – 9% | 7 – 9% | Clock Modulator, Sequencer | Generates a set of 8 synchronised gates and triggers |
| CountModula |  Comparator |
2 – 4% | 2% | 2% | 2% | 2% | 2 – 4% | 2% | 2% | 2% | 2% | Utility | Compares the input signal with either an internal or external threshold value and outputs gate signals based on the outcome. |
| CountModula |  Euclidean Sequencer |
4 – 14% | 4 – 14% | 4 – 14% | 4 – 12% | 4 – 9% | 4 – 14% | 4 – 14% | 4 – 14% | 4 – 12% | 4 – 9% | Sequencer | Algorithmic trigger sequencer based on Euclidean division |
| CountModula |  Event Arranger |
5% | 5% | 5% | 5% | 5% | 5% | 5% | 5% | 5% | 5% | Clock modulator, Sequencer | A VCV Rack implementation of the VC Clock and Event Arranger published in an article by John Blacet in the Jan/Feb edition of Synapse magazine |
| CountModula |  Countdown |
3 – 4% | 3 – 4% | 3% | 3% | 3% | 3 – 4% | 3 – 4% | 3% | 3% | 3% | Clock modulator | Clocked/realtime event counter with 3 digits |
| CountModula |  Countdown 5 |
3% | 3% | 3% | 3% | 3% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3% | Clock modulator | Clocked/realtime event counter with 5 digits |
| CountModula |  Fade-in/Fade-out and Record Controller |
3% | 3 – 4% | 3 – 4% | 2 – 3% | 2 – 3% | 3 – 4% | 3 – 4% | 3 – 4% | 2 – 4% | 2 – 4% | Controller, Polyphonic | Automated fade in/out with integrated start/stop control for the VCV Record module |
| CountModula |  Gate to Trigger Converter |
3 – 4% | 2 – 4% | 2 – 3% | 2 – 3% | 2% | 3 – 4% | 2 – 4% | 2 – 3% | 2 – 3% | 2% | Utility | Gate to Trigger Converter |
| CountModula |  Gate Delay |
7 – 9% | 7 – 8% | 7 – 8% | 7 – 8% | 7% | 7 – 9% | 7 – 9% | 7 – 8% | 7 – 8% | 7 – 8% | Delay, Dual | A dual gate delay line giving up to 40 seconds of delay with voltage control over the delay time |
| CountModula |  Tapped Gate Delay |
4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | 4% | 4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | 4% | Delay | A gate delay that offers up to 40 seconds of delay with tapped outputs at equal intervals along the delay line |
| CountModula |  Gate Modifier |
4% | 4% | 4% | 4% | 4% | 4% | 4 – 5% | 4% | 4% | 4% | Logic, Utility | Voltage controlled gate length modifier |
| CountModula |  8 x 16 Gate Sequencer |
4 – 7% | 5 – 7% | 4 – 6% | 4 – 6% | 5 – 6% | 4 – 7% | 5 – 7% | 4 – 6% | 4 – 6% | 5 – 6% | Sequencer | An 8 Channel 16 Step Gate/Trigger Sequencer |
| CountModula |  12 x 16 Gate Sequencer |
5 – 7% | 5 – 7% | 5 – 7% | 5 – 7% | 5 – 7% | 5 – 7% | 5 – 7% | 5 – 7% | 5 – 7% | 5 – 7% | Sequencer | A 12 Channel 16 Step Gate/Trigger Sequencer |
| CountModula |  8 x 8 Gate Sequencer |
4 – 6% | 4 – 6% | 4 – 6% | 4 – 6% | 4 – 6% | 4 – 6% | 4 – 6% | 4 – 6% | 4 – 6% | 4 – 6% | Sequencer | An 8 Channel 8 Step Gate/Trigger Sequencer |
| CountModula |  Gated Comparator |
3% | 3% | 3% | 3% | 3% | 3% | 3% | 3% | 3% | 3% | Sequencer, Random | Gated Comparator |
| CountModula |  Hyper Maniacal LFO |
22 – 24% | 23% | 22 – 23% | 22 – 23% | 22 – 23% | 22 – 24% | 23% | 22 – 23% | 22 – 23% | 22 – 23% | LFO | Complex LFO |
| CountModula |  Mangler |
4% | 4% | 4% | 4% | 4% | 4% | 4% | 4% | 4% | 4% | Distortion, Polyphonic | A voltage controlled sample rate/bit depth reducer |
| CountModula |  Signal Manifold |
3 – 5% | 3 – 5% | 2 – 4% | 2 – 4% | 2 – 4% | 3 – 5% | 3 – 5% | 2 – 5% | 2 – 5% | 2 – 5% | Multiple, Polyphonic | Replicates a mono/poly input signal to a selected number of channels in a poly output signal |
| CountModula |  Manual CV Generator |
3% | 3% | 3% | 3% | 3% | 3% | 3% | 3% | 3% | 3% | Dual, Controller, Utility | A simple dual manual CV generator offering +/- 10V with both coarse and fine controls |
| CountModula |  Polyphonic Manual CV Generator |
2 – 3% | 2% | 2% | 2% | 2% | 2 – 3% | 2% | 2% | 2% | 2% | Polyphonic, Utility, Controller | A basic manual CV generator with a range of output voltages |
| CountModula |  Manual Gate |
3 – 4% | 3% | 3% | 3% | 3% | 3 – 4% | 3% | 3% | 3% | 3% | Utility, Controller | A manually triggered gate generator offering a number of simultaneous gate and inverted gate outputs |
| CountModula |  Master Reset Controller |
3% | 2 – 3% | 2 – 4% | 2 – 3% | 2% | 3% | 2 – 3% | 2 – 4% | 2 – 3% | 2 – 3% | Clock modulator, Controller, Utility | Master reset button and clock wrangler |
| CountModula |  Matrix Combiner |
5 – 6% | 4 – 6% | 4 – 8% | 4 – 5% | 4 – 6% | 5 – 6% | 4 – 6% | 4 – 8% | 4 – 5% | 4 – 6% | Switch, Logic, Multiple | Gate combiner/switched multiple |
| CountModula |  Matrix Mixer |
7% | 7% | 7% | 7% | 6 – 7% | 7% | 7% | 7% | 7% | 6 – 7% | Mixer | A 4 x 4 matrix mixer allowing up to 4 input signals to be independently mixed to 4 different outputs |
| CountModula |  Minimus Maximus |
2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | Utility | A signal processor that determines and outputs the minimum, maximum and mean (average) of up to 4 input signals |
| CountModula |  Mixer |
3% | 3% | 3% | 3% | 3% | 3% | 3% | 3% | 3% | 3% | Mixer | A basic 4 input utility mixer with output level control, overload indicator, inverted output and selectable bipolar/unipolar operation |
| CountModula |  Morph Shaper |
5 – 6% | 5% | 5% | 5% | 5% | 5 – 6% | 5% | 5% | 5% | 5% | Utility, Waveshaper | Morphing controller and wave shaper |
| CountModula |  Multiple |
3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | Multiple, Polyphonic | Normalled polyphonic multiple |
| CountModula |  Multi-step Sequencer |
4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | 3 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | 3 – 5% | Sequencer | Step sequencer with repeat and probability per step |
| CountModula |  Multiplexer |
4 – 7% | 4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | 4 – 7% | 4 – 6% | 4 – 5% | 4 – 5% | 4 – 5% | Switch | A 1 input to 8 output and 8 input to 1 output multiplexer |
| CountModula |  Mute |
3 – 4% | 3 – 4% | 3% | 3% | 2 – 4% | 3 – 4% | 3 – 4% | 3% | 3% | 2 – 4% | Controller, Polyphonic | A voltage controlled mute |
| CountModula |  Mute-iple |
5 – 6% | 5 – 6% | 5 – 6% | 5 – 6% | 5 – 6% | 5 – 8% | 5 – 8% | 5 – 8% | 5 – 8% | 5 – 8% | Dual, Multiple, Controller, Polyphonic | A dual 4-way/ Single 8 way mutable multiple |
| CountModula |  Nibble Trigger Sequencer |
3 – 4% | 3 – 4% | 3% | 3% | 3% | 3 – 4% | 3 – 4% | 3% | 3% | 3% | Sequencer | Binary nibble based trigger sequencer |
| CountModula |  Octet Trigger Sequencer |
4 – 5% | 3 – 4% | 3 – 4% | 3 – 4% | 3% | 4 – 5% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | Sequencer | Binary octet based trigger sequencer |
| CountModula |  Offset Generator |
2 – 3% | 2% | 2% | 2% | 2% | 2 – 3% | 2 – 3% | 2 – 3% | 2% | 2% | Utility, Polyphonic | Offsets a CV signal by a given amount |
| CountModula |  Oscilloscope |
3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3% | Utility, Visual | Quad trace oscilloscope. |
| CountModula |  Polyphonic Bernoulli Gate |
3 – 5% | 2 – 5% | 2 – 5% | 2 – 4% | 2 – 4% | 3 – 6% | 2 – 6% | 2 – 6% | 2 – 6% | 2 – 6% | Random, Logic, Clock Modulator, Polyphonic | Randomized routing of polyphonic gate signals |
| CountModula |  gate to Trigger Converter |
2 – 11% | 3 – 11% | 2 – 10% | 2 – 10% | 2 – 10% | 2 – 11% | 3 – 11% | 2 – 10% | 2 – 10% | 2 – 10% | Utility, Polyphonic | Description. |
| CountModula |  Poly Gate Modifier |
7 – 8% | 7 – 8% | 6 – 8% | 6 – 7% | 6 – 8% | 7 – 10% | 7 – 10% | 6 – 10% | 6 – 10% | 6 – 10% | Logic, Utility, Polyphonic | Polyphonic voltage controlled gate length modifier |
| CountModula |  Polyphonic Boolean Logic Processor |
2 – 4% | 2 – 4% | 2 – 4% | 2 – 4% | 2 – 4% | 2 – 5% | 2 – 5% | 2 – 5% | 2 – 5% | 2 – 5% | Polyphonic, Logic | Applies boolean logic across the channels of a polyphonic signal |
| CountModula |  Polyphonic Min/Max |
2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 4% | 2 – 4% | 2 – 4% | 2 – 3% | 2 – 3% | Utility, Polyphonic | Determines minimum and maximum values from a polyphonic CV input |
| CountModula |  Polyphonic Mute |
3 – 12% | 2 – 12% | 2 – 12% | 2 – 12% | 2 – 12% | 3 – 12% | 2 – 12% | 2 – 12% | 2 – 12% | 2 – 12% | Controller, Polyphonic | Polyphonic Manual/VC Mute |
| CountModula |  Polyphonic VC Polarizer |
2 – 19% | 2 – 19% | 2 – 19% | 2 – 19% | 2 – 19% | 2 – 21% | 2 – 21% | 2 – 22% | 2 – 22% | 2 – 21% | Polyphonic, Attenuator, Utility | A polyphonic voltage controlled polarizer |
| CountModula |  Polyphonic Voltage Controlled Switch |
8 – 10% | 8 – 10% | 8 – 10% | 8 – 9% | 8 – 9% | 8 – 10% | 8 – 10% | 8 – 10% | 8 – 9% | 8 – 9% | Switch, Polyphonic | Selects between 2 polyphonic inputs or routes 1 polyphonic input to one of 2 polyphonic outputs based on the level of the signal at the polyphonic CV input |
| CountModula |  Polyrhythmic Generator MkII |
12 – 14% | 12 – 14% | 12 – 14% | 12 – 14% | 12 – 14% | 12 – 14% | 12 – 14% | 12 – 14% | 12 – 14% | 12 – 14% | Clock modulator, Sequencer, Polyphonic | A set of 8 voltage controlled clock dividers that can be used to generate polyrhythms by clocking and/or dividing at different rates |
| CountModula |  Random Access Switch 1-8 |
3 – 4% | 3 – 4% | 3% | 3% | 3% | 3 – 4% | 3 – 4% | 3% | 3% | 3% | Switch | Random access switch 1 input to 8 output |
| CountModula |  Random Access Switch 8-1 |
2 – 4% | 2 – 3% | 2 – 3% | 2% | 2% | 2 – 4% | 2 – 3% | 2 – 3% | 2% | 2% | Switch | Random access switch 8 inputs to 1 output |
| CountModula |  Rectifier |
4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | 3 – 5% | 4 – 9% | 4 – 9% | 4 – 9% | 4 – 9% | 3 – 9% | Waveshaper, Polyphonic | A full/half wave rectifier with variable rectification axis |
| CountModula |  Dual SR Flip Flop |
3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | Logic, Dual | A dual logical Set/Reset flip flop with enable |
| CountModula |  Sample & Hold |
2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 4% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | Sample and hold, Polyphonic | Sample and Hold/Track and hold |
| CountModula |  Super Sample & Hold |
2 – 6% | 2 – 6% | 2 – 5% | 2 – 5% | 2 – 5% | 2 – 7% | 2 – 7% | 2 – 7% | 2 – 7% | 2 – 7% | Sample and hold, Polyphonic | Sample and Hold/Track and hold with probability, offset and inbuilt noise source |
| CountModula |  4Bit Sequence Encoder |
2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | Sequencer | Binary addressed encoder for sequencer expanders |
| CountModula |  16 Step Sequencer |
6 – 7% | 5 – 7% | 5 – 7% | 5 – 7% | 6 – 7% | 6 – 7% | 5 – 7% | 5 – 7% | 5 – 7% | 6 – 7% | Sequencer | 16 Step Sequencer |
| CountModula |  64 Step Sequencer |
6 – 9% | 6 – 8% | 6 – 8% | 6 – 8% | 6 – 8% | 6 – 9% | 6 – 8% | 6 – 8% | 6 – 8% | 6 – 8% | Sequencer | 64 Step CV/gate sequencer |
| CountModula |  8 Step Sequencer |
4 – 9% | 4 – 9% | 4 – 9% | 4 – 6% | 4 – 6% | 4 – 9% | 4 – 9% | 4 – 9% | 4 – 6% | 4 – 6% | Sequencer | 8 Step Sequencer |
| CountModula |  Shepard Generator |
7 – 9% | 7 – 9% | 7% | 7% | 7% | 7 – 9% | 7 – 9% | 7 – 8% | 7% | 7% | LFO, Function generator, Polyphonic | Generates a set of 8 ramp and sawtooth control signals appropriately phased for generation of Shepard tones |
| CountModula |  16 Step Shift Register |
6 – 7% | 6 – 7% | 5 – 7% | 5 – 7% | 5 – 7% | 6 – 7% | 6 – 7% | 5 – 7% | 5 – 7% | 5 – 7% | Sample and Hold | 16 step bi-directional shift register for CV or gates |
| CountModula |  32 Step Shift Register |
8 – 10% | 8 – 9% | 8 – 9% | 8 – 9% | 8 – 9% | 8 – 10% | 8 – 9% | 8 – 9% | 8 – 9% | 8 – 9% | Sample and Hold | 32 step bi-directional shift register for CV or gates |
| CountModula |  D Flip Flop |
3 – 4% | 3 – 4% | 3% | 2 – 3% | 2 – 3% | 3 – 4% | 3 – 4% | 3% | 2 – 3% | 2 – 3% | Logic | A logical D type flip flop with clock enable |
| CountModula |  SR Flip Flop |
3 – 4% | 3 – 4% | 3% | 3% | 2 – 3% | 3 – 4% | 3 – 4% | 3% | 3% | 2 – 3% | Logic | A logical Set/Reset flip flop with enable |
| CountModula |  T Flip Flop |
3 – 4% | 3 – 4% | 2 – 4% | 2 – 3% | 2 – 3% | 3 – 4% | 3 – 4% | 2 – 4% | 2 – 3% | 2 – 3% | Logic | A logical T type (toggle) flip flop with enable |
| CountModula |  Slope Detector |
3 – 5% | 3 – 5% | 2 – 4% | 2 – 4% | 2 – 4% | 3 – 5% | 3 – 5% | 2 – 4% | 2 – 4% | 2 – 4% | Utility | Slope Detector |
| CountModula |  CV Stack |
4% | 3 – 4% | 3 – 4% | 3% | 3% | 3 – 4% | 3 – 4% | 3 – 4% | 3% | 3% | Sequencer, Sample and hold | Sequential voltage storage stack with First In First Out or Last In First Out operation |
| CountModula |  Startup Delay |
4% | 4% | 3 – 4% | 3 – 4% | 2 – 3% | 4% | 4% | 3 – 4% | 3 – 4% | 2 – 3% | Utility | Generates delayed start signals for sequencers on load or startup |
| CountModula |  Dual 8 Step Sequencer |
7 – 11% | 7 – 11% | 7 – 10% | 7 – 10% | 7 – 10% | 7 – 11% | 7 – 11% | 7 – 10% | 7 – 10% | 7 – 10% | Sequencer, Dual, Polyphonic | Fully featured dual channel 8 step sequencer |
| CountModula |  Sub Harmonic Generator |
4% | 4% | 4% | 4% | 4% | 4% | 4% | 4% | 4% | 4% | Waveshaper | Fatten up a single oscillator with sub harmonics |
| CountModula |  Switch 16-1 |
3 – 7% | 4 – 7% | 4 – 6% | 4 – 6% | 3 – 6% | 3 – 7% | 4 – 7% | 4 – 6% | 4 – 6% | 3 – 6% | Switch | 16 input to 1 output sequential/VC switch/router |
| CountModula |  Switch 1-16 |
4 – 11% | 4 – 11% | 4 – 11% | 4 – 11% | 4 – 11% | 4 – 11% | 4 – 11% | 4 – 11% | 4 – 11% | 4 – 11% | Switch | 1 input to 16 output sequential/VC switch |
| CountModula |  Switch 1-8 |
4 – 8% | 4 – 8% | 4 – 8% | 4 – 8% | 4 – 8% | 4 – 8% | 4 – 8% | 4 – 8% | 4 – 8% | 4 – 8% | Switch | 1 input to 8 output sequential/VC switch |
| CountModula |  Manual DPDT Switch |
2% | 2% | 2% | 2% | 2% | 2 – 3% | 2% | 2% | 2% | 2% | Switch | Manually switch between 2 inputs |
| CountModula |  Manual 3 Input Switch |
2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | Switch | Manually select any one of 3 inputs |
| CountModula |  Manual 4 Input Switch |
2% | 2% | 2% | 2% | 2% | 2% | 2 – 3% | 2% | 2% | 2% | Switch | Manually select any one of 4 inputs |
| CountModula |  Switch 8-1 |
4 – 6% | 3 – 6% | 3 – 5% | 3 – 5% | 3 – 5% | 4 – 6% | 3 – 6% | 3 – 5% | 3 – 5% | 3 – 5% | Switch | 8 input to 1 output sequential/VC switch/router |
| CountModula |  Dual T Flip Flop |
3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | Logic, Dual | A dual logical T type (toggle) flip flop with enable |
| CountModula |  Trigger Sequencer (16 Step) |
11 – 15% | 11 – 15% | 11 – 15% | 11 – 15% | 11 – 15% | 11 – 15% | 11 – 15% | 11 – 15% | 11 – 15% | 11 – 15% | Quad, Sequencer | Quad 16 step trigger sequencer |
| CountModula |  Trigger Sequencer (8 Step) |
9 – 13% | 9 – 13% | 9 – 13% | 9 – 13% | 9 – 12% | 9 – 13% | 9 – 13% | 9 – 13% | 9 – 13% | 9 – 12% | Quad, Sequencer | Quad 8 step trigger sequencer |
| CountModula |  Voltage Controlled Frequency Divider MkII |
2 – 3% | 2% | 2% | 2% | 2% | 2 – 3% | 2% | 2% | 2% | 2% | Clock modulator | Frequency divider with a variable and voltage controlled division ratio from 1 to around 20 |
| CountModula |  Voltage Controlled Polarizer |
4 – 5% | 2 – 5% | 2 – 5% | 2 – 5% | 2 – 5% | 4 – 8% | 2 – 8% | 2 – 8% | 2 – 8% | 2 – 8% | Dual, Polyphonic, Attenuator, Utility | A dual voltage controlled polarizer |
| CountModula |  Voltage Controlled Pulse Divider |
3 – 4% | 3% | 3% | 3% | 3% | 3 – 4% | 3 – 4% | 3 – 4% | 3% | 3 – 4% | Clock modulator | Voltage controlled division of pulse signals such as gates and triggers |
| CountModula |  Voltage Controlled Switch |
2 – 4% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 4% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | Switch, Polyphonic | Selects between 2 inputs or routes 1 input to one of 2 outputs based on the level of the signal at the CV input |
| CountModula |  Voltage Inverter |
2 – 3% | 2 – 3% | 2% | 2% | 2% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | Utility, Polyphonic, Quad | A quad voltage inverter that inverts signals around zero |
| CountModula |  Voltage Scaler |
3 – 5% | 3 – 5% | 3 – 5% | 3 – 5% | 3 – 5% | 3 – 6% | 3 – 6% | 3 – 6% | 3 – 6% | 3 – 6% | Attenuator, Utility, Polyphonic | Rescale a voltage from one range to another |
| CuteLab |  Mom Jeans |
oscillator, polyphonic | Pulsar synthesis oscillator with a twist | ||||||||||
| CV funk |  Alloy |
41 – 48% | 41 – 48% | 41 – 48% | 40 – 49% | 41 – 48% | 41 – 192% | 41 – 190% | 41 – 191% | 40 – 191% | 41 – 191% | Drum, Physical modeling, Polyphonic, Effect, Oscillator | A metallic sound generator that uses Karplus–Strong fractional delay networks to produce shimmering, percussive tones. |
| CV funk |  Arrange |
4 – 13% | 4 – 13% | 4 – 13% | 4 – 13% | 4 – 13% | 4 – 13% | 4 – 13% | 4 – 13% | 4 – 13% | 4 – 13% | Sequencer, Polyphonic | A seven channel sequencer with quantize/volt option per channel, and adjustable length. |
| CV funk |  CV funk Blank 8HP |
2% | 2% | 2% | 2% | 2% | 2% (mono) | 2% (mono) | 2% (mono) | 2% (mono) | 2% (mono) | Blank | Blank panel for CV funk. |
| CV funk |  CV funk Blank 4HP |
2% | 2% | 2% | 2% | 2% | 2% (mono) | 2% (mono) | 2% (mono) | 2% (mono) | 2% (mono) | Blank | Blank panel for CV funk. |
| CV funk |  Cartesia |
20 – 24% | 20 – 24% | 20 – 23% | 20 – 23% | 20 – 23% | 20 – 24% | 20 – 24% | 20 – 23% | 20 – 23% | 20 – 23% | Sequencer, Polyphonic | A 4x4x4 sequencer for both quantized and non-quantized voltages, gates per step, and polyphonic outputs with stacked z-layer options. |
| CV funk |  Clpy |
11% | 11% | 11% | 11% | 11% | 11 – 35% | 11 – 35% | 11 – 35% | 11 – 35% | 11 – 35% | Waveshaper, Polyphonic | Stereo polyphonic waveshaper folds your waves and clips them to a target CV value or audio input. |
| CV funk |  Collatz |
4 – 6% | 3 – 4% | 3 – 4% | 3% | 2 – 3% | 4 – 6% | 3 – 4% | 3 – 4% | 3% | 2 – 3% | Sequencer, Clock modulator | Clock-synchronized trigger burst generator, based on sequences of the Collatz conjecture. |
| CV funk |  Count |
4 – 5% | 4% | 4% | 4% | 4% | 4 – 5% | 4% | 4 – 5% | 4% | 4% | Utility | Counts up. Counts down. Auto-adapting display can handle very large numbers. |
| CV funk |  Decima |
4 – 5% | 5% | 4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | 5% | 4 – 5% | 4 – 5% | 4 – 5% | Sequencer, Utility | Ten-channel gate sequencer with per-step probability. |
| CV funk |  Envelope Array |
12 – 14% | 12 – 14% | 12 – 14% | 11 – 14% | 11 – 14% | 12 – 15% | 12 – 15% | 12 – 14% | 11 – 14% | 11 – 14% | Envelope generator, Function generator | Six related envelopes and gates |
| CV funk |  Flower Patch |
2 – 4% | 2 – 4% | 2 – 4% | 2 – 4% | 2 – 4% | 2 – 4% | 2 – 4% | 2 – 4% | 2 – 4% | 2 – 4% | Visual, Utility | A 12-tone scale polar visualizer with FFT analysis. |
| CV funk |  Hammer |
17 – 18% | 17 – 18% | 17 – 18% | 17 – 18% | 17 – 18% | 17 – 18% | 17 – 18% | 17 – 18% | 17 – 18% | 17 – 18% | Clock generator, Clock modulator, Polyphonic | A compact and more-precise version of the Syncro eight-channel clock ratio generator. |
| CV funk |  Hex Mod |
18 – 20% | 18 – 20% | 18 – 20% | 18 – 20% | 18 – 20% | 18 – 20% | 18 – 20% | 18 – 20% | 18 – 20% | 18 – 20% | Low-frequency oscillator, Visual | Six phase-related LFOs with rate sync and individual phase reset triggers. |
| CV funk |  Hub |
4 – 9% | 4 – 7% | 4 – 7% | 4 – 7% | 4 – 7% | 4 – 17% | 4 – 17% | 4 – 17% | 4 – 16% | 4 – 17% | Voltage-controlled amplifier, Utility, Dual, Polyphonic | Two animated knob macro controllers with gain, offset, and knob range CV control. |
| CV funk |  Impulse Controller |
25 – 27% | 24 – 27% | 24 – 27% | 23 – 26% | 23 – 25% | 25 – 27% | 24 – 27% | 24 – 27% | 23 – 26% | 23 – 25% | Envelope generator, Function generator, Visual | Decay envelopes propagate across a network of 24 nodes |
| CV funk |  Junk DNA |
11 – 14% | 11 – 14% | 11 – 14% | 11 – 12% | 11% | 11 – 14% | 11 – 14% | 11 – 14% | 11 – 12% | 11% | Sequencer | Input DNA codes to generate repetative genes, convert DNA sequence to numerous simultaneous gate signals. |
| CV funk |  Magnets |
18 – 33% | 19 – 33% | 18 – 33% | 18 – 34% | 18 – 33% | 18 – 33% | 19 – 33% | 18 – 33% | 18 – 34% | 18 – 33% | Random, Low-frequency oscillator | Simulate and interact with a small magnetic spin-lattice. |
| CV funk |  Morta |
4 – 5% | 4 – 5% | 3 – 5% | 3 – 5% | 3 – 5% | 4 – 13% | 4 – 12% | 3 – 13% | 3 – 13% | 3 – 13% | Controller, Utility, Polyphonic | Single-knob macro-controller utility with 16 simultaneous outputs in different ranges. |
| CV funk |  Node |
8 – 12% | 8 – 12% | 8 – 12% | 8 – 12% | 8 – 12% | 8 – 16% | 8 – 16% | 8 – 16% | 8 – 16% | 8 – 16% | Voltage-controlled amplifier, Mixer, Dual, Polyphonic | A two-channel stereo crossfading mixer. |
| CV funk |  Nona |
10 – 11% | 10 – 11% | 10 – 11% | 10 – 11% | 10 – 11% | 10 – 11% | 10 – 11% | 10 – 11% | 10 – 11% | 10 – 11% | Attenuator, Utility | Nine-channel CV gain/offset utility mixer. |
| CV funk |  Ouros |
11 – 56% | 11 – 35% | 11 – 25% | 11 – 24% | 11 – 22% | 11 – 91% | 11 – 71% | 11 – 61% | 11 – 60% | 11 – 58% | Oscillator, Polyphonic | A stereo phase injection oscillator, with polar waveform display. |
| CV funk |  Penta Sequencer |
7 – 15% | 7 – 15% | 7 – 15% | 7 – 15% | 7 – 15% | 7 – 15% | 7 – 15% | 7 – 15% | 7 – 15% | 7 – 15% | Sequencer | A five step sequencer with five simultaneous outputs and tempo-synced slew |
| CV funk |  Picus |
4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | Sequencer, Clock modulator | Compose sequences of trigger bursts. Program a sequence of up to seven clock multiplier stages. Customizable trigger patterns. |
| CV funk |  Preeeeeeeeeeessed Duck |
26 – 103% | 26 – 105% | 26 – 106% | 26 – 106% | 26 – 106% | 26 – 105% | 26 – 106% | 26 – 107% | 26 – 107% | 26 – 107% | Mixer, Compressor, Dynamics, Distortion, Panning, Voltage-controlled Amplifier | A stereo sixteen-channel dynamic compressing mixer with side-chain ducking, tanh saturation and ADAA. |
| CV funk |  Pressed Duck |
14 – 51% | 15 – 52% | 14 – 52% | 14 – 52% | 14 – 52% | 14 – 52% | 15 – 52% | 14 – 52% | 14 – 53% | 14 – 53% | Mixer, Compressor, Dynamics, Distortion, Panning, Voltage-controlled Amplifier | A stereo six-channel dynamic compressing mixer with side-chain ducking, tanh saturation and ADAA. |
| CV funk |  Ranges |
4% | 4% | 4% | 4% | 4% | 4% | 4% | 4% | 4% | 4% | Utility, Attenuator | Convert two input voltages into equal intervals. |
| CV funk |  Rat |
5% | 5% | 5% | 5% | 5% | 5 – 12% | 5 – 12% | 5 – 12% | 5 – 12% | 5 – 12% | Utility, Polyphonic | Polyphonic ratio CV generator for exploring FMop ratios. Knob scales non-linearly around ratios, or optionally locks onto exact ratios. |
| CV funk |  Signals |
6 – 21% | 6 – 16% | 6 – 14% | 6 – 12% | 6 – 11% | 6 – 21% | 6 – 16% | 6 – 14% | 6 – 12% | 6 – 12% | Visual | A small six-channel oscilloscope for visualizing rack signals. |
| CV funk |  Step Wave |
19 – 23% | 19 – 24% | 19 – 23% | 19 – 23% | 19 – 23% | 19 – 23% | 19 – 24% | 19 – 23% | 19 – 23% | 19 – 23% | Sequencer | 8-step programmable sequencer/envelope generator with rhythmic displacement and variable shape. |
| CV funk |  Steps |
6% | 6 – 7% | 6% | 6% | 6% | 6 – 7% | 6 – 7% | 6% | 6% | 6% | Function generator, Sample and hold, Utility | Fusion of a comparator and a step generator |
| CV funk |  Strings |
5 – 6% | 4% | 3% | 3% | 3% | 5 – 6% | 4% | 3% | 3% | 3% | Sequencer, Quantizer | Generates guitar chords from a button interface or CV. Implements bending, whammy bar and capo. |
| CV funk |  Syncro |
14 – 15% | 14 – 15% | 14 – 15% | 14 – 15% | 14 – 15% | 14 – 15% | 14 – 15% | 14 – 15% | 14 – 15% | 14 – 15% | Clock generator, Clock modulator | Eight channel clock ratio generator. |
| CV funk |  Tatami |
26 – 32% | 25 – 31% | 25 – 31% | 25 – 30% | 25 – 30% | 26 – 102% | 25 – 102% | 25 – 101% | 25 – 101% | 25 – 101% | Waveshaper, Polyphonic | A stereo polyphonic wave-shaper and wave-folder with display and ADAA antialising. |
| CV funk |  Tri Delay |
2 – 45% | 2 – 46% | 2 – 46% | 2 – 46% | 2 – 45% | 2 – 45% | 2 – 46% | 2 – 46% | 2 – 46% | 2 – 45% | Delay | A three tap fractional-delay with ranges from ms to a few seconds. |
| CV funk |  Tuner |
7 – 8% | 7 – 8% | 7 – 8% | 7 – 8% | 6 – 8% | 7 – 8% | 7 – 8% | 7 – 8% | 7 – 8% | 6 – 8% | Tuner, Dual, Utility | Dual autocorrelation tuner and zero-centered waveform display. |
| CV funk |  Wonk |
18 – 20% | 18 – 20% | 18 – 20% | 18 – 20% | 18 – 20% | 18 – 20% | 18 – 20% | 18 – 20% | 18 – 20% | 18 – 20% | Low-frequency Oscillator, Polyphonic | Generate clock-synced and wonky modulationss in six phase-locked channels. |
| dBiz |  Bench |
9% | 9% | 9% | 9% | 9% | 9% | 9% | 9% | 9% | 9% | Utility | |
| dBiz |  Bene |
28 – 37% | 27 – 37% | 27 – 38% | 27 – 38% | 27 – 36% | 28 – 37% | 27 – 37% | 27 – 38% | 27 – 38% | 27 – 36% | Sequencer | |
| dBiz |  BigSmorph |
18 – 19% | 18 – 20% | 18 – 20% | 18 – 19% | 18 – 19% | 18 – 19% | 18 – 20% | 18 – 20% | 18 – 19% | 18 – 19% | Sequencer | |
| dBiz |  Chord |
5% | 5 – 6% | 5% | 5% | 5% | 5 – 6% | 5 – 6% | 5% | 5% | 5% | Quantizer | |
| dBiz |  Contorno |
5 – 14% | 5 – 14% | 5 – 14% | 5 – 14% | 5 – 14% | 5 – 14% | 5 – 14% | 5 – 14% | 5 – 14% | 5 – 14% | Envelope Generator | |
| dBiz |  DAOSC |
68 – 86% | 69 – 87% | 69 – 88% | 69 – 88% | 69 – 88% | 68 – 86% | 69 – 87% | 69 – 88% | 69 – 88% | 69 – 88% | VCO | |
| dBiz |  DVCO |
29 – 35% | 29 – 34% | 29 – 34% | 29 – 33% | 29 – 33% | 29 – 44% | 29 – 44% | 29 – 44% | 29 – 44% | 29 – 44% | VCO | |
| dBiz |  Divider |
11 – 12% | 11 – 12% | 11 – 12% | 11 – 12% | 11 – 12% | 11 – 12% | 11 – 12% | 11 – 12% | 11 – 12% | 11 – 12% | Utility | |
| dBiz |  DrMix |
6 – 7% | 6 – 7% | 6 – 7% | 6 – 7% | 6 – 7% | 6 – 7% | 6 – 7% | 6 – 7% | 6 – 7% | 6 – 7% | Mixer, VCA | |
| dBiz |  DualFilter |
14 – 15% | 15% | 15% | 15% | 15% | 14 – 15% | 15% | 15% | 15% | 15% | Filter | |
| dBiz |  DualMatrix |
9 – 13% | 9 – 13% | 9 – 13% | 8 – 13% | 8 – 13% | 9 – 13% | 9 – 13% | 9 – 13% | 8 – 13% | 8 – 13% | Mixer | |
| dBiz |  FourSeq |
4% | 4 – 5% | 4 – 5% | 4% | 4% | 4% | 4 – 5% | 4 – 5% | 4 – 5% | 4% | Sequencer | |
| dBiz |  NavControl |
2 – 4% | 2 – 3% | 2% | 2% | 2% | 2 – 4% | 2 – 3% | 2% | 2% | 2% | Utility | |
| dBiz |  Order |
4 – 17% | 4 – 17% | 4 – 17% | 4 – 17% | 4 – 17% | 4 – 17% | 4 – 17% | 4 – 17% | 4 – 17% | 4 – 17% | Utility | |
| dBiz |  PerfMixer |
16 – 25% | 16 – 25% | 16 – 25% | 16 – 25% | 16 – 25% | 16 – 25% | 16 – 25% | 16 – 25% | 16 – 25% | 16 – 25% | Mixer, VCA | |
| dBiz |  PerfMixer4 |
9 – 14% | 9 – 12% | 9 – 12% | 8 – 12% | 8 – 12% | 9 – 14% | 9 – 12% | 9 – 12% | 8 – 12% | 8 – 12% | Mixer, VCA | |
| dBiz |  QuePasa |
17 – 18% | 17 – 18% | 17 – 18% | 17 – 18% | 17% | 17 – 18% | 17 – 18% | 17 – 18% | 17 – 18% | 17% | Filter | |
| dBiz |  Remix |
29 – 30% | 30% | 30% | 30% | 30% | 29 – 30% | 30% | 30% | 30% | 30% | Mixer, VCA | |
| dBiz |  SPan |
3% | 3% | 3% | 3% | 3% | 3% | 3% | 3% | 3% | 3% | VCA | |
| dBiz |  Smixer |
16% | 16% | 16% | 16 – 17% | 16% | 16 – 17% | 16 – 17% | 16 – 17% | 16 – 17% | 16% | Mixer, VCA | |
| dBiz |  Smorph |
17 – 18% | 17 – 18% | 17 – 18% | 17 – 18% | 17 – 18% | 17 – 18% | 17 – 18% | 17 – 18% | 17 – 18% | 17 – 18% | Sequencer | |
| dBiz |  SuHa |
27% | 27 – 28% | 27 – 28% | 27 – 28% | 27 – 28% | 27% | 27 – 28% | 27 – 28% | 27 – 28% | 27 – 28% | VCO | |
| dBiz |  SuHaMK2 |
39 – 40% | 39 – 40% | 40 – 41% | 40% | 40% | 39 – 40% | 39 – 40% | 40 – 41% | 40% | 40% | VCO | |
| dBiz |  TROSC |
39 – 51% | 40 – 51% | 40 – 50% | 39 – 50% | 40 – 50% | 39 – 62% | 40 – 62% | 40 – 61% | 39 – 62% | 40 – 61% | VCO | |
| dBiz |  TROSCMK2 |
33 – 37% | 33 – 37% | 33 – 37% | 32 – 37% | 33 – 37% | 33 – 37% | 32 – 37% | 33 – 37% | 32 – 37% | 32 – 37% | VCO | |
| dBiz |  Transpose |
3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | Utility | |
| dBiz |  Util2 |
7 – 9% | 7 – 9% | 7 – 9% | 7 – 9% | 7 – 9% | 7 – 9% | 7 – 10% | 7 – 9% | 7 – 9% | 7 – 9% | Utility | |
| dBiz |  Utility |
12 – 13% | 11 – 12% | 11 – 12% | 11 – 12% | 11 – 12% | 12 – 13% | 11 – 12% | 11 – 12% | 11 – 12% | 11 – 12% | Utility | |
| dBiz |  VCA4 |
6 – 7% | 5 – 7% | 5 – 7% | 5 – 7% | 5 – 7% | 6 – 7% | 5 – 7% | 5 – 7% | 5 – 7% | 5 – 7% | Mixer, VCA | |
| dBiz |  VCA530 |
6 – 7% | 6% | 6% | 6% | 5 – 6% | 6 – 7% | 6% | 6% | 6% | 5 – 6% | Mixer, VCA | |
| dBiz |  Verbo |
62 – 65% | 63 – 65% | 63 – 65% | 63 – 65% | 63 – 65% | 62 – 65% | 63 – 65% | 63 – 65% | 63 – 65% | 63 – 65% | VCO | |
| DrumKit |  Baronial |
7 – 8% | 6 – 8% | 6 – 8% | 6 – 7% | 6 – 7% | 7 – 8% | 6 – 8% | 6 – 8% | 6 – 7% | 6 – 7% | Envelope generator | Drum Focused Envelope Generator |
| DrumKit |  Bass Drum 9 |
3 – 7% | 3 – 6% | 2 – 6% | 2 – 6% | 2 – 6% | 3 – 7% | 3 – 6% | 2 – 6% | 2 – 6% | 2 – 6% | Drum | Bass Drum Kit based on 909 |
| DrumKit |  CR78 |
3 – 6% | 2 – 7% | 2 – 6% | 2 – 6% | 2 – 6% | 3 – 6% | 2 – 7% | 2 – 6% | 2 – 6% | 2 – 6% | DRUM | CompuRhythm 78 Kit |
| DrumKit |  Closed HiHat |
2 – 7% | 2 – 7% | 2 – 6% | 2 – 6% | 2 – 6% | 2 – 7% | 2 – 7% | 2 – 6% | 2 – 6% | 2 – 6% | DRUM | HiHat Module |
| DrumKit |  DMX |
2 – 7% | 2 – 6% | 2 – 6% | 2 – 6% | 2 – 6% | 2 – 7% | 2 – 6% | 2 – 6% | 2 – 6% | 2 – 6% | Drum | DMX Drum Kit |
| DrumKit |  Gnome |
5% | 5 – 6% | 5% | 5% | 5% | 5% | 5 – 6% | 5% | 5% | 5% | Clock generator | Gnome Clock Module |
| DrumKit |  Marionette Bass |
9 – 14% | 9 – 14% | 10 – 14% | 9 – 14% | 9 – 14% | 9 – 14% | 9 – 14% | 10 – 14% | 9 – 14% | 9 – 14% | Drum | Hybrid Bass Drum |
| DrumKit |  Open HiHat |
3 – 9% | 2 – 10% | 3 – 9% | 3 – 9% | 2 – 9% | 3 – 9% | 2 – 10% | 3 – 9% | 3 – 9% | 2 – 9% | Drum | HiHat Module |
| DrumKit |  Sequencer |
8 – 19% | 8 – 18% | 8 – 18% | 8 – 18% | 8 – 18% | 8 – 19% | 8 – 18% | 8 – 18% | 8 – 18% | 8 – 18% | Sequencer | Drum Focused Step Sequencer |
| DrumKit |  Snare Drum N |
3 – 6% | 3 – 6% | 2 – 6% | 2 – 6% | 2 – 6% | 3 – 6% | 3 – 6% | 2 – 6% | 2 – 6% | 2 – 6% | Drum | Snare Drum Kit based on Novation Drumstation |
| DrumKit |  Synthetic Bass Drum |
16 – 18% | 16 – 17% | 16% | 16% | 16% | 16 – 18% | 16 – 17% | 16% | 16% | 16% | Drum | Synthetic Bass Drum |
| DrumKit |  Tomi |
3 – 6% | 2 – 7% | 2 – 6% | 2 – 6% | 2 – 6% | 3 – 6% | 2 – 7% | 2 – 6% | 2 – 6% | 2 – 6% | Drum | Tom Drum Kit Module |
| E-Series |  E340 Cloud Generator |
9 – 20% | 9 – 19% | 9 – 20% | 9 – 19% | 9 – 19% | 9 – 66% | 9 – 67% | 9 – 68% | 9 – 68% | 9 – 68% | VCO, Polyphonic, Hardware clone | Based on Synthesis Technology E340 |
| eightfold |  SDOrcasHeartV2 |
12 – 15% | 12 – 14% | 12 – 14% | 11 – 15% | 11 – 14% | 12 – 15% | 12 – 14% | 12 – 14% | 11 – 15% | 11 – 14% | Arpeggiator, Polyphonic, Sequencer | eight-voice algorithmic sequence generator |
| Fehler Fabrik |  Arpanet |
4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | Sequencer | 1601 Sequencer |
| Fehler Fabrik |  Aspect |
3 – 4% | 3% | 3% | 3% | 3% | 3 – 4% | 3% | 3% | 3% | 3% | Clock modulator | Clock Dividers and Sequential Sequencer |
| Fehler Fabrik |  Botzinger |
4 – 6% | 4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | 4 – 6% | 4 – 6% | 4 – 5% | 4 – 5% | 4 – 5% | Sequencer | Arbitrary Rhythm Generator |
| Fehler Fabrik |  Chi |
2 – 14% | 2 – 14% | 2 – 12% | 2 – 12% | 2 – 12% | 2 – 41% | 2 – 41% | 2 – 41% | 2 – 41% | 2 – 41% | Equalizer, Filter, Poly | 3 Band Crossover |
| Fehler Fabrik |  Fax |
4 – 6% | 4 – 6% | 4 – 6% | 4 – 6% | 4 – 6% | 4 – 6% | 4 – 6% | 4 – 6% | 4 – 6% | 4 – 6% | Sequencer, Recording, Polyphonic | CV Recording Sequencer |
| Fehler Fabrik |  Lilt |
3 – 5% | 4 – 5% | 3 – 5% | 3 – 5% | 3 – 5% | 3 – 5% | 4 – 5% | 3 – 5% | 3 – 5% | 3 – 5% | Clock | Phase-Shifted Shuffling Clock Pair |
| Fehler Fabrik |  Luigi |
3 – 4% | 3 – 4% | 2 – 4% | 3 – 4% | 2 – 3% | 3 – 4% | 3 – 4% | 2 – 4% | 3 – 4% | 2 – 3% | noise, random | Random Clock and Noise/Dust Generator |
| Fehler Fabrik |  Monte |
3 – 4% | 3% | 3% | 2 – 3% | 2 – 3% | 3 – 4% | 3% | 3% | 2 – 3% | 2 – 3% | Sequencer | Probabalistic Clock Generator |
| Fehler Fabrik |  Nova |
5 – 12% | 5 – 9% | 5 – 8% | 5 – 7% | 5 – 7% | 5 – 12% | 5 – 9% | 5 – 8% | 5 – 7% | 5 – 7% | Sampler, Sequencer, Random | Cut-up Sequenced Sampler |
| Fehler Fabrik |  PSI OP |
7 – 13% | 7 – 12% | 7 – 12% | 7 – 12% | 7 – 11% | 7 – 13% | 7 – 12% | 7 – 12% | 7 – 12% | 7 – 11% | Oscillator, Drum, Synth voice | FM Percussion Synth |
| Fehler Fabrik |  Planck |
4% | 4% | 4% | 4% | 4% | 4 – 9% | 4 – 9% | 4 – 9% | 4 – 9% | 4 – 9% | Effect, Polyphonic | Bit Depth and Sample Rate Crusher |
| Fehler Fabrik |  Rasoir |
22 – 26% | 22 – 24% | 22 – 23% | 21 – 23% | 20 – 22% | 22 – 26% | 22 – 24% | 22 – 23% | 21 – 23% | 20 – 22% | Effect, Waveshaper, Slew Limiter, Delay | Asymmetrical Voltage Processor |
| Fehler Fabrik |  Sigma |
2 – 4% | 2 – 3% | 2 – 3% | 2% | 2% | 2 – 4% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | Utility, Polyphonic | Fixed Voltage Adder |
| Fundamental |  8vert |
4 – 5% | 3 – 5% | 3 – 5% | 3 – 5% | 3 – 5% | 4 – 9% | 3 – 8% | 3 – 8% | 3 – 8% | 3 – 8% | Attenuator, Polyphonic | Attenuverts 8 signals or creates constant voltages |
| Fundamental |  ADSR EG |
4 – 6% | 4 – 5% | 4 – 5% | 4% | 4% | 4 – 6% | 4 – 5% | 4 – 5% | 4% | 4% | Envelope Generator, Polyphonic | Generates an envelope with Attack/Decay/Sustain/Release |
| Fundamental |  CV Mix |
2 – 3% | 2% | 2% | 2% | 2% | 2 – 3% | 2% | 2% | 2% | 2% | Mixer, Utility, Polyphonic | Mixes 3 CV signals with attenuverters |
| Fundamental |  Compare |
3 – 4% | 3 – 4% | 3% | 3% | 3% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | Utility, Polyphonic | Compares two voltages |
| Fundamental |  Delay |
21 – 25% | 21 – 23% | 21 – 22% | 20 – 22% | 20 – 21% | 21 – 25% | 21 – 23% | 21 – 22% | 20 – 22% | 20 – 21% | Delay | |
| Fundamental |  Fade |
2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | Panning, Voltage-controlled amplifier, Utility, Polyphonic | Crossfades audio or CV |
| Fundamental |  Gates |
3 – 5% | 4 – 5% | 4 – 5% | 3 – 5% | 3 – 5% | 3 – 14% | 4 – 13% | 4 – 13% | 3 – 13% | 3 – 13% | Polyphonic | Gate processor |
| Fundamental |  LFO |
5 – 10% | 6 – 10% | 5 – 10% | 5 – 10% | 5 – 10% | 5 – 10% | 6 – 10% | 5 – 10% | 5 – 10% | 5 – 10% | LFO, Polyphonic | Low-frequency oscillator |
| Fundamental |  Wavetable LFO |
7 – 9% | 7% | 7% | 7% | 7% | 7 – 9% | 7 – 9% | 7 – 9% | 7 – 9% | 7 – 9% | LFO, Polyphonic | Low-frequency wavetable oscillator |
| Fundamental |  Logic |
3 – 4% | 3% | 3% | 3% | 3% | 3 – 5% | 3 – 5% | 3 – 5% | 3 – 5% | 3 – 5% | Logic, Polyphonic | Gate logic processor |
| Fundamental |  Merge |
2 – 3% | 2 – 4% | 2% | 2% | 2% | 2 – 3% | 2 – 4% | 2% | 2% | 2% | Polyphonic, Utility | Combines multiple monophonic cables into a polyphonic cable |
| Fundamental |  Mid/Side |
2 – 4% | 2 – 4% | 2 – 4% | 2 – 4% | 2 – 4% | 2 – 4% | 2 – 4% | 2 – 4% | 2 – 4% | 2 – 4% | Utility, Polyphonic | Encodes/decodes between mid/side and left/right stereo signals |
| Fundamental |  Mix |
2 – 4% | 2 – 3% | 2% | 2% | 2% | 2 – 4% | 2 – 3% | 2% | 2% | 2% | Mixer, Polyphonic | Mixes 6 signals |
| Fundamental |  Mult |
2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 4% | 2 – 4% | 2 – 4% | 2 – 4% | 2 – 4% | Multiple, Utility, Polyphonic | Copies a signal to 8 outputs |
| Fundamental |  Mutes |
4 – 7% | 3 – 7% | 3 – 6% | 3 – 6% | 3 – 6% | 4 – 9% | 3 – 9% | 3 – 8% | 3 – 8% | 3 – 8% | Switch, Polyphonic | Toggles up to 10 signals |
| Fundamental |  Noise |
2 – 39% | 2 – 21% | 2 – 14% | 2 – 10% | 2 – 8% | 2 – 39% | 2 – 21% | 2 – 14% | 2 – 10% | 2 – 8% | Noise | Multicolored noise generator |
| Fundamental |  Octave |
2 – 3% | 2% | 2% | 2% | 2% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | Utility, Polyphonic | Shifts 1V/oct pitch CV by octaves |
| Fundamental |  Process |
2 – 5% | 3 – 5% | 2 – 5% | 2 – 5% | 2 – 5% | 2 – 12% | 3 – 12% | 2 – 12% | 2 – 12% | 2 – 12% | Polyphonic | CV processor |
| Fundamental |  Pulses |
3% | 3% | 3% | 3% | 3% | 3% | 3% | 3% | 3% | 3% | Switch | Generates up to 10 trigger and gate signals |
| Fundamental |  Push |
2 – 3% | 2% | 2% | 2% | 2% | 2 – 3% | 2% | 2% | 2% | 2% | Utility | Button with gate/trigger outputs and hold switch |
| Fundamental |  Quantizer |
2 – 4% | 2 – 3% | 2 – 3% | 2% | 2% | 2 – 4% (mono) | 2 – 3% (mono) | 2 – 3% (mono) | 2% (mono) | 2% (mono) | Quantizer, Polyphonic | 12-note quantizer and scale selector |
| Fundamental |  Random |
5 – 11% | 4 – 11% | 5 – 11% | 4 – 10% | 4 – 10% | 5 – 11% | 4 – 11% | 5 – 11% | 4 – 10% | 4 – 10% | Random, Sample and hold | Random CV generator |
| Fundamental |  Random Values |
3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 5% | 3 – 6% | 3 – 5% | 3 – 5% | 3 – 5% | Random, Utility, Polyphonic | Generates 7 random fixed voltages |
| Fundamental |  Rescale |
3 – 4% | 3% | 2 – 3% | 2 – 3% | 2% | 3 – 4% | 2 – 3% | 2 – 3% | 2 – 3% | 2% | Attenuator, Utility, Polyphonic | Rescales voltages with gain, offset, and range limiting |
| Fundamental |  SEQ 3 |
6% | 5 – 6% | 5 – 6% | 5 – 6% | 5 – 6% | 6% | 5 – 6% | 5 – 6% | 5 – 6% | 5 – 6% | Sequencer | 3-channel 8-step sequencer also with gate outputs |
| Fundamental |  S&H Analog Shift Register |
3 – 4% | 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 4% | 3 – 4% | 3 – 4% | 3 – 4% | Sample and hold | 8 channel sample & hold combined with a shift register |
| Fundamental |  Scope |
3 – 4% | 3 – 4% | 3 – 4% | 3% | 3% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | Visual, Polyphonic | Inspect waveforms with an oscilloscope |
| Fundamental |  Sequential Switch 1 to 4 |
3% | 3% | 3% | 3% | 3% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | Switch, Utility, Polyphonic | Routes 1 input to one of 4 outputs |
| Fundamental |  Sequential Switch 4 to 1 |
2 – 4% | 2 – 4% | 2 – 3% | 2 – 3% | 2% | 2 – 4% | 2 – 4% | 2 – 3% | 2 – 3% | 2 – 3% | Switch, Utility, Polyphonic | Routes one of 4 inputs to 1 output |
| Fundamental |  Split |
2% | 2% | 2% | 2% | 2% | 2 – 3% | 2% | 2% | 2% | 2% | Polyphonic, Utility | Splits a polyphonic cable into multiple monophonic cables |
| Fundamental |  Sum |
2 – 3% | 2% | 2% | 2% | 2% | 2 – 4% | 2% | 2% | 2% | 2% | Polyphonic, Utility | Sums all channels of a polyphonic cable |
| Fundamental |  Unity |
3 – 5% | 3 – 4% | 3% | 3% | 3% | 3 – 5% | 3 – 4% | 3% | 3% | 3% | Mixer, Utility, Dual | Mixes or averages signals with unity gain |
| Fundamental |  VCA (2 chan) |
4 – 8% | 3 – 7% | 3 – 7% | 3 – 7% | 2 – 7% | 4 – 10% | 3 – 10% | 3 – 10% | 3 – 10% | 2 – 10% | VCA, Dual, Polyphonic | 2-channel voltage-controlled amplifier |
| Fundamental |  VCA |
2 – 4% | 2 – 4% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 5% | 2 – 5% | 2 – 5% | 2 – 5% | 2 – 5% | VCA, Polyphonic | Voltage-controlled amplifier |
| Fundamental |  VCF |
2 – 26% | 2 – 26% | 2 – 26% | 2 – 25% | 2 – 25% | 2 – 26% | 2 – 26% | 2 – 26% | 2 – 25% | 2 – 25% | VCF, Polyphonic | Voltage-controlled filter |
| Fundamental |  VCA Mixer |
4 – 8% | 3 – 7% | 3 – 7% | 3 – 7% | 3 – 7% | 4 – 9% | 3 – 9% | 3 – 9% | 3 – 9% | 3 – 7% | Mixer, VCA, Polyphonic | Mixes 4 signals with built-in VCAs |
| Fundamental |  VCO |
13 – 14% | 13 – 14% | 13 – 14% | 13 – 14% | 13 – 14% | 13 – 15% | 13 – 15% | 13 – 15% | 13 – 15% | 13 – 15% | VCO, Polyphonic | Voltage-controlled oscillator |
| Fundamental |  Wavetable VCO |
10 – 11% | 10 – 11% | 9 – 11% | 9 – 11% | 9 – 11% | 10 – 17% | 10 – 16% | 9 – 15% | 9 – 15% | 9 – 15% | VCO, Polyphonic | Voltage-controlled wavetable oscillator |
| Fundamental |  Viz |
2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | Polyphonic, Visual | Visualizes all channels of a polyphonic cable |
| Geodesics |  BlackHoles |
11 – 12% | 11% | 11% | 11% | 11% | 11 – 31% | 11 – 31% | 11 – 31% | 11 – 31% | 11 – 31% | Ring modulator, VCA, Polyphonic, Attenuator, Controller, Mixer, Quad | Gravitational attenumixset |
| Geodesics |  Branes |
4 – 13% | 4 – 12% | 3 – 13% | 3 – 12% | 3 – 12% | 4 – 13% | 4 – 13% | 3 – 13% | 3 – 12% | 3 – 12% | Sample and hold, Random, Dual, Noise | Coliding sample and hold |
| Geodesics |  DarkEnergy |
8 – 30% | 7 – 31% | 7 – 30% | 7 – 29% | 7 – 29% | 8 – 112% | 7 – 110% | 7 – 110% | 7 – 107% | 7 – 106% | Oscillator, Synth voice, Polyphonic, Digital, LFO | Complex RM FM oscillator |
| Geodesics |  Energy |
3 – 29% | 3 – 29% | 2 – 28% | 3 – 28% | 2 – 28% | 3 – 104% | 3 – 104% | 2 – 104% | 3 – 105% | 2 – 105% | Oscillator, Synth voice, Polyphonic, Digital, LFO | Relativistic oscillator |
| Geodesics |  Entropia |
3 – 5% | 3 – 4% | 3% | 3% | 3 – 4% | 3 – 5% | 3 – 4% | 3% | 3% | 3 – 4% | Sequencer, Switch, Random, Attenuator | Thermodynamic microstate sequencer |
| Geodesics |  Fate |
2 – 3% | 2 – 3% | 2 – 3% | 2% | 2 – 3% | 2 – 4% | 2 – 4% | 2 – 4% | 2 – 3% | 2 – 3% | Utility, Random, Clock modulator, Dual, Switch | Event modifier |
| Geodesics |  Ions |
4% | 4% | 3 – 4% | 3 – 4% | 3 – 4% | 4% | 4% | 3 – 4% | 3 – 4% | 3 – 4% | Sequencer, Dual | Atomic dual cv sequencer |
| Geodesics |  Pulsars |
5 – 7% | 5 – 7% | 5 – 6% | 4 – 6% | 4 – 6% | 5 – 9% | 5 – 10% | 5 – 9% | 4 – 9% | 4 – 9% | Mixer, Polyphonic, Switch, Sequencer | Neutron powered morphing |
| Geodesics |  Torus |
3 – 14% | 3 – 14% | 3 – 14% | 2 – 14% | 2 – 14% | 3 – 16% | 3 – 16% | 3 – 16% | 2 – 16% | 2 – 16% | Mixer, Filter, Equalizer, Multiple, Utility, Attenuator | Bi-dimensional multimixer |
| Geodesics |  Twin Paradox |
5 – 7% | 5 – 7% | 5 – 7% | 5 – 7% | 5 – 7% | 5 – 7% | 5 – 7% | 5 – 7% | 5 – 7% | 5 – 7% | Clock generator | Relativistic clock generator |
| HetrickCV |  2To4 |
4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | Mixer, Polyphonic | Takes two signals and generates four variations. |
| HetrickCV |  ASR |
3 – 4% | 3% | 3% | 3% | 3% | 3 – 4% | 3% | 3% | 3% | 3% | Sequencer | Analog shift register. Multi-stage sample and hold |
| HetrickCV |  AnalogToDigital |
3 – 4% | 3 – 4% | 2 – 3% | 2 – 3% | 2 – 3% | 3 – 4% | 3 – 4% | 2 – 3% | 2 – 3% | 2 – 3% | Logic, Polyphonic | Converts a continuous signal into eight gates representing bit values. |
| HetrickCV |  BinaryGate |
2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | Logic | Manually turn a gate on or off, or toggle its current state. |
| HetrickCV |  BinaryNoise |
2 – 3% | 2 – 3% | 2 – 3% | 2% | 2% | 2 – 3% | 2 – 3% | 2 – 3% | 2% | 2% | Noise, Random | Generates a random gate or square wave signal. |
| HetrickCV |  Bitshift |
5% | 5% | 5% | 5% | 5% | 5% | 5% | 5% | 5% | 5% | Effect, Distortion, Waveshaper, Polyphonic | Bitshifting distortion and waveshaping effect |
| HetrickCV |  Boolean3 |
2 – 3% | 2% | 2% | 2% | 2% | 2 – 3% | 2% | 2% | 2% | 2% | Logic | Six way boolean logic processor |
| HetrickCV |  Chaos1Op |
3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3% | Noise, Random | Multimode audio and modulation chaos generator. |
| HetrickCV |  Chaos2Op |
3 – 4% | 3% | 3% | 3% | 3% | 3 – 4% | 3% | 3% | 3% | 3% | Noise, Random | Multimode audio and modulation chaos generator. |
| HetrickCV |  Chaos3Op |
3 – 4% | 3 – 4% | 3 – 4% | 3% | 2 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3% | 2 – 4% | Noise, Random | Multimode audio and modulation chaos generator. |
| HetrickCV |  ChaoticAttractors |
3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | Noise, Random | Multimode audio and modulation chaos generator. |
| HetrickCV |  ClockedNoise |
3% | 3% | 3% | 3% | 3% | 3% | 3% | 3% | 3% | 3% | Noise, Random | Multimode audio and modulation noise generator. |
| HetrickCV |  Comparator |
3% | 3 – 4% | 3% | 3% | 3% | 3% | 3 – 4% | 3% | 3% | 3% | Logic, Utility | Determine whether a signal is above or below a threshold. |
| HetrickCV |  Contrast |
5% | 5 – 6% | 5% | 5% | 5% | 5% | 5 – 6% | 5% | 5% | 5% | Effect, Distortion, Polyphonic | A mild distortion that brightens up a signal. |
| HetrickCV |  Crackle |
2 – 4% | 2 – 4% | 2 – 3% | 2 – 3% | 2% | 2 – 4% | 2 – 4% | 2 – 3% | 2 – 3% | 2% | Noise | Vinyl-like noise generator ported from SuperCollider. |
| HetrickCV |  DataCompander |
8 – 13% | 8 – 11% | 8 – 11% | 7 – 11% | 8 – 11% | 8 – 18% | 8 – 18% | 8 – 18% | 7 – 18% | 8 – 18% | Utility, Waveshaper, Polyphonic | Compresses and expands signals with a-law or mu-law compansion. |
| HetrickCV |  Delta |
3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3% | Logic, Utility | Determine which direction a signal is heading. |
| HetrickCV |  DigitalToAnalog |
2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | Logic, Polyphonic | Converts eight gates to a smooth signal. |
| HetrickCV |  Dust |
3 – 4% | 3 – 4% | 3 – 4% | 3% | 3% | 3 – 4% | 3 – 4% | 3 – 4% | 3% | 3% | Noise, Granular | Random impulse and noise generator ported from SuperCollider |
| HetrickCV |  Exponent |
5% | 5% | 5% | 5% | 5% | 5% | 5% | 5% | 5% | 5% | Waveshaper, Polyphonic | Raise a signal to a power |
| HetrickCV |  FBSineChaos |
3 – 4% | 3 – 4% | 3% | 3% | 3% | 3 – 4% | 3 – 4% | 3% | 3% | 3% | Noise, Oscillator, Low-frequency Oscillator, Random | A chaotic oscillator and LFO created through phase distortion and feedback. |
| HetrickCV |  FlipFlop |
2 – 3% | 2% | 2% | 2% | 2% | 2 – 3% | 2% | 2% | 2% | 2% | Logic | A flexible toggle switch |
| HetrickCV |  FlipPan |
3 – 4% | 3 – 4% | 3% | 3% | 3% | 3 – 4% | 3 – 4% | 3% | 3% | 3% | Panning, VCA, Utility, Polyphonic | A bidirectional panner, crossfader, and VCA |
| HetrickCV |  GateDelay |
3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3% | 3 – 7% | 3 – 7% | 3 – 7% | 3 – 7% | 3 – 7% | Utility, Clock Modulator, Polyphonic | Trigger input to delayed Gate output |
| HetrickCV |  GateJunction |
4% | 4% | 4% | 4% | 4% | 4% | 4% | 4% | 4% | 4% | Switch, Logic | Eight channel gate processor. |
| HetrickCV |  GateJunctionExp |
6 – 8% | 6 – 7% | 6 – 7% | 6 – 7% | 6 – 7% | 6 – 8% | 6 – 8% | 6 – 8% | 6 – 8% | 6 – 8% | Switch, Logic, Polyphonic | Eight channel gate processor, expanded with more jacks and polyphony. |
| HetrickCV |  Gingerbread |
3% | 3% | 3% | 3% | 3% | 3% | 3% | 3% | 3% | 3% | Noise, Random | Self-modulating audio and modulation chaos generator. |
| HetrickCV |  LogicCombine |
3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3% | 3 – 5% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | Logic, Polyphonic | Combines multiple gates into one gate. |
| HetrickCV |  MidSide |
3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3% | Utility, Polyphonic | Converts Left/Right signals to Mid/Side and vice versa. |
| HetrickCV |  MinMax |
3 – 4% | 3% | 3% | 3% | 3% | 3 – 4% | 3 – 4% | 3% | 3% | 3 – 4% | Utility, Polyphonic | Outputs the greatest and least voltages from up to 4 inputs. |
| HetrickCV |  PhaseDrivenSequencer |
8 – 9% | 8 – 9% | 8 – 9% | 8 – 9% | 8 – 9% | 8 – 14% | 8 – 14% | 8 – 14% | 8 – 14% | 8 – 14% | Clock Modulator, Sequencer, Polyphonic | A 16-step gate and voltage sequencer driven by a phasor. |
| HetrickCV |  PhaseDrivenSequencer32 |
11 – 12% | 11 – 12% | 11 – 13% | 11 – 12% | 11 – 12% | 11 – 18% | 11 – 18% | 11 – 18% | 11 – 18% | 11 – 18% | Clock Modulator, Sequencer, Polyphonic | A 32-step gate and voltage sequencer driven by a phasor. |
| HetrickCV |  PhasorAnalyzer |
4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | 4 – 9% | 4 – 9% | 4 – 9% | 4 – 9% | 4 – 9% | Utility, Polyphonic | Detects multiple movement parameters from an incoming phasor signal. |
| HetrickCV |  PhasorBurstGen |
7 – 8% | 6 – 7% | 6 – 7% | 6 – 7% | 6 – 7% | 7 – 18% | 6 – 18% | 6 – 18% | 6 – 17% | 6 – 17% | Oscillator, Clock Generator, Clock Modulator, Low-frequency Oscillator, Polyphonic | Generates a phasor repeatedly for a given number of times. |
| HetrickCV |  PhasorDivMult |
4 – 5% | 5% | 5% | 5% | 5% | 4 – 10% | 5 – 11% | 5 – 10% | 5 – 10% | 5 – 10% | Clock Modulator, Polyphonic | Processes a phasor signal and outputs a phasor at a precise, variable time multiple or division. |
| HetrickCV |  PhasorEuclidean |
7 – 8% | 7% | 7% | 7% | 7% | 7 – 18% | 7 – 18% | 7 – 18% | 7 – 18% | 7 – 18% | Clock Generator, Clock Modulator, Polyphonic | Generates a Euclidean rhythm via a 0-5V Phasor input |
| HetrickCV |  PhasorGates |
6% | 6% | 6% | 6% | 6% | 6 – 13% | 6 – 11% | 6 – 11% | 6 – 11% | 6 – 10% | Clock Modulator, Sequencer, Polyphonic | An 8-step gate sequencer driven by a phasor. |
| HetrickCV |  PhasorGates32 |
12 – 13% | 13% | 13% | 13% | 13% | 12 – 18% | 13 – 18% | 13 – 18% | 13 – 18% | 13 – 18% | Clock Modulator, Sequencer, Polyphonic | A 32-step gate sequencer driven by a phasor. |
| HetrickCV |  PhasorGates64 |
21% | 21% | 21% | 21% | 21% | 21 – 26% | 21 – 26% | 21 – 26% | 21 – 26% | 21 – 26% | Clock Modulator, Sequencer, Polyphonic | A 64-step gate sequencer driven by a phasor. |
| HetrickCV |  PhasorGen |
7% | 7% | 7% | 7% | 6 – 7% | 7 – 17% | 7 – 18% | 7 – 17% | 7 – 17% | 6 – 17% | Oscillator, Clock Generator, Clock Modulator, Low-frequency Oscillator, Random, Polyphonic | Generates a phasor along with time-synced gates. |
| HetrickCV |  PhasorGeometry |
3% | 3% | 3% | 3% | 3% | 3 – 5% | 3 – 5% | 3 – 5% | 3 – 5% | 3 – 5% | Waveshaper, Distortion, Polyphonic | Processes phasor signals with useful waveshapers. |
| HetrickCV |  PhasorHumanizer |
4% | 4% | 4% | 4% | 4% | 4 – 11% | 4 – 11% | 4 – 11% | 4 – 10% | 4 – 10% | Waveshaper, Clock Modulator, Polyphonic | Repeatedly modifies the slope of an incoming phasor to make the timing less robotic. |
| HetrickCV |  PhasorMixer |
3% | 3% | 3% | 3% | 3% | 3 – 5% | 3 – 5% | 3 – 5% | 3 – 5% | 3 – 4% | Mixer, Polyphonic | Adds together multiple signals and forces them into a unipolar range via folding or wrapping. |
| HetrickCV |  PhasorOctature |
4% | 4% | 4% | 3 – 4% | 3 – 4% | 4 – 6% | 4 – 6% | 4 – 6% | 3 – 6% | 3 – 6% | Waveshaper, Low-frequency Oscillator, Polyphonic | Takes a phasor and rotates it at 45 degree intervals. |
| HetrickCV |  PhasorQuadrature |
6 – 7% | 6 – 7% | 6 – 7% | 6 – 7% | 6 – 7% | 6 – 18% | 6 – 18% | 6 – 18% | 6 – 17% | 6 – 16% | Waveshaper, Low-frequency Oscillator, Polyphonic | Shapes a phasor into a sine, and outputs both phasors and sines at 90 degree intervals. |
| HetrickCV |  PhasorRandom |
5 – 6% | 5 – 6% | 5 – 6% | 5 – 6% | 5 – 6% | 5 – 14% | 5 – 14% | 5 – 14% | 5 – 14% | 5 – 13% | Random, Polyphonic | Randomizes phasor signals to create different offset patterns for sequencers. |
| HetrickCV |  PhasorRanger |
3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | Utility, Polyphonic | Converts HetrickCV phasor signals (and any other unipolar signal) to other useful voltage ranges. |
| HetrickCV |  PhasorReset |
3 – 4% | 3 – 4% | 3 – 4% | 3% | 3% | 3 – 7% | 3 – 7% | 3 – 7% | 3 – 7% | 3 – 7% | Utility, Polyphonic | Duplicates an incoming phasor, but allows you to reset it independently of the input. |
| HetrickCV |  PhasorRhythmGroup |
6 – 9% | 5 – 7% | 5 – 7% | 5 – 7% | 5 – 6% | 6 – 16% | 5 – 16% | 5 – 16% | 5 – 16% | 5 – 16% | Clock Generator, Clock Modulator, Polyphonic | Generates a clock by dividing a phasor into a series of triggers, and then groups the clock into two subrhythms. |
| HetrickCV |  PhasorShape |
3 – 5% | 3 – 5% | 3 – 4% | 3 – 5% | 3 – 5% | 3 – 10% | 3 – 9% | 3 – 9% | 3 – 9% | 3 – 9% | Waveshaper, Distortion, Clock Modulator, Polyphonic | Processes phasor signals in interesting ways for sequence modification or phase distortion synthesis. |
| HetrickCV |  PhasorShift |
4% | 4% | 4% | 3 – 4% | 3 – 4% | 4 – 7% | 4 – 7% | 4 – 7% | 3 – 7% | 3 – 7% | Waveshaper, Polyphonic | Processes phasor signals and provides a phase shifted output, optionally quantized to step distances. |
| HetrickCV |  PhasorStutter |
4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | 4 – 11% | 4 – 10% | 4 – 10% | 4 – 10% | 4 – 10% | Waveshaper, Clock Modulator, Polyphonic | Processes phasor signals and adds stutters/ratchets/repeats within substeps. |
| HetrickCV |  PhasorSubstepShape |
5 – 8% | 5 – 7% | 5 – 7% | 5 – 7% | 5 – 6% | 5 – 13% | 5 – 13% | 5 – 13% | 5 – 13% | 5 – 13% | Waveshaper, Distortion, Clock Modulator, Polyphonic | Processes individual steps of phasor signals in interesting ways for sequence modification or phase distortion synthesis. |
| HetrickCV |  PhasorSwing |
6 – 7% | 6 – 7% | 6 – 7% | 6 – 7% | 6 – 7% | 6 – 16% | 6 – 16% | 6 – 16% | 6 – 16% | 6 – 16% | Waveshaper, Clock Modulator, Polyphonic | Bends a phasor input to provide swing timing on the outputs. |
| HetrickCV |  PhasorTimetable |
9% | 9% | 9% | 9% | 9% | 9 – 27% | 9 – 27% | 9 – 27% | 9 – 27% | 9 – 27% | Waveshaper, Clock Modulator, Polyphonic | Processes a phasor signal and outputs phasors and standard timing ratios. |
| HetrickCV |  PhasorToClock |
4% | 4% | 4% | 4% | 4% | 4 – 9% | 4 – 8% | 4 – 8% | 4 – 8% | 4 – 8% | Clock Generator, Clock Modulator, Polyphonic | Generates a clock by dividing a phasor into a series of gates. |
| HetrickCV |  PhasorToLFO |
6 – 8% | 6 – 7% | 6 – 7% | 6% | 6% | 6 – 14% | 6 – 14% | 6 – 14% | 6 – 14% | 6 – 14% | Waveshaper, Low-frequency Oscillator, Polyphonic | Shapes incoming phasor signals to useful, morphing LFO waveshapes. These waveforms are not anti-aliased, hence the LFO designation. |
| HetrickCV |  PhasorToWaveforms |
4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | 4 – 8% | 4 – 9% | 4 – 9% | 4 – 9% | 4 – 8% | Waveshaper, Low-frequency Oscillator, Polyphonic | Shapes incoming phasor signals to useful, static LFO waveshapes. These waveforms are not anti-aliased, hence the LFO designation. |
| HetrickCV |  Probability |
3% | 3% | 3% | 3% | 3% | 3 – 5% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | Random, Polyphonic | Sends one gate to two places randomly. |
| HetrickCV |  RandomGates |
5 – 6% | 5% | 5% | 5% | 5% | 5 – 6% | 5% | 5% | 5% | 5% | Random | Generates up to eight random gates. |
| HetrickCV |  Rotator |
9% | 9 – 10% | 9% | 9 – 10% | 9% | 9 – 10% | 9 – 10% | 9 – 10% | 9 – 10% | 9% | Switch | Eight-way channel rotation. |
| HetrickCV |  Rungler |
3% | 3% | 3% | 3% | 3% | 3% | 3% | 3% | 3% | 3% | Sequencer, Random | 8-Bit Shift Register and Comparator with stepped signal output via bits 6, 7, and 8. |
| HetrickCV |  Scanner |
11 – 12% | 11 – 12% | 11 – 12% | 11 – 12% | 11 – 12% | 11 – 28% | 11 – 28% | 11 – 28% | 11 – 28% | 11 – 28% | Mixer, Switch | 8-channel signal crossfader, mixer, scanner, and router. |
| HetrickCV |  VectorMix |
6% | 5 – 6% | 6% | 5 – 6% | 5 – 6% | 6% | 5 – 6% | 6% | 5 – 6% | 5 – 6% | Mixer, Polyphonic | Two-dimensional crossfading between four signals. |
| HetrickCV |  Waveshaper |
3% | 3 – 4% | 3 – 4% | 3% | 3% | 3% | 3 – 4% | 3 – 4% | 3% | 3% | Distortion, Effect, Waveshaper, Polyphonic | Modulatable hyperbolic waveshaper |
| HetrickCV |  XYToPolar |
7% | 7 – 8% | 7 – 8% | 7% | 7% | 7% | 7 – 8% | 7 – 8% | 7% | 7% | Utility, Waveshaper, Polyphonic | Converts XY coordinates to Polar and vice versa. |
| Impromptu |  AdaptiveQuantizer |
4 – 7% | 3 – 6% | 3 – 6% | 3 – 5% | 3 – 5% | 4 – 8% | 3 – 6% | 3 – 6% | 3 – 6% | 3 – 5% | Quantizer | Adaptive reference based quantizer |
| Impromptu |  BigButtonSeq |
4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | Sequencer | 6-channel, 64-step trigger sequencer |
| Impromptu |  BigButtonSeq2 |
6 – 7% | 6 – 7% | 6 – 7% | 6 – 7% | 6% | 6 – 9% | 6 – 7% | 6 – 7% | 6 – 7% | 6 – 7% | Sequencer | 6-channel, 128-step sequencer |
| Impromptu |  ChordKey |
4% | 4% | 3 – 4% | 3 – 4% | 3 – 4% | 4% | 4% | 3 – 4% | 3 – 4% | 3 – 4% | Sequencer, Polyphonic | Keyboard-based chord generator |
| Impromptu |  Clocked |
7 – 9% | 7 – 8% | 7% | 7% | 7% | 7 – 9% | 7 – 8% | 7% | 7% | 7% | Clock generator | Chainable master clock with swing, clock delay and pulse width |
| Impromptu |  Clkd |
5 – 7% | 5 – 6% | 5 – 6% | 5 – 6% | 5 – 6% | 5 – 7% | 5 – 6% | 5 – 6% | 5 – 6% | 5 – 6% | Clock generator | Chainable master clock |
| Impromptu |  CV-Pad |
4% | 3 – 4% | 3% | 3% | 3% | 4% | 3 – 4% | 3% | 3% | 3% | Controller | 16-pad CV controller |
| Impromptu |  Foundry |
7 – 10% | 7 – 8% | 7 – 8% | 6 – 7% | 7% | 7 – 10% | 7 – 8% | 6 – 8% | 6 – 7% | 6 – 7% | Sequencer | 4-track, 32-step, 64-pattern sequencer |
| Impromptu |  GateSeq64 |
4 – 5% | 3 – 5% | 3 – 4% | 3% | 3% | 4 – 5% | 3 – 5% | 3 – 4% | 3% | 3% | Sequencer | 64-step, 32-pattern gate sequencer |
| Impromptu |  NoteEcho |
6 – 7% | 6 – 7% | 6 – 7% | 5 – 6% | 5 – 6% | 6 – 8% | 6 – 7% | 6 – 7% | 5 – 7% | 5 – 7% | Sample and hold, Delay, Polyphonic | CV/Gate-based delay |
| Impromptu |  Part |
3 – 5% | 3% | 3% | 2 – 3% | 2% | 3 – 5% | 3% | 3% | 2 – 3% | 2 – 3% | Utility, Polyphonic | Polyphonic gate splitter |
| Impromptu |  PhraseSeq16 |
4% | 4 – 5% | 4% | 3 – 4% | 3 – 4% | 4% | 4 – 5% | 3 – 4% | 3 – 4% | 3 – 4% | Sequencer | 16-step, 16-pattern sequencer |
| Impromptu |  PhraseSeq32 |
4 – 5% | 4 – 5% | 4% | 4% | 4% | 4 – 5% | 4 – 5% | 4 – 5% | 4% | 4% | Sequencer | 32-step, 32-pattern sequencer |
| Impromptu |  ProbKey |
4 – 5% | 3 – 5% | 3 – 4% | 3 – 4% | 3 – 4% | 4 – 7% | 3 – 7% | 3 – 6% | 3 – 6% | 3 – 6% | Sequencer, Random, Polyphonic | Keyboard-based random sequencer |
| Impromptu |  Sygen |
2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | Utility | Synchronous gate enable |
| Impromptu |  Variations |
2 – 5% | 2 – 4% | 2 – 4% | 2 – 4% | 2 – 4% | 2 – 5% | 2 – 4% | 2 – 4% | 2 – 4% | 2 – 4% | Sample and hold, Random, Noise, Polyphonic | Sample and hold a CV with addition of a random noise value |
| Impromptu |  WriteSeq32 |
3 – 4% | 3 – 4% | 3% | 3% | 3% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3% | Sequencer | 3-channel, 32-step sequencer |
| Impromptu |  WriteSeq64 |
3 – 4% | 3 – 4% | 3% | 3% | 3% | 3 – 4% | 3 – 4% | 3% | 3% | 3% | Sequencer | 4-channel, 64-step sequencer |
| JWModules |  0Cat |
2% | 2% | 2% | 2% | 2% | 2% (mono) | 2% (mono) | 2% (mono) | 2% (mono) | 2% (mono) | Visual | |
| JWModules |  1Pattern |
2 – 3% | 2 – 3% | 2 – 3% | 2% | 2% | 2 – 3% | 2 – 3% | 2 – 3% | 2% | 2 – 3% | Sequencer, Clock Modulator | |
| JWModules |  8Seq |
5 – 10% | 5 – 10% | 5 – 9% | 5 – 8% | 5 – 8% | 5 – 10% | 5 – 10% | 5 – 9% | 5 – 8% | 5 – 8% | Sequencer | |
| JWModules |  AbcdSeq |
24 – 38% | 24 – 37% | 24 – 35% | 24 – 33% | 24 – 34% | 24 – 38% | 24 – 38% | 24 – 36% | 24 – 35% | 24 – 35% | Sequencer | |
| JWModules |  Add5 |
3 – 14% | 3 – 14% | 3 – 13% | 3 – 12% | 3 – 12% | 3 – 39% | 3 – 40% | 3 – 40% | 3 – 40% | 3 – 40% | Utility, Poly | |
| JWModules |  Arrange |
5 – 14% | 5 – 12% | 5 – 10% | 5 – 10% | 5 – 9% | 5 – 15% | 5 – 12% | 5 – 11% | 5 – 10% | 5 – 10% | Sequencer, Utility, Switch, Poly | |
| JWModules |  Arrange16 |
5 – 9% | 5 – 8% | 5 – 8% | 5 – 8% | 5 – 7% | 5 – 10% | 5 – 9% | 5 – 9% | 5 – 8% | 5 – 8% | Sequencer, Utility, Switch, Poly | |
| JWModules |  Blank Panel (1HP) |
2% | 2% | 2% | 2% | 2% | 2% (mono) | 2% (mono) | 2% (mono) | 2% (mono) | 2% (mono) | Visual | |
| JWModules |  Blank Panel (2HP) |
2% | 2% | 2% | 2% | 2% | 2% (mono) | 2% (mono) | 2% (mono) | 2% (mono) | 2% (mono) | Visual | |
| JWModules |  Blank Panel (4HP) |
2% | 2% | 2% | 2% | 2% | 2% (mono) | 2% (mono) | 2% (mono) | 2% (mono) | 2% (mono) | Visual | |
| JWModules |  Blank Panel (Large) |
2% | 2% | 2% | 2% | 2% | 2% (mono) | 2% (mono) | 2% (mono) | 2% (mono) | 2% (mono) | Visual | |
| JWModules |  Blank Panel (Medium) |
2% | 2% | 2% | 2% | 2% | 2% (mono) | 2% (mono) | 2% (mono) | 2% (mono) | 2% (mono) | Visual | |
| JWModules |  Blank Panel (Small) |
2% | 2% | 2% | 2% | 2% | 2% (mono) | 2% (mono) | 2% (mono) | 2% (mono) | 2% (mono) | Visual | |
| JWModules |  Bouncy Balls |
16 – 28% | 16 – 28% | 17 – 28% | 16 – 28% | 16 – 28% | 16 – 28% | 16 – 28% | 17 – 28% | 16 – 28% | 16 – 28% | Sequencer, Visual | |
| JWModules |  Buffer |
12 – 34% | 11 – 23% | 11 – 17% | 11 – 17% | 11 – 17% | 12 – 34% | 11 – 23% | 11 – 18% | 11 – 17% | 11 – 17% | Effect, Delay | |
| JWModules |  Cool Breeze |
2% | 2% | 2% | 2% | 2% | 2% (mono) | 2% (mono) | 2% (mono) | 2% (mono) | 2% (mono) | Visual | |
| JWModules |  D1v1de |
2 – 3% | 2% | 2% | 2% | 2% | 2 – 3% | 2% | 2% | 2% | 2% | Clock modulator, Visual | Clock Divider |
| JWModules |  DivSeq |
8 – 9% | 7 – 9% | 7 – 9% | 7 – 8% | 7 – 8% | 8 – 9% | 7 – 9% | 7 – 9% | 7 – 8% | 7 – 9% | Sequencer | |
| JWModules |  FM16Seq |
15 – 31% | 15 – 30% | 15 – 29% | 15 – 29% | 15 – 29% | 15 – 31% | 15 – 30% | 15 – 29% | 15 – 29% | 15 – 29% | Sequencer, Oscillator | |
| JWModules |  FM4Dice |
3 – 56% | 4 – 57% | 4 – 54% | 3 – 54% | 3 – 54% | 3 – 56% | 4 – 57% | 4 – 54% | 3 – 54% | 3 – 54% | Oscillator, Synth Voice, Random | |
| JWModules |  Fract |
4% | 4% | 4% | 4% | 4% | 4 – 5% | 4% | 4% | 4% | 4% | Clock Modulator, Delay | |
| JWModules |  Full Scope |
3 – 4% | 3 – 4% | 3% | 3% | 3% | 3 – 4% | 3 – 4% | 3% | 3% | 3% | Visual | |
| JWModules |  Grains |
4 – 27% | 2 – 21% | 2 – 18% | 2 – 16% | 2 – 16% | 4 – 27% | 2 – 21% | 2 – 18% | 2 – 16% | 2 – 16% | Sampler, Granular | |
| JWModules |  GridSeq |
6 – 14% | 6 – 12% | 6 – 12% | 6 – 12% | 6 – 12% | 6 – 16% | 6 – 13% | 6 – 13% | 6 – 12% | 6 – 12% | Sequencer | |
| JWModules |  Min Max |
3% | 3% | 3% | 3% | 3% | 3% | 3% | 3% | 3% | 3% | Utility | |
| JWModules |  NoteSeq |
5 – 164% | 5 – 162% | 5 – 160% | 5 – 158% | 5 – 156% | 5 – 165% | 5 – 162% | 5 – 160% | 5 – 158% | 5 – 156% | Sequencer, Poly | |
| JWModules |  NoteSeq16 |
3 – 104% | 3 – 114% | 3 – 94% | 3 – 93% | 3 – 90% | 3 – 104% | 3 – 114% | 3 – 94% | 3 – 93% | 3 – 91% | Sequencer, Poly | |
| JWModules |  NoteSeqFu |
9 – 82% | 9 – 64% | 9 – 56% | 9 – 54% | 9 – 51% | 9 – 82% | 9 – 64% | 9 – 56% | 9 – 54% | 9 – 52% | Sequencer, Poly | |
| JWModules |  Patterns |
9 – 16% | 9 – 15% | 10 – 16% | 9 – 15% | 9 – 15% | 9 – 16% | 9 – 15% | 10 – 16% | 9 – 15% | 9 – 15% | Sequencer, Clock Modulator | |
| JWModules |  Pete |
2% | 2% | 2% | 2% | 2% | 2% (mono) | 2% (mono) | 2% (mono) | 2% (mono) | 2% (mono) | Visual | |
| JWModules |  Pres1t |
2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | Utility | Voltage Storage |
| JWModules |  Quantizer |
3 – 7% | 3 – 6% | 3 – 6% | 3 – 6% | 3 – 6% | 3 – 12% | 3 – 12% | 3 – 12% | 3 – 12% | 3 – 12% | Quantizer, Poly | |
| JWModules |  Random Sound |
7 – 13% | 6 – 13% | 6 – 13% | 6 – 12% | 6 – 13% | 7 – 13% | 6 – 13% | 6 – 13% | 6 – 12% | 6 – 13% | Oscillator, Random, Poly | |
| JWModules |  Sample Grid |
5 – 6% | 5 – 6% | 5 – 6% | 5 – 6% | 5 – 6% | 5 – 6% | 5 – 6% | 5 – 6% | 5 – 6% | 5 – 6% | Sampler, Poly | |
| JWModules |  Shift Register Random |
13 – 14% | 12 – 14% | 12 – 14% | 12 – 14% | 12 – 14% | 13 – 14% | 12 – 14% | 12 – 14% | 12 – 14% | 12 – 14% | Utility, Poly | |
| JWModules |  Simple Clock |
3 – 4% | 3 – 4% | 3 – 4% | 2 – 3% | 2 – 3% | 3 – 4% | 3 – 4% | 3 – 4% | 2 – 3% | 2 – 3% | Clock, Random | |
| JWModules |  Stereo Switch |
3% | 3% | 3% | 3% | 3% | 3% | 3% | 3% | 3% | 3% | Utility | |
| JWModules |  Stereo Switch Inverted |
3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3% | Utility | |
| JWModules |  Str1ker |
3 – 8% | 3 – 8% | 3 – 7% | 3 – 8% | 3 – 7% | 3 – 8% | 3 – 8% | 3 – 7% | 3 – 8% | 3 – 7% | Clock | |
| JWModules |  Subtract5 |
3 – 13% | 3 – 14% | 3 – 14% | 3 – 12% | 3 – 12% | 3 – 39% | 3 – 40% | 3 – 40% | 3 – 40% | 3 – 40% | Utility, Poly | |
| JWModules |  Thing Thing |
2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | Visual | |
| JWModules |  Timer |
2 – 3% | 2 – 3% | 2 – 3% | 2% | 2% | 2 – 3% | 2 – 3% | 2 – 3% | 2% | 2% | Clock, Utility | |
| JWModules |  Tree |
2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | Visual | |
| JWModules |  Trigs |
3 – 12% | 3 – 10% | 3 – 10% | 3 – 10% | 3 – 10% | 3 – 12% | 3 – 12% | 3 – 11% | 3 – 11% | 3 – 11% | Sequencer | |
| JWModules |  Wav Head |
2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | Visual, Poly | |
| JWModules |  XY Pad |
3 – 4% | 3 – 4% | 3% | 3% | 3% | 3 – 4% | 3 – 4% | 3% | 3% | 3% | LFO, Random | |
| kocmoc |  DDLY |
4% | 4% | 3 – 4% | 3 – 4% | 3 – 4% | 4% | 4% | 3 – 4% | 3 – 4% | 3 – 4% | Delay | Digital Delay |
| kocmoc |  DIOD |
22 – 23% | 23% | 23% | 23% | 23% | 22 – 84% | 23 – 85% | 23 – 85% | 23 – 85% | 23 – 85% | Filter, Polyphonic | 4-pole Diode Ladder Filter |
| kocmoc |  LADR |
21 – 23% | 21 – 22% | 21 – 22% | 21 – 22% | 21 – 22% | 21 – 79% | 21 – 80% | 21 – 81% | 21 – 81% | 21 – 81% | Filter, Polyphonic | 4-pole Ladder Filter |
| kocmoc |  MUL |
2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | Utility | Multiplier |
| kocmoc |  OP |
5 – 6% | 5 – 6% | 5 – 6% | 5 – 6% | 5 – 6% | 5 – 16% | 5 – 15% | 5 – 16% | 5 – 15% | 5 – 15% | Oscillator, Polyphonic | Phase-modulation operator |
| kocmoc |  PHASR |
5 – 6% | 5 – 6% | 5 – 6% | 5 – 6% | 5 – 6% | 5 – 11% | 5 – 10% | 5 – 10% | 5 – 10% | 5 – 10% | Oscillator | Phasor oscillator |
| kocmoc |  SKF |
11 – 13% | 11 – 13% | 11 – 13% | 11 – 13% | 11 – 13% | 11 – 44% | 11 – 44% | 11 – 44% | 11 – 44% | 11 – 44% | Filter, Polyphonic | Sallen-Key filter |
| kocmoc |  SVF |
18 – 19% | 18 – 19% | 18 – 19% | 18 – 19% | 18 – 19% | 18 – 68% | 18 – 68% | 18 – 68% | 18 – 68% | 18 – 68% | Filter, Polyphonic | State Variable Filter |
| kocmoc |  TRG |
3 – 4% | 3 – 4% | 3% | 3% | 3% | 3 – 4% | 3 – 4% | 3% | 3% | 3% | Sequencer | Trigger Sequencer |
| kocmoc |  uLADR |
5 – 9% | 5 – 8% | 6 – 7% | 5 – 7% | 5 – 7% | 5 – 18% | 5 – 18% | 6 – 19% | 5 – 18% | 5 – 18% | Filter, Polyphonic | 4-pole Ladder Filter |
| kocmoc |  uSVF |
4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | 4 – 11% | 4 – 11% | 4 – 11% | 4 – 11% | 4 – 11% | Filter, Polyphonic | State Variable Filter |
| KRTPluginA |  A |
11% | 11% | 11% | 11% | 11% | 11 – 30% | 11 – 30% | 11 – 30% | 11 – 30% | 11 – 30% | Effect, Filter, Polyphonic | Plate 18 dB filter. Band pass phased ring mod. Other ins and outs with different order are available. The ring modulation is between a low and high pass for a band pass with harmonics effect. |
| KRTPluginA |  B |
8 – 9% | 8 – 9% | 8 – 9% | 8 – 9% | 8 – 9% | 8 – 23% | 8 – 23% | 8 – 23% | 8 – 23% | 8 – 23% | Switch, Controller, Polyphonic | Crossbar performance switch. Remembers internal routing for performance switching. |
| KRTPluginA |  C |
13 – 14% | 13 – 14% | 13 – 14% | 13 – 14% | 13 – 14% | 13 – 20% | 13 – 20% | 13 – 20% | 13 – 20% | 13 – 20% | Attenuator, Mixer, Utility, Polyphonic | A set of three attenuverters with mixing. Kind of useful chainable mixer. Includes LPF per channel. |
| KRTPluginA |  ;D |
8% | 8% | 8% | 8% | 8% | 8 – 14% | 8 – 13% | 8 – 13% | 8 – 13% | 8 – 13% | Utility, Attenuator, Voltage-controlled amplifier, Dynamics, Polyphonic | Exponential VCA and future estimator with error? A very simple utility. |
| KRTPluginA |  E |
7 – 9% | 6 – 9% | 7% | 7% | 6 – 7% | 7 – 9% | 6 – 9% | 7 – 8% | 7 – 8% | 6 – 8% | Envelope generator, Voltage-controlled amplifier, Polyphonic | Simple AR envelope with VCA. Nice. Gained modulation out. |
| KRTPluginA |  F |
14 – 15% | 14 – 15% | 14 – 15% | 14 – 15% | 14 – 15% | 14 – 48% | 14 – 49% | 14 – 49% | 14 – 49% | 14 – 49% | Filter, Polyphonic | 24 dB morph filter. A 2D interpolation and extrapolation between 4 classic analytic filter responses of Bessel, Butterworth, Linkwitz and Legendre. Includes an inter-pole distortion effect and morphing to the inverse filter. |
| KRTPluginA |  G |
12 – 14% | 13 – 14% | 12 – 14% | 12 – 13% | 12 – 13% | 12 – 30% | 13 – 30% | 12 – 30% | 12 – 30% | 12 – 30% | Polyphonic, Compressor, Limiter, Dynamics | Compressor with control outs. Has a low pass peaking filter. |
| KRTPluginA |  H |
6 – 7% | 6 – 7% | 6 – 7% | 6 – 7% | 6 – 7% | 6 – 17% | 6 – 17% | 6 – 17% | 6 – 17% | 6 – 17% | Polyphonic, Oscillator | Base gimpathizer. An organ with phase modulation. Bass how low can you go? |
| KRTPluginA |  I |
3 – 4% | 3% | 2 – 3% | 3% | 2 – 3% | 3 – 5% | 3 – 5% | 2 – 4% | 3 – 4% | 2 – 4% | Clock modulator, Polyphonic | Clock divider with downbeat extract. |
| KRTPluginA |  J |
8% | 8% | 8% | 8% | 8% | 8 – 24% | 8 – 23% | 8 – 24% | 8 – 24% | 8 – 24% | Filter, Polyphonic, Utility, Phaser, Low-frequency oscillator | All-pass filter and phaser. Has an LFO built-in. |
| KRTPluginA |  K |
9% | 9% | 9% | 9% | 9% | 9 – 27% | 9 – 27% | 9 – 27% | 9 – 27% | 9 – 27% | Polyphonic, Oscillator | Phase modulation oscillator. |
| KRTPluginA |  L |
4 – 5% | 4 – 5% | 5% | 4 – 5% | 4 – 5% | 4 – 8% | 4 – 8% | 5 – 8% | 4 – 8% | 4 – 8% | Utility, Clock modulator, Delay, Polyphonic | Synchronized delay with shortening. To synchronize with a buffer but delayed by a bar or some other timed quantity. |
| KRTPluginA |  M |
10% | 10% | 10% | 10% | 10% | 10 – 30% | 10 – 29% | 10 – 29% | 10 – 29% | 10 – 29% | Polyphonic, Filter, Effect, Utility | Emphasis and de-emphasis filter. Default is RIAA and inverse. This module has large gain. WARNING! |
| KRTPluginA |  μ |
15 – 23% | 15 – 23% | 15 – 23% | 15 – 23% | 15 – 23% | 15 – 64% | 15 – 65% | 15 – 65% | 15 – 65% | 15 – 66% | Effect, Waveshaper, Polyphonic | Time dependant calculus on a summing junction with series truncation distortion. This is complex to explain. Much better to listen and fiddle. |
| KRTPluginA |  O |
7 – 8% | 7 – 8% | 7% | 7% | 7% | 7 – 21% | 7 – 20% | 7 – 21% | 7 – 20% | 7 – 21% | Polyphonic, Oscillator | Triple parabolic skew feedback oscillator. An experimental module. |
| KRTPluginA |  Ω |
3 – 5% | 3 – 5% | 3 – 5% | 3 – 5% | 3 – 5% | 3 – 9% | 3 – 9% | 3 – 9% | 3 – 9% | 3 – 9% | Clock modulator, Polyphonic, Random, Switch | Clock distribution randomizer. Generates a random like sequence of length 64 and depending on the left-most displayed letter outputs a trigger when the clock is high or low. |
| KRTPluginA |  Q |
9 – 10% | 9 – 10% | 9 – 10% | 9 – 10% | 9 – 10% | 9 – 30% | 9 – 30% | 9 – 30% | 9 – 30% | 9 – 30% | Polyphonic, Effect, Physical modeling, Oscillator | Quantum gravimitator. Imitates a coupled gravity quantum idea. I really shouldn't explain. Just play. |
| KRTPluginA |  R |
7% | 6 – 7% | 6 – 7% | 6% | 6% | 7% | 6 – 7% | 6 – 7% | 6 – 7% | 6 – 7% | Attenuator, Mixer, Utility, Polyphonic | Simple mixer split. Put a signal on another as an insert. |
| KRTPluginA |  S |
3 – 4% | 3% | 3% | 3% | 3% | 3 – 4% | 3% | 3% | 3% | 3% | MIDI, Clock modulator, Low-frequency oscillator | Clock to CV generator. Needs MIDI clk, cont, stop and start. Produces a time based CV. |
| KRTPluginA |  T |
5 – 7% | 5 – 7% | 5 – 6% | 5% | 5% | 5 – 10% | 5 – 10% | 5 – 10% | 5 – 10% | 5 – 10% | Effect, Tuner, Delay, Polyphonic | Pitched time stretch and matched trigger sync delay. Spools and then plays back faster such that the overall waveform is produced at two different frequencies. |
| KRTPluginA |  U |
4 – 7% | 4 – 6% | 4 – 6% | 4 – 6% | 4 – 6% | 4 – 13% | 4 – 13% | 4 – 14% | 4 – 13% | 4 – 13% | Quantizer, Polyphonic, Sample and hold, Noise | Sample and hold quantizer. Simple. |
| KRTPluginA |  V |
9% | 8 – 9% | 8 – 9% | 7 – 9% | 7 – 9% | 9 – 25% | 8 – 25% | 8 – 25% | 7 – 25% | 7 – 25% | Envelope generator, Voltage-controlled amplifier, Polyphonic | Envelope VCA and CV producer. A bit weird. An experiment in module design. |
| KRTPluginA |  W |
4% | 4% | 3 – 4% | 3 – 4% | 3% | 4 – 7% | 4 – 7% | 3 – 7% | 3 – 7% | 3 – 7% | Attenuator, Mixer, Tuner, Polyphonic | Gate transposer. Kind of a tuning plug-board for gate triggers. |
| KRTPluginA |  X |
6 – 7% | 6 – 7% | 6% | 6 – 7% | 6% | 6 – 15% | 6 – 15% | 6 – 15% | 6 – 15% | 6 – 15% | Waveshaper, Polyphonic | Over-sampled wave-folder. A lot of fizz in such a little module. |
| KRTPluginA |  Y |
16 – 17% | 16 – 18% | 16 – 17% | 16 – 17% | 16 – 17% | 16 – 17% | 16 – 18% | 16 – 17% | 16 – 17% | 16 – 17% | Clock generator, Sequencer | Triple sequencer. Nice but complex to operate. Try the online help. |
| KRTPluginA |  Z |
3 – 4% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 4% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | Polyphonic, Filter, Waveshaper | |
| MADZINE |  AD Generator |
10 – 14% | 10 – 14% | 10 – 14% | 10 – 13% | 10 – 13% | 10 – 14% | 10 – 14% | 10 – 14% | 10 – 14% | 10 – 14% | Envelope generator | Attack Decay envelope generator |
| MADZINE |  ALEXANDERPLATZ |
7 – 16% | 7 – 17% | 7 – 17% | 7 – 16% | 7 – 16% | 7 – 16% | 7 – 17% | 7 – 17% | 7 – 16% | 7 – 16% | Mixer, Equalizer | 4-track mixer with 8-band master EQ, level, duck and mute controls |
| MADZINE |  DECAPyramid |
74 – 102% | 75 – 102% | 75 – 102% | 76 – 102% | 76 – 102% | 74 – 102% | 75 – 102% | 75 – 102% | 76 – 102% | 76 – 102% | Mixer, Utility | 8-track 3D panning router with send/return |
| MADZINE |  Drummmmmmer |
20 – 38% | 20 – 38% | 20 – 37% | 20 – 36% | 20 – 35% | 20 – 39% | 20 – 38% | 20 – 37% | 20 – 36% | 20 – 35% | Drum, Synth voice | 4-voice world drum synthesizer with style presets and spread control |
| MADZINE |  EllenRipley |
17 – 21% | 17 – 22% | 17 – 21% | 17 – 21% | 17 – 21% | 17 – 21% | 17 – 22% | 17 – 21% | 17 – 21% | 17 – 21% | Delay, Reverb, Granular, Effect, Random | Multi-effect processor with delay, granular synthesis, reverb, and chaos modulation |
| MADZINE |  Env VCA 6 |
17 – 29% | 18 – 29% | 17 – 30% | 17 – 30% | 17 – 30% | 17 – 30% | 18 – 30% | 17 – 30% | 17 – 30% | 17 – 30% | Envelope generator, VCA, Mixer | 6-channel envelope VCA processor with AD generators |
| MADZINE |  Euclidean Rhythm |
20 – 23% | 20 – 23% | 20 – 23% | 20 – 23% | 20 – 23% | 20 – 23% | 20 – 23% | 20 – 23% | 20 – 23% | 20 – 23% | Sequencer, Clock generator | A three-track Euclidean Rhythm Generator with CV control and Slew |
| MADZINE |  Facehugger |
10 – 12% | 10 – 12% | 10 – 12% | 10 – 12% | 10 – 12% | 10 – 12% | 10 – 12% | 10 – 12% | 10 – 12% | 10 – 12% | Granular, Effect, Random | Chaos-modulated granular processor with delay and pitch shifting |
| MADZINE |  KEN |
3 – 15% | 4 – 15% | 3 – 15% | 3 – 14% | 2 – 14% | 3 – 15% | 4 – 15% | 3 – 15% | 3 – 14% | 2 – 14% | Mixer, Utility | 8-to-2 binaural processor for 3D spatial audio rendering |
| MADZINE |  KIMO |
12 – 19% | 12 – 19% | 12 – 19% | 12 – 19% | 12 – 18% | 12 – 19% | 12 – 19% | 12 – 19% | 12 – 19% | 12 – 18% | Sequencer, Envelope generator, Drum | Single-track Euclidean drum machine with bass drum synthesis |
| MADZINE |  Launchpad |
9 – 10% | 9 – 10% | 9 – 10% | 9% | 9% | 9 – 10% | 9 – 10% | 9 – 10% | 9% | 9% | Sampler, Sequencer, Recording, Mixer | 8x8 grid CV/audio looper with session mode, per-cell recording, and send/return mixer |
| MADZINE |  MADDY |
15% | 15% | 15% | 15% | 15% | 15% | 15% | 15% | 15% | 15% | Sequencer, Clock generator, Low-frequency oscillator | Integrated sequencer with swing clock and 3-track Euclidean rhythm generator |
| MADZINE |  MADDY Plus |
18 – 20% | 18 – 20% | 18 – 20% | 18 – 20% | 18 – 20% | 18 – 20% | 18 – 20% | 18 – 20% | 18 – 20% | 18 – 20% | Sequencer, Clock generator, Envelope generator | Enhanced integrated sequencer with swing clock, 3-track Euclidean rhythm generator, and dual CV sequencers |
| MADZINE |  NIGOQ |
49 – 67% | 49 – 67% | 49 – 66% | 49 – 66% | 48 – 64% | 49 – 67% | 49 – 67% | 49 – 66% | 49 – 66% | 48 – 64% | Oscillator | Complex oscillator module |
| MADZINE |  Obserfour |
3 – 4% | 3 – 4% | 3 – 4% | 3% | 3% | 3 – 4% | 3 – 4% | 3 – 4% | 3% | 3% | Visual, Utility | 4-track color scope module for waveform visualization |
| MADZINE |  Observer |
3 – 4% | 3% | 3 – 4% | 3% | 3% | 3 – 4% | 3% | 3 – 4% | 3% | 3% | Visual, Utility | 8-track color scope module for waveform visualization |
| MADZINE |  Ovomorph |
12 – 14% | 12 – 14% | 12 – 13% | 12 – 13% | 12 – 13% | 12 – 14% | 12 – 14% | 12 – 13% | 12 – 13% | 12 – 13% | Reverb, Effect, Random | Chaos-modulated stereo reverb with room and decay control |
| MADZINE |  PPaTTTerning |
3 – 155% | 3 – 117% | 3 – 117% | 3 – 117% | 3 – 117% | 3 – 155% | 3 – 117% | 3 – 117% | 3 – 117% | 3 – 117% | Sequencer | Pattern-based CV sequencer with style and density control |
| MADZINE |  Pinpple |
37 – 38% | 38 – 39% | 37 – 39% | 37 – 39% | 37 – 39% | 37 – 38% | 38 – 39% | 37 – 39% | 37 – 39% | 37 – 39% | Drum, Filter, Synth voice | A ping filter hihat synthesizer with dynamic FM modulation |
| MADZINE |  Pyramid |
10 – 14% | 10 – 14% | 10 – 14% | 10 – 14% | 10 – 14% | 10 – 14% | 10 – 14% | 10 – 14% | 10 – 14% | 10 – 14% | Mixer, Utility | 3D panning router |
| MADZINE |  QQ |
3 – 8% | 3 – 8% | 3 – 7% | 3 – 7% | 3 – 7% | 3 – 8% | 3 – 8% | 3 – 7% | 3 – 7% | 3 – 7% | Envelope generator, Visual | 3-track S-Curve Decay Trigger envelope generator with CV control and waveform scope |
| MADZINE |  Quantizer |
5 – 9% | 5 – 9% | 5 – 7% | 5 – 6% | 5 – 6% | 5 – 13% | 5 – 13% | 5 – 13% | 5 – 13% | 5 – 13% | Quantizer, Tuner | 8HP chromatic quantizer with 12-note microtuning and cultural scale presets |
| MADZINE |  Runner |
8 – 10% | 8 – 10% | 8 – 10% | 8 – 10% | 8 – 10% | 8 – 10% | 8 – 10% | 8 – 10% | 8 – 10% | 8 – 10% | Delay, Effect, Random | Chaos-modulated stereo delay with spread control |
| MADZINE |  Runshow |
4% | 3 – 4% | 3 – 4% | 2 – 4% | 2 – 4% | 4% | 3 – 4% | 3 – 4% | 2 – 4% | 2 – 4% | Visual, Clock generator, Utility | Timer with bar counting and visual feedback |
| MADZINE |  SHINJUKU |
10 – 28% | 10 – 28% | 10 – 28% | 10 – 28% | 10 – 28% | 10 – 28% | 10 – 28% | 10 – 28% | 10 – 28% | 10 – 28% | Mixer, Equalizer | 8-track mixer with 12-band master EQ, level, duck and mute controls |
| MADZINE |  SONG MODE |
4% | 4% | 4% | 4% | 4% | 4 – 5% | 4% | 4% | 4% | 4% | Switch, Sequencer, Utility | 8-input sequential switch with customizable playback order, per-input clock length, and learn mode |
| MADZINE |  SwingLFO |
6 – 7% | 5 – 7% | 5 – 6% | 5 – 7% | 5 – 6% | 6 – 7% | 5 – 7% | 5 – 6% | 5 – 7% | 5 – 6% | Low-frequency oscillator | A dual-waveform LFO with swing and shape control |
| MADZINE |  TWNC |
23 – 24% | 23 – 24% | 23 – 24% | 22 – 24% | 23 – 24% | 23 – 24% | 23 – 24% | 23 – 24% | 22 – 24% | 23 – 24% | Sequencer, Clock generator, Drum | Dual-track Euclidean rhythm generator with drum and hi-hats synthesis |
| MADZINE |  TWNC2 |
23 – 29% | 23 – 30% | 23 – 29% | 23 – 28% | 23 – 28% | 23 – 29% | 23 – 30% | 23 – 29% | 23 – 28% | 23 – 28% | Sequencer, Clock generator, Drum | Three-track Euclidean drum machine with drum synthesis |
| MADZINE |  TWNC Light |
10 – 12% | 10 – 12% | 10 – 12% | 10 – 12% | 10 – 12% | 10 – 12% | 10 – 12% | 10 – 12% | 10 – 12% | 10 – 12% | Sequencer, Clock generator, Envelope generator | Simplified dual-track Euclidean rhythm generator with envelope control |
| MADZINE |  U8 |
4 – 9% | 4 – 9% | 4 – 9% | 4 – 7% | 4 – 8% | 4 – 19% | 4 – 19% | 4 – 19% | 4 – 19% | 4 – 18% | Mixer, Utility, Compressor | 4HP channel processor with gain/saturation, duck control and mute |
| MADZINE |  Uni Rhythm |
15 – 573% | 15 – 562% | 15 – 548% | 15 – 533% | 15 – 530% | 15 – 573% | 15 – 562% | 15 – 548% | 15 – 534% | 15 – 531% | Sequencer, Drum, Clock generator | Compact 4-track rhythm generator with 8 voice drum synthesis and 3-band isolator |
| MADZINE |  Universal Rhythm |
16 – 591% | 16 – 559% | 16 – 559% | 16 – 547% | 16 – 543% | 16 – 591% | 16 – 559% | 16 – 560% | 16 – 547% | 16 – 543% | Sequencer, Drum, Clock generator | Cross-cultural rhythm generator with integrated synthesis and 8 voice outputs |
| MADZINE |  weiii documenta |
19 – 40% | 19 – 38% | 19 – 35% | 19 – 34% | 19 – 34% | 19 – 40% | 19 – 38% | 19 – 35% | 19 – 34% | 19 – 34% | Sampler, Recording, Granular, Effect | Stereo audio recorder with slice scanning, morphing, feedback, and polyphonic playback |
| MADZINE |  YAMANOTE |
4 – 5% | 4% | 4% | 4% | 4% | 4 – 12% | 4 – 11% | 4 – 11% | 4 – 11% | 4 – 12% | Mixer, Utility | 8HP channel processor with chain, send/return function |
| MADZINE |  theKICK |
4 – 20% | 4 – 21% | 4 – 20% | 3 – 20% | 3 – 20% | 4 – 21% | 4 – 21% | 4 – 21% | 3 – 20% | 3 – 21% | Drum, Synth voice | Kick drum synthesizer with pitch sweep, bend curve and tanh waveshaper |
| Mockba Modular |  Blank |
2% | 2% | 2% | 2% | 2% | 2% (mono) | 2% (mono) | 2% (mono) | 2% (mono) | 2% (mono) | Blank | Simple blank |
| Mockba Modular |  CZDblSine |
7 – 9% | 7% | 7% | 7% | 7 – 8% | 7 – 9% | 7% | 7% | 7% | 7 – 8% | Oscillator, Polyphonic | Simple CZ style DBLSINE oscillator |
| Mockba Modular |  CZOsc |
7 – 8% | 7% | 7% | 7% | 7% | 7 – 8% | 7% | 7% | 7% | 7% | Oscillator, Polyphonic | Simple CZ style oscillator |
| Mockba Modular |  CZPulse |
7% | 7% | 7% | 7% | 7% | 7% | 7% | 7% | 7% | 7% | Oscillator, Polyphonic | Simple CZ style PULSE oscillator |
| Mockba Modular |  CZReso1 |
6 – 7% | 6 – 7% | 6 – 7% | 6% | 6% | 6 – 9% | 6 – 9% | 6 – 9% | 6 – 8% | 6% | Oscillator, Polyphonic | Simple CZ style RESO1 oscillator |
| Mockba Modular |  CZReso2 |
7 – 8% | 7% | 7% | 7% | 7% | 7 – 8% | 7% | 7% | 7% | 7% | Oscillator, Polyphonic | Simple CZ style RESO2 oscillator |
| Mockba Modular |  CZReso3 |
7% | 6 – 7% | 6 – 7% | 6 – 7% | 6 – 7% | 7% | 6 – 7% | 6 – 7% | 6 – 7% | 6 – 7% | Oscillator, Polyphonic | Simple CZ style RESO3 oscillator |
| Mockba Modular |  CZSaw |
7 – 8% | 7% | 7 – 8% | 7% | 7% | 7 – 8% | 7% | 7 – 8% | 7% | 7% | Oscillator, Polyphonic | Simple CZ style SAW oscillator |
| Mockba Modular |  CZSawPulse |
7 – 9% | 7% | 7% | 7% | 7% | 7 – 9% | 7% | 7% | 7% | 7% | Oscillator, Polyphonic | Simple CZ style SAWPULSE oscillator |
| Mockba Modular |  CZSquare |
7 – 9% | 7 – 9% | 7 – 8% | 7 – 8% | 7% | 7 – 9% | 7 – 9% | 7 – 8% | 7 – 8% | 7% | Oscillator, Polyphonic | Simple CZ style SQUARE oscillator |
| Mockba Modular |  Comparator |
2 – 4% | 2 – 3% | 2% | 2% | 2% | 2 – 4% | 2 – 3% | 2% | 2% | 2% | Logic, Utility | Simple voltage comparator |
| Mockba Modular |  Countah |
2 – 4% | 2 – 3% | 2% | 2% | 2% | 2 – 4% | 2 – 3% | 2% | 2% | 2% | Clock modulator | Simple clock counter |
| Mockba Modular |  Dividah |
2 – 3% | 2 – 3% | 2 – 3% | 2% | 2% | 2 – 3% | 2 – 3% | 2 – 3% | 2% | 2% | Clock modulator | Simple clock divider |
| Mockba Modular |  DualAND |
2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | Logic, Utility | Simple AND gates |
| Mockba Modular |  DualBUFFER |
2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | Logic, Utility | Simple BUFFER gates (3 actually) |
| Mockba Modular |  DualNAND |
2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | Logic, Utility | Simple NAND gates |
| Mockba Modular |  DualNOR |
2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | Logic, Utility | Simple NOR gates |
| Mockba Modular |  DualNOT |
2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | Logic, Utility | Simple NOT gates (3 actually) |
| Mockba Modular |  DualOR |
2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | Logic, Utility | Simple OR gates |
| Mockba Modular |  DualXNOR |
2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | Logic, Utility | Simple XNOR gates |
| Mockba Modular |  DualXOR |
2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | Logic, Utility | Simple XOR gates |
| Mockba Modular |  Feidah |
2 – 4% | 2% | 2% | 2% | 2% | 2 – 4% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | Attenuator, VCA, Polyphonic | Simple signal fader with VCA |
| Mockba Modular |  FeidahS |
2 – 3% | 2 – 3% | 2% | 2% | 2% | 2 – 4% | 2 – 4% | 2 – 4% | 2 – 4% | 2 – 4% | Attenuator, VCA, Polyphonic | Simple stereo signal fader with VCA |
| Mockba Modular |  Filtah |
10 – 11% | 10 – 11% | 10% | 10% | 10% | 10 – 11% | 10 – 11% | 10% | 10% | 10% | Filter, Polyphonic | Simple Moog style filter |
| Mockba Modular |  Holdah |
2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | Sample and hold | Simple Sample & Hold |
| Mockba Modular |  MaugOsc |
12 – 13% | 12 – 13% | 12% | 12 – 13% | 12% | 12 – 13% | 12 – 13% | 12% | 12 – 13% | 12% | Oscillator, Polyphonic | Simple Moog style oscillator |
| Mockba Modular |  MaugSaw |
12 – 14% | 12% | 12 – 13% | 12% | 12% | 12 – 14% | 12% | 12 – 13% | 12% | 12% | Oscillator, Polyphonic | Simple Moog style SAW oscillator |
| Mockba Modular |  MaugSaw2 |
12 – 14% | 12% | 12% | 12% | 12% | 12 – 14% | 12% | 12% | 12% | 12% | Oscillator, Polyphonic | Simple Moog style INVSAW oscillator |
| Mockba Modular |  MaugShark |
12 – 14% | 12 – 13% | 12 – 13% | 12% | 12% | 12 – 14% | 12 – 13% | 12 – 13% | 12% | 12% | Oscillator, Polyphonic | Simple Moog style SHARK oscillator |
| Mockba Modular |  MaugSquare |
12 – 14% | 12 – 13% | 12% | 12% | 12% | 12 – 14% | 12 – 13% | 12% | 12% | 12% | Oscillator, Polyphonic | Simple Moog style SQUARE .48 oscillator |
| Mockba Modular |  MaugSquare2 |
12% | 12 – 13% | 12% | 12% | 12% | 12% | 12 – 13% | 12% | 12% | 12% | Oscillator, Polyphonic | Simple Moog style SQUARE .29 oscillator |
| Mockba Modular |  MaugSquare3 |
12 – 13% | 12% | 12 – 13% | 12% | 12 – 13% | 12 – 13% | 12% | 12 – 13% | 12% | 12 – 13% | Oscillator, Polyphonic | Simple Moog style SQUARE .17 oscillator |
| Mockba Modular |  MaugTriangle |
12 – 14% | 12 – 13% | 12% | 12% | 12% | 12 – 14% | 12 – 13% | 12% | 12% | 12% | Oscillator, Polyphonic | Simple Moog style TRIANGLE oscillator |
| Mockba Modular |  Mixah |
2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 4% | 2 – 4% | 2 – 4% | 2 – 4% | 2 – 4% | Mixer, VCA, Polyphonic | Simple two signal mixer with VCA |
| Mockba Modular |  Mixah3 |
5 – 7% | 5 – 9% | 5 – 6% | 5 – 7% | 5 – 6% | 5 – 7% | 5 – 9% | 5 – 7% | 5 – 7% | 5 – 7% | Mixer, Polyphonic | Simple three signal mixer |
| Mockba Modular |  PSelectah |
2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | Logic, Utility | Simple Priority Selector (AND->OR MUX) |
| Mockba Modular |  Pannah |
2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 9% | 2 – 6% | 2 – 6% | 2 – 6% | 2 – 6% | Panning, Polyphonic | Simple stereo panner with modulation |
| Mockba Modular |  ReVoltah |
3 – 4% | 3% | 2 – 3% | 2 – 3% | 2 – 3% | 3 – 4% | 3 – 4% | 2 – 4% | 2 – 4% | 2 – 4% | Utility, Polyphonic | Simple voltage range adapter |
| Mockba Modular |  Selectah |
2 – 4% | 2 – 4% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 4% | 2 – 4% | 2 – 3% | 2 – 3% | 2 – 3% | Utility, Polyphonic | Simple 4 to 1 selector |
| Mockba Modular |  Shapah |
4% | 2 – 4% | 2 – 4% | 4% | 2 – 4% | 4 – 5% | 2 – 5% | 2 – 4% | 4% | 2 – 4% | Envelope generator, Polyphonic | Simple ADSR envelope shaper |
| Moffenzeef |  Bad Idea 1800-Call-Yer-Mum |
9 – 18% | 9 – 17% | 9 – 17% | 9 – 17% | 9 – 17% | 9 – 18% | 9 – 17% | 9 – 17% | 9 – 17% | 9 – 17% | oscillator, noise, drum, hardware clone | DTMF tone generator |
| Moffenzeef |  Bad Idea #9 |
3% | 3 – 4% | 3% | 3% | 3% | 3% | 3 – 4% | 3% | 3% | 3% | oscillator, noise, drum, hardware clone | Power starved glitch oscillator |
| Moffenzeef |  Bobcat |
11 – 12% | 11 – 12% | 11 – 12% | 11 – 12% | 11 – 12% | 11 – 12% | 11 – 12% | 11 – 12% | 11 – 12% | 11 – 12% | drum, noise, hardware clone | Dual noise drum |
| Moffenzeef |  Bus Mult |
2 – 3% | 2% | 2% | 2% | 2% | 2 – 3% | 2% | 2% | 2% | 2% | multiple, utility, hardware clone | 1x3 and 1x2 mult |
| Moffenzeef |  Count |
2 – 4% | 2 – 3% | 2 – 3% | 2% | 2% | 2 – 4% | 2 – 3% | 2 – 3% | 2% | 2% | clock generator, clock modulator, utility, hardware clone | Master clock with divided outputs |
| Moffenzeef |  Deviant |
5% | 5 – 6% | 5% | 5% | 5% | 5% | 5 – 6% | 5% | 5% | 5% | random, utility, hardware clone | Dual max/min stepped random with slew |
| Moffenzeef |  Dial Up |
4% | 4% | 4% | 4% | 4% | 4% | 4% | 4% | 4% | 4% | drum, noise, hardware clone | Dial up modem drum module |
| Moffenzeef |  Genetically Modified Oscillator |
4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | 4% | 4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | 4% | drum, noise, oscillator, hardware clone | Lofi ROMPLER with only one bank of metal clangs |
| Moffenzeef |  INTENSIFIES |
5 – 6% | 5 – 6% | 5 – 6% | 5 – 6% | 5 – 6% | 5 – 6% | 5 – 6% | 5 – 6% | 5 – 6% | 5 – 6% | hardware clone, Noise, effect, distortion | Eurorack fantasy version of a previously released effect pedal: Amplitude modulated sample rate reduction and distortion |
| Moffenzeef |  Kleztizer |
15 – 16% | 15 – 16% | 15 – 16% | 15 – 16% | 15 – 16% | 15 – 17% | 15 – 17% | 15 – 16% | 15 – 17% | 15 – 17% | quantizer, sequencer | A quantizer that follows the harmonic structure of Klezmer modes |
| Moffenzeef |  Kriket |
8 – 9% | 8 – 9% | 7 – 8% | 7 – 8% | 7 – 8% | 8 – 9% | 8 – 9% | 7 – 8% | 7 – 8% | 7 – 8% | drum, noise, oscillator, hardware clone | Quad blip and beep generator |
| Moffenzeef |  Mito |
6 – 7% | 6% | 6% | 6% | 6% | 6 – 7% | 6% | 6% | 6% | 6% | clock modulator, sequencer, hardware clone | 6 channel clock divider sequencer with swing and pulsewidth control |
| Moffenzeef |  Moffenmix |
3% | 3% | 3% | 3% | 3% | 3% | 3% | 3% | 3% | 3% | mixer, distortion, hardware clone | Quad distortion mixer |
| Moffenzeef |  Mongrel |
6% | 6% | 6% | 5 – 6% | 6% | 6% | 6% | 6% | 5 – 6% | 6% | drum, noise, hardware clone | Ring mod drum |
| Moffenzeef |  Muskrat |
7 – 10% | 7 – 9% | 7 – 9% | 7 – 9% | 7 – 9% | 7 – 10% | 7 – 9% | 7 – 9% | 7 – 9% | 7 – 9% | drum, noise, hardware clone | Lofi wavetable drum with additional algorithms |
| Moffenzeef |  Quad Deviant |
6% | 6% | 5 – 6% | 5 – 6% | 5 – 6% | 6 – 7% | 6 – 7% | 5 – 7% | 5 – 6% | 5 – 6% | random, utility | Quad version of Deviant with range switches and CV bus |
| Moffenzeef |  Simplify |
3 – 4% | 3% | 3% | 3% | 3% | 3 – 4% | 3 – 4% | 3% | 3% | 3% | sequencer, clock modulator, hardware clone | Dynamic mute module |
| Moffenzeef |  Stargazer |
20 – 26% | 20 – 27% | 20 – 26% | 20 – 25% | 20 – 24% | 20 – 26% | 20 – 27% | 20 – 26% | 20 – 25% | 20 – 24% | Synth voice, oscillator, hardware clone, LFO, Random | Eurorack fantasy version of a previously released drone synth. |
| Moffenzeef |  Swarm |
6% | 5 – 6% | 5 – 6% | 5 – 6% | 5 – 6% | 6 – 8% | 5 – 9% | 5 – 7% | 5 – 6% | 5 – 6% | hardware clone, clock, random, sequencer, oscillator, utility | Asynchronous gate generator |
| Moffenzeef |  Tantz! |
5 – 6% | 5% | 5% | 4 – 5% | 4 – 5% | 5 – 6% | 5% | 5% | 4 – 5% | 4 – 5% | sequencer, clock modulator | Klezmer preset drum sequencer |
| Moffenzeef |  The Runner |
9 – 10% | 9 – 10% | 9 – 10% | 9 – 10% | 9 – 10% | 9 – 10% | 9 – 10% | 9 – 10% | 9 – 10% | 9 – 10% | hardware clone, oscillator, synth voice | A Eurorack fantasy version of a previously released drone synth: The Runner was made in collaboration with Boy Harsher as part of promo for their film with the same name |
| mscHack |  ASAF8 |
4 – 10% | 4 – 9% | 4 – 10% | 4 – 9% | 4 – 9% | 4 – 10% | 4 – 10% | 4 – 10% | 4 – 11% | 4 – 10% | Mixer | 8 Channel Auto Stereo Audio Fader |
| mscHack |  Alienz |
2 – 27% | 2 – 25% | 2 – 16% | 2 – 12% | 2 – 12% | 2 – 28% | 2 – 25% | 2 – 16% | 2 – 12% | 2 – 12% | Oscillator | Alien transmissions |
| mscHack |  Compressor |
10 – 11% | 10 – 11% | 10 – 11% | 10% | 10% | 10 – 11% | 10 – 11% | 10 – 11% | 10% | 10% | Compressor | Compressor |
| mscHack |  Dronez |
56 – 222% | 59 – 199% | 59 – 185% | 56 – 183% | 56 – 179% | 56 – 223% | 59 – 199% | 59 – 185% | 56 – 183% | 56 – 179% | Oscillator | Random Drone |
| mscHack |  Lorenz |
13 – 16% | 12 – 16% | 12 – 16% | 12 – 16% | 12 – 16% | 13 – 16% | 12 – 16% | 12 – 16% | 12 – 16% | 12 – 16% | Random, Noise | Lorenz Attractor |
| mscHack |  MSC Clock x4 |
5 – 7% | 5 – 6% | 5 – 6% | 5 – 6% | 5 – 6% | 5 – 7% | 5 – 6% | 5 – 6% | 5 – 6% | 5 – 6% | Clock | 4 Channel Clock |
| mscHack |  Maude Two to One |
2 – 5% | 2 – 5% | 2 – 5% | 2 – 5% | 2 – 5% | 2 – 5% | 2 – 5% | 2 – 5% | 2 – 5% | 2 – 5% | Waveshaper | Rectify/Combine 2 mono signals |
| mscHack |  MIX 4 Channel |
2 – 3% | 2% | 2% | 2% | 2% | 2 – 3% | 2% | 2% | 2% | 2% | Mixer | 4 Channel Mixer |
| mscHack |  Morze |
2 – 4% | 2% | 2 – 3% | 2% | 2% | 2 – 4% | 2 – 3% | 2 – 3% | 2% | 2% | Sequencer | Morse Code Generator |
| mscHack |  Wave morph Oscillator |
11 – 18% | 11 – 18% | 11 – 18% | 11 – 18% | 11 – 18% | 11 – 18% | 11 – 18% | 11 – 18% | 11 – 18% | 11 – 18% | Oscillator | CV Morph 3 Drawable Waveforms |
| mscHack |  OSC 3 Channel |
21 – 25% | 20 – 25% | 21 – 25% | 20 – 25% | 20 – 25% | 21 – 25% | 20 – 25% | 21 – 25% | 20 – 25% | 20 – 25% | Synth voice | 3 Channel Synth |
| mscHack |  Ping Pong |
4% | 4% | 4% | 3 – 4% | 3 – 4% | 4 – 5% | 4 – 5% | 4% | 3 – 4% | 3 – 5% | Delay | Ping Pong Delay |
| mscHack |  Step Delay |
7 – 9% | 7 – 8% | 7% | 7 – 8% | 7% | 7 – 9% | 7 – 8% | 7 – 8% | 7 – 8% | 7% | Delay | Step Delay |
| mscHack |  Synth Drums |
4 – 17% | 4 – 17% | 4 – 17% | 4 – 17% | 4 – 17% | 4 – 18% | 4 – 17% | 4 – 17% | 4 – 17% | 4 – 17% | Drum | 3 Channel Synth Drums |
| mscHack |  Windz |
24 – 47% | 24 – 45% | 24 – 35% | 24 – 30% | 24 – 30% | 24 – 47% | 24 – 45% | 24 – 35% | 24 – 30% | 24 – 30% | Random, Noise | Random Noise |
| MSM |  ADSR |
3 – 6% | 3 – 6% | 3 – 6% | 3 – 6% | 3 – 6% | 3 – 7% | 3 – 6% | 3 – 6% | 3 – 6% | 3 – 6% | Envelope generator | ADSR Envelope Generator with modifiable curve shapes |
| MSM |  Bitcrusher |
4 – 5% | 4 – 5% | 4 – 5% | 4% | 4% | 4 – 5% | 4 – 5% | 4 – 5% | 4% | 4% | Effect | Distortion effect by changing the sample's bit length and sample rate |
| MSM |  Blank Panel |
2% | 2% | 2% | 2% | 2% | 2% (mono) | 2% (mono) | 2% (mono) | 2% (mono) | 2% (mono) | Blank | Blank panel utilizing the MSM logo |
| MSM |  CrazyMult |
18 – 19% | 18 – 20% | 18 – 20% | 18 – 20% | 18 – 19% | 18 – 20% | 18 – 20% | 18 – 20% | 18 – 20% | 18 – 19% | Multiple | 8 way dual output signal router |
| MSM |  Dual Delay |
28 – 29% | 28 – 29% | 28 – 29% | 28 – 29% | 28 – 29% | 28 – 29% | 28 – 29% | 28 – 29% | 28 – 29% | 28 – 29% | Delay | Two independent delay lines with low/hi pass filters |
| MSM |  Fade |
4% | 4% | 4% | 4% | 4% | 4% | 4% | 4% | 4% | 4% | Mixer | Triple fader module |
| MSM |  MLFO |
14% | 14% | 14% | 14 – 15% | 14 – 15% | 14% | 14% | 14% | 14 – 15% | 14 – 15% | LFO | Low frequency oscillator with multiple waveform types |
| MSM |  Morph |
3% | 3% | 3% | 3% | 3% | 3% | 3% | 3% | 3% | 3% | Effect | Variable input morpher with 8 inputs |
| MSM |  Mult |
2% | 2 – 3% | 2% | 2% | 2% | 2% | 2 – 3% | 2% | 2% | 2% | Multiple | Triple independent add/subtract split utility |
| MSM |  Noise |
11 – 12% | 10 – 12% | 10 – 12% | 10 – 12% | 10 – 12% | 11 – 12% | 10 – 13% | 10 – 12% | 10 – 12% | 10 – 12% | Noise | Noise generator with white, pink, brown and variable colored noise outputs |
| MSM |  OSCiX |
27 – 29% | 27 – 30% | 27 – 30% | 28 – 30% | 27 – 29% | 27 – 29% | 27 – 30% | 27 – 30% | 28 – 30% | 27 – 29% | Oscillator | Advanced dual oscillator/LFO with a built-in wave folder |
| MSM |  PAN-VCA |
2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | Amplifier, Panning | Stereo VCA/PAN combination |
| MSM |  Phaser |
6 – 7% | 6 – 7% | 6 – 7% | 6 – 7% | 6% | 6 – 7% | 6 – 7% | 6 – 7% | 6 – 7% | 6% | Effect | 2-20 stage phaser distortion effect |
| MSM |  Random Source |
3 – 4% | 2 – 4% | 2 – 4% | 2 – 4% | 2 – 4% | 3 – 4% | 2 – 4% | 2 – 4% | 2 – 4% | 2 – 4% | Sample and hold, Random | Random source that produces variable shape staircase waveforms |
| MSM |  Ring |
4% | 4% | 4% | 4% | 4% | 4% | 4% | 4% | 4% | 4% | Effect | Dual ring modulator |
| MSM |  Rogue |
10 – 21% | 11 – 22% | 10 – 22% | 10 – 21% | 10 – 21% | 10 – 21% | 11 – 22% | 10 – 22% | 10 – 21% | 10 – 21% | Oscillator | OSCiX's little brother. Advanced oscillator/LFO with multiple waveform type outputs |
| MSM |  Simple Slider |
3 – 4% | 3% | 3% | 2 – 3% | 2 – 3% | 3 – 4% | 3% | 3% | 2 – 3% | 2 – 3% | Mixer, Amplifier | Dual input VCA/Crossfader slider |
| MSM |  Treasure VCO |
9 – 32% | 9 – 32% | 9 – 32% | 9 – 32% | 9 – 32% | 9 – 32% | 9 – 32% | 9 – 32% | 9 – 32% | 9 – 32% | Oscillator | Voltage Controlled Oscillator with complex waveform modulation |
| MSM |  WaveShaper |
3 – 9% | 4 – 8% | 2 – 8% | 2 – 9% | 2 – 8% | 3 – 9% | 4 – 9% | 2 – 9% | 2 – 9% | 2 – 8% | Waveshaper | Unique wave folder with multiple folding algorithms |
| MSM |  Wavefolder |
4 – 8% | 4 – 8% | 4 – 9% | 4 – 8% | 4 – 8% | 4 – 8% | 4 – 8% | 4 – 9% | 4 – 8% | 4 – 8% | Waveshaper | Advanced wave folder with variable symmetry controls |
| MSM |  XSEQ |
11 – 12% | 11 – 12% | 11 – 12% | 11 – 12% | 11 – 12% | 11 – 12% | 11 – 12% | 11 – 12% | 11 – 12% | 11 – 12% | Logic, Random | Boolean logic sequencer |
| MUS-X |  ADSR |
6 – 9% | 6 – 8% | 6 – 7% | 6% | 6 – 7% | 6 – 9% | 6 – 8% | 6 – 7% | 6% | 6 – 7% | Envelope generator, Polyphonic | ADSR envelope generator. |
| MUS-X |  Delay |
45 – 46% | 45 – 46% | 45 – 47% | 45 – 47% | 45 – 47% | 45 – 46% | 45 – 46% | 45 – 47% | 45 – 47% | 45 – 47% | Delay, Effect | Bucket-brigade ping-pong delay. |
| MUS-X |  Drift |
2 – 4% | 2% | 2% | 2% | 2% | 2 – 4% | 2% | 2 – 4% | 2% | 2% | Random, Polyphonic | Random constant offset and drift. |
| MUS-X |  Filter |
85% | 86% | 87% | 87% | 87% | 85 – 87% | 86 – 87% | 87% | 87% | 87% | Filter, Polyphonic | Collection of virtual analog filters |
| MUS-X |  LFO |
6 – 9% | 6 – 8% | 6 – 9% | 6 – 7% | 6 – 7% | 6 – 9% | 6 – 8% | 6 – 9% | 6 – 7% | 6 – 7% | Low-frequency oscillator, Polyphonic | Low frequency oscillator |
| MUS-X |  Last |
2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | Utility | Output the value of the last moved knob |
| MUS-X |  Mod Matrix |
20 – 57% | 20 – 59% | 20 – 58% | 20 – 59% | 20 – 58% | 20 – 58% | 20 – 59% | 20 – 60% | 20 – 60% | 20 – 60% | Mixer, Polyphonic, Utility | MIDI controllable 13x16 Modulation Matrix |
| MUS-X |  OnePole |
3 – 5% | 3 – 5% | 3 – 4% | 3% | 3% | 3 – 5% | 3 – 5% | 3 – 4% | 3% | 3% | Filter, Polyphonic | Simple one-pole highpass and lowpass filters. |
| MUS-X |  OnePoleLP |
3 – 4% | 3 – 4% | 3% | 3% | 3% | 3 – 4% | 3 – 4% | 3% | 3% | 3% | Filter, Polyphonic | Simple one-pole lowpass filter. |
| MUS-X |  Oscillators |
111 – 115% | 113 – 115% | 111 – 115% | 111 – 115% | 111 – 115% | 111 – 148% | 113 – 144% | 111 – 142% | 111 – 142% | 111 – 140% | Oscillator, Low-frequency oscillator, Polyphonic | Massively oversampled analog oscillator pair with sync, FM and ringmod. |
| MUS-X |  Split/Stack |
3% | 2 – 3% | 3% | 3% | 3 – 4% | 3% | 2 – 3% | 3% | 3% | 3 – 4% | Utility | Utility for splitting or layering two synthesizer parts |
| MUS-X |  Synth |
301 – 426% | 154 – 303% | 80 – 239% | 43 – 208% | 24 – 192% | 301 – 429% | 154 – 305% | 80 – 242% | 43 – 210% | 24 – 195% | Synth voice, Polyphonic | A virtual-analogue polyphonic synthesizer with 2 oscillators, dual filters and intuitive modulation system |
| MUS-X |  Tuner |
3 – 4% | 3% | 3% | 3% | 3% | 3 – 4% | 3% | 3% | 3% | 3% | Tuner, Polyphonic | Tune a V/Oct signal by octaves, semitones and cents. |
| NANO Modules |  ALT |
4 – 6% | 4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | 4 – 6% | 4 – 6% | 4 – 6% | 4 – 5% | 4 – 5% | Attenuator, Mixer, Quad, VCA, Hardware clone | Quad Voltage Controlled Amplifier & Cascading Mixer |
| NANO Modules |  ARC |
12 – 18% | 12 – 17% | 12 – 17% | 12 – 17% | 12 – 17% | 12 – 18% | 12 – 17% | 12 – 17% | 12 – 17% | 12 – 17% | Envelope generator, Oscillator, LFO, Slew limiter, VCA, Logic, Hardware clone | Dual Function Generator |
| NANO Modules |  CEQ |
11 – 14% | 11 – 13% | 11 – 12% | 11 – 12% | 11 – 12% | 11 – 14% | 11 – 13% | 11 – 12% | 11 – 12% | 11 – 12% | Effect, Dynamics, Equalizer, Filter, Hardware clone | DJ Equalizer & Compressor |
| NANO Modules |  EXP4 |
2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | Expander, Hardware clone | Performance Mixer Expander |
| NANO Modules |  FONT |
7 – 8% | 7 – 9% | 7 – 8% | 7% | 7% | 7 – 8% | 7 – 9% | 7 – 8% | 7 – 8% | 7% | Filter, Oscillator, Hardware clone | Massive Sounding Liquid Filter |
| NANO Modules |  MAR |
4% | 4% | 3 – 4% | 3 – 4% | 3 – 4% | 4% | 4% | 3 – 4% | 3 – 4% | 3 – 4% | Mixer, Attenuator, Hardware clone | Dual Eurorack Mixer |
| NANO Modules |  OCTA |
20 – 25% | 20 – 24% | 20 – 24% | 20 – 24% | 20 – 24% | 20 – 25% | 20 – 24% | 20 – 24% | 20 – 24% | 20 – 24% | Drum, Quad, Hardware clone | Analog drums |
| NANO Modules |  ONA |
13% | 13% | 13 – 14% | 13% | 13% | 13 – 14% | 13% | 13 – 14% | 13% | 13% | Oscillator, LFO, Hardware clone | Analog Multifunction Oscillator |
| NANO Modules |  Performance Mixer |
17 – 18% | 17 – 19% | 17 – 18% | 17 – 18% | 17 – 18% | 17 – 19% | 17 – 19% | 17 – 18% | 17 – 18% | 17 – 18% | Attenuator, Mixer, Panning, Quad, VCA, Hardware clone | Advanced Mixing. Effortless Automation |
| NANO Modules |  QUART |
11 – 18% | 11 – 19% | 11 – 19% | 11 – 19% | 11 – 19% | 11 – 19% | 11 – 19% | 11 – 19% | 11 – 19% | 11 – 19% | Envelope generator, LFO, Oscillator, Function generator, Quad, Hardware clone | Quad AD Envelope & LFO Generator |
| NANO Modules |  SERRA |
7 – 11% | 8 – 11% | 7 – 11% | 7 – 10% | 7 – 10% | 7 – 11% | 8 – 11% | 7 – 11% | 7 – 10% | 7 – 10% | Envelope generator, Function generator, Attenuator, Hardware clone | Envelope (ADSR) function generator |
| NANO Modules |  ST FONT |
18 – 19% | 18 – 19% | 18 – 20% | 18 – 19% | 17 – 20% | 18 – 19% | 18 – 19% | 18 – 20% | 18 – 19% | 17 – 20% | Filter, Oscillator, VCA, Distortion, Hardware clone | Stereo Liquid Filter |
| NANO Modules |  ST MAR |
4 – 6% | 4 – 6% | 4 – 6% | 4 – 6% | 4 – 6% | 4 – 6% | 4 – 6% | 4 – 6% | 4 – 6% | 4 – 6% | Attenuator, Mixer, VCA, Hardware clone | Stereo Mixer |
| NANO Modules |  VCV Random |
15 – 16% | 15 – 17% | 15 – 16% | 15 – 16% | 15 – 16% | 15 – 16% | 15 – 17% | 15 – 16% | 15 – 16% | 15 – 16% | Clock generator, Noise, Random, Sample and hold, Slew limiter, Quad, Hardware clone | Random CV Generator |
| NOI |  Dicotyledon |
2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | Logic | Logic processor |
| NOI |  Hellebore |
38 – 43% | 38 – 43% | 37 – 43% | 37 – 43% | 37 – 43% | 38 – 43% | 38 – 43% | 37 – 43% | 37 – 43% | 37 – 43% | Digital, Effect | granular reverb |
| NOI |  Pruners |
14 – 16% | 13 – 15% | 13 – 15% | 13 – 15% | 12 – 15% | 13 – 16% | 13 – 15% | 13 – 15% | 13 – 15% | 12 – 15% | Sampler | Sampler |
| NOI |  Sinensis |
13 – 24% | 13 – 23% | 13 – 23% | 13 – 22% | 13 – 21% | 13 – 24% | 13 – 23% | 13 – 23% | 13 – 22% | 13 – 21% | VCF | Multiband Resonating Filter |
| NOI |  Sunflower |
4 – 14% | 3 – 15% | 3 – 14% | 3 – 15% | 3 – 15% | 4 – 14% | 3 – 15% | 3 – 14% | 3 – 15% | 3 – 15% | Mixer | Circular mixer |
| NOI |  Wilt |
22% | 22% | 22 – 23% | 22 – 23% | 22% | 22 – 23% | 22 – 23% | 22 – 23% | 22 – 23% | 22 – 23% | Digital, Effect | Digital Wilt |
| NonlinearCircuits |  4Seq |
2 – 3% | 2 – 3% | 2% | 2% | 2% | 2 – 3% | 2 – 3% | 2% | 2% | 2% | Sequencer, Hardware Clone, Clock Modulator | Dual sequencer and clock divider. Panel by jk. |
| NonlinearCircuits |  Cipher |
3 – 4% | 3 – 4% | 3% | 3% | 2 – 3% | 3 – 4% | 3 – 4% | 3% | 3% | 2 – 3% | Sequencer, Hardware Clone, Clock Modulator | Dual sequencer and clock divider. Panel by jk. |
| NonlinearCircuits |  BOOLs |
3% | 3% | 3% | 2 – 3% | 2 – 3% | 3% | 3% | 3% | 2 – 3% | 2 – 3% | Logic, Hardware Clone, Quad | Four binary logic jumblers. Panel by Papernoise. |
| NonlinearCircuits |  DivideConquer |
3% | 3% | 3% | 3% | 3% | 3 – 4% | 3% | 3% | 3% | 3% | Logic, Clock Modulator, Hardware Clone | More clock dividers than you will ever need. |
| NonlinearCircuits |  DivineCMOS |
3% | 3% | 3% | 3% | 3% | 3% | 3% | 3% | 3% | 3% | Logic, Hardware Clone | Waveform and clock divider with multiple divison outputs, slew, and a mixer. |
| NonlinearCircuits |  DoubleNeuron |
3 – 4% | 3% | 3% | 2 – 3% | 2 – 3% | 3 – 4% | 3% | 2 – 3% | 2 – 3% | 2 – 3% | Mixer, Noise, Utility, Random, Hardware Clone, Dual | Two Neurons and Two Difference Rectifiers. Panel by Papernoise. |
| NonlinearCircuits |  Genie |
3% | 3% | 3% | 3% | 3% | 3% | 3% | 3% | 3% | 3% | Mixer, Noise, Utility, Random, Hardware Clone | Three Neurons tangled together in a feedback network of chaos. Panel by jk. |
| NonlinearCircuits |  LetsSplosh |
5% | 5% | 5% | 5% | 5% | 5% | 5% | 5% | 5% | 5% | Mixer, Noise, Utility, Random, Hardware Clone, Quad | Four inputs run into lots of Difference Rectifiers for many output variations. Panel by Papernoise. |
| NonlinearCircuits |  Neuron |
2 – 3% | 2% | 2% | 2% | 2% | 2 – 3% | 2% | 2% | 2% | 2% | Mixer, Noise, Utility, Random, Hardware Clone, Dual | 3-input comparator and Difference Rectifier for creating unpredictable interactions. Panel by jk. |
| NonlinearCircuits |  Numberwang |
3 – 4% | 3 – 4% | 3% | 3% | 3% | 3 – 4% | 3 – 4% | 3% | 3% | 3% | Logic, Hardware Clone | Four gates make sixteen. That's Numberwang! Panel by jk. |
| NonlinearCircuits |  Router |
3% | 3% | 3% | 3% | 3% | 3% | 3% | 3% | 3% | 3% | Switch, Mixer, Quad, Hardware Clone | Simple switch. If the CV input is below the knob voltage setting, the output is active. Panel by jk. |
| NonlinearCircuits |  Segue |
2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | Mixer, Hardware Clone | Stereo channel-flipping panner, crossfader, or VCA |
| NonlinearCircuits |  SlothApathy |
5 – 6% | 5% | 5% | 5% | 5% | 5 – 6% | 5% | 5% | 5% | 5% | Hardware Clone, Low-frequency oscillator | Very slow chaotic oscillator. DSP engine by Don Cross. |
| NonlinearCircuits |  SlothInertia |
5% | 5% | 5% | 5% | 5% | 5% | 5% | 5% | 5% | 5% | Hardware Clone, Low-frequency oscillator | Extremely slow chaotic oscillator. DSP engine by Don Cross. |
| NonlinearCircuits |  SlothTorpor |
5% | 5% | 5% | 5% | 5% | 5% | 5% | 5% | 5% | 5% | Hardware Clone, Low-frequency oscillator | Slow chaotic oscillator. DSP engine by Don Cross. |
| NonlinearCircuits |  SquidAxon |
2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | Mixer, Random, Hardware Clone | Mixer, Shift Register, and Feedback. Panel by Jason Wehmhoener. |
| NonlinearCircuits |  Statues |
3 – 4% | 3% | 3% | 3% | 3% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3% | Logic, Hardware Clone | 1->8 Signal switch using binary inputs. Panel by jk. |
| NonlinearCircuits |  TripleSloth |
12 – 14% | 12 – 14% | 12 – 14% | 12 – 14% | 12 – 14% | 12 – 14% | 12 – 14% | 12 – 14% | 12 – 14% | 12 – 14% | Hardware Clone, Low-frequency oscillator | Three combined slow chaotic oscillators. DSP engine by Don Cross. |
| Nozoid |  Nozori_68_ADSR |
4 – 6% | 4 – 6% | 4 – 6% | 4 – 5% | 4 – 5% | 4 – 6% | 4 – 6% | 4 – 6% | 4 – 5% | 4 – 5% | Hardware clone, Envelope generator, Dual, LFO | Dual loopable ADSR with modulation speed and integrated VCA |
| Nozoid |  Nozori_68_AR |
4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | Hardware clone, Envelope generator, Dual | Dual Attack Release with independent modulation |
| Nozoid |  Nozori_68_CRUSH |
5 – 6% | 5 – 6% | 5 – 6% | 5 – 6% | 5 – 6% | 5 – 6% | 5 – 6% | 5 – 6% | 5 – 6% | 5 – 6% | Hardware clone, Digital, Effect, Dual | Stereo Down-sampler / Bitcrusher |
| Nozoid |  Nozori_68_CV_REC |
5 – 7% | 5 – 6% | 5 – 6% | 5 – 6% | 5 – 6% | 5 – 7% | 5 – 6% | 5 – 6% | 5 – 6% | 5 – 6% | Hardware clone, Dual, Digital, Envelope generator, Recording | Record and play back 2 independent CV, at variable speed |
| Nozoid |  Nozori_68_DELAY |
5 – 7% | 5 – 7% | 5 – 7% | 5 – 6% | 5 – 6% | 5 – 7% | 5 – 7% | 5 – 7% | 5 – 6% | 5 – 6% | Hardware clone, Dual, Delay, Effect | Audio Delay, with tempo synchronisation |
| Nozoid |  Nozori_68_EQ |
5 – 6% | 6% | 5 – 6% | 5 – 6% | 5 – 6% | 5 – 6% | 6% | 5 – 6% | 5 – 6% | 5 – 6% | Hardware clone, Dual, Effect, Equalizer | 3 band equalizer |
| Nozoid |  Nozori_68_GRAN |
5 – 7% | 5 – 7% | 5 – 7% | 5 – 7% | 5 – 6% | 5 – 7% | 5 – 7% | 5 – 7% | 5 – 7% | 5 – 6% | Hardware clone, Digital, Effect, Granular | Audio Granulator |
| Nozoid |  Nozori_68_KS |
6 – 8% | 5 – 7% | 5 – 7% | 5 – 7% | 5 – 7% | 6 – 8% | 5 – 7% | 5 – 7% | 5 – 7% | 5 – 7% | Hardware clone, Delay, Effect | Karplus-Strong audio model |
| Nozoid |  Nozori_68_LFO |
6% | 5 – 6% | 5 – 6% | 5 – 6% | 5 – 6% | 6% | 5 – 6% | 5 – 6% | 5 – 6% | 5 – 6% | Hardware clone, Dual, Function generator, LFO, Sample and hold | Dual LFO, with parametric waveform and syncronisation to any signal |
| Nozoid |  Nozori_68_LFO_MOD |
5 – 7% | 5 – 6% | 5 – 6% | 5 – 6% | 5 – 6% | 5 – 7% | 5 – 6% | 5 – 6% | 5 – 6% | 5 – 6% | Hardware clone, Dual, Function generator, LFO, Sample and hold | LFO, with parametric waveform and syncronisation to any signal |
| Nozoid |  Nozori_68_NOISE |
5 – 7% | 4 – 7% | 5 – 6% | 4 – 7% | 4 – 6% | 5 – 7% | 4 – 7% | 5 – 7% | 4 – 7% | 4 – 6% | Hardware clone, Dual, Noise | Stereo Noise source, with low and high frequency filter |
| Nozoid |  Nozori_68_PITCH |
6 – 8% | 6 – 9% | 6 – 7% | 6 – 7% | 6 – 7% | 6 – 8% | 6 – 9% | 6 – 7% | 6 – 7% | 6 – 7% | Hardware clone, Dual, Effect | Dual Pitch shifter using tape emulation |
| Nozoid |  Nozori_68_RND_LOOP |
5 – 7% | 4 – 6% | 4 – 6% | 4 – 6% | 4 – 6% | 5 – 7% | 4 – 6% | 4 – 6% | 4 – 6% | 4 – 6% | Hardware clone, Dual, Function generator, LFO, Random | Loop of Random Value, with various interpolation and external synchronisation |
| Nozoid |  Nozori_68_SIN_MOD |
5 – 9% | 5 – 7% | 5 – 7% | 5 – 7% | 5 – 6% | 5 – 9% | 5 – 7% | 5 – 7% | 5 – 7% | 5 – 6% | Hardware clone, Oscillator | Sinusoidal oscillator with 2 external modulation (PM / FM / AM) |
| Nozoid |  Nozori_68_VCA_PAN |
5 – 6% | 5 – 7% | 5 – 6% | 5 – 6% | 5 – 7% | 5 – 6% | 5 – 7% | 5 – 6% | 5 – 6% | 5 – 7% | Hardware clone, Dual, Effect, Panning, Voltage-controlled amplifier | Stereo VCA-Panoramic, with modulation of the panoramic control |
| Nozoid |  Nozori_68_VCF_MOD |
5 – 7% | 6 – 7% | 5 – 8% | 5 – 6% | 5 – 6% | 5 – 7% | 6 – 7% | 5 – 8% | 5 – 6% | 5 – 6% | Hardware clone, Dual, Filter | Stereo VCF |
| Nozoid |  Nozori_68_VCF_MORPH |
6 – 8% | 6 – 7% | 6 – 7% | 5 – 7% | 5 – 7% | 6 – 8% | 6 – 7% | 6 – 7% | 5 – 7% | 5 – 7% | Hardware clone, Dual, Filter | Parametric stereo filter. |
| Nozoid |  Nozori_68_VCO |
6 – 10% | 5 – 7% | 5 – 9% | 5 – 7% | 5 – 7% | 6 – 10% | 5 – 7% | 5 – 9% | 5 – 7% | 5 – 7% | Hardware clone, Oscillator | Simple VCO, with VCA and VC Panoramic |
| Nozoid |  Nozori_68_VCO_LOOP |
5 – 8% | 5 – 6% | 5 – 6% | 5 – 7% | 5 – 6% | 5 – 8% | 5 – 6% | 5 – 6% | 5 – 7% | 5 – 6% | Hardware clone, Oscillator, Random | Loop of Random Value at audio rate |
| Nozoid |  Nozori_68_VCO_MORPH |
6 – 8% | 5 – 7% | 5 – 7% | 5 – 7% | 5 – 7% | 6 – 8% | 5 – 7% | 5 – 7% | 5 – 7% | 5 – 7% | Hardware clone, Oscillator | Parametric VCO, with VCA and VC Panoramic |
| Nozoid |  Nozori_68_VCO_QTZ |
6 – 7% | 5 – 7% | 5 – 7% | 5 – 6% | 5 – 6% | 6 – 7% | 5 – 7% | 5 – 7% | 5 – 6% | 5 – 6% | Hardware clone, Oscillator, Quantizer | Simple VCO, with VCA |
| Nozoid |  Nozori_68_VCO_WS |
6 – 10% | 6 – 8% | 5 – 7% | 5 – 7% | 5 – 7% | 6 – 10% | 6 – 8% | 5 – 7% | 5 – 7% | 5 – 7% | Hardware clone, Oscillator | Sinusoidal oscillator with VC waveshaper and VCA and VC Panoramic |
| Nozoid |  Nozori_68_WS |
5 – 8% | 6 – 7% | 6 – 7% | 5 – 7% | 5 – 7% | 5 – 8% | 6 – 7% | 6 – 7% | 5 – 7% | 5 – 7% | Hardware clone, Dual, Distortion, Effect, Waveshaper | Wave shaper and distortion with a VC Panoramic |
| Nozoid |  Nozori_84_8_BITS |
5% | 4 – 5% | 4 – 5% | 4% | 4 – 5% | 5% | 4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | Hardware clone, Dual, Digital, Effect, Oscillator | 8 bit audio generator |
| Nozoid |  Nozori_84_ADD |
5 – 6% | 5 – 6% | 5% | 5% | 5% | 5 – 6% | 5 – 6% | 5% | 5% | 5% | Hardware clone, Oscillator | Additive synthesis : a sinusoidal oscillator with 6 different harmonics |
| Nozoid |  Nozori_84_ADSR |
4 – 5% | 4 – 5% | 4% | 4% | 4% | 4 – 5% | 4 – 5% | 4% | 4% | 4% | Hardware clone, Dual, Envelope generator, LFO | Dual ADSR with loop mode |
| Nozoid |  Nozori_84_CLOCK |
4 – 5% | 4 – 5% | 4% | 4% | 4% | 4 – 5% | 4 – 5% | 4% | 4% | 4% | Hardware clone, Clock generator, Envelope generator, LFO | Stochastic Clock with ADSR and VCA |
| Nozoid |  Nozori_84_DOPPLER |
5 – 6% | 5 – 6% | 5% | 5% | 5% | 5 – 6% | 5 – 6% | 5% | 5% | 5% | Hardware clone, Delay, Effect | Emulate a Doppler effect applied on an audio source |
| Nozoid |  Nozori_84_FM |
5 – 6% | 5% | 5% | 5% | 5% | 5 – 6% | 5% | 5% | 5% | 5% | Hardware clone, Oscillator | Sinusoidal oscillator with 3 modulations oscillators |
| Nozoid |  Nozori_84_FM_LIN |
6% | 6% | 5 – 6% | 5 – 6% | 5 – 6% | 6 – 7% | 6% | 5 – 6% | 5 – 6% | 5 – 6% | Hardware clone, Oscillator | 4 sinusoidal oscillators linear FM synthesis |
| Nozoid |  Nozori_84_HARMONICS |
5% | 5 – 6% | 5% | 5% | 5% | 5% | 5 – 6% | 5% | 5% | 5% | Hardware clone, Oscillator | Sinusoidal oscillator with 3 harmonics at variable relative frequency |
| Nozoid |  Nozori_84_JONG_LFO |
5% | 5% | 5% | 5% | 5% | 5% | 5% | 5% | 5% | 5% | Hardware clone, Function generator, LFO | Peter de Jong chaotic attractor |
| Nozoid |  Nozori_84_JONG_VCO |
5% | 5% | 5% | 5% | 5% | 5 – 6% | 5 – 6% | 5% | 5% | 5% | Hardware clone, Oscillator | Peter de Jong chaotic attractor at audio frequency |
| Nozoid |  Nozori_84_LFO |
6% | 6% | 5 – 6% | 5 – 6% | 5 – 6% | 6% | 6% | 5 – 6% | 5 – 6% | 5 – 6% | Hardware clone, Dual, Function generator, LFO, Sample and hold | Dual LFO |
| Nozoid |  Nozori_84_LFO_SEQ |
4 – 5% | 4 – 5% | 4% | 4% | 4% | 4 – 5% | 4 – 5% | 4 – 5% | 4% | 4% | Hardware clone, Function generator, LFO, Sequencer | 6 step LFO / Sequencer |
| Nozoid |  Nozori_84_MODULATE |
5% | 5% | 5% | 5% | 4 – 5% | 5% | 5% | 5% | 5% | 4 – 5% | Hardware clone, Digital, Effect, Ring modulator | Modulate 2 audio sources together using various algorithms |
| Nozoid |  Nozori_84_PARAM |
5 – 6% | 5% | 5% | 5% | 5% | 5 – 6% | 5 – 6% | 5% | 5% | 5% | Hardware clone, Oscillator | 6 points parametric audio oscillator |
| Nozoid |  Nozori_84_SEQ_4 |
4 – 5% | 4 – 5% | 4 – 5% | 4% | 4% | 4 – 5% | 4 – 5% | 4 – 5% | 4% | 4% | Hardware clone, Sequencer | 4 step sequencer with parameterizable step length |
| Nozoid |  Nozori_84_SEQ_8 |
4% | 4% | 4% | 4% | 4% | 4% | 4% | 4% | 4% | 4% | Hardware clone, Sequencer | 8 steps sequencer |
| Nozoid |  Nozori_84_SIN_AM |
5 – 6% | 5 – 6% | 5% | 5 – 6% | 5% | 5 – 6% | 5 – 6% | 5% | 5 – 6% | 5% | Hardware clone, Oscillator | 4 oscillators AM modulation oscillator |
| Nozoid |  Nozori_84_SIN_FM |
6% | 5 – 6% | 5% | 5 – 6% | 5 – 6% | 6% | 5 – 6% | 5 – 6% | 5 – 6% | 5 – 6% | Hardware clone, Oscillator | 4 oscillators FM modulation oscillator |
| Nozoid |  Nozori_84_SIN_PM |
5 – 7% | 5 – 6% | 5 – 6% | 5 – 6% | 5% | 5 – 7% | 5 – 6% | 5 – 6% | 5 – 6% | 5% | Hardware clone, Oscillator | 4 oscillators Phase Modulation oscillator |
| Nozoid |  Nozori_84_SIN_WS |
6 – 7% | 6% | 6 – 7% | 6% | 6% | 6 – 8% | 6 – 7% | 6 – 7% | 6 – 7% | 6% | Hardware clone, Oscillator | Dual oscillator and a Peter De Jong waveshaper |
| Nozoid |  Nozori_84_THOMAS |
5 – 6% | 5 – 6% | 5 – 6% | 5% | 5 – 6% | 5 – 6% | 5 – 6% | 5 – 6% | 5% | 5 – 6% | Hardware clone, Digital, LFO, Oscillator | Dual Thomas strange attractor for CV or audio noise source |
| Nozoid |  Nozori_84_TROPICAL |
5% | 5% | 5% | 5% | 5% | 5 – 6% | 5% | 5% | 5% | 5% | Hardware clone, Digital, Oscillator | Tropical additive synthesis |
| Nozoid |  Nozori_84_VCF |
5 – 6% | 5 – 6% | 5% | 5% | 5% | 5 – 6% | 5 – 6% | 5% | 5% | 5% | Hardware clone, Filter | Dual filter with parametric control of the frequency response. |
| Nozoid |  Nozori_84_WS |
7 – 8% | 6 – 8% | 6 – 7% | 6 – 7% | 6% | 7 – 8% | 6 – 8% | 6 – 7% | 6 – 7% | 6% | Hardware clone, Distortion, Effect, Waveshaper | Stereo Wave Shaper |
| NullPath |  Cascade |
13 – 25% | 13 – 25% | 13 – 25% | 13 – 25% | 13 – 25% | 13 – 25% | 13 – 25% | 13 – 25% | 13 – 25% | 13 – 25% | Envelope generator | A 4 channel envelope/function generator |
| NullPath |  Entangle |
12 – 15% | 12 – 14% | 12 – 14% | 12 – 14% | 12 – 14% | 12 – 25% | 12 – 24% | 12 – 24% | 12 – 24% | 12 – 24% | Switch, Utility | 9-9 random router |
| NullPath |  Turbulence |
18 – 24% | 18 – 24% | 18 – 24% | 18 – 24% | 18 – 24% | 18 – 24% | 18 – 24% | 18 – 24% | 18 – 24% | 18 – 24% | Oscillator, Polyphonic, Synth voice | A supersaw oscillator/synth voice, with noise and a built-in ADSR envelope |
| NullPath |  Expand |
3 – 5% | 3 – 5% | 3 – 5% | 3 – 5% | 3 – 5% | 3 – 5% | 3 – 5% | 3 – 5% | 3 – 5% | 3 – 5% | Switch, Utility, Polyphonic | A 1-9 not-so-sequential switch |
| NullPath |  Collapse |
3 – 4% | 3% | 3% | 3% | 3% | 3 – 4% | 3% | 3% | 3% | 3% | Switch, Utility, Polyphonic | A 9-1 not-so-sequential switch |
| Ondas |  BaBum |
3 – 26% | 3 – 26% | 3 – 26% | 3 – 26% | 3 – 26% | 3 – 26% | 3 – 26% | 3 – 26% | 3 – 26% | 3 – 26% | Drum | Drum synthesizer |
| Ondas |  Distroi |
3 – 11% | 3 – 11% | 2 – 11% | 2 – 11% | 2 – 11% | 3 – 12% | 3 – 13% | 2 – 11% | 2 – 11% | 2 – 11% | Effect, Distortion, Digital | Signal corruption effects |
| Ondas |  Klok |
3% | 3% | 3% | 3% | 3% | 3% | 3% | 3% | 3% | 3% | Clock generator, Clock modulator | Clock generator with modulo outputs |
| Ondas |  Scener |
3 – 4% | 3% | 3% | 3% | 3% | 3 – 4% | 3% | 3% | 3% | 3% | Sequencer, Utility | Scene-based channel mixer |
| Ondas |  Secu |
3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 5% | 3 – 5% | 3 – 5% | 3 – 5% | 3 – 4% | Sequencer, Clock modulator | Step sequencer with probability & randomization |
| OrangeLine |  Dejavu |
16 – 117% | 16 – 72% | 16 – 47% | 16 – 36% | 16 – 30% | 16 – 117% | 16 – 74% | 16 – 53% | 16 – 41% | 16 – 36% | Utility, Polyphonic, Random, Sequencer, Visual | Random Cv and Trigger generator with nested repeat functionality |
| OrangeLine |  Fence |
7 – 14% | 7 – 14% | 7 – 14% | 7 – 14% | 7 – 14% | 7 – 27% | 7 – 25% | 7 – 23% | 7 – 23% | 7 – 23% | Quantizer, Tuner, Utility, Distortion, WaveShaper, Polyphonic | Keep CVs in a defined pitch range |
| OrangeLine |  Gator |
6 – 16% | 6 – 13% | 6 – 11% | 6 – 11% | 6 – 11% | 6 – 21% | 6 – 18% | 6 – 15% | 6 – 16% | 6 – 15% | Utility, Polyphonic, Clock Modulator | Phased Based Microtiming, Ratcheting and Strumming |
| OrangeLine |  Morph |
9 – 16% | 9 – 14% | 9 – 14% | 9 – 14% | 8 – 13% | 9 – 26% | 9 – 23% | 9 – 23% | 9 – 23% | 8 – 23% | Utility, Sequencer, Random, Polyphonic | Morphing of given or random sequences with turing machine functionality |
| OrangeLine |  Morpheus |
12 – 28% | 12 – 26% | 12 – 24% | 12 – 23% | 12 – 23% | 12 – 55% | 12 – 50% | 12 – 48% | 12 – 46% | 12 – 46% | Utility, Sequencer, Random, Polyphonic | Morphing of given or random sequences with turing machine functionality and 16 Internal Memory Slots. |
| OrangeLine |  Mother |
29 – 143% | 29 – 145% | 29 – 145% | 29 – 131% | 29 – 111% | 29 – 245% | 29 – 245% | 29 – 241% | 29 – 238% | 29 – 238% | Quantizer, Sequencer, Polyphonic | Mode aware probability driven quantizer |
| OrangeLine |  Phrase |
8 – 11% | 8 – 10% | 8 – 10% | 8 – 10% | 8 – 10% | 8 – 11% | 8 – 10% | 8 – 10% | 8 – 10% | 8 – 10% | Sequencer, Utility, Clock modulator | Utility to sequence phrases by sequencing a sequencer |
| OrangeLine |  Resc |
6 – 10% | 6 – 10% | 6 – 10% | 6 – 10% | 6 – 10% | 6 – 18% | 6 – 18% | 6 – 18% | 6 – 18% | 6 – 17% | Utility, Polyphonic | Utility to harmonicaly rescales pitch from one scale to another scale |
| OrangeLine |  Swing |
8 – 10% | 8 – 10% | 8 – 10% | 8 – 10% | 8 – 10% | 8 – 10% | 8 – 10% | 8 – 10% | 8 – 10% | 8 – 10% | Sequencer, Clock, Clock modulator | Micro Timing Sequencer |
| Path Set: Free |  AstroVibe |
16 – 23% | 15 – 23% | 15 – 21% | 15 – 21% | 15 – 20% | 16 – 62% | 15 – 62% | 15 – 61% | 15 – 60% | 15 – 60% | VCO, LFO, Physical modeling | Three stereo oscillators or LFOs with random waveforms. Explore a universe of unique waveforms. |
| Path Set: Free |  GlassPane |
9 – 21% | 9 – 20% | 9 – 18% | 9 – 18% | 9 – 18% | 9 – 22% | 9 – 20% | 9 – 19% | 9 – 18% | 9 – 18% | Sequencer, Random | Patchable, branchable, network sequencer. Create a cascading intricate self modulating sequence. |
| Path Set: Free |  IceTray |
8 – 388% | 7 – 382% | 7 – 390% | 7 – 320% | 7 – 321% | 8 – 400% | 7 – 384% | 7 – 392% | 7 – 324% | 7 – 321% | Delay, Recording, Granular | Speed shifter and tape delay with selective memory. Perform into this and it will never forget your mistakes. |
| Path Set: Free |  Nudge |
7 – 10% | 7 – 10% | 7 – 10% | 7 – 10% | 7 – 10% | 7 – 10% | 7 – 10% | 7 – 10% | 7 – 10% | 7 – 10% | Random | Modulation generator that lets you randomly nudge the modulations whenever you want. |
| Path Set: Free |  OneShot |
2 – 3% | 2 – 3% | 2% | 2% | 2% | 2 – 3% | 2 – 3% | 2% | 2% | 2% | Sequencer, Random | One-shot Sequencer that can be daisy-chained with other sequencers or more OneShots. |
| Path Set: Free |  Shifty |
2 – 4% | 2 – 4% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 5% | 2 – 4% | 2 – 3% | 2 – 3% | 2 – 3% | Clock, Clock modulator, Sample and hold | Gate shift register with controllable delays. Create generative gate sequences from a single clock. |
| Phase Oscillator | Warp Core | 24 – 25% | 24% | 24% | 24% | 24% | 24 – 84% | 24 – 84% | 24 – 83% | 24 – 83% | 24 – 83% | Oscillator, Polyphonic | Dual-algorithm phase distortion and phase modulation oscillator |
| Producer Pack |  AuxSends |
3 – 7% | 3 – 7% | 3 – 7% | 3 – 7% | 3 – 7% | 3 – 14% | 3 – 14% | 3 – 14% | 3 – 14% | 3 – 14% | Stereo, Utility, Mixer, Effect | 3 sets of stereo auxillary sends and returns with CV control |
| Producer Pack |  Bitcrusher |
4 – 9% | 4 – 8% | 4 – 8% | 4 – 8% | 4 – 8% | 4 – 12% | 4 – 12% | 4 – 12% | 4 – 12% | 4 – 12% | Stereo, Effect, Filter, VCF, Distortion | Stereo bitcrusher, sample rate reducer, and selectable resonant filter |
| Producer Pack |  Boost |
2 – 4% | 2 – 4% | 2 – 4% | 2 – 3% | 2 – 3% | 2 – 4% | 2 – 4% | 2 – 4% | 2 – 4% | 2 – 4% | Dynamics, Utility, Effect, Distortion | Stereo gain + distortion module |
| Producer Pack |  DJFilter |
3 – 9% | 3 – 9% | 3 – 6% | 2 – 7% | 2 – 6% | 3 – 11% | 3 – 11% | 3 – 10% | 2 – 11% | 2 – 10% | Effect, Filter, Stereo, VCF | A continous lowpass to highpass filter effect in the spirit of DJ mixers |
| Producer Pack |  Decay |
2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 4% | 2 – 4% | 2 – 4% | 2 – 4% | 2 – 4% | Utility, Drum, Envelope generator, VCA, Voltage-controlled amplifier | Decay envelope with built in VCA |
| Producer Pack |  DrumBus |
3 – 7% | 3 – 5% | 2 – 5% | 3 – 5% | 2 – 5% | 3 – 9% | 3 – 9% | 2 – 9% | 3 – 9% | 2 – 9% | Stereo, Mixer, Drum, Utility | 8 channel mono to stereo mixer with mute per channel |
| Producer Pack |  SeventiesComp |
4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | 4 – 8% | 4 – 8% | 4 – 8% | 4 – 8% | 4 – 8% | Stereo, Utility, Effect, Compressor, Dynamics | LA2A inspired optical compressor |
| Producer Pack |  SeventiesEQ |
4 – 9% | 4 – 7% | 4 – 7% | 4 – 7% | 4 – 7% | 4 – 13% | 4 – 14% | 4 – 14% | 4 – 14% | 4 – 14% | Stereo, Utility, Equalizer, EQ, Effect | Neve 1073 inspired stereo EQ |
| Producer Pack |  Spatializer |
3 – 5% | 3 – 5% | 3 – 5% | 3 – 5% | 3 – 5% | 3 – 8% | 3 – 8% | 3 – 8% | 3 – 7% | 3 – 7% | Stereo, Utility, Effect | Exploitation of the Haas effect + mid/side processing techniques |
| Producer Pack |  StereoCrossfader |
2 – 5% | 2 – 5% | 2 – 5% | 2 – 5% | 2 – 5% | 2 – 6% | 2 – 6% | 2 – 6% | 2 – 6% | 2 – 6% | Stereo, Utility | Crossfade between two stereo audio sources |
| Producer Pack |  StereoWidth |
2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 4% | 2 – 4% | 2 – 4% | 2 – 4% | 2 – 4% | Stereo, Utility | Shrink or expand the stereo image of a stereo track |
| RebelTech |  CLK |
3% | 3% | 3% | 3% | 3% | 3% | 3% | 3% | 3% | 3% | Clock generator, Clock modulator, Hardware clone | Triple clock generator that produces synchronised clock signals |
| RebelTech |  Klasmata |
6 – 9% | 6 – 8% | 6 – 8% | 6 – 8% | 6 – 8% | 6 – 9% | 6 – 8% | 6 – 8% | 6 – 8% | 6 – 8% | Clock modulator, Sequencer, Hardware clone | Voltage controlled Euclidean sequencer |
| RebelTech |  Logoi |
6 – 7% | 6 – 8% | 6 – 7% | 6% | 6% | 6 – 7% | 6 – 8% | 6 – 7% | 6% | 6% | Clock modulator, Delay, Hardware clone | Voltage controlled clock divider, counter, and delay |
| RebelTech |  Phoreo |
6 – 7% | 7% | 6 – 7% | 6 – 7% | 6 – 7% | 6 – 7% | 7% | 6 – 7% | 6 – 7% | 6 – 7% | Clock modulator, Hardware clone | Trigger modulator, multiplier and repeater |
| RebelTech |  Stoicheia |
4 – 5% | 4% | 4% | 4% | 4% | 4 – 5% | 4% | 4% | 4% | 4% | Clock modulator, Dual, Hardware clone, Sequencer | Dual Euclidean Sequencer |
| RebelTech |  Tonic |
10% | 10% | 10% | 10% | 10% | 9 – 10% | 9 – 10% | 9 – 10% | 9 – 10% | 9 – 10% | Sequencer, Hardware clone, Polyphonic | Additive Interval Sequencer |
| Rigatoni |  Loom |
93 – 142% | 95 – 137% | 95 – 133% | 95 – 133% | 96 – 133% | 93 – 142% | 95 – 137% | 95 – 133% | 95 – 133% | 96 – 133% | Digital, Low-frequency oscillator, Oscillator, Synth voice | An additive oscillator based loosely on the structure of Euclidean pattern sequencing |
| Rigatoni |  Thru Zero |
4% | 4% | 4% | 4% | 4% | 4% | 4% | 4% | 4% | 4% | Distortion, Utility, Waveshaper | A small waveshaping utility that mimics soft oscillator sync for input ramp waves and acts as a through zero FM helper |
| ROMplers |  AyysKing |
5 – 9% | 5 – 9% | 5 – 9% | 5 – 9% | 5 – 9% | 5 – 9% | 5 – 9% | 5 – 9% | 5 – 9% | 5 – 9% | Drum | Ace Tone Rhythm King samples with playback speed, sample length, and looping |
| ROMplers |  Clap |
2 – 5% | 2 – 4% | 2 – 4% | 2 – 4% | 2 – 4% | 2 – 5% | 2 – 5% | 2 – 5% | 2 – 4% | 2 – 4% | Drum | 'Real' acoustic clap samples with playback speed, velocity, and a decay envelope |
| ROMplers |  ClosedHat |
2 – 4% | 2 – 4% | 2 – 4% | 2 – 4% | 2 – 4% | 2 – 4% | 2 – 5% | 2 – 4% | 2 – 4% | 2 – 4% | Drum | 'Real' acoustic closed hi-hat samples with playback speed, velocity, and a decay envelope |
| ROMplers |  Crash |
2 – 5% | 2 – 4% | 2 – 4% | 2 – 4% | 2 – 4% | 2 – 5% | 2 – 5% | 2 – 4% | 2 – 4% | 2 – 4% | Drum | 'Real' acoustic crash samples with playback speed, velocity, and a decay envelope |
| ROMplers |  DeeArr |
3 – 5% | 3 – 5% | 3 – 5% | 3 – 5% | 3 – 5% | 3 – 5% | 3 – 5% | 3 – 5% | 3 – 5% | 3 – 5% | Drum | DR-55 samples with playback speed, sample length, looping, and direct outs. |
| ROMplers |  KayArr |
5 – 9% | 5 – 9% | 5 – 9% | 5 – 9% | 5 – 9% | 5 – 9% | 5 – 9% | 5 – 9% | 5 – 9% | 5 – 9% | Drum | KR55 samples with playback speed, sample length, and looping. |
| ROMplers |  KayOne |
4 – 6% | 4 – 6% | 4 – 6% | 4 – 6% | 4 – 6% | 4 – 6% | 4 – 6% | 4 – 6% | 4 – 6% | 4 – 6% | Drum | Casio SK-1 samples with playback speed, sample length, and looping. Samples by Brian Hilmers, license: CC-BY-SA-4.0 |
| ROMplers |  Kick |
2 – 5% | 2 – 5% | 2 – 4% | 2 – 4% | 2 – 4% | 2 – 5% | 2 – 5% | 2 – 4% | 2 – 4% | 2 – 4% | Drum | 'Real' acoustic kick samples with playback speed, velocity, and a decay envelope |
| ROMplers |  OpenHat |
2 – 4% | 2 – 5% | 2 – 4% | 2 – 4% | 2 – 4% | 2 – 5% | 2 – 5% | 2 – 4% | 2 – 5% | 2 – 4% | Drum | 'Real' acoustic open hi-hat samples with playback speed, velocity, and a decay envelope |
| ROMplers |  OrchHits |
3 – 8% | 3 – 6% | 2 – 6% | 2 – 6% | 2 – 6% | 3 – 8% | 3 – 6% | 2 – 6% | 2 – 6% | 2 – 6% | Drum, synth voice | Pitched orchestra hits |
| ROMplers |  Percussion |
3 – 5% | 2 – 5% | 2 – 5% | 2 – 5% | 2 – 5% | 3 – 5% | 2 – 5% | 2 – 5% | 2 – 5% | 2 – 5% | Drum | 'Real' acoustic auxillary percussion samples with playback speed, velocity, and a decay envelope |
| ROMplers |  Ride |
2 – 5% | 2 – 5% | 2 – 5% | 2 – 4% | 2 – 4% | 2 – 5% | 2 – 5% | 2 – 5% | 2 – 4% | 2 – 4% | Drum | 'Real' acoustic ride samples with playback speed, velocity, and a decay envelope |
| ROMplers |  Rimshot |
3 – 4% | 2 – 5% | 2 – 5% | 2 – 4% | 2 – 5% | 3 – 5% | 2 – 5% | 2 – 5% | 2 – 5% | 2 – 5% | Drum | 'Real' acoustic rimshot samples with playback speed, velocity, and a decay envelope |
| ROMplers |  SeaArr |
6 – 10% | 6 – 10% | 6 – 10% | 6 – 10% | 6 – 10% | 6 – 10% | 6 – 10% | 6 – 10% | 6 – 10% | 6 – 10% | Drum | CR-78 samples with playback speed, sample length, looping, and direct outs. Samples provided by Oramics, license: Public Domain. |
| ROMplers |  SehvenToo |
6 – 11% | 6 – 10% | 6 – 10% | 6 – 10% | 6 – 10% | 6 – 11% | 6 – 10% | 6 – 10% | 6 – 10% | 6 – 10% | Drum | TR-727 samples with playback speed, sample length, looping, and direct outs. |
| ROMplers |  SicksOh |
5 – 7% | 5 – 7% | 4 – 7% | 5 – 7% | 5 – 7% | 5 – 9% | 5 – 7% | 4 – 7% | 5 – 7% | 5 – 7% | Drum | TR-606 samples with playback speed, sample length, and looping. |
| ROMplers |  SinSahnix |
4 – 6% | 4 – 6% | 4 – 6% | 4 – 6% | 4 – 6% | 4 – 6% | 4 – 6% | 4 – 6% | 4 – 6% | 4 – 6% | Drum | Synsonics samples with playback speed, sample length, and looping. |
| ROMplers |  Slap |
2 – 7% | 2 – 7% | 2 – 6% | 2 – 6% | 2 – 6% | 2 – 7% | 2 – 7% | 2 – 6% | 2 – 6% | 2 – 6% | Synth Voice | The best pitched slap bass sample in the whole wide world. |
| ROMplers |  Snare |
2 – 5% | 2 – 5% | 2 – 5% | 2 – 4% | 2 – 4% | 2 – 5% | 2 – 5% | 2 – 5% | 2 – 4% | 2 – 4% | Drum | 'Real' acoustic snare samples with playback speed, velocity, and a decay envelope |
| ROMplers |  Tom |
3 – 5% | 2 – 5% | 2 – 4% | 2 – 4% | 2 – 4% | 3 – 5% | 2 – 5% | 2 – 4% | 2 – 4% | 2 – 4% | Drum | 'Real' acoustic tom samples with playback speed, velocity, and a decay envelope |
| RPJ |  BlindCurve |
2 – 6% | 2 – 6% | 2 – 6% | 2 – 6% | 2 – 6% | 2 – 6% | 2 – 6% | 2 – 6% | 2 – 6% | 2 – 6% | Envelope Follower, Polyphonic | Audio Detector |
| RPJ |  Brave |
2 – 17% | 2 – 17% | 2 – 17% | 2 – 17% | 2 – 17% | 2 – 18% | 2 – 17% | 2 – 17% | 2 – 17% | 2 – 17% | VCF, Polyphonic | Brave is a 2nd Order Parametric EQ Filter: Non constant Q. |
| RPJ |  CircularRide |
4 – 52% | 4 – 52% | 3 – 53% | 3 – 53% | 3 – 53% | 4 – 53% | 4 – 53% | 3 – 54% | 3 – 54% | 3 – 54% | Delay, Polyphonic | Stereo Delay |
| RPJ |  DrillingHoles |
2 – 6% | 2 – 6% | 2 – 5% | 2 – 5% | 2 – 5% | 2 – 6% | 2 – 6% | 2 – 5% | 2 – 5% | 2 – 5% | Utility, Switch, Polyphonic | Normalizer |
| RPJ |  DryLand |
2 – 20% | 2 – 20% | 2 – 20% | 2 – 20% | 2 – 20% | 2 – 21% | 2 – 21% | 2 – 20% | 2 – 20% | 2 – 20% | VCF, Polyphonic | Module with 1st order LPF and HPF |
| RPJ |  Easter |
3 – 15% | 3 – 15% | 3 – 15% | 3 – 15% | 3 – 15% | 3 – 18% | 3 – 18% | 3 – 17% | 3 – 15% | 3 – 15% | VCF, Polyphonic | Module with 2 resonators |
| RPJ |  Essence |
2 – 15% | 2 – 15% | 2 – 15% | 2 – 15% | 2 – 15% | 2 – 15% | 2 – 15% | 2 – 15% | 2 – 15% | 2 – 15% | VCF, Polyphonic | Essence is a 2nd Order Parametric EQ Filter with a constant Q. |
| RPJ |  Estonia |
4 – 15% | 3 – 15% | 3 – 15% | 3 – 15% | 3 – 15% | 4 – 15% | 3 – 15% | 3 – 15% | 3 – 15% | 3 – 15% | VCF, Polyphonic | Estonia is a 1st order High and Low shelving filter. |
| RPJ |  Gaza |
2 – 25% | 2 – 25% | 2 – 25% | 2 – 25% | 2 – 25% | 2 – 25% | 2 – 25% | 2 – 25% | 2 – 25% | 2 – 25% | Envelope Follower, Polyphonic | Envelope Follower |
| RPJ |  Gazpacho |
2 – 19% | 2 – 18% | 2 – 19% | 2 – 19% | 2 – 19% | 2 – 20% | 2 – 21% | 2 – 20% | 2 – 20% | 2 – 20% | VCF, Polyphonic | Module with 2nd order Linkwitz-Riley LPF and HPF |
| RPJ |  Genie |
107 – 108% | 108 – 111% | 109 – 111% | 110 – 111% | 109 – 111% | 107 – 108% | 108 – 111% | 109 – 111% | 110 – 111% | 109 – 111% | S&H | Chaos generator |
| RPJ |  Grendel |
16 – 29% | 16 – 30% | 16 – 30% | 16 – 30% | 16 – 30% | 16 – 29% | 16 – 30% | 16 – 30% | 16 – 30% | 16 – 30% | LFO | Quadruple low frequency oscillator, inspired by XAOC Batumi |
| RPJ |  LadyNina |
2 – 32% | 2 – 33% | 2 – 33% | 2 – 32% | 2 – 32% | 2 – 32% | 2 – 33% | 2 – 33% | 2 – 32% | 2 – 32% | VCF, Polyphonic | LadyNina is a 2nd order SFV (LPF, HPF, BPF, BSF) |
| RPJ |  Lavender |
2 – 36% | 2 – 36% | 2 – 36% | 2 – 36% | 2 – 36% | 2 – 36% | 2 – 36% | 2 – 36% | 2 – 36% | 2 – 36% | VCF, Polyphonic | Module with 2nd order LPF, HPF, BPF and BSF |
| RPJ |  Montreal |
2 – 46% | 2 – 46% | 2 – 47% | 2 – 47% | 2 – 47% | 2 – 46% | 2 – 46% | 2 – 47% | 2 – 47% | 2 – 47% | VCF, Polyphonic | Ideal 2nd Order RLC Filters LPF, HPF, BPF and BSF |
| RPJ |  FM Pigeon Plink |
18 – 20% | 18 – 20% | 18 – 20% | 18 – 20% | 18 – 20% | 18 – 21% | 18 – 21% | 18 – 21% | 18 – 21% | 18 – 21% | VCO, Polyphonic, Synth voice | Many function VCO |
| RPJ |  SugarMice |
2 – 32% | 2 – 33% | 2 – 33% | 2 – 33% | 2 – 33% | 2 – 32% | 2 – 33% | 2 – 33% | 2 – 33% | 2 – 33% | VCF, Polyphonic | 3rd order Butterworth low-pass ladder filter. |
| RPJ |  TheWeb |
2 – 35% | 2 – 36% | 2 – 36% | 2 – 35% | 2 – 35% | 2 – 35% | 2 – 36% | 2 – 36% | 2 – 35% | 2 – 35% | VCF, Polyphonic | Module with 2nd order Butterworth LPF, HPF, BPF and BSF |
| Sanguine Monsters |  Aion |
3 – 5% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 5% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | Quad, Utility, Clock modulator | Four counters that can be advanced by triggers or their internal clock |
| Sanguine Monsters |  Kitsune |
5% | 5% | 5% | 5% | 5% | 5% | 5% | 5% | 5% | 5% | Attenuator, Quad, Polyphonic | Attenuate; invert, and offset up to 4 voltages |
| Sanguine Monsters |  Medusa |
5 – 9% | 5 – 9% | 5 – 9% | 5 – 9% | 5 – 9% | 5 – 9% | 5 – 9% | 5 – 9% | 5 – 9% | 5 – 9% | Multiple, Polyphonic | A normalled, polyphonic mega multiple with 32 inputs and outputs |
| Sanguine Monsters |  Bukavac |
2 – 44% | 2 – 27% | 2 – 19% | 2 – 15% | 2 – 13% | 2 – 44% | 2 – 27% | 2 – 19% | 2 – 15% | 2 – 13% | Noise | A noise generator with a plethora of colors... and Perlin |
| Sanguine Monsters |  Dungeon |
4 – 6% | 4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | 4 – 6% | 4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | Noise, Sample and hold, Random | A sample and hold, track and hold, hold and track and white noise source. |
| Sanguine Monsters |  Oraculus |
2 – 5% | 3 – 5% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 5% | 3 – 5% | 2 – 4% | 2 – 3% | 2 – 3% | Utility, Polyphonic, Switch | n to 1 switch/sequencer that takes a polyphonic cable input. |
| Sanguine Monsters |  Sphinx |
3 – 4% | 3 – 5% | 3 – 4% | 2 – 3% | 2 – 3% | 3 – 4% (mono) | 3 – 5% (mono) | 3 – 4% (mono) | 2 – 3% (mono) | 2 – 3% (mono) | Sequencer | An euclidean sequencer with different modes. |
| Sanguine Monsters |  Oubliette |
2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | Utility | A null sink and cable holder for your input and output wires. Also works as a null voltage source. |
| Sanguine Monsters |  Gegenees |
3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | Switch, Random, Sequencer, Polyphonic | A 1 to 8 switch/sequencer that can avoid consecutive random repeated values; can be one shot, and can be reset to either no step value or the first step. |
| Sanguine Monsters |  Hydra |
3 – 5% | 3 – 4% | 3 – 4% | 3 – 4% | 2 – 4% | 3 – 5% | 3 – 4% | 3 – 4% | 3 – 4% | 2 – 4% | Switch, Random, Sequencer, Polyphonic | An 8 to 1 switch/sequencer that can avoid consecutive random repeated values; can be one shot, and can be reset to either no step value or the first step. |
| Sanguine Monsters |  Werewolf |
2 – 7% | 2 – 5% | 2 – 5% | 2 – 5% | 2 – 5% | 2 – 22% | 2 – 17% | 2 – 15% | 2 – 12% | 2 – 12% | Distortion, Polyphonic | Dirty stereo distortion |
| Sanguine Mutants |  Funes |
11 – 15% | 11 – 12% | 10 – 11% | 10 – 11% | 10% | 11 – 44% | 11 – 39% | 10 – 36% | 10 – 30% | 10 – 29% | Digital, Drum, Hardware clone, Noise, Oscillator, Polyphonic, Speech, Synth voice | Powerful, polyphonic macro oscillator based on Mutable Instruments' Plaits 1.2 |
| Sanguine Mutants |  Aestus |
6 – 7% | 5 – 6% | 5 – 6% | 5 – 6% | 5 – 6% | 6 – 7% | 5 – 6% | 5 – 6% | 5 – 6% | 5 – 6% | Clock generator, Digital, Envelope generator, Function generator, Hardware clone, Low-frequency oscillator, Oscillator, Waveshaper | Modulator based on Mutable Instruments' Tides |
| Sanguine Mutants |  Aleae |
3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 6% | 3 – 6% | 3 – 6% | 3 – 6% | 3 – 6% | Random, Dual, Hardware clone, Polyphonic | Pair of polyphonic Bernoully gates based on Mutable Instruments' Branches |
| Sanguine Mutants |  Anuli |
27 – 46% | 21 – 32% | 19 – 29% | 18 – 27% | 17 – 25% | 27 – 116% | 21 – 108% | 19 – 102% | 18 – 94% | 17 – 95% | Effect, Filter, Hardware clone, Oscillator, Physical modeling, Polyphonic | Polyphonic resonator based on Mutable Instruments' Rings |
| Sanguine Mutants |  Apices |
7 – 10% | 7 – 8% | 6 – 7% | 6 – 7% | 6 – 7% | 7 – 10% | 7 – 8% | 6 – 7% | 6 – 7% | 6 – 7% | Delay, Drum, Dual, Envelope generator, Hardware clone, Low-frequency oscillator, Oscillator, Sequencer, Speech | Versatile complement to any patch, based on Mutable Instruments' Peaks |
| Sanguine Mutants |  Contextus |
12 – 13% | 10 – 12% | 10 – 12% | 10 – 11% | 10 – 11% | 12 – 34% | 10 – 33% | 10 – 31% | 10 – 30% | 10 – 28% | Digital, Hardware clone, Noise, Oscillator, Polyphonic, Speech, Synth voice, Waveshaper | Multipurpose, polyphonic macro oscillator based on the Renaissance alternative firmware for Mutable Instruments' Braids |
| Sanguine Mutants |  Distortiones |
8 – 24% | 7 – 21% | 7 – 17% | 6 – 14% | 6 – 13% | 8 – 47% | 7 – 27% | 7 – 27% | 6 – 25% | 6 – 23% | Delay, Digital, Effect, Hardware clone, Oscillator, Polyphonic, Ring modulator, Vocoder, Waveshaper | Doctored, flexible and fully polyphonic meta-modulator based on the Parasite alternative firmware for Mutable Instruments' Warps |
| Sanguine Mutants |  Etesia |
50 – 75% | 28 – 47% | 22 – 35% | 20 – 30% | 17 – 22% | 50 – 75% | 28 – 47% | 22 – 35% | 20 – 30% | 17 – 22% | Delay, Digital, Effect, Granular, Hardware clone, Reverb | Texture synthesizer based on the Parasite firmware for Mutable Instruments' Clouds |
| Sanguine Mutants |  Explorator |
5 – 7% | 4 – 6% | 4 – 6% | 3 – 6% | 3 – 6% | 5 – 10% | 4 – 9% | 4 – 9% | 3 – 9% | 3 – 9% | Hardware clone, Logic, Mixer, Multiple, Noise, Polyphonic, Sample and hold, Utility, Waveshaper | Polyphonic multiple, mixer, noise source, sample and hold, inverter, rectifier and logic unit, based on Mutable Instruments' Links and Kinks |
| Sanguine Mutants |  Fluctus |
51 – 75% | 28 – 48% | 22 – 36% | 21 – 30% | 18 – 22% | 51 – 75% | 28 – 48% | 22 – 36% | 21 – 30% | 18 – 22% | Delay, Digital, Effect, Granular, Hardware clone | Texture synthesizer based on the Kammerl Beat-Repeat firmware for Mutable Instruments' Clouds |
| Sanguine Mutants |  Incurvationes |
22 – 28% | 20 – 25% | 16 – 20% | 14 – 17% | 13 – 15% | 22 – 94% | 20 – 71% | 16 – 58% | 14 – 52% | 13 – 48% | Digital, Effect, Hardware clone, Oscillator, Polyphonic, Ring modulator, Vocoder, Waveshaper | Polyphonic meta modulator based on Mutable Instruments' Warps |
| Sanguine Mutants |  Marmora |
13 – 18% | 11 – 16% | 11 – 15% | 10 – 14% | 10 – 13% | 13 – 18% | 11 – 16% | 11 – 15% | 10 – 14% | 10 – 13% | Clock generator, Clock modulator, Digital, Hardware clone, Quantizer, Random, Sequencer | Random sampler based on Mutable Instruments' Marbles |
| Sanguine Mutants |  Mortuus |
7 – 9% | 6 – 7% | 6 – 7% | 6 – 7% | 6% | 7 – 9% | 6 – 7% | 6 – 7% | 6 – 7% | 6% | Delay, Drum, Dual, Envelope generator, Hardware clone, Low-frequency oscillator, Oscillator, Sequencer, Speech | All-around gap filler based on the Dead Man's Catch firmware, with some additions, for Mutable Instruments' Peaks |
| Sanguine Mutants |  Sanguine Mutants Blank |
2% | 2% | 2% | 2% | 2% | 2% (mono) | 2% (mono) | 2% (mono) | 2% (mono) | 2% (mono) | Blank, Visual | Rack sleekerizer: add the Mutants goblin and a glowing Mutants logo to your rack! |
| Sanguine Mutants |  Mutuus |
8 – 26% | 8 – 21% | 6 – 17% | 6 – 14% | 6 – 13% | 8 – 87% | 8 – 69% | 6 – 62% | 6 – 53% | 6 – 48% | Delay, Digital, Effect, Filter, Hardware clone, Oscillator, Polyphonic, Reverb, Ring modulator, Vocoder, Waveshaper | Experimental, polyphonic and multifaceted meta-modulator based on the Symbiote firmware for Mutable Instruments' Warps |
| Sanguine Mutants |  Nebulae |
51 – 75% | 27 – 47% | 22 – 35% | 20 – 30% | 17 – 22% | 51 – 75% | 27 – 47% | 22 – 35% | 20 – 30% | 17 – 22% | Delay, Digital, Effect, Granular, Hardware clone, Reverb | Texture synthesizer based on the Monsoon version of Mutable Instruments' Clouds |
| Sanguine Mutants |  Nodi |
11 – 12% | 11 – 12% | 10 – 12% | 10 – 11% | 10 – 11% | 11 – 33% | 11 – 31% | 10 – 30% | 10 – 29% | 10 – 28% | Digital, Hardware clone, Noise, Oscillator, Polyphonic, Speech, Synth voice, Waveshaper | Adaptable, polyphonic macro oscillator based on Mutable Instruments' Braids |
| Sanguine Mutants |  Scalaria |
10 – 11% | 10% | 8% | 7% | 7% | 10 – 34% | 10 – 30% | 8 – 26% | 7 – 23% | 7 – 21% | Filter, Oscillator, Polyphonic | A polyphonic Moog inspired low-pass ladder filter from the original Symbiote firmware for Mutable Instruments' Warps |
| Sanguine Mutants |  Temulenti |
7 – 8% | 8 – 9% | 9 – 10% | 9 – 10% | 9 – 10% | 7 – 8% | 8 – 10% | 9 – 10% | 9 – 10% | 9 – 10% | Clock generator, Digital, Envelope generator, Function generator, Hardware clone, Low-frequency oscillator, Oscillator, Waveshaper | Multifaceted modulator based on the Parasite firmware for Mutable Instruments' Tides |
| Sanguine Mutants |  Velamina |
9 – 20% | 8 – 20% | 9 – 20% | 8 – 20% | 8 – 20% | 9 – 20% | 8 – 21% | 9 – 20% | 8 – 20% | 8 – 20% | Mixer, Polyphonic, Quad, Voltage-controlled amplifier | Tetrad of voltage controller amplifiers based on the revised Veils from Mutable Instruments |
| Sanguine Mutants |  Vimina |
4 – 8% | 3 – 8% | 3 – 8% | 3 – 8% | 3 – 8% | 4 – 21% | 3 – 21% | 3 – 21% | 3 – 21% | 3 – 21% | Clock modulator, Dual, Hardware clone, Polyphonic, Utility | Polyphonic dual clock divider, multiplier and swinger based on the Twigs firmware for Mutable Instruments' Branches |
| Sapphire |  Elastika |
3 – 88% | 3 – 90% | 2 – 85% | 2 – 73% | 2 – 73% | 3 – 88% | 3 – 90% | 2 – 85% | 2 – 73% | 2 – 73% | Physical modeling, Effect, Filter, Reverb | Filters audio through a simulated network of balls and springs. |
| Sapphire |  Frolic |
9% | 9% | 9% | 9% | 9% | 9% | 9% | 9% | 9% | 9% | Physical modeling, Effect, Low-frequency oscillator | Chaotic oscillator based on the Rucklidge Attractor. |
| Sapphire |  Galaxy |
21 – 429% | 21 – 428% | 20 – 377% | 21 – 389% | 21 – 377% | 21 – 429% | 21 – 428% | 20 – 378% | 21 – 389% | 21 – 377% | Reverb, Effect, Filter, Distortion | An adaptation of the Airwindows Galactic algorithm by Chris Johnson (https://github.com/airwindows). |
| Sapphire |  Glee |
11% | 11% | 11% | 11% | 11% | 11 – 12% | 11% | 11% | 11% | 11% | Physical modeling, Effect, Low-frequency oscillator | Chaotic oscillator based on the Aizawa Attractor. |
| Sapphire |  Gravy |
6 – 8% | 6 – 8% | 6 – 8% | 6 – 7% | 6 – 7% | 3 – 8% | 3 – 8% | 3 – 8% | 2 – 7% | 2 – 7% | Filter | Low/high/band-pass filter with resonance control. |
| Sapphire |  Hiss |
4 – 31% | 4 – 32% | 3 – 32% | 3 – 32% | 3 – 31% | 4 – 31% | 4 – 32% | 3 – 32% | 3 – 32% | 3 – 31% | Noise, Polyphonic | Generates directionally unbiased N-dimensional vector noise. |
| Seaside Modular |  Jawari |
6 – 22% | 6 – 14% | 6 – 13% | 6 – 11% | 6 – 11% | 6 – 22% | 6 – 14% | 6 – 13% | 6 – 12% | 6 – 11% | Physical modeling, Synth voice | Jawari is a synthesized version of the tanpura, the Indian drone instrument |
| Seaside Modular |  Proteus |
9 – 31% | 9 – 31% | 9 – 29% | 9 – 29% | 9 – 28% | 9 – 32% | 9 – 31% | 9 – 29% | 9 – 29% | 9 – 28% | Sequencer | Proteus is a generative sequencer that makes looping melodies which evolve and renew. |
| Seaside Modular |  Raga |
26 – 138% | 26 – 105% | 26 – 96% | 26 – 95% | 26 – 90% | 26 – 138% | 26 – 105% | 26 – 97% | 26 – 95% | 26 – 91% | Physical modeling, Synth voice | Raga is a 19-string sitar simulator. |
| Seaside Modular |  Tala |
50005 – 354810% | 25069 – 179007% | 12522 – 113751% | 6276 – 81225% | 6394 – 66895% | 50005 – 354977% | 25069 – 179007% | 12522 – 113751% | 6276 – 81225% | 6394 – 66895% | Drum | Tala is a sample-based tabla machine, simulating the Indian drums. |
| Sickozell |  ad mini |
3 – 4% | 3% | 3% | 3% | 2 – 3% | 3 – 7% | 3 – 7% | 3 – 7% | 3 – 7% | 2 – 7% | Function generator, Voltage-controlled amplifier, Polyphonic | Ad function generator with VCA |
| Sickozell |  adder8 |
4 – 6% | 4 – 7% | 4 – 6% | 4 – 6% | 4 – 6% | 4 – 6% | 4 – 7% | 4 – 6% | 4 – 6% | 4 – 6% | Mixer, Utility | 8 adder and subtractor |
| Sickozell |  bGates |
4 – 6% | 4 – 6% | 4 – 6% | 4 – 6% | 4 – 6% | 4 – 6% | 4 – 6% | 4 – 6% | 4 – 6% | 4 – 6% | Logic | 8 Buffered gates and triggers |
| Sickozell |  blender |
2 – 3% | 2 – 4% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 5% | 2 – 5% | 2 – 6% | 2 – 5% | 2 – 5% | Mixer, Polyphonic | Stereo crossfade mixer with double modulation |
| Sickozell |  blender8 |
3 – 6% | 3 – 7% | 2 – 6% | 2 – 6% | 2 – 6% | 3 – 6% | 3 – 7% | 2 – 6% | 2 – 6% | 2 – 6% | Mixer | 8 single crossfade mixers |
| Sickozell |  bToggler8 |
4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | 4 – 6% | 4 – 6% | 4 – 5% | 4 – 5% | 4 – 5% | Logic | 8 buffered toggle switch signal router |
| Sickozell |  bToggler8+ |
4 – 6% | 4 – 6% | 4 – 6% | 4 – 6% | 4 – 6% | 4 – 6% | 4 – 6% | 4 – 6% | 4 – 6% | 4 – 6% | Logic, Utility | 8 buffered toggle switch router, plus warnings to use with led midi controllers |
| Sickozell |  bToggler |
3 – 4% | 3 – 4% | 2 – 3% | 2 – 3% | 2 – 3% | 3 – 4% | 3 – 4% | 2 – 4% | 2 – 3% | 2 – 3% | Logic, Envelope generator, Voltage-controlled amplifier, Polyphonic | Buffered stereo signal toggle switch router, with VCA and ASR envelope generator |
| Sickozell |  bToggler Compact |
3 – 4% | 2 – 4% | 2 – 4% | 2 – 4% | 2 – 3% | 3 – 4% | 2 – 4% | 2 – 4% | 2 – 4% | 2 – 3% | Logic, Envelope generator, Voltage-controlled amplifier, Polyphonic | Buffered stereo signal toggle switch router, with VCA and ASR envelope generator, in a compact form factor |
| Sickozell |  cvMeter |
3 – 4% | 3% | 2 – 3% | 2 – 3% | 2 – 3% | 3 – 4% | 3% | 2 – 3% | 2 – 3% | 2 – 3% | Utility | Shows input voltage, v/oct note, midi values, bpm and sample distance between two triggers or cv change from two different inputs |
| Sickozell |  cvRouter |
2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | Switch, Polyphonic | 1>2 voltage controlled switch |
| Sickozell |  cvSwitcher |
2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | Switch, Polyphonic | 2>1 voltage controlled switch |
| Sickozell |  calcs |
4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | Utility | Calculates sums, differences, multiplications, divisions and averages of 3 CV inputs |
| Sickozell |  clocker |
3 – 4% | 3 – 4% | 3% | 3% | 3% | 3 – 4% | 3 – 4% | 3 – 4% | 3% | 3% | Clock generator, Clock modulator | Clock generator with 4 dividers/multipliers and audio metronome |
| Sickozell |  clocker2 |
3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 5% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | Clock generator, Clock modulator | Clock generator with 6 dividers/multipliers |
| Sickozell |  drumPlayer |
3 – 4% | 3% | 3% | 3% | 3% | 3 – 4% | 3 – 4% | 3% | 3% | 3% | Sampler, Drum, Quad | Drum Sample Player (dp) |
| Sickozell |  drumPlayer mini |
2 – 3% | 2 – 3% | 2% | 2% | 2% | 2 – 3% | 2 – 3% | 2% | 2% | 2% | Sampler | Drum Sample Player (dp) |
| Sickozell |  drumPlayer mk2 |
4% | 4% | 4% | 4% | 4% | 4% | 4% | 4% | 4% | 4% | Sampler, Drum, Quad | Drum Sample Player (dp2) |
| Sickozell |  drumPlayer+ |
3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3% | Sampler, Drum, Quad | Drum Sample Player (dpp) |
| Sickozell |  drumPlayerXtra |
5% | 5% | 5% | 5% | 5% | 5% | 5% | 5% | 5% | 5% | Sampler, Drum, Quad | Drum Sample Player (dpx) |
| Sickozell |  drummer |
2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | Utility, Drum, Dual | Accent and choke utility for drum modules lacking these features (dr) |
| Sickozell |  drummer4 |
3% | 3 – 4% | 3% | 2 – 3% | 2 – 3% | 3% | 3 – 4% | 3% | 2 – 3% | 2 – 3% | Utility, Drum, Quad | 4 channel accent and choke utility for drum modules lacking this feature (d4) |
| Sickozell |  drummer4+ |
3 – 4% | 3 – 4% | 2 – 3% | 2 – 3% | 2 – 3% | 3 – 4% | 3 – 4% | 2 – 3% | 2 – 3% | 2 – 3% | Utility, Drum, Quad | 4 channel accent and choke utility for drum modules lacking this feature (d4p) |
| Sickozell |  enver |
3 – 5% | 3 – 5% | 3 – 5% | 3 – 5% | 3 – 5% | 3 – 13% | 3 – 14% | 3 – 12% | 3 – 11% | 3 – 11% | Envelope generator, Voltage-controlled amplifier, Polyphonic | Envelope generator with stereo VCA |
| Sickozell |  enver mini |
3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 7% | 3 – 7% | 3 – 7% | 3 – 7% | 3 – 6% | Envelope generator, Voltage-controlled amplifier, Polyphonic | Envelope generator with VCA |
| Sickozell |  enver mini expander |
2% | 2% | 2% | 2% | 2% | 2 – 4% | 2 – 4% | 2 – 4% | 2 – 3% | 2% | Envelope generator, Voltage-controlled amplifier, Polyphonic, Expander | Expander for enver mini and ad mini |
| Sickozell |  holder |
2 – 4% | 3 – 4% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 5% | 3 – 4% | 2 – 4% | 2 – 4% | 2 – 4% | Sample and hold, Noise, Polyphonic | Sample & Hold or Track & Hold with noise generator, probability and range |
| Sickozell |  holder8 |
4 – 6% | 4 – 6% | 4 – 6% | 4 – 6% | 4 – 6% | 4 – 12% | 4 – 12% | 4 – 12% | 4 – 12% | 4 – 12% | Sample and hold, Noise, Quad, Polyphonic | 8 Sample & Hold or Track & Hold with noise generator, probability and range |
| Sickozell |  holder Compact |
3 – 4% | 2 – 3% | 2% | 2% | 2% | 3 – 4% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | Sample and hold, Noise, Polyphonic | Sample & Hold or Track & Hold with noise generator, probability and range in a compact form factor |
| Sickozell |  keySampler |
11% | 11% | 11% | 11% | 11% | 11 – 24% | 11 – 24% | 11 – 24% | 11 – 25% | 11 – 25% | Sampler | Keyboard controlled sampler |
| Sickozell |  modulator |
3% | 3 – 4% | 3% | 3% | 3% | 3% | 3 – 4% | 3% | 3% | 3% | Low-frequency oscillator | triangle/ramp LFOs with sync feature (mod) |
| Sickozell |  modulator7 |
7% | 7% | 7% | 6 – 7% | 6 – 7% | 7% | 7% | 7% | 6 – 7% | 6 – 7% | Low-frequency oscillator, Polyphonic | 7 triangle/ramp LFOs with sync feature (mod7) |
| Sickozell |  modulator7 Compact |
5% | 5 – 7% | 5% | 5% | 5% | 5% | 5 – 7% | 5% | 5% | 5% | Low-frequency oscillator | 7 unipolar triangle LFOs (mod7) |
| Sickozell |  multiRouter |
4 – 6% | 4 – 6% | 4 – 5% | 3 – 5% | 3 – 5% | 4 – 10% | 4 – 10% | 4 – 10% | 3 – 10% | 3 – 10% | Switch, Polyphonic | Stereo 1>8 router |
| Sickozell |  multiSwitcher |
3 – 5% | 3 – 5% | 3 – 5% | 3 – 5% | 3 – 5% | 3 – 8% | 3 – 7% | 3 – 7% | 3 – 7% | 3 – 7% | Switch, Polyphonic | Stereo 8>1 switch |
| Sickozell |  parking |
2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | Utility | Set of unconnected inputs and outputs just to park unused cables |
| Sickozell |  polyMuter16 |
5 – 7% | 5 – 7% | 5% | 5% | 5% | 5 – 7% | 5 – 7% | 5% | 5% | 5% | Utility | Mutes single channels of a poly-cable |
| Sickozell |  polyMuter16+ |
3% | 3 – 4% | 3% | 3% | 3% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | Utility | Mutes or Soloes single channels of a poly-cable |
| Sickozell |  polyMuter8 |
4% | 4% | 4% | 4% | 4% | 4% | 4% | 4% | 4% | 4% | Utility | Mutes up to 8 single channels of a poly-cable |
| Sickozell |  polyMuter8+ |
3 – 4% | 3 – 4% | 3 – 4% | 3% | 3% | 3 – 4% | 3 – 4% | 3 – 4% | 3% | 3% | Utility | Mutes or Soloes up to 8 single channels of a poly-cable |
| Sickozell |  randLoops |
4 – 6% | 4 – 6% | 4 – 6% | 4 – 5% | 4 – 5% | 4 – 6% | 4 – 6% | 4 – 6% | 4 – 5% | 4 – 5% | Sequencer | random voltage/trigger sequencer inspired by Turing Machine |
| Sickozell |  randLoops8 |
6 – 7% | 6 – 7% | 5 – 7% | 5 – 7% | 5 – 7% | 6 – 7% | 6 – 7% | 5 – 7% | 5 – 7% | 5 – 7% | Sequencer, Polyphonic | 8 looped random voltage/trigger sequencer inspired by Turing Machine |
| Sickozell |  randLoops mini |
2 – 3% | 2% | 2% | 2% | 2% | 2 – 3% | 2% | 2 – 3% | 2% | 2% | Sequencer | random voltage/trigger sequencer inspired by Turing Machine (rl) |
| Sickozell |  randMod7 |
10 – 17% | 10 – 17% | 10 – 17% | 10 – 17% | 10 – 17% | 10 – 18% | 10 – 18% | 10 – 18% | 10 – 18% | 10 – 17% | Random | 7 random smooth cv generators (rmod7) |
| Sickozell |  sampleDelay |
2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | Utility | a simple signal delay up to 5 samples |
| Sickozell |  shifter |
2 – 3% | 2% | 2 – 3% | 2 – 3% | 2% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | 2% | Sample and hold, Utility | 64 selectable stages shift register |
| Sickozell |  sickoAmp |
3% | 2 – 3% | 2 – 3% | 2 – 3% | 2% | 3 – 4% | 2 – 4% | 2 – 4% | 2 – 4% | 2 – 4% | Voltage-controlled amplifier, Polyphonic | Stereo VCA up to 200% with limiter |
| Sickozell |  sickoCrosser |
3 – 4% | 3 – 4% | 2 – 3% | 2 – 3% | 2 – 3% | 3 – 4% | 3 – 4% | 2 – 3% | 2 – 3% | 2 – 3% | Mixer, Polyphonic | multi stereo input crossfader |
| Sickozell |  sickoCrosser4 |
4% | 4% | 4% | 4% | 4% | 4% | 4% | 4% | 4% | 4% | Mixer | 4 multi input crossfader |
| Sickozell |  sickoLooper1 |
6 – 20% | 6 – 16% | 6 – 15% | 6 – 14% | 6 – 13% | 6 – 20% | 6 – 17% | 6 – 15% | 6 – 14% | 6 – 13% | Sampler | 1 track looper with builtin clock generator, click and meter |
| Sickozell |  sickoLooperX |
4 – 18% | 4 – 15% | 4 – 14% | 5 – 12% | 4 – 12% | 4 – 18% | 4 – 15% | 4 – 14% | 5 – 12% | 4 – 12% | Sampler, Expander | 1 track Looper / Expander for sickoLooper1 |
| Sickozell |  sickoLooper3 |
12 – 39% | 12 – 34% | 12 – 30% | 12 – 27% | 11 – 23% | 12 – 40% | 12 – 34% | 12 – 30% | 12 – 27% | 11 – 24% | Sampler | 3 track looper with builtin clock generator, click and meter |
| Sickozell |  sickoLooper5 |
16 – 57% | 16 – 50% | 16 – 43% | 16 – 38% | 15 – 34% | 16 – 57% | 16 – 50% | 16 – 44% | 16 – 38% | 15 – 34% | Sampler | 5 track looper with builtin clock generator, click and meter |
| Sickozell |  sickoPlayer |
2 – 3% | 2 – 3% | 2% | 2 – 3% | 2% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | Sampler, Polyphonic | Sample Player |
| Sickozell |  sickoQuant |
4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | 4% | 4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | Quantizer, Polyphonic | Polyphonic quantizer with scales and presets (sQuant) |
| Sickozell |  sickoQuant4 |
5% | 4 – 5% | 5% | 4 – 5% | 4 – 5% | 5 – 6% | 4 – 6% | 5 – 6% | 4 – 6% | 4 – 6% | Quantizer, Polyphonic | Four channels polyphonic quantizer with scales and presets (sQuant4) |
| Sickozell |  sickoSampler |
4 – 6% | 4 – 6% | 4 – 6% | 4 – 6% | 4 – 5% | 4 – 6% | 4 – 6% | 4 – 6% | 4 – 6% | 4 – 5% | Sampler, Polyphonic | Sample Player and Recorder |
| Sickozell |  sickoSampler2 |
3 – 5% | 3 – 4% | 3 – 4% | 3 – 4% | 3% | 3 – 5% | 3 – 4% | 3 – 4% | 3 – 4% | 3% | Sampler, Polyphonic | Sample Player and Recorder |
| Sickozell |  simpleSeq4 |
2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | Sequencer | 4 step sequencer with direction and range setting (ss4) |
| Sickozell |  slewer |
3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 6% | 3 – 6% | 3 – 6% | 3 – 6% | 3 – 6% | Slew limiter, Low-frequency oscillator, Polyphonic | Slew Limiter |
| Sickozell |  slewer mini |
3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 6% | 3 – 7% | 3 – 6% | 3 – 6% | 3 – 6% | Slew limiter, Low-frequency oscillator, Polyphonic | Slew Limiter |
| Sickozell |  stepSeq |
2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | Sequencer | 16 step sequencer with direction (ss16) |
| Sickozell |  stepSeq8x |
9 – 11% | 9 – 12% | 8 – 10% | 8 – 10% | 7 – 10% | 9 – 12% | 9 – 12% | 8 – 11% | 8 – 11% | 7 – 10% | Sequencer | 8 track / 16 step sequencer with direction and presets (ss8x) |
| Sickozell |  stepSeq+ |
3 – 5% | 3 – 5% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 5% | 3 – 5% | 3 – 4% | 3 – 4% | 3 – 4% | Sequencer | 16 step sequencer with direction and presets (ss16+) |
| Sickozell |  stepStation |
15 – 41% | 15 – 32% | 15 – 28% | 15 – 25% | 15 – 24% | 15 – 42% | 15 – 33% | 15 – 28% | 15 – 25% | 15 – 24% | Sequencer | 8 independent track / 16 step sequencer with configurable user inputs/knobs and presets (stst) |
| Sickozell |  switcher |
2 – 4% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 4% | 2 – 4% | 2 – 3% | 2 – 3% | 2 – 3% | Switch, Utility, Polyphonic | 2>1 switch, 1>2 router, 2 signal swapper, mute, flip flop, toggle gate |
| Sickozell |  switcher8 |
3 – 11% | 3 – 11% | 3 – 11% | 3 – 10% | 3 – 11% | 3 – 14% | 3 – 14% | 3 – 13% | 3 – 13% | 3 – 12% | Switch, Utility, Polyphonic, Quad | Eight 2>1 switch, 1>2 router, 2 signal swapper, mute, flip flop, toggle gate |
| Sickozell |  switcherSt |
2 – 4% | 2 – 4% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 4% | 2 – 4% | 2 – 3% | 2 – 3% | 2 – 3% | Switch, Utility, Polyphonic | Stereo 2>1 switch, 1>2 router, 2 signal swapper, mute, flip flop, toggle gate |
| Sickozell |  toggler |
3 – 4% | 3 – 4% | 2 – 3% | 2 – 3% | 2 – 3% | 3 – 4% | 3 – 4% | 2 – 3% | 2 – 3% | 2 – 3% | Logic, Envelope generator, Voltage-controlled amplifier, Polyphonic | Stereo signal toggle switch router, with VCA and ASR envelope generator |
| Sickozell |  toggler Compact |
3 – 4% | 2 – 4% | 2 – 3% | 2 – 3% | 2% | 3 – 4% | 2 – 4% | 2 – 3% | 2 – 3% | 2 – 3% | Logic, Envelope generator, Voltage-controlled amplifier, Polyphonic | Stereo signal toggle switch router, with VCA and ASR envelope generator, in a compact form factor |
| Sickozell |  trigSeq |
3% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | 3% | 2 – 3% | 2 – 3% | 2 – 3% | 2 – 3% | Sequencer | 16 step trig sequencer with direction (ts16) |
| Sickozell |  trigSeq8x |
11 – 17% | 11 – 16% | 11 – 17% | 11 – 16% | 11 – 16% | 11 – 17% | 11 – 17% | 11 – 17% | 11 – 16% | 11 – 16% | Sequencer | 8 track / 16 step trig sequencer with direction and presets (ts8x) |
| Sickozell |  trigSeq+ |
3 – 5% | 3 – 5% | 3 – 5% | 3 – 4% | 3 – 4% | 3 – 5% | 3 – 5% | 3 – 5% | 3 – 4% | 3 – 4% | Sequencer | 16 step trig sequencer with direction and presets (ts16+) |
| Sickozell |  trigStation |
15 – 43% | 15 – 34% | 15 – 31% | 15 – 29% | 15 – 28% | 15 – 43% | 15 – 34% | 15 – 32% | 15 – 29% | 15 – 28% | Sequencer | 8 independent track / 16 step trig sequencer with configurable user inputs/knobs and presets (trst) |
| Signal Function Set |  Drift |
9% | 9% | 9% | 9% | 9% | 9% | 9% | 9% | 9% | 9% | LFO, Quad, Random, Utility | Phase shifted LFO with offset, attenuation and stability controls |
| Signal Function Set |  Fugue |
5 – 10% | 5 – 9% | 5 – 8% | 4 – 8% | 5 – 8% | 5 – 10% | 5 – 9% | 5 – 8% | 4 – 8% | 5 – 8% | Sequencer, Polyphonic, Quantizer | 8-step harmonic deviation sequencer with three independent CV/gate voices |
| Signal Function Set |  Intone |
7 – 19% | 6 – 19% | 6 – 19% | 6 – 18% | 6 – 19% | 7 – 19% | 6 – 19% | 6 – 19% | 6 – 18% | 6 – 19% | Oscillator, Synth voice, Filter, Speech | CHANT/FOF formant synthesis voice with vowel morphing, 5 formant cells, and dual excitation modes |
| Signal Function Set |  Meter |
7 – 9% | 7 – 9% | 7 – 9% | 7 – 8% | 7 – 8% | 7 – 9% | 7 – 9% | 7 – 9% | 7 – 8% | 7 – 8% | Clock generator, Clock modulator, Utility | Time-signature-aware musical clock with bar/quarter/eighth/sixteenth/triplet outputs, CV-controllable time signature, and external clock sync |
| Signal Function Set |  Overtone |
9 – 13% | 9 – 12% | 9 – 11% | 9 – 11% | 9 – 11% | 9 – 13% | 9 – 12% | 9 – 11% | 9 – 11% | 9 – 11% | Oscillator, Waveshaper | Additive synthesis VCO with 8 individually-toggled harmonics, even/odd filter, binary mask CV, and waveform display |
| Signal Function Set |  Phase |
2 – 11% | 2 – 11% | 2 – 11% | 2 – 11% | 2 – 9% | 2 – 11% | 2 – 11% | 2 – 11% | 2 – 11% | 2 – 9% | Sampler, Dual, Recording, Looper | Dual sample looper with phase drift via sleep and rotate modes, transient detection, and waveform display |
| Signal Function Set |  Swell |
7 – 9% | 7 – 8% | 7 – 8% | 7% | 7% | 7 – 9% | 7 – 8% | 7 – 8% | 7% | 7% | Envelope generator, Slew limiter, Function generator, Utility | Ping-driven additive A/D envelope generator. Each ping adds voltage with a per-ping rise; pings stack additively. Continuous decay with selectable linear/exponential curve. Soft-saturated 0-10V output. |
| Signal Function Set |  Tine |
7 – 8% | 7 – 8% | 7 – 8% | 7 – 8% | 7 – 8% | 7 – 9% | 7 – 8% | 7 – 8% | 7 – 8% | 7 – 8% | Filter, Synth voice, Physical modeling, Drum | Tunable 3rd-order pingable resonator based on the Gamelan Resonator circuit, with variable damping and VCA anti-click mode |
| Signal Function Set |  GSX |
13 – 27% | 13 – 24% | 13 – 23% | 13 – 22% | 13 – 23% | 13 – 27% | 13 – 24% | 13 – 23% | 13 – 23% | 13 – 23% | Granular, Oscillator | Granular synthesis module based on Barry Truax's GSX system (1985-86), with real-time control over temporal, spectral, and spatial parameters |
| Sonus Modular |  Addiction |
27% | 27 – 28% | 27% | 26 – 27% | 26 – 27% | 27% | 27 – 28% | 27% | 26 – 27% | 26 – 27% | VCO | Additive Oscillator |
| Sonus Modular |  Bitter |
4% | 4% | 4% | 4% | 4% | 4% | 4% | 4% | 4% | 4% | Distortion, Effect | Bit Manipulator |
| Sonus Modular |  Bymidside |
2% | 2 – 4% | 2% | 2 – 3% | 2% | 2% | 2 – 4% | 2% | 2 – 3% | 2% | Dynamics, Utility | MS Encoder |
| Sonus Modular |  Campione |
3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | Sampler | Live Sampler |
| Sonus Modular |  Chainsaw |
25 – 27% | 25% | 25% | 25% | 25% | 25 – 27% | 25% | 25% | 25% | 25% | VCO | Fat Sawish VCO |
| Sonus Modular |  Ctrl |
2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | Controller, Utility | Customizable Controller |
| Sonus Modular |  Deathcrush |
4 – 6% | 4 – 6% | 4 – 6% | 4 – 6% | 4 – 6% | 4 – 6% | 4 – 6% | 4 – 6% | 4 – 6% | 4 – 6% | Distortion, Effect | Driver and Crusher |
| Sonus Modular |  Fluidmix |
3% | 3% | 3% | 3% | 3% | 3% | 3% | 3% | 3% | 3% | Mixer, Utility | Continuous Input Selector |
| Sonus Modular |  Fraction |
8 – 9% | 8% | 8% | 7 – 8% | 7% | 8 – 9% | 8% | 7 – 8% | 7 – 8% | 7% | VCO | n^x / (n^x + 1) Oscillator |
| Sonus Modular |  Harmony |
3 – 4% | 3% | 2 – 3% | 2% | 2 – 3% | 3 – 4% | 2 – 3% | 2 – 3% | 2% | 2 – 3% | Tuner, Utility | Chord Tool |
| Sonus Modular |  Ladrone |
21 – 22% | 21 – 22% | 20 – 21% | 19 – 21% | 19 – 20% | 20 – 22% | 20 – 22% | 20 – 21% | 19 – 21% | 19 – 20% | VCO | Drone Oscillator |
| Sonus Modular |  Luppolo |
2 – 3% | 2% | 2% | 2% | 2% | 2 – 3% | 2% | 2% | 2% | 2% | Sampler | Simple Looper |
| Sonus Modular |  Luppolo3 |
3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | Sampler | Loop Station |
| Sonus Modular |  Micromacro |
59 – 60% | 60% | 60 – 61% | 61% | 60 – 61% | 59 – 60% | 60% | 60 – 61% | 61% | 60 – 61% | Sequencer | Pitch Quantized Sequencer |
| Sonus Modular |  Mr. Cheb |
12 – 29% | 12 – 28% | 12 – 21% | 12 – 21% | 12 – 21% | 12 – 29% | 12 – 28% | 12 – 21% | 12 – 21% | 12 – 21% | Effect, Waveshaper | Chebyshev Waveshaper |
| Sonus Modular |  Multimulti |
2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | Multiple, Utility | 2x8 Multiples |
| Sonus Modular |  Neurosc |
31 – 39% | 17 – 20% | 11 – 18% | 8 – 14% | 6 – 12% | 31 – 39% | 17 – 20% | 11 – 18% | 8 – 14% | 6 – 12% | VCO | Neural Wavetable Oscillator |
| Sonus Modular |  Oktagon |
9 – 10% | 9 – 10% | 9 – 10% | 9 – 10% | 9 – 10% | 9 – 10% | 9 – 10% | 9 – 10% | 9 – 10% | 9 – 10% | LFO, Quad, VCO | Quad-Quad LFO/VCO |
| Sonus Modular |  Osculum |
8 – 9% | 8% | 8% | 8% | 8% | 8 – 9% | 8% | 8% | 8% | 8% | VCO | Unusual Oscillator |
| Sonus Modular |  Pan in the Haas |
3 – 4% | 3 – 4% | 3% | 3% | 3% | 3 – 4% | 3 – 4% | 3% | 3% | 2 – 3% | Delay, Dual, Panning | Haas Delay |
| Sonus Modular |  Paramath |
2 – 3% | 2 – 3% | 2% | 2% | 2% | 2 – 3% | 2 – 3% | 2% | 2% | 2% | Logic, Utility | Comparing and Maths |
| Sonus Modular |  Piconoise |
2 – 3% | 2% | 2% | 2% | 2% | 2 – 3% | 2% | 2% | 2% | 2% | Noise | Noise Generator |
| Sonus Modular |  Pusher |
2 – 3% | 2% | 2% | 2% | 2% | 2 – 3% | 2% | 2% | 2% | 2% | Controller, Utility | Buttons Controller |
| Sonus Modular |  Ringo |
4% | 4% | 4% | 4% | 4% | 4% | 4% | 4% | 4% | 4% | Ring modulator, Effect | Ring Modulator |
| Sonus Modular |  Scramblase |
3 – 4% | 3% | 3% | 3% | 3% | 3 – 4% | 3% | 3% | 3% | 3% | Effect, Waveshaper | Many Waveshapers |
| Sonus Modular |  Tropicana |
22% | 22 – 23% | 22 – 23% | 22% | 22% | 22 – 23% | 22 – 23% | 22 – 23% | 22 – 23% | 22 – 23% | VCO | Tropical Additive Oscillator |
| Sonus Modular |  Twoff |
2% | 2 – 4% | 2 – 3% | 2 – 4% | 2% | 2% | 2 – 4% | 2 – 3% | 2 – 4% | 2% | Dual, Utility | CV Offset |
| Sonus Modular |  Yabp |
2% | 2% | 2% | 2% | 2% | 2% (mono) | 2% (mono) | 2% (mono) | 2% (mono) | 2% (mono) | Blank | Yet Another Blank Panel |
| Squinky Labs |  Chebyshev II |
11 – 12% | 11 – 12% | 11 – 12% | 11 – 12% | 11 – 12% | 11 – 12% | 11 – 12% | 11 – 12% | 11 – 12% | 11 – 12% | VCO | Waveshaper VCO with FM |
| Squinky Labs |  Basic VCO |
5 – 6% | 5% | 5% | 5% | 5% | 5 – 6% | 5% | 5% | 5% | 5% | VCO, Polyphonic | Precision VCO |
| Squinky Labs |  Comp |
3 – 9% | 3 – 5% | 2 – 4% | 2 – 3% | 2 – 3% | 3 – 9% | 3 – 6% | 2 – 4% | 2 – 3% | 2 – 3% | Compressor, Dynamics, Polyphonic | Ultra clean Compressor |
| Squinky Labs |  Polygate |
2 – 3% | 2% | 2 – 3% | 2% | 2% | 2 – 3% | 2 – 3% | 2 – 3% | 2% | 2% | Polyphonic | Polyphonic gate demultiplexer |
| Squinky Labs |  EV3 |
11 – 12% | 11 – 12% | 11 – 12% | 11% | 11% | 11 – 13% | 11 – 12% | 11 – 12% | 11% | 11% | VCO, Multiple | Triple VCO with even waveform |
| Squinky Labs |  F2 - Multimode Filter |
3 – 9% | 3 – 9% | 3 – 9% | 3 – 9% | 3 – 9% | 3 – 10% | 3 – 9% | 3 – 9% | 3 – 9% | 3 – 9% | VCF, Polyphonic | Multimode state-variable filter |
| Squinky Labs |  Stairway |
3 – 35% | 3 – 31% | 3 – 30% | 3 – 29% | 3 – 29% | 3 – 58% | 3 – 57% | 3 – 55% | 3 – 54% | 3 – 53% | VCF, Polyphonic, Distortion | Ladder filter on steroids |
| Squinky Labs |  Booty Shifter |
6% | 6% | 6% | 6% | 6% | 6% | 6 – 7% | 6% | 6% | 6% | Ring Modulator, effect | Frequency Shifter |
| Squinky Labs |  Functional VCO-1 |
8 – 46% | 8 – 47% | 8 – 47% | 8 – 47% | 8 – 47% | 8 – 47% | 8 – 47% | 8 – 47% | 8 – 48% | 8 – 48% | VCO | [deprecated] Multi-function VCO with low aliasing |
| Squinky Labs |  Gray Code |
2 – 3% | 2 – 3% | 2% | 2% | 2% | 2 – 4% | 2 – 4% | 2 – 3% | 2 – 3% | 2% | Clock modulator, Random, Logic | Eclectic clock divider |
| Squinky Labs |  LFN |
3 – 5% | 3 – 4% | 3 – 4% | 3 – 4% | 3% | 3 – 5% | 3 – 4% | 3 – 4% | 3 – 4% | 3% | Noise, Random, LFO | Low frequency random voltage generator |
| Squinky Labs |  Mixer-8 |
6 – 7% | 6 – 7% | 6 – 7% | 6% | 6% | 6 – 7% | 6 – 7% | 6 – 7% | 6% | 6% | Mixer | 8 channel mixer |
| Squinky Labs |  Mix Stereo |
4 – 5% | 4 – 5% | 4% | 4% | 4% | 4 – 5% | 4 – 5% | 4% | 4% | 4% | Mixer, Expander | Two channel stereo mixer expander |
| Squinky Labs |  Form |
7 – 8% | 7% | 7% | 7% | 7% | 7 – 8% | 7 – 8% | 7 – 8% | 7 – 8% | 7 – 8% | Mixer | Mixer master module |
| Squinky Labs |  Shaper |
7 – 26% | 4 – 21% | 3 – 18% | 3 – 17% | 3 – 16% | 7 – 26% | 4 – 21% | 3 – 18% | 3 – 17% | 3 – 16% | Effect, Waveshaper, Distortion | Precision Wave Shaper |
| Squinky Labs |  Organ Three |
11 – 28% | 11 – 29% | 10 – 28% | 10 – 28% | 9 – 28% | 11 – 41% | 11 – 42% | 10 – 42% | 10 – 42% | 9 – 42% | VCO, Polyphonic, Hardware, Synth voice | Hammond organ emulator |
| Squinky Labs |  Slade |
5% | 5% | 5% | 5% | 5% | 5% | 5% | 5% | 5% | 5% | Slew limiter, VCA | Octal slew/lag/VCA |
| Squinky Labs |  Substitute |
14 – 15% | 14 – 15% | 14% | 13 – 14% | 13 – 14% | 14 – 28% | 14 – 27% | 14 – 27% | 13 – 27% | 13 – 27% | VCO, Polyphonic | Subharmonic VCO |
| Squinky Labs |  Saws |
9 – 11% | 8 – 11% | 8 – 11% | 9 – 11% | 8 – 11% | 9 – 35% | 8 – 35% | 8 – 35% | 9 – 35% | 8 – 35% | VCO, Polyphonic | Super saw VCO emulation |
| Squinky Labs |  Chopper |
4 – 5% | 4% | 4% | 4% | 4% | 4 – 5% | 4% | 4% | 4% | 4% | Clock modulator, Effect, LFO | Tremolo with synched LFO |
| Squinky Labs |  Growler |
8% | 8 – 9% | 8% | 8% | 8% | 8% | 8 – 9% | 8% | 8% | 8% | Effect, Filter | Vocal Animator |
| Squinky Labs |  Formants |
9% | 8 – 9% | 8% | 8% | 8% | 9% | 8 – 9% | 8% | 8% | 8% | Effect, Filter | Singing Vocal Filter |
| Squinky Labs |  FM Kitchen Sink |
22 – 24% | 22 – 23% | 22 – 23% | 22 – 23% | 22 – 23% | 22 – 24% | 22 – 24% | 22 – 24% | 22 – 24% | 22 – 24% | VCO, Polyphonic, Synth voice | Many function VCO |
| Stellare Modular | BLANK | 2% | 2% | 2% | 2% | 2% | 2% (mono) | 2% (mono) | 2% (mono) | 2% (mono) | 2% (mono) | Blank | |
| Stellare Modular | TURING MACHINE | 4% | 4% | 4% | 4% | 4% | 4% | 4% | 4% | 4% | 4% | Sequencer, Random | |
| Stellare Modular |  AL14 |
5 – 6% | 5 – 6% | 5 – 6% | 5 – 6% | 5 – 6% | 5 – 8% | 5 – 6% | 5 – 6% | 5 – 6% | 5 – 6% | Switch | |
| Stellare Modular |  AL18 |
7% | 7% | 7% | 6 – 7% | 7% | 7% | 7% | 7% | 6 – 7% | 7% | Switch | |
| Stellare Modular |  AL41 |
5 – 6% | 5 – 7% | 5 – 7% | 5% | 5% | 5 – 6% | 5 – 7% | 5 – 7% | 5% | 5% | Switch | |
| Stellare Modular |  AL81 |
6% | 6% | 6% | 6% | 6% | 6% | 6% | 6% | 6% | 6% | Switch | |
| Stellare Modular |  ANDROMEDA |
20 – 22% | 21 – 23% | 20 – 22% | 20 – 22% | 20 – 22% | 20 – 23% | 21 – 23% | 20 – 22% | 20 – 22% | 20 – 22% | Sequencer | |
| Stellare Modular |  AZULAR |
18% | 18% | 18% | 18% | 18% | 18% | 18% | 18% | 18% | 18% | Sequencer | |
| Stellare Modular |  BLANK |
2% | 2% | 2% | 2% | 2% | 2% (mono) | 2% (mono) | 2% (mono) | 2% (mono) | 2% (mono) | Blank | |
| Stellare Modular |  DELTA |
4% | 4% | 4% | 4% | 4% | 4% | 4% | 4% | 4% | 4% | Clock Modulator | |
| Stellare Modular |  NOMLIA |
9% | 9% | 9% | 9% | 9% | 9% | 9 – 10% | 9% | 9% | 9% | Sequencer | |
| Stellare Modular |  PELISIA |
3% | 3% | 3% | 3% | 3% | 3% | 3% | 3% | 3% | 3% | Mixer, Utilities | |
| Stellare Modular |  QUSIA |
5 – 6% | 5 – 6% | 5 – 6% | 5 – 6% | 5 – 6% | 5 – 6% | 5 – 6% | 5 – 6% | 5 – 6% | 5 – 6% | Utilities, Delay | |
| Stellare Modular |  SIGMA |
2 – 3% | 2 – 3% | 2 – 3% | 2% | 2% | 2 – 3% | 2 – 3% | 2 – 3% | 2% | 2% | Utilities | |
| Studio Six Plus One |  Amburgh |
49 – 51% | 50 – 51% | 50 – 51% | 50 – 51% | 50 – 51% | 49 – 51% | 50 – 51% | 50 – 51% | 50 – 51% | 50 – 51% | Polyphonic, Filter | Non Linear Filter self oscillating vcf |
| Studio Six Plus One |  Bascom |
44% | 44 – 45% | 44 – 45% | 44 – 45% | 45% | 44 – 45% | 44 – 45% | 44 – 46% | 44 – 46% | 45 – 46% | Polyphonic, Filter | Multi form Non Linear Filter self oscillating vcf |
| Studio Six Plus One |  Bose |
3 – 9% | 3 – 9% | 2 – 9% | 2 – 8% | 2 – 7% | 3 – 9% | 3 – 9% | 2 – 9% | 2 – 8% | 2 – 7% | Polyphonic, sample and hold, noise, random | Multi output random voltage generator, sample and hold with no input, steady or analog style drooping outputs |
| Studio Six Plus One |  Massarti |
7% | 7% | 7% | 7% | 7% | 7 – 20% | 7 – 21% | 7 – 20% | 7 – 20% | 7 – 20% | Polyphonic, Filter, Effect | Comb Filter |
| Studio Six Plus One |  Duffy |
3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3% | Polyphonic, Utility | Transposes incoming voct, the amount increased by a set number of semitones, can be used to traverse the circle of fifths |
| Studio Six Plus One |  Eva |
3 – 4% | 3 – 4% | 2 – 4% | 3 – 4% | 2 – 4% | 3 – 4% | 3 – 4% | 2 – 4% | 3 – 4% | 2 – 4% | Mixer, Voltage-controlled amplifier, Polyphonic | Mixer |
| Studio Six Plus One |  Farini |
10 – 12% | 10 – 11% | 10% | 10% | 10% | 10 – 12% | 10 – 11% | 10% | 10% | 10% | Envelope generator, Voltage-controlled amplifier | Multimode envelope generator and stereo vca, based on CEM3310 AND CEM3360 diy circuits. |
| Studio Six Plus One |  Hula |
18 – 19% | 18 – 20% | 18 – 19% | 18 – 19% | 18 – 19% | 18 – 22% | 18 – 21% | 18 – 21% | 18 – 21% | 18 – 20% | Low-frequency oscillator, Oscillator, Polyphonic | fm VCO unique per instance |
| Studio Six Plus One |  Iverson |
19 – 20% | 19 – 20% | 19 – 20% | 19% | 19% | 19 – 20% | 19 – 20% | 19 – 20% | 19% | 19% | Controller, Sequencer | Trigger Sequencer for use with midi controller |
| Studio Six Plus One |  IversonJr |
11 – 13% | 11 – 13% | 11 – 12% | 11 – 12% | 11 – 12% | 11 – 13% | 11 – 13% | 11 – 12% | 11 – 12% | 11 – 12% | Controller, Sequencer | Trigger Sequencer for use with midi controller |
| Studio Six Plus One |  Wallenda |
10 – 12% | 10 – 12% | 10 – 12% | 10 – 12% | 10 – 12% | 10 – 37% | 10 – 37% | 10 – 37% | 10 – 36% | 10 – 35% | Polyphonic, Delay, Effect, Physical modeling | Karplus–Strong Delay with unison |
| Studio Six Plus One |  LaLa |
2 – 17% | 3 – 17% | 2 – 17% | 2 – 16% | 2 – 17% | 2 – 17% | 3 – 17% | 2 – 17% | 2 – 16% | 2 – 17% | Filter, Polyphonic, Utility, Voltage-controlled amplifier | Two way cross over |
| Studio Six Plus One |  LalaStereo |
4 – 30% | 3 – 31% | 3 – 31% | 2 – 31% | 3 – 31% | 4 – 30% | 3 – 31% | 3 – 31% | 2 – 31% | 3 – 31% | Filter, Polyphonic, Utility | Stereo two way crossover |
| Studio Six Plus One |  Maccomo |
11 – 23% | 11 – 24% | 11 – 23% | 11 – 23% | 11 – 23% | 11 – 85% | 11 – 85% | 11 – 85% | 11 – 85% | 11 – 85% | Polyphonic, Filter | Ladder Filter self oscillating vcf |
| Studio Six Plus One |  Mix |
3 – 4% | 2 – 4% | 2 – 3% | 2 – 4% | 2 – 3% | 3 – 4% | 2 – 4% | 2 – 3% | 2 – 4% | 2 – 3% | Mixer, Polyphonic | A simple 5 channel mixer with non linear characters |
| Studio Six Plus One |  PatchNotes |
2% | 2% | 2% | 2% | 2% | 2% (mono) | 2% (mono) | 2% (mono) | 2% (mono) | 2% (mono) | Utility | Slimline text area for making patch notes |
| Studio Six Plus One |  Tyrant |
16 – 41% | 16 – 34% | 16 – 33% | 16 – 31% | 16 – 30% | 16 – 41% | 16 – 37% | 16 – 36% | 16 – 36% | 16 – 35% | Polyphonic, Sample and Hold, Random | Polyphonic Shift Register |
| Studio Six Plus One |  Thru |
3 – 4% | 3 – 4% | 3 – 4% | 3% | 3% | 3 – 4% | 3 – 4% | 3 – 4% | 3% | 3% | Multiple, Utility | Thru module with assignable labels |
| Studio Six Plus One |  Zazel |
5 – 7% | 4 – 7% | 4 – 6% | 4 – 5% | 4 – 5% | 5 – 7% | 4 – 7% | 4 – 6% | 4 – 5% | 4 – 5% | Clock modulator, Function generator, Low-frequency oscillator, Envelope generator, Controller | Parameter Controller for fades and LFO, Ramp generator |
| Studio Six Plus One |  Zilah |
24 – 25% | 24 – 25% | 25% | 25% | 25% | 24 – 25% | 24 – 25% | 25% | 25% | 25% | MIDI, external | 14 bit Midi-CC input |
| Submit |  Chain |
4 – 6% | 4 – 6% | 4 – 5% | 4 – 5% | 4 – 5% | 4 – 6% | 4 – 6% | 4 – 5% | 4 – 5% | 4 – 5% | Mixer, Effect | Chainable stereo 2 channel mixer with aux sends |
| Submit |  Chrono |
33 – 35% | 34 – 36% | 34 – 36% | 34 – 36% | 34 – 36% | 33 – 35% | 34 – 36% | 34 – 36% | 34 – 36% | 34 – 36% | Delay, Effect | Tape delay with movement and character |
| Submit |  Drift |
15 – 18% | 15 – 18% | 14 – 18% | 14 – 18% | 14 – 18% | 15 – 18% | 15 – 18% | 14 – 18% | 14 – 18% | 14 – 18% | Oscillator, Envelope generator, Waveshaper, Dynamics | Voice module with oscillator, wavefolder, slope and contour |
| Submit |  Gain |
3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | Mixer, Amplifier, Utility | Line level booster with soft clip, FX send and chain |
| Submit |  Impact |
4 – 31% | 4 – 31% | 4 – 31% | 4 – 31% | 4 – 31% | 4 – 31% | 4 – 31% | 4 – 31% | 4 – 31% | 4 – 31% | Drum, Oscillator, Envelope | Dual-engine drum synthesizer with stereo output |
| Submit |  Loop |
2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | ||
| Submit |  Master |
9% | 8 – 9% | 8 – 9% | 8% | 8% | 8 – 9% | 8 – 9% | 8 – 9% | 8% | 8% | Dynamics, Effect | Warm master bus processor |
| Submit |  Shape |
5% | 4 – 5% | 5% | 5% | 5% | 4 – 5% | 4 – 5% | 5% | 4 – 5% | 4 – 5% | Equalizer, Filter | 6-band SSL-style EQ |
| Submit |  Squeeze |
3 – 4% | 2 – 4% | 2 – 4% | 2 – 3% | 2 – 3% | 3 – 4% | 2 – 4% | 2 – 4% | 2 – 3% | 2 – 3% | Envelope follower, Dynamics | Sidechain envelope generator |
| Submit |  Sweep |
7 – 9% | 7% | 7% | 7% | 7% | 7 – 9% | 7 – 8% | 7 – 8% | 7 – 8% | 7 – 8% | Filter, Effect | DJ filter with low pass, high pass, resonance and sweep reset |
| Unfiltered Audio Battalion |  Battalion Shatter Delay |
22 – 427% | 21 – 223% | 20 – 121% | 19 – 70% | 18 – 69% | 22 – 427% | 21 – 223% | 20 – 121% | 19 – 70% | 18 – 69% | Delay, Clock Generator, Granular, Effect | Stereo glitch delay with ping-pong, ducking, tilt EQ, sample-rate reduction, and clock sync |
| Unfiltered Audio Battalion |  Battalion Output |
46 – 73% | 46 – 74% | 46 – 75% | 47 – 75% | 47 – 75% | 46 – 73% | 46 – 74% | 46 – 75% | 47 – 75% | 47 – 75% | Effect, Equalizer, Compressor, Distortion, Limiter, Utility | Output section: maximizer, 3-band EQ, gain, multimode clipper |
| Unfiltered Audio Battalion |  Battalion Headspace Reverb |
113 – 573% | 72 – 301% | 58 – 172% | 49 – 99% | 47 – 97% | 113 – 573% | 72 – 301% | 58 – 172% | 49 – 99% | 47 – 97% | Reverb, Effect | Multi-mode reverb with predelay, tilt EQ in/out, and sample-rate reduction |
| Unfiltered Audio Battalion |  Battalion Drum Synth |
15 – 27% | 15 – 26% | 15 – 23% | 15 – 23% | 15 – 20% | 15 – 85% | 15 – 77% | 15 – 70% | 15 – 69% | 15 – 68% | Drum, Digital, Envelope generator, Polyphonic | Multimode drum synthesizer |
| Unfiltered Audio Battalion |  Battalion Tone |
18 – 23% | 17 – 22% | 17 – 22% | 17 – 22% | 17 – 21% | 18 – 66% | 17 – 67% | 17 – 66% | 17 – 66% | 17 – 66% | Distortion, Filter, Effect | Multimode distortion + multimode filter with switchable internal routing order |
| Unfiltered Volume 1 |  Dent Crusher |
9 – 14% | 8 – 13% | 8 – 12% | 7 – 11% | 7 – 10% | 9 – 14% | 8 – 13% | 8 – 12% | 7 – 11% | 7 – 10% | Effect, Digital, Distortion | Multimode bitcrusher |
| Unfiltered Volume 1 |  Fusion |
6% | 5 – 6% | 6% | 5 – 6% | 6% | 6 – 14% | 5 – 14% | 6 – 14% | 5 – 14% | 6 – 14% | Effect, Digital, Mixer, Polyphonic | Two-input signal smasher and creative mixer |
| Unfiltered Volume 1 |  Glitch Shifter |
17 – 18% | 17 – 18% | 17 – 19% | 17 – 18% | 17 – 18% | 17 – 60% | 17 – 60% | 17 – 60% | 17 – 61% | 17 – 60% | Effect, Digital, Granular, Clock Generator, Polyphonic | Unpredictable granular delay buffer |
| Unfiltered Volume 1 |  Indent Saturation |
24 – 39% | 24 – 39% | 24 – 39% | 23 – 39% | 24 – 39% | 24 – 39% | 24 – 39% | 24 – 39% | 23 – 39% | 24 – 39% | Effect, Waveshaper, ADistortion | Multimode distortion and saturation |
| Unfiltered Volume 1 |  Instant Delay |
16% | 16% | 16% | 16% | 16% | 16 – 55% | 16 – 56% | 16 – 55% | 16 – 56% | 16 – 56% | Effect, Delay, Granular, Clock Generator, Polyphonic | Smooth granular delay without artifacts |
| Unfiltered Volume 1 |  Pitch Delay |
28% | 28% | 28% | 27 – 28% | 27 – 28% | 28 – 101% | 28 – 103% | 28 – 103% | 27 – 103% | 27 – 103% | Effect, Delay, Granular, Clock Generator, Polyphonic | Granular pitch-shifting delay |
| Unfiltered Volume 2 |  Sunder |
24 – 28% | 25 – 28% | 24 – 28% | 24 – 27% | 24 – 27% | 24 – 28% | 25 – 28% | 24 – 28% | 24 – 28% | 24 – 28% | Effect, Digital, Mixer, Dynamics | 3-Band Amplitude Splitter |
| Unfiltered Volume 2 |  Yoko |
27 – 32% | 27 – 32% | 27 – 33% | 27 – 32% | 27 – 32% | 27 – 32% | 27 – 32% | 27 – 33% | 27 – 32% | 27 – 32% | Effect, Digital, Mixer, Equalizer | 3-Band Frequency Splitter |
| Valley |  Amalgam |
9 – 10% | 9 – 10% | 9 – 10% | 8 – 10% | 8 – 9% | 9 – 10% | 9 – 10% | 9 – 10% | 8 – 10% | 8 – 9% | Ring Modulator, Effect, Waveshaper | Multi-mode stereo signal combiner. Amalgam lets you combine and smash together signals in many different ways. |
| Valley |  Feline |
9 – 12% | 9 – 13% | 9 – 12% | 9 – 12% | 9 – 12% | 9 – 13% | 9 – 13% | 9 – 12% | 9 – 12% | 9 – 12% | Filter | A stereo, state variable, virtual analogue filter. |
| Valley |  Interzone |
26 – 27% | 25 – 26% | 25 – 26% | 25 – 26% | 25 – 26% | 26 – 31% | 25 – 31% | 25 – 31% | 25 – 30% | 25 – 30% | Synth Voice, Polyphonic | Polyphonic, virtual analogue synthesiser voice complete with a VCO, mixer, filter, LFO, and envelope generator. |
| Valley |  Plateau |
19 – 42% | 19 – 42% | 19 – 42% | 19 – 43% | 19 – 37% | 19 – 42% | 19 – 43% | 19 – 42% | 19 – 43% | 19 – 37% | Reverb, Effect, Polyphonic | Lush and bendable plate reverb based on the Dattorro 1997 algorithm. |
| Valley |  Topograph |
5 – 7% | 5 – 6% | 5 – 6% | 5% | 5% | 5 – 7% | 5 – 6% | 5 – 6% | 5% | 5% | Sequencer | Topographic drum machine. This module is based on the original Mutable Instruments (TM) Grids sequencer module. The Map and Density controls explore and control the denisty of many pre-baked drum patterns. |
| Valley |  uGraph |
5 – 6% | 5 – 6% | 5 – 6% | 5% | 5% | 5 – 6% | 5 – 6% | 5 – 6% | 5% | 5% | Sequencer | Topographic drum machine. This module is based on the original Mutable Instruments (TM) Grids sequencer module. The Map and Density controls explore and control the denisty of many pre-baked drum patterns. |
| van Ties |  Ad |
2 – 41% | 2 – 39% | 2 – 38% | 2 – 37% | 2 – 38% | 2 – 150% | 2 – 148% | 2 – 147% | 2 – 146% | 2 – 145% | Oscillator, Polyphonic | eratosthenean additive oscillator |
| van Ties |  Adje |
2 – 20% | 2 – 20% | 2 – 20% | 2 – 20% | 2 – 20% | 2 – 21% | 2 – 20% | 2 – 20% | 2 – 20% | 2 – 20% | eratosthenean spectrum generator | |
| van Ties |  Funs |
12 – 13% | 13 – 14% | 13% | 13% | 13% | 12 – 45% | 13 – 46% | 13 – 46% | 13 – 46% | 13 – 46% | Oscillator, Polyphonic | rational function oscillator |
| van Ties |  Sjoegele |
10 – 11% | 10% | 10% | 9 – 10% | 10% | 10 – 33% | 10 – 33% | 10 – 33% | 9 – 33% | 10 – 33% | Random, Polyphonic | double pendulum simulator |
| Venom |  AD/ASR Envelope Generator |
15% | 14 – 15% | 15% | 15% | 15% | 15% | 14 – 15% | 15% | 15% | 15% | Envelope generator, Low-frequency oscillator, Oscillator, Polyphonic | Hybrid polyphonic Attack,Decay and Attack,Sustain,Release envelope generator with looping capabilities |
| Venom |  Benjolin Oscillator |
18 – 23% | 18 – 23% | 18 – 23% | 18 – 23% | 18 – 23% | 18 – 23% | 18 – 23% | 18 – 23% | 18 – 23% | 18 – 23% | Low-frequency oscillator, Oscillator, Random, Sequencer | Complex chaotic oscillator emulating the oscillator and rungler components of a Benjolin |
| Venom |  Bernoulli Switch |
5 – 6% | 6 – 8% | 6 – 7% | 5 – 6% | 5 – 6% | 5 – 7% | 6 – 8% | 6 – 7% | 5 – 7% | 5 – 7% | Attenuator, Controller, Logic, Polyphonic, Random, Switch, Utility, Waveshaper | Stochastically route two inputs to two outputs, with built in scaling and offset capabilities |
| Venom |  Clone Merge |
3 – 4% | 3% | 3% | 3% | 2 – 3% | 3 – 4% | 3 – 4% | 3 – 4% | 3% | 2 – 3% | Polyphonic, Utility | Clone up to 8 monophonic inputs and merge all channels into 1 polyphonic output |
| Venom |  WinComp2 + Logic |
31 – 163% | 31 – 165% | 30 – 166% | 30 – 167% | 30 – 167% | 31 – 164% | 31 – 167% | 30 – 168% | 30 – 168% | 30 – 169% | Logic, Polyphonic, Utility | Dual windowed comparator with logic outputs inspired by the Joranalogue Compare 2 |
| Venom |  Cross Fade 3D |
5 – 6% | 5 – 6% | 5% | 5% | 5% | 5 – 6% | 5 – 6% | 5 – 6% | 5 – 6% | 5 – 6% | Mixer, Polyphonic | Cross fade 8 inputs to 1 output using X, Y, and Z axes |
| Venom |  HQ - Harmonic Quantizer |
6 – 7% | 6 – 7% | 6% | 6% | 6% | 6 – 9% | 6 – 9% | 6 – 9% | 6 – 9% | 6 – 9% | Polyphonic, Quantizer | Computes a selected harmonic or subharmonic partial relative to a root V/Oct, or quantizes input V/Oct to the nearest partial relative to the root |
| Venom |  Knob 5 |
2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | Controller, Polyphonic, Utility | 5 configurable constant voltage knobs |
| Venom |  Linear Beats |
4 – 6% | 4 – 6% | 4 – 6% | 4 – 6% | 4 – 6% | 4 – 9% | 4 – 9% | 4 – 9% | 4 – 9% | 4 – 9% | Logic, Polyphonic, Sample and hold | Convert multiple trigger/gate channels into a linear drumming pattern |
| Venom |  Logic |
28 – 193% | 27 – 195% | 28 – 196% | 28 – 197% | 28 – 197% | 28 – 198% | 27 – 200% | 28 – 198% | 28 – 198% | 28 – 198% | Logic, Polyphonic, Utility | Flexible logic gate processor suitable for both CV and audio applications |
| Venom |  Merge 4x2 |
2 – 4% | 2 – 4% | 2 – 4% | 2 – 4% | 2 – 4% | 2 – 5% | 2 – 5% | 2 – 5% | 2 – 5% | 2 – 5% | Polyphonic, Utility | Compact and versatile polyphonic merge utility |
| Venom |  Merge Split |
3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 5% | 3 – 5% | 3 – 5% | 3 – 5% | 3 – 5% | Polyphonic, Utility | Compact and versatile polyphonic merge and split utility |
| Venom |  Mix 4 |
7% | 7% | 7% | 7% | 7% | 7% | 7% | 7% | 7% | 7% | Attenuator, Mixer, Polyphonic, Utility | Compact audio or CV mixer, attenuator, inverter, amplifier, and/or offset |
| Venom |  Mix 4 Stereo |
9% | 8 – 9% | 8 – 9% | 8 – 9% | 8 – 9% | 9 – 10% | 8 – 10% | 8 – 10% | 8 – 10% | 8 – 10% | Attenuator, Mixer, Polyphonic, Utility | Stereo compact audio or CV mixer, attenuator, inverter, amplifier, and/or offset |
| Venom |  Multi Merge |
7 – 9% | 7 – 8% | 7 – 10% | 7 – 8% | 7 – 8% | 7 – 11% | 7 – 11% | 7 – 11% | 7 – 11% | 7 – 11% | Polyphonic, Utility | Merge one or more sets of mono and/or poly inputs into polyphonic outputs |
| Venom |  Multi Split |
6 – 11% | 5 – 11% | 5 – 11% | 5 – 11% | 5 – 11% | 6 – 16% | 5 – 16% | 5 – 16% | 5 – 16% | 5 – 16% | Polyphonic, Utility | Split one or more poly inputs into multiple mono or poly outputs |
| Venom |  Non-Octave-Repeating Scale Intervallic Quantizer |
8 – 10% | 8 – 10% | 8 – 10% | 8 – 10% | 7 – 10% | 8 – 11% | 8 – 11% | 8 – 11% | 8 – 11% | 7 – 11% | Quantizer, Polyphonic | Quantizer for any scale defined by up to 13 intervals between notes |
| Venom |  Null Cable |
3 – 4% | 2 – 4% | 2 – 4% | 2 – 4% | 2 – 3% | 3 – 4% | 2 – 4% | 2 – 4% | 2 – 4% | 2 – 3% | Controller, Switch, Polyphonic, Utility | Nullify a cable by setting it to 0 channels via manual or CV control |
| Venom |  Octaver |
2 – 34% | 2 – 34% | 2 – 34% | 2 – 34% | 2 – 35% | 2 – 34% | 2 – 34% | 2 – 34% | 2 – 35% | 2 – 35% | Effect, Polyphonic | An old school octave effect in the style of the Pearl OC-7 and Boss OC-2 analog pedals |
| Venom |  VCO Lab |
22 – 410% | 23 – 417% | 23 – 420% | 23 – 421% | 23 – 421% | 22 – 415% | 23 – 421% | 23 – 423% | 23 – 424% | 23 – 425% | Function generator, Low-frequency oscillator, Oscillator, Polyphonic | Audio or low frequency oscillator with 4 simultaneous waveforms, mixing, linear/exponential FM, phase modulation, hard/soft sync, PWM, and more |
| Venom |  Pan 3D |
5 – 6% | 5 – 6% | 5 – 6% | 5 – 6% | 5% | 5 – 6% | 5 – 6% | 5 – 6% | 5 – 6% | 5 – 6% | Panning, Polyphonic | Pan 1 input to 8 outputs using X, Y, and Z axes |
| Venom |  Poly Clone |
3% | 3% | 2 – 3% | 2 – 3% | 2% | 3% | 3% | 2 – 3% | 2 – 3% | 2 – 3% | Polyphonic, Utility | Clone each channel of a polyphonic input and merge the results into a single polyphonic output |
| Venom |  Poly Fade |
9 – 18% | 9 – 18% | 9 – 18% | 9 – 17% | 9 – 16% | 9 – 18% | 9 – 18% | 9 – 18% | 9 – 17% | 9 – 17% | Envelope Generator, Low-frequency oscillator, Mixer, Polyphonic, Sequencer, Switch | Cross fade between channels of a polyphonic signal |
| Venom |  Poly Mute |
6 – 8% | 6 – 8% | 6 – 8% | 6 – 8% | 6 – 8% | 6 – 8% | 6 – 8% | 6 – 8% | 6 – 8% | 6 – 8% | Polyphonic, Switch, Utility | Mute individual channels of a polyphonic input via buttons or CV |
| Venom |  Poly Offset |
2 – 3% | 2 – 3% | 2 – 3% | 2% | 2% | 2 – 3% | 2 – 3% | 2 – 3% | 2% | 2% | Polyphonic, Utility | Provides an offset control for each channel of a polyphonic signal |
| Venom |  Poly Prune |
5 – 6% | 5 – 6% | 5 – 6% | 5 – 6% | 5% | 5 – 7% | 5 – 7% | 5 – 7% | 5 – 7% | 5 – 7% | Polyphonic, Utility | Remove selected channels and/or sort channels from a polyphonic input |
| Venom |  Poly Sample & Hold Analog Shift Register |
37 – 183% | 37 – 185% | 37 – 186% | 37 – 189% | 37 – 187% | 37 – 186% | 37 – 187% | 37 – 190% | 37 – 190% | 37 – 190% | Polyphonic, Random, Sample and hold | Ten channel polyphonic sample and hold combined with a shift register |
| Venom |  Poly Scale |
2 – 4% | 2 – 4% | 2 – 4% | 2 – 4% | 2 – 4% | 2 – 4% | 2 – 4% | 2 – 4% | 2 – 4% | 2 – 4% | Attenuator, Polyphonic, Utility | Provides a level control for each channel of a polyphonic signal |
| Venom |  Poly Unison |
3 – 4% | 3% | 3% | 3% | 3% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3% | Polyphonic, Tuner, Utility | Replicate each channel of a polyphonic input with a variable detune spread, and merge the results into a single polyphonic output |
| Venom |  Push 5 |
3% | 3% | 3% | 3% | 3% | 3% | 3% | 3% | 3% | 3% | Controller, Polyphonic, Utility | 5 configurable push buttons |
| Venom |  Quad VC Polarizer |
5 – 79% | 5 – 80% | 5 – 81% | 5 – 81% | 5 – 80% | 5 – 79% | 5 – 80% | 5 – 81% | 5 – 81% | 5 – 80% | Attenuator, Mixer, Polyphonic, Ring modulator, Utility, Voltage-controlled amplifier | Compact polyphonic bipolar VCA and mixer inspired by Mutable Instruments Blinds |
| Venom |  Reformation |
47 – 163% | 48 – 166% | 49 – 166% | 48 – 166% | 48 – 166% | 47 – 164% | 48 – 166% | 49 – 166% | 48 – 166% | 48 – 166% | Distortion, Effect, Polyphonic, Utility, Voltage-controlled amplifier, Waveshaper | Transform CV or audio by mapping way point voltages to new values |
| Venom |  Rhythm Explorer |
6 – 10% | 7 – 9% | 7 – 8% | 6 – 8% | 6 – 8% | 6 – 10% | 7 – 9% | 7 – 8% | 6 – 8% | 6 – 8% | Clock modulator, Random, Sequencer | Stochastic rhythm generator, trigger sequencer and clock divider |
| Venom |  Multimode Filter |
34 – 116% | 34 – 118% | 34 – 119% | 34 – 119% | 34 – 119% | 34 – 228% | 34 – 232% | 34 – 233% | 34 – 234% | 34 – 234% | Filter, Polyphonic | Stereo state variable filter for audio and low frequency use with some extra goodies |
| Venom |  Shaped VCA |
18 – 72% | 18 – 73% | 18 – 74% | 18 – 74% | 18 – 74% | 18 – 73% | 18 – 73% | 18 – 74% | 18 – 74% | 18 – 74% | Attenuator, Polyphonic, Ring modulator, Utility, Voltage-controlled amplifier, Waveshaper | Stereo VCA with a variable response curve, hard/soft clipping, ring modulation, and oversampling |
| Venom |  Slew |
20 – 65% | 20 – 66% | 20 – 66% | 20 – 67% | 20 – 67% | 20 – 66% | 20 – 66% | 20 – 67% | 20 – 67% | 20 – 67% | Polyphonic, Slew limiter, Utility, Waveshaper | Slew limiter and slope detector for both CV and audio processing |
| Venom |  Sphere To XYZ |
40 – 42% | 40 – 42% | 41 – 43% | 41% | 41% | 40 – 42% | 40 – 42% | 41 – 43% | 41% | 41% | Polyphonic, Utility | Convert spherical coordinates r,theta, phi to cartesian coordinates x, y, z |
| Venom |  Split 4x2 |
3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | Polyphonic, Utility | Compact and versatile polyphonic split utility |
| Venom |  Thru |
5 – 6% | 5 – 6% | 5 – 6% | 5 – 6% | 5 – 6% | 5 – 6% | 5 – 6% | 5 – 6% | 5 – 6% | 5 – 6% | Delay, Mixer, Polyphonic, Utility | 5 polyphonic input/output pairs suitable for stacked input unity mixes and/or introduction of sample delays |
| Venom |  VCA Mix 4 |
13 – 14% | 13 – 14% | 13 – 14% | 13 – 14% | 13 – 14% | 13 – 15% | 13 – 15% | 13 – 15% | 13 – 15% | 13 – 15% | Attenuator, Mixer, Polyphonic, Ring modulator, Utility, Voltage-controlled amplifier | Compact audio or CV VCA, mixer, attenuator, inverter, amplifier, and/or offset |
| Venom |  VCA Mix 4 Stereo |
16 – 19% | 16 – 18% | 16 – 19% | 16 – 18% | 16 – 19% | 16 – 20% | 16 – 20% | 16 – 20% | 16 – 20% | 16 – 20% | Attenuator, Mixer, Polyphonic, Ring modulator, Utility, Voltage-controlled amplifier | Stereo compact audio or CV VCA, mixer, attenuator, inverter, amplifier, and/or offset |
| Venom |  VCO Unit |
43 – 119% | 44 – 120% | 44 – 121% | 44 – 121% | 44 – 121% | 43 – 119% | 44 – 121% | 44 – 122% | 44 – 122% | 44 – 122% | Function generator, Low-frequency oscillator, Oscillator, Polyphonic | A smaller version of VCO Lab with only one selectable waveform at a time, and no mixing capabilities |
| Venom |  Wave Folder |
21 – 36% | 21 – 36% | 21 – 37% | 21 – 37% | 21 – 37% | 21 – 36% | 21 – 37% | 21 – 37% | 21 – 37% | 21 – 37% | Polyphonic, Ring modulator, Voltage-controlled amplifier, Waveshaper | A polyphonic configurable wave folder |
| Venom |  Wave Mangler |
15 – 51% | 15 – 52% | 15 – 52% | 15 – 52% | 15 – 52% | 15 – 52% | 15 – 52% | 15 – 53% | 15 – 53% | 15 – 53% | Distortion, Polyphonic, Waveshaper | A polyphonic distortion / waveshaper inspired by the Doepfer A-136 module |
| Venom |  Wave Multiplier |
16 – 30% | 16 – 30% | 16 – 30% | 16 – 30% | 16 – 30% | 16 – 102% | 16 – 103% | 16 – 104% | 16 – 104% | 16 – 105% | Low-frequency oscillator, Polyphonic, Ring modulator, Voltage-controlled amplifier, Waveshaper | A polyphonic waveshaper inspired by the Doepfer A-137-2 coupled with integrated LFO modulation |
| Venom |  WinComp |
7% | 7% | 7% | 6 – 7% | 6 – 7% | 7% | 7% | 7% | 6 – 7% | 6 – 7% | Distortion, Limiter, Logic, Polyphonic, Utility, Waveshaper | Windowed comparator, rectifier, and/or slope detector |
| Venom |  XM-OP |
37 – 38% | 38% | 38% | 38 – 39% | 38 – 39% | 37 – 38% | 38 – 39% | 38 – 39% | 38 – 39% | 38 – 39% | Envelope generator, Oscillator, Polyphonic, Synth voice | Polyphonic synth voice with selectable waveform, modulation and feedback types (FM, PM, RM, AM), and integer ratios. |
| voxglitch |  Grain Engine MK2 |
3 – 4% | 3 – 4% | 3 – 4% | 3% | 3% | 3 – 4% | 3 – 4% | 3 – 4% | 3% | 3% | Granular, Sampler | Granular syntesis based .wav player |
| voxglitch |  Autobreak |
3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 2 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 2 – 4% | Sampler, Drum | Automatic breakbeat sample chopper |
| voxglitch |  Byte Beat |
31 – 34% | 31 – 33% | 31 – 33% | 31 – 33% | 32 – 33% | 31 – 34% | 31 – 33% | 31 – 33% | 31 – 33% | 32 – 33% | Oscillator | Bytebeat player with built-in presets. |
| voxglitch |  Drum Randomizer |
3 – 36% | 3 – 19% | 3 – 11% | 3 – 7% | 3 – 5% | 3 – 36% | 3 – 19% | 3 – 11% | 3 – 7% | 3 – 5% | Utility, Polyphonic | Apply per-step percentage playback to gate sequences. |
| voxglitch |  Ghosts |
4 – 65% | 4 – 65% | 4 – 66% | 4 – 66% | 4 – 54% | 4 – 65% | 4 – 65% | 4 – 66% | 4 – 66% | 4 – 54% | Granular, Sampler | Granular synthesis sample player/scanner with looping grains. |
| voxglitch |  Glitch Sequencer |
4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | 4 – 5% | Sequencer | Cellular Automaton Gate Sequencer. |
| voxglitch |  Grain Fx |
9 – 28% | 9 – 28% | 9 – 28% | 9 – 28% | 9 – 28% | 9 – 28% | 9 – 28% | 9 – 28% | 9 – 28% | 9 – 28% | Granular, Sampler | Granular effects for incoming audio. |
| voxglitch |  Hazumi |
3 – 4% | 3% | 3% | 2 – 3% | 3% | 3 – 4% | 3% | 3% | 2 – 3% | 3% | Sequencer | Bouncing ball sequencer |
| voxglitch |  Looper |
2 – 4% | 2 – 4% | 2 – 4% | 2 – 4% | 2 – 3% | 2 – 4% | 2 – 4% | 2 – 4% | 2 – 4% | 2 – 3% | Sampler | Bare minimum sample looper |
| voxglitch |  Note Detector |
4 – 5% | 4 – 5% | 4 – 5% | 4% | 4% | 4 – 5% | 4 – 5% | 4 – 5% | 4% | 4% | Utility | Produces a gate or trigger output when a specified note is detected at the CV input |
| voxglitch |  One Point |
2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | Sequencer | CV sequencer that uses external file as sequence data |
| voxglitch |  One Zero |
2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | 2% | Sequencer | Gate sequencer that uses external file as sequence data |
| voxglitch |  Repeater |
3 – 4% | 3 – 4% | 3 – 4% | 2 – 3% | 2 – 3% | 3 – 4% | 3 – 4% | 3 – 4% | 2 – 3% | 2 – 3% | Sampler | Looping sample player with playback offset control. |
| voxglitch |  SamplerX8 |
5 – 6% | 5 – 6% | 5 – 6% | 5 – 6% | 5 – 6% | 5 – 6% | 5 – 6% | 5 – 6% | 5 – 6% | 5 – 6% | Sampler | Eight stereo sample playback devices in one compact module. |
| voxglitch |  Vector Rotation |
6 – 9% | 6 – 7% | 6% | 5 – 6% | 6% | 6 – 9% | 6 – 7% | 5 – 6% | 5 – 6% | 5 – 6% | Envelope Generator, Oscillator | Utility module for laser enthusiasts. |
| voxglitch |  Wav Bank |
2 – 3% | 2% | 2% | 2% | 2% | 2 – 3% | 2% | 2% | 2% | 2% | Sampler | Sample player that can load and switch between all .wav files in a folder. |
| Word Generator |  Word Generator |
6 – 7% | 6 – 7% | 6 – 7% | 6 – 7% | 6 – 7% | 6 – 9% | 6 – 9% | 6 – 8% | 6 – 8% | 6 – 7% | Sequencer, Digital, Clock Modulator | Digital sequencer inspired by the HP 8006A Word Generator |
| xOx Drums |  Accent |
2 – 4% | 2 – 3% | 2% | 2% | 2% | 2 – 4% (mono) | 2 – 3% (mono) | 2% (mono) | 2% (mono) | 2% (mono) | Dynamics | A drum utility for adding dynamics to drums. |
| xOx Drums |  Clap |
5 – 7% | 5 – 7% | 5 – 6% | 5% | 5% | 5 – 7% (mono) | 5 – 7% (mono) | 5 – 6% (mono) | 5% (mono) | 5% (mono) | Drum | Clap inspired by XOX style. |
| xOx Drums |  Clave |
3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% | 3 – 4% (mono) | 3 – 4% (mono) | 3 – 4% (mono) | 3 – 4% (mono) | 3 – 4% (mono) | Drum | Clave inspired by XOX style. |
| xOx Drums |  Congabongo |
4% | 4% | 4% | 4% | 4% | 4% (mono) | 4% (mono) | 4% (mono) | 4% (mono) | 4% (mono) | Drum | Conga/Bongo inspired by XOX style with added slap inputs |
| xOx Drums |  Cowbell |
2% | 2% | 2% | 2% | 2% | 2% (mono) | 2% (mono) | 2% (mono) | 2% (mono) | 2% (mono) | Drum | Cowbell inspired by XOX style. |
| xOx Drums |  Duck |
2 – 3% | 2 – 3% | 2% | 2% | 2% | 2 – 3% (mono) | 2 – 3% (mono) | 2% (mono) | 2% (mono) | 2% (mono) | Dynamics | A ducking module for sidechain effect |
| xOx Drums |  HiHat |
3 – 4% | 3% | 3% | 3% | 3% | 3 – 4% (mono) | 3% (mono) | 3% (mono) | 3% (mono) | 3% (mono) | Drum | Hi-hat inspired by XOX style |
| xOx Drums |  Kick |
3 – 4% | 3 – 4% | 3% | 3% | 3% | 3 – 4% (mono) | 3 – 4% (mono) | 3% (mono) | 3% (mono) | 3% (mono) | Drum | Kick inspired by XOX style |
| xOx Drums |  Maraca |
2% | 2 – 3% | 2% | 2% | 2% | 2% (mono) | 2 – 3% (mono) | 2% (mono) | 2% (mono) | 2% (mono) | Drum | Maraca inspired by XOX style |
| xOx Drums |  Rimshot |
2% | 2% | 2% | 2% | 2% | 2% (mono) | 2% (mono) | 2% (mono) | 2% (mono) | 2% (mono) | Drum | Rimshot inspired by XOX style |
| xOx Drums |  Snare |
5% | 5% | 5% | 5% | 5% | 5% (mono) | 5% (mono) | 5% (mono) | 5% (mono) | 5% (mono) | Drum | Snare inspired by XOX style |
| xOx Drums |  Tom |
3 – 4% | 3% | 3% | 3% | 3% | 3 – 4% (mono) | 3% (mono) | 3% (mono) | 3% (mono) | 3% (mono) | Drum | Tom inspired by XOX style |
