Troubleshooting startup issues

Normally you should update firmware by following these instructions.

However, sometimes something goes wrong and the module will not start up properly. In that case, there is a way to install updated firmware using a USB cable.

USB DFU Bootloader

  1. Download the latest firmware release and unzip the it. Look inside the metamodule-firmware folder. You should see a file called main.uimg.

  2. Connect a USB cable from a computer to the module. It must be a USB cable capable of transmitting data, not just a charging cable.

  3. Power cycle the module while holding down the rotary encoder.

  4. The button will be flashing green, this tells you that you are in USB-DFU bootloader mode

  5. Open Chrome browser (other browsers will not work). Go to this web page: Web DFU

  6. Click Connect, and then select “STM Device in DFU Mode”.

  7. Click “Choose File” and select the main.uimg file you just downloaded.

  8. Click “Download”.

  9. Wait a couple minutes… it takes a while. There will be this error message: DFU GETSTATUS failed: ControlTransferIn failed: NetworkError: Failed to execute 'controlTransferIn' on 'USBDevice': A transfer error has occurred. This is normal, and is not a problem. It’s safe to ignore this.

  10. When the web page says it’s done, unplug the USB cable and power cycle the module
